PK-mol-KF Adaptor Kits
for molbloc-S®
Instruction Sheet
25 mm ISO-KF Style Kits Include:
These adaptor kits allow the conversion of the
molbloc-S ISO-KF style flange to various common
types of fittings. The molbloc-S elements with the 48
mm square bodies have 16 mm ISO-KF style vacuum
flange outlet fittings. The Downstream Tee Assembly
(PN 401884) end fitting, and the molbloc-S elements
with the 80 mm square body utilize the 25 mm ISO-KF
style vacuum flange fitting. The outlet of the molbloc-
S elements with the 80 mm square body utilizes the
40 mm ISO-KF style vacuum flange. These fittings
can be converted to Swagelok tube fitting, VCR®face
seal, male NPT or female NPT fittings using one of the
following adaptor kits.
KIT
PART NO DESIGNATOR
DESCRIPTIO
N QTY
ADAPTOR
PART NO
401894 PK-MOL-KF25-
1/4SWG
25 mm ISO-KF
x 1/4 in. SWG 1 103265
401895 PK-MOL-KF25-
3/8SWG
25 mm ISO-KF
x 3/8 in. SWG 1 103266
401896 PK-MOL-KF25-
1/4VCR
25 mm ISO-KF
x 1/4 in. male
VCR
1 103267
401897 PK-MOL-KF25-
1/2VCR
25 mm ISO-KF
x 1/2 in. male
VCR
1 103268
401986 PK-MOL-KF25-
1/2SWG
25 mm ISO-KF
x 1/2 in. SWG 1 103317
401987 PK-MOL-KF25-
3/4SWG
25 mm ISO-KF
x 3/4 in. SWG 1 103318
401988 PK-MOL-KF25-
1/4FNPT
25 mm ISO-KF
x 1/4 in. female
NPT
1 103319
401989 PK-MOL-KF25-
1/2FNPT
25 mm ISO-KF
x 1/2 in. female
NPT
1 103320
401990 PK-MOL-KF25-
3/4FNPT
25 mm ISO-KF
x 3/4 in. female
NPT
1 103321
401991 PK-MOL-KF25-
1FNPT
25 mm ISO-KF
x 1 in. female
NPT
1 103322
401992 PK-MOL-KF25-
1/4MNPT
25 mm ISO-KF
x 1/4 in. male
NPT
1 103323
401993 PK-MOL-KF25-
1/2MNPT
25 mm ISO-KF
x 1/2 in. male
NPT
1 103324
401994 PK-MOL-KF25-
3/4MNPT
25 mm ISO-KF
x 3/4 in. male
NPT
1 103325
401995 PK-MOL-KF25-
1MNPT
25 mm ISO-KF
x 1 in. male
NPT
1 103307
ADAPTOR KIT CONTENTS
16 mm ISO-KF Style Kits Include:
KIT
PART NO DESIGNATOR
DESCRIPTIO
N QTY
ADAPTOR
PART NO
401890 PK-MOL-KF16-
1/4SWG
16 mm ISO-KF
x 1/4 in. SWG 1 103261
401891 PK-MOL-KF16-
3/8SWG
16 mm ISO-KF
x 3/8 in. SWG 1 103262
401892 PK-MOL-KF16-
1/4VCR
16 mm ISO-KF
x 1/4 in. male
VCR
1 103263
401893 PK-MOL-KF16-
1/2VCR
16 mm ISO-KF
x 1/2 in. male
VCR
1 103264
402005 PK-MOL-KF16-
1/4FNPT
16 mm ISO-KF
x 1/4 in. female
NPT
1 103336
402006 PK-MOL-KF16-
1/4MNPT
16 mm ISO-KF
x 1/4 in. male
NPT
1 103337
402007 PK-MOL-KF16-
1/2MNPT
16 mm ISO-KF
x 1/2 in. male
NPT
1 103338
In addition to these adaptors, the 16 mm ISO-KF kits
include:
QTY PART NO. DESCRIPTION
1 101544 16 mm ISO-KF Centering ring, Viton
1 103240 16 mm ISO-KF Overpressure ring
1 102975 16 mm ISO-KF Clamp
In addition to these adaptors, the 25 mm ISO-KF kits
include:
QTY PART NO. DESCRIPTION
1 101542 25 mm ISO-KF Centering ring, Viton
1 103241 25 mm ISO-KF Overpressure ring
1 102121 25 mm ISO-KF Clamp

05/20/0405/20/04
40 mm ISO-KF Style Kits Include:
KIT
PART NO. DESIGNATOR
DESCRIPTIO
N QTY
ADAPTOR
PART NO.
