DGS BAKERY/WINE WALL DUMP BIN User manual

A
DETAIL A
SCALE 1 : 12
CONTENTS
INCLUDED:
DUMP BIN
QTY: 1
SIDE VIEW
B
DETAIL B
SCALE 1 : 12
PAN HEAD SCREW
QTY 10
BAKERY /WINE WALL DUMP BIN
assembly instructions
HORIZONTAL MOUNT
TO DISPLAY DUMP BIN HORIZONTALLY,
ATTACH THE LH&RH HORIZ BRACKETS TO
THE BOTTOM SIDE OF THE BIN AND
ATTACH USING 5 SCREWS EACH INTO
PROVIDED PILOT HOLES.
LH BRACKET
HORIZ MOUNT
(5 HOLES)
QTY 1
RH BRACKET
HORIZ MOUNT
(5 HOLES)
QTY 1
HORIZONTAL MOUNT
VERTICAL MOUNT
VERTICAL MOUNT
TO DISPLAY DUMP BIN VERTICALLY,
ATTACH THE LH&RH VERT BRACKETS TO
THE BOTTOM SIDE OF THE BIN AND
ATTACH USING 5 SCREWS EACH INTO
PROVIDED PILOT HOLES.
SIDE VIEW RH BRACKET
VERT MOUNT
(4 HOLES)
QTY 1
LH BRACKET
VERT MOUNT
(4 HOLES)
QTY 1
SIDE VIEW
RH BRACKET
65 DEG MOUNT
(4 HOLES)
QTY 1
LH BRACKET
65 DEG MOUNT
(4 HOLES)
QTY 1
PAGE 1 OF 2
rev date:12/14/16

C
DETAIL C
SCALE 1 : 12
BAKERY /WINE WALL DUMP BIN
assembly instructions
65 DEG MOUNT
TO DISPLAY DUMP BIN WITH 65 DEG
SETBACK, ATTACH THE LH&RH 65 DEG
BRACKETS TO THE BOTTOM SIDE OF THE
BIN AND ATTACH USING 4 SCREWS EACH
(SCREWS MAY NOT ALIGN WITH PILOT
HOLES).
65 DEG MOUNT
PAGE 2 OF 2
rev date:12/14/16
