Overview
The MN-COM1S is a TCP/IP to RS-232 interface with one RJ-45
port and one RS-232 port. It is used in mass notification settings
to connect a FireWorks workstation to an EST3 control panel.
The MN-COM1S mounts on an MN-BRKT1F or an MN-BRKT3F
bracket. These install inside the EST3 control panel or Auxiliary
Power Supply for a neat and self-contained mass notification
solution.
Standard Features
• Connect a FireWorks workstation to an EST3 control panel.
• RS-232 Serial port for connection to 3-CPU3
• One RJ-45 port
• One RS-232 port
• Browser-based setup and configuration
TCP/IP to
RS-232 interface
MN-COM1S
7165-1657:
0186/0306
S3000

Page 2 of 4 DATA SHEET E85010-0155
Not to be used for installation purposes. Issue 1.1
Mounting
The MN-COM1S mounts on an MN-BRKT1F or an MN-BRKT3F
bracket. These install inside the EST3 control panel or Auxiliary
Power Supply for a neat and self-contained mass notification solu-
tion.
Compatible Control Panel
Component Layout
TB1
MN-BRKT3F
MN-COM1S
MN-FVPN
MN-FNS4C2F3
or MN-FNS8C2F3
MN-NETRLY4
MN-BRKT3F
(3)
(2)
(1)
MN-BRKT1F
MN-BRKT1F
TB1
MN-COM1S
MN-FNS4C2F3
or MN-FNS8C2F3
MN-FVPN
or MN-NETRLY4
MN-PASM2
and SIGA-CT1
MN-ABPM

Page 3 of 4 DATA SHEET E85010-0155
Not to be used for installation purposes. Issue 1.1
Note
Use the control panel power supply or a compatible regulated 24VDC
power supply that is UL/ULC listed for fire protective signaling systems.
FCC compliance
This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful
interference to radio communications. Operation of this equipment in a residential area is likely to cause harmful interference in which case the user will be
required to correct the interference at his own expense.
Wiring
Typical EST3(X) Connection
To control panel
serial port terminal
connections
DB-25 serial cable
provided with
MN-COM1S
MN-COM1S
Dedicated
Local Area
Network
Ordering Information
MN-COM1S UL 864 Listed FireWorks Communications Ethernet Port, Command & Control. Comes with power and RS232 data cables.
Related Equipment
MN-BRKT1F MN-FVP mounting bracket for EST3 enclosures
MN-BRKT3F MN-FVP mounting bracket for APS-(6)(10)A power supplies
FW-NCCA4 Ethernet cable conduit connector assembly for UL4 computer
MN-FVPN Fire VoIP encoder/decoder, includes power and audio cables
MN-PASM2 MN-FVPN preamp signal supervisory booster module (one required per MN-FVPN, along with SIGA-RM1 or SIGA-MRM1).
SIGA -RM1/MRM1 Riser Supervision Module
MN-ABPM Audio Bridge (Panel mount 3-ATPINT)
Specifications
Voltage 18 to 28 VDC
Current 60 mA
Dimensions (W × H × D) 2.5 × 0.9 × 3.5 in. (6.4 × 2.3 × 9.0 cm)
Serial interface RS-232C
Network Interface
Connector
Cable type
Other
RJ-45
Category 5, min.
10/100 Mbps, TCP/IP, autonegotiating
Operating environment
Temperature
Humidity
32 to 120°F (0 to 49°C)
0 to 93% RH, noncondensing at 90°F (32°C)

Page 4 of 4 DATA SHEET E85010-0155
Not to be used for installation purposes. Issue 1.1
03-26-20