401996 PK-MOL-KF40-
1/2SWG
40 mm ISO-KF
x 1/2 in. SWG 1 103327
401997 PK-MOL-KF40-
3/4SWG
40 mm ISO-KF
x 3/4 in. SWG 1 103328
401998 PK-MOL-KF40-
1SWG
40 mm ISO-KF
x 1 in. SWG 1 103329
401999 PK-MOL-KF40-
1/2FNPT
40 mm ISO-KF
x 1/2 in. female
NPT
1 103330
402000 PK-MOL-KF25-
3/4FNPT
40 mm ISO-KF
x 3/4 in. female
NPT
1 103331
402001 PK-MOL-KF25-
1FNPT
40 mm ISO-KF
x 1 in. female
NPT
1 103332
402002 PK-MOL-KF25-
1/2MNPT
40 mm ISO-KF
x 1/2 in. male
NPT
1 103333
402003 PK-MOL-KF25-
3/4MNPT
40 mm ISO-KF
x 3/4 in. male
NPT
1 103334
402004 PK-MOL-KF25-
1MNPT
40 mm ISO-KF
x 1 in. male
NPT
1 103252
molbloc and molbloc-S are trademarks, registered and otherwise, of DH Instruments, Inc.
VCR is a registered trademark of the Swagelok Company.
Viton is a registered trademarks of DuPont deNemours Company.
Document 560057b-01 040520
DH Instruments, Inc. Tel [phone]
In addition to these adaptors, the 40 mm ISO-KF kits
include:
QTY PART NO. DESCRIPTION
1 103245 40 mm ISO-KF Centering ring, Viton
1 103309 40 mm ISO-KF Overpressure ring
1 103246 40 mm ISO-KF Clamp
CONNECTING, DISCONNECTING AND
MOUNTING MOLBLOC-S COMPONENTS
WITH ISO-KF STYLE VACUUM FLANGE
ISO-KF Style Vacuum Flange Fittings
The outlet connection system on the molbloc-S body
is the ISO-KF style vacuum flange. It utilizes an
internal centering ring, an external overpressure ring
and clamp. The seal is effected by the uniform
application of pressure by the clamp on the 15°
surface of the mating stainless steel flanges. These
mating flange surfaces compress a Viton®O-ring that
is held in place by the centering ring. The
overpressure ring keeps the O-ring in place, and
maintains a leak free connection when the system is
subjected to internal pressures above vacuum level.
This connection is reusable, rotatable, and can operate
leak free in vacuum applications up to 10-8 Torr, and in
positive pressures of 700 kPa (100 psig).
When performing a leak test of a plumbing system
that contains the ISO-KF Style Vacuum Flanges, do
not exceed the maximum operating pressure of the
molbox: 600 kPa (87 psia) for molbox A700k; 250
kPa (36 psia) for molbox A350K.
Making and Breaking Procedure for molbloc-S
ISO-KF Vacuum Flange Connection
Place the overpressure ring past one of the
ISO-KF flanges to be mated.
Place the centering ring into the groove of the
ISO-KF flange on the outlet of the molbloc-S.
Align the mating flange against molbloc’s ISO-KF
flange, and close the gap by hand.
Hold the flanges together and move the
overpressure ring directly over the mated flanges.
Place the clamp around the mated flanges.
Swing the clamp closed. If necessary loosen the
thumbscrew to allow the thrust washer and wing nut
to fall into position on top of the clamp. Fully tighten
the wing nut by hand.
To break the fitting, hold the molbloc-S with your
hand and loosen the wing nut until the clamp can
be separated. Remove the clamp, centering ring,
and overpressure ring.
Never use wrenches to hold the molbloc-S body,
or to tighten the clamp.
