DHP DA4050429 User manual

DA4050429 (French Gray)
B34DA405042900-218021
Date of Purchase
Junior Loft Bed
V.C. - 4/26/2021
Lot Number (TAKEN FROM CARTON)
Thank you for purchasing from Dorel!
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
1
© 2021 Dorel Home Products All Rights Reserved
Weight Limit: 165 Lb / 75 Kg
Twin
Questions, concerns, missing parts?
CONTACT OUR CUSTOMER SERVICE DEPARTMENT
BEFORE RETURNING PRODUCT TO THE RETAILER.
If parts are missing or damaged, we will gladly ship your
replacement parts free of charge.
Visit www.dhpfurniture.com/eng/replacement-parts
or call Toll-Free 1-800-267-1739.
You can also chat with us at www.dhpfurniture.com

2
Read Before Beginning Assembly
•Work in a spacious area and near where the unit will be used, preferably on a
carpet, or use a piece of the cardboard packaging to protect your floor and
product.
•Make sure all parts are included. Most parts are labeled or stamped on the raw
•edge.
•Read each step carefully. It is very important that each step of the instructions is
performed in the correct order. If these steps are not followed in sequence,
assembly difficulties will occur.
•This product may contain small components. Please ensure that they are kept
away from small children.
•This product is designed for home use and is not intended for commercial use.
Contact Us!
For help with assembly, identifying parts, product information or to order parts,
please contact us:
Limited 1 year Warranty
Dorel warrants this product to be free from defects in material and
workmanship and agrees to remedy any such defect. This warranty covers
one year from the date of original purchase from authorized retailers. This is
solely limited to the repair or replacement of defective parts and assembly
labor is not included.
This warranty does not apply to any product which has been improperly
assembled, subjected to misuse or abuse or which has been altered or repaired
in any way.The warranty does not cover wearing, tearing, fading or splitting of the
fabric (where applicable). Liability for consequential damages is excluded to the
extent exclusion is permitted by law. This warranty gives you specific legal rights
and you may also have other rights which vary from state to state or province to
province.
To obtain warranty service, purchaser must present original bill of sale.
Components repaired or replaced are warranted through the remainder of the
original warranty period only. The defective components will be repaired or
replaced without charge, subject to the terms and conditions described above.
Visit www.dhpfurniture.com to view the limited warranty valid in the U.S.
and Canada.
Do NOT use
powertools
This product is packaged in
1 carton
1-800-267-1739
Monday to Friday
Saturday Sunday
DHP Consumer Services
12345 Albert Hudon, Suite 100,
Montreal, Quebec H1G 3L1
cs@dhpfurniture.com
9am to 9 pm (Eastern Time)
10 am to 6:30 pm (Eastern Time)
11 am to 7 pm (Eastern Time)
www.dhpfurniture.com
Phillips head screwdriver
Needed for assembly
(Not included):
1 hour

WARNING -Loft bed : Twin
3
•STRANGULATION HAZARD -Never attach or hang items to any part of the bunk bed that are not designed for use with the bed;
for example, but not limited to, hooks, belts and jump ropes.
•Follow the information on the warnings appearing on the upper bunk end structure and on the carton. Do not remove warning label
from bed.
•The mattress platform is designed to support a mattress without the need for a posture board or box spring.
•Always use the recommended size mattresses or mattress supports, or both, to help prevent the likelihood of entrapment or falls.
•USE ONLY A COIL SPRING MATTRESS ON THE UPPER BUNK. FAILURE TO DO SO CAN RESULT IN INJURY.
•Use only mattresses which are 74"-75" long and 37 1/2"-38 1/2" wide on upper bed. Ensure thickness of mattress does not
exceed 6". Surface of mattress must be at least 5" (127 mm) below the upper edge of guardrails.
•Do not allow children under 6 years of age to use the upper bunk.
•Always use guardrails on both long sides of the upper bunk. If the bunk bed will be placed next to the wall, the guardrail that runs
the full length of the bed should be placed against the wall to prevent entrapment between the bed and wall (applicable for bunk
beds with full length guardrails on one side).
•Periodically check and ensure that the guardrail, ladder, and other components are in their proper position, free from damage, and
that all connectors are tight.
•Do not allow horseplay on or under the bed and prohibit jumping on the bed.
•Do not use substitute parts. Contact the manufacturer or dealer for replacement parts.
•Use of a night light may provide added safety precaution for a child using the upper bunk.
•The use of water or sleep flotation mattresses is prohibited.
•Always use the ladder for entering and leaving the upper bunk.
•Prohibit more than one person on upper bunk.
•Keep these instructions for future reference.

