DH Instruments PPC - TEST PORT CONNECTIONS KIT User manual

PPC Test Port Connections Kit
Installation Instructions
PPC is a trademark, registered and otherwise, of DH Instruments, a Fluke Company
Document 560021a 071023
DH Instruments, a Fluke Company
4765 East Beautiful Lane
Phoenix AZ 85044-5318
USA
Tel [phone]
Fax [phone]
[email protected]
www.dhinstruments.com
INTERCONNECTIONS KIT, P/N 401460
•1 401459 Quick connector on stand
•1 101988-Z 1/8 in. stainless steel tubing (75 cm)
•1 100319 1/8 in. swage x 1/8 in. NPT male adaptor
•1 102116 Quick connector stem, 1/8 in. NPTF
•1 102117 Quick connector stem, 1/4 in. NPTF
•1 102184 Reducer, 1/4 in. swage x 1/8 in. swage
TO CONNECT TO THE PPC
nScrew the 1/8 in. swage x 1/8 in. NPT male adaptor into the PPC test port using teflon tape as a seal.
oInstall reducer into quick connector on stand.
pPosition quick connector on stand on bench or other stable surface. (Mounting is optional, holes are
provided.)
qTo connect PPC test port to the quick connect stand cut 1/8 in. SS tubing to desired length, bend as
needed including 90°angle under reducer.
1/8 in. SS tubing can be bent by hand to desired shape but use caution not to kink the tube.
rSwage the 1/8 in. SS tube to adaptor on PPC and to reducer on quick connect stand.
