DH Instruments PG7000RPM Assembly instructions

PG7000, RPM, PPC and MPC are trademarks, registered and otherwise, of DH Instruments, Inc.
Document 560003f 031103
DH Instruments, Inc.
4765 East Beautiful Lane
Phoenix AZ 85044-5318
USA
Tel [phone]
Fax [phone]
[email protected]
www.dhinstruments.com
PG7000™/RPM™ to PPC™/MPC™
Interconnections Kit
Installation Sheet
INTERCONNECTIONS KIT, P/N 400985,
INCLUDES
QTY PART NO DESCRIPTION
2 100319 Adaptor, 1/8 in. Tube x 1/8 in. NPTM
1 100327 Tee, 2T
1 101563 Filter, 2T
1 101980 Union, 2P
1 101982 Reducer, 4P x 2P
2 101988-Z Tubing, SS, .125 OD x 100 cm LG
1 102115 Quick Connect, AN4M
1 102116 Quick Connect, 1/8 in. NPTF
1 401459 Quick Connect and Stand Assembly
PARTS ON TEST PORT OR IN
ACCESSORIES OF PG7000
1 101200 Collar
1 100272 Gland
1 400518 1/8 in. Tube x DH 200 M Adaptor
TO PNEUMATICALLY CONNECT THE
PG7000 OR RPM TO THE PPC OR MPC
If you are using an RPM (not a PG7000) go directly
to Step pb.
nRemove gland, collar and plastic plug from the
PG7000 TEST port.
oInstall gland and collar onto 1/8" tube x DH200 male
adaptor supplied in PG7000 accessories.
The collar threads left- handed. Ensure it is
securely attached. The plastic plug is not used.
pa PG7000 - Screw the adaptor (as assembled) into the
PG7000 test port. Torque to 15 Nm (Newton meter).
pb RPM3 - Screw 1/8 in. tube x 1/8 in. NPT male adaptor
into the RPM3 test port using teflon tape as seal.
qConnect tee and filter assembly to quick connect
stand assembly.
rScrew 1/8 in. tube x 1/8 in. NPT male adaptor into
PPC test port using Teflon tape as a seal.
sMount quick connect stand on bench (mounting
holes provided).
tTo connect PG7000 or RPM3 test port to the quick
connect stand cut 1/8" SS tubing to desired length
and Swage nut together.
uTo connect PPC to the quick connect stand cut
1/8 in. SS tubing to desired length and Swage nut
together.
1/8 in. SS tubing can be bent by hand to
desired shape but use caution not to kink the
tube.