PARTS
4

5
PARTS LIST
FRONT LEFT POST
1 PC
BACK LEFT POST
1PC
FRONT RIGHT POST
1 PC
BACK RIGHT POST
1 PC
HEADBOARD TOP CROSS
2 PCS
HEADBOARD PANEL
2 PCS
HEADBOARD CENTER CROSS
2 PCS
BOTTOM PANEL
2 PCS
HEADBOARD BOTTOM CROSS
2 PCS
LEFT SHORT GUARDRAIL POST
1 PC
GUARDRAIL LEG
2 PCS
RIGHT SHORT GUARDRAIL
POST
1 PC
SHORT BOTTOM GUARDRAIL
1 PC
SHORT TOP GUARDRAIL
1 PC
LONG TOP GUARDRAIL
1 PC
ΑB C D E
F G H I J
K L M N O

6
Each part has a unique part number. Please reference the appropriate part number
when contacting customer service for replacement parts.
Before throwing any packaging, please verify all contents and make sure you have
received all the parts listed above!
PARTS LIST
SIDE RAIL (WITH 4 HOLES)
1 PC
SIDE RAIL (WITH 1 HOLE)
1 PC
LONG BOTTOM GUARDRAIL
1 PC
SLAT
13 PCS
LEFT LADDER END
1 PC
LADDER STEP
2 PCS
RIGHT LADDER END
1 PC
P Q R S T
U V

Each part has a unique part number.
Please reference the appropriate part
number when contacting customer
service for replacement parts.
Before throwing any packaging, please
verify all contents and make sure you have
received all the parts listed above!
8
PART NUMBERS
PART
LABELS
DA4050429
(French Gray)
AT1009870
BT1009880
CT1009890
DT1009900
ET1009910
FT1009920
GT1009930
HT1009940
IT1009950
JT1009960
KT1009970
LT1009980
MT1009990
NT1010000
OT1010010
PT1010020
QT1010030
RT1010040
ST1010050
TT1010060
UT1010070
VT1010080

7
HARDWARE LIST
Ø1/4” x 100mm Ø12mm x 15mm Ø1/4” x 35mm Ø1/4” x 13mm
JOINT CONNECTOR
8 PCS
BARREL NUT
8 PCS
JOINT CONNECTOR
4PCS
JCN NUT
4PCS
Ø4mm x 30mm Ø10mm x 40mm Ø8mm x 30mm Ø1/4” x 60mm
ALLEN KEY
1 PC
FLAT HEAD SCREW
32 PCS
WOOD DOWEL
28 PCS
WOOD DOWEL
8 PCS
JOINT CONNECTOR
4 PCS
Ø1/4” x 90mm Ø1/4” x 50mm Ø4mm x 15mm
JOINT CONNECTOR
16 PCS
JOINT CONNECTOR
4 PCS
SCREW
2 PCS
MOON PLASTIC PAD
4 PCS
12 3 4
5 6 7 8 9
10 11 12 13

DA4050429 (French Gray) HP#: TDA4050429-00
Hardware Pack
8
Please do not completely tighten all the hardware,
until the entire assembly is complete, unless
otherwise indicated in the step-by-step
instructions.
The screw(s), bolt(s) to be used at each step are
shown in actual size in the lower right corner of the
page.

