dexPro FB13SS Specification sheet

4
PRODUCT INSTRUCTION MANUAL
AUTOMATIC HAND DRYER
1
SPECIFICATION:
Voltage rang: 110-130V, 220-240V / 50Hz
Power: 1150W-1350W (Hot) / 500W-510W (Cold)
Air Temperature: 40 C (Room Temp - 25 C)
Air Speed: >100m/sec
Air Volume: 130m3/h
Acng distance: 50-150 mm
Sound Level: 75dB
IP Rang: IPX1
Dimensions: W173 x D150 x H255
Weight: 5.8kg
Air Nozzle
Warranty
This hand dryer has a 1 year warranty from the date of purchase for any manufacturing defect.
It covers replacement of defective parts, except when caused by improper use.
Before taking any action in the event of a fault, contact our customer service team who will assist
you. The products serial number and proof of purchase must be provided. In the event of a faulty
product, deXpro will replace faulty parts or at its sole discretion replace the product.
Labour costs and consequential losses are excluded.
DEXPRO LTD
Main telephone line 01244 631370
Email links [email protected]
[email protected]
[email protected] FB13SS

2
Thank you for purchasing the FEISTY automatic electric hand dryer. With greater emphasis
on air flow and reduced heat, the unit has high efficiency, with powerful concentrated air
giving a short hand-dry me. Please carefully read and understand these instructions
before commencing installation and leave them with the user when installation is
complete. It is an ideal choice for hotels, household and public places.
PLEASE READ ALL INSTRUCTIONS BEFORE USING
Important safety points
ŸThe Electrical installaon must be carried out by a qualified electrician in accordance with the current
edion of the I.E.E. Wiring Regulaons.
ŸThis appliance must be earthed.
ŸMeans for electrical disconnecon must be incorporated in the fixed wiring in accordance with the
wiring rules.
ŸAvoid spaering the product with water.
ŸThe hand dryer must be fixed out of reach of a person taking a bath or shower.
ŸThis appliance can be used by children aged from 8 years and above and persons with reduced physical,
sensory or mental capabilies or lack of experience and knowledge if they have been given supervision
or instrucon concerning use of the appliance in safe way and understand the hazard involved.
Children shall not play with the appliance. Cleaning and us1er maintenance shall not be made by
children without supervision.
ŸDo not cover the air inlet or outlet.
INSTALLATION:
Recommended installaon height (measured from air outlet to the floor): for man 1.2m, for woman
Ÿ
1.1m, for child 0.9m.
A 2-pole switch with contact gap >3mm must be installed before connecon to power source.
Grounding wire must be connected to the unit.
Hand
Dryer
Heang
Heang
Motor
Power
Motor
Power
Blue
Brown
Motor
Transformer
Hand Dryer Main Circuit Board
Program Board
Blue LED Light
Sensor Board
HOT/COLD Switch
Turn clockwise to
increase sensor range
Black
Black
Brown
Blue
Earthing
Terminal
Block
Yellow
Heat Element
220V - 240V OR
110V - 120V
L
N
E
POWER SCHEME
3
ELECTRICAL:
ŸThis appliance must be earthed.
ŸMeans for electrical disconnecon must be incorporated in the fixed wiring in accordance with the
wiring rules.
The power cord should be connected following the colour coding below:
➢Brown: L
➢Blue: N
➢Green / Yellow: E
APPLICATION:
1. Aer installaon of the hand dryer, connect the unit to power source and it will be in standby status.
2. When a hand reaches within 15cm range to the air outlet, the dryer will sense the hand and
automacally start to blow warm air. (The lamp will also be on at the same me). Blow your hands with
the warm air unl they are dry. The unit will stop working aer connuous operaon for 1 minute. To
restart the unit, put your hands again within the sensing range.
MAINTENANCE
Always isolate the appliance from the power supply before commencing any maintenance.
Never use abrasive chemicals or materials when cleaning the unit.
Use a vacuum cleaner to clear the inlet and outlet vents of any dust or debris.
FEISTY Le Side FEISTY Front Side
Air Filter
Heater
Replace easily
Hot/Cold
Switch
LED Light
Blue Air
Nozzle
Sensor
Circuit Board
inside