lnsert wood dowels ❼into the ends of
headboard top cross E, headboard center
cross Gand headboard bottom cross I.
lnsert headboard panel Finto the grooves of
the headboard top cross Eand headboard
center cross G.
lnsert bottom panel Hinto the grooves of the
headboard center cross Gand headboard
bottom cross I.
lnsert wood dowels ❽into the ends of bottom
panel H.
lnsert moon pads ⓭into the ends of
headboard bottom cross I.
Attach the assembled unit to the posts A& B
with joint connectors ❿& ⓫. Use Allen key
❺to tighten the joint connectors ❿& ⓫.
Step 1
8
x 4
7
x 4
8
x 4
10
x 2
11
x 2
13

lnsert wood dowels ❼into the ends of headboard
top cross E, headboard center cross Gand
headboard bottom cross I.
lnsert headboard panel Finto the grooves of the
headboard top cross Eand headboard center
cross G.
lnsert bottom panel Hinto the grooves of the
headboard center cross Gand headboard bottom
cross I.
lnsert wood dowels ❽into the ends of bottom
panel H.
lnsert moon pads ⓭into the ends of headboard
bottom cross I.
Attach the assembled unit to the posts C& Dwith
joint connectors ❿& ⓫. Use Allen key ❺to
tighten the joint connectors ❿& ⓫.
Step 2
8
x 4
7
x 4
8
x 4
10
x 2
11
x 2
13

Insert barrel nuts ❷into side rails P& Qas
shown.
Attach side rails P& Qto the posts A& B&
C& Dusing joint connectors ❶.
Insert wood dowels ❼into long guardrails
O& Ras shown.
Attach the long guardrails O& Rto the back
posts B& Dusing joint connectors ❿.
Use Allen key ❺to tighten all joint
connectors.
Step 3
9
1
2
7
10
x 4
x 8
x 8 x 8

Insert wood dowels ❼into short guardrails
M& N.
Attach the short guardrails M& Nto guardrail
posts J& Land secure with joint connectors
❿.
Attach the guardrail leg Kto short guardrail
M& Nusing flat head screw ❻.
Attach guardrail posts J& Land guardrail leg
Kto side rail Pusing joint connector ❸, hex
cap ❹and flat head screw ❻.
Attach guardrail leg Kto long guardrails O&
Rusing flat head screw ❻.
Use Allen key ❺to tighten join connectors.
Use screwdriver to tighten flat head screws.
Step 4
10
3
6
7
10
x 4
x 8
x 6
x 4
77
7
5
6
M
N
10
10
J
L
K
x 4
4

Attach slat Sto side rails P& Qusing flat
head screw ❻.
Use screwdriver to tighten flat head screws.
Step 5
11
6
x 26

Step 6
12
To assemble the ladder, insert wood dowels
❼into the end of the ladder steps U.
Attach left ladder end Tand right ladder end
Vto ladder steps Uwith wood joint
connectors ❾.
9
x 4
x 4
7

Attach the ladder to the top side rail Pwith
screws ⓬as shown.
Step 7
13
X 2
12

CAUTION: This unit is intended for use only with the products and/or maximum
weights indicated. Use with other products and/or products heavier than the
maximum weights indicated may result in instability or cause possible injury. •Move your new furniture carefully, with
two people lifting and carrying the unit to
its new location.
•Your furniture can be disassembled and
reassembled to move.
•Dust this item regularly with a soft, lint-
free cloth to prevent soil build up. DO
NOT use harsh chemicals or abrasive
cleaners. Wipe with a soft, damp cloth if
necessary.
•Check bolts and nuts periodically and
tighten if necessary.
Helpful Hints
Weight Limit:
165 Lb / 75 Kg
That's it ! You've finished assembling your Junior Loft Bed !
15
CAUTION: Do NOT
use bed risers under
this bed.

DA4050429 (Gris Francés)
Fecha de compra Número de lote
¡Gracias por tu compra Dorel!
Información sobre la garantía
Dorel garantiza que este producto está libre de defectos de material y mano de
obra y se compromete a remediar cualquier defecto de este tipo. Esta garantía
cubre 1 año a partir de la fecha de compra original. Esta garantía es válida
solamente con presentación de una prueba de compra. Esto se limita a la
reparación o reemplazo de componentes defectuosos del mueble y no se incluye
ningún trabajo de ensamblaje.
Esta garantía no se aplica a ningún producto que haya sido mal ensamblado,
sujeto a mal uso o abuso, o que haya sido alterado o reparado de cualquier
manera. Cualquier uso, rotura o pérdida de color de la tela no están incluidos en
esta garantía (donde corresponda). Esta garantía le da derechos legales
específicas y usted puede también tener otros derechos que varían de estado a
estado o de provincia a provincia.
Para obtener el servicio de garantía, debe presentar la factura original de su
compra. Los componentes reparados o reemplazados están garantizados durante
el periodo original de la garantía. Las partes defectuosas serán reparadas o
reemplazadas sin cargo extra y sujetas a los términos y condiciones descritos
anteriormente. Visite www.dhpfurniture.com para ver la garantía limitada válida
en E.U. y Canadá.
Precauciones
•Este producto está diseñado para uso doméstico y no para uso comercial.
•ADVERTENCIA PARA NIÑOS PEQUEÑOS -Este producto contiene
componentes pequeños. Por favor asegúrese de que las piezas estén fuera del
alcance de los niños.
•No utilice herramientas eléctricas para ensamblar su mueble. Este tipo de
herramientas pueden rasgar o dañar las partes.
ES
ESTE INSTRUCTIVO CONTIENE INFORMACION IMPORTANTE DE SEGURIDAD. POR
FAVOR LEA Y GUARDE PARA SU REFERENCIA FUTURA.
Lea antes de comenzar a ensamblar
•Llame a nuestro número gratuito si necesita asistencia.
•Trabaje en un área espaciosa y cerca de donde su producto será utilizado,
preferiblemente sobre una alfombra o utilice el cartón del empaque para
proteger su piso y su producto.
•El número de personas recomendadas para el montaje de este producto
es: 2(sin embargo es recomendable contar con ayuda adicional).
•Tiempo estimado de ensamble es 1 hora.
• Asegúrese de que todas las partes están incluidas. La mayoría de las partes
están etiquetadas o selladas en los bordes.
•Lea cada paso cuidadosamente. Es muy importante que cada paso de las
instrucciones sea realizado en el orden correcto. Si estos pasos no se siguen
en secuencia, pueden ocurrir dificultades durante el ensamblado.
¡Contáctenos!
Para solicitar ayuda con el ensamblaje, identificación de partes, información del
producto o simplemente ordenar otras partes, diríjase a:
•Chatea con nosotros : www.dhpfurniture.com
• cs@dhpfurniture.com
• 1-800-267-1739
Lunes -Viernes / 9 am -9 pm (hora del este)
Sábado / 10 am -6:30 pm (hora del este)
Domingo / 11 am -7 pm (hora del este)
•DHP Servicios al Cliente
12345 Albert Hudon, Suite 100, Montreal, Quebec, Canada, H1G 3L1
Litera Mezanina junior
Individual
Preguntas, inquietudes, partes que faltan? CONTACTE
NUESTRO DEPARTAMENTO DE SERVICIO AL CLIENTE
ANTES DE DEVOLVER EL PRODUCTO ALATIENDA.
Si le faltan piezas o las que se incluyen están dañadas, con mucho
gusto le enviaremos sus piezas de reemplazo sin cargo extra.
Visite www.dhpfurniture.com/spa/replacement-parts ,llame gratis al
1-800-267-1739 ochatea con nosotros al www.dhpfurniture.com

ADVERTENCIA -Litera Mezanina : Individual
•PELIGRO DE ESTRANGULAMIENTO -Nunca cuelgue o ate en la cama artículos que no estén diseñados para usarlos con la cama;
por ejemplo, pero no limitado a esto, ganchos, cinturones y cuerdas de saltar.
•Siga la información de las advertencias inscritas en la estructura de la cucheta superior y en el cartón. No retire la etiqueta de
advertencias de la cama.
•La base del colchón está diseñada para soportar un colchón sin necesidad de usar una tabla para mantener la posición o un soporte
con resortes.
•Siempre utilice el tamaño de colchón o de soporte de colchón recomendado, o los dos, para evitar la posibilidad de caídas o que el
niño quede atrapado.
•UTILICE SOLAMENTE UN COLCHON CON RESORTES EN ESPIRAL EN LA CUCHETA DE ARRIBA. EL NO RESPETAR ESTO
PUEDE CAUSAR LESIONES.
•Utilice únicamente colchones de 74"-75" de largo y 37 1/2"-38 1/2" de ancho. Asegúrese de que el espesor del colchón no exceda
15 cm (6"). La superficie del colchón debe quedar por lo menos 5" (127 mm) por debajo del borde superior del marco de las
cuchetas.
•No permita que niños menores de 6 años duerman en la cucheta superior.
•Siempre utilice las barandas en los dos lados de la cucheta superior.Si la cucheta está colocada al lado de una pared, la baranda
que cubre el lado largo de la cucheta debe ser colocada contra la pared para evitar que el niño quede atrapado entre la cama yla
pared (esto se aplica alas cuchetas con baranda larga de un solo lado).
•Verifique la cama periódicamente y asegúrese de que el cuadro, la escalerilla y otros componentes estén en la posición correcta, no
estén dañados y todas las uniones estén bien ajustadas.
•No permita que los niños hagan payasadas sobre o debajo de la cama y prohiba que salten sobre ella.
•No utilice piezas de sustitución. Contacte con el fabricante o el distribuidor para obtener piezas para remplazar.
•El uso de una veladora sirve como medida de precaución para el niño que utiliza la cucheta superior.
•Se prohibe el uso de colchones de agua o colchonetas de flotación.
•Siempre utilice la escalerilla para subir a la cucheta superior o bajar de ella.
•Prohiba que más de un niño suba a la cucheta superior.
•Conserve estas instrucciones para referencia futura.
ES

Paquete de componentes
Nota: Por favor apriete completamente los pernos durante el
ensamblaje, aprietelos en la ultima etapa del ensamblaje, a menos
que este indicado específicamente en alguna etapa de las
instrucciones.
Los tornillo(s), perno(s) que se utilizan en cada paso se muestran en
tamaño real en la esquina inferior derecha de cada página.
Piezas de reemplazo, visite www.dhpfurniture.com/spa/replacement-parts
Todo se incluye en 1caja(s) grande(s)!
Antes de deshacerse de las cajas de cartón, asegúrese de que estén
vacías. También confirme que ha recibido todos los componentes necesarios
para el ensamblaje al compararlos con la tabla de piezas indicadas en la
sección en inglés.
Partes
ES
DA4050429 (Gris Francés) # de paquete:TDA4050429-00
NÚMERO DE PIEZAS
ETIQUETAS
DE PIEZAS DESCRIPCIÓN
DA4050429
(Gris Francés)
APie frontal izquierdo T1009870
BPie trasero izquierdo T1009880
CPie frontal derecho T1009890
DPie trasero derecho T1009900
ETravesaño superior T1009910
FPanel de la cabecera T1009920
GTravesaño central de la cabecera T1009930
HPanel inferior T1009940
ITravesaño inferior de la cabecera T1009950
JPie izquierdo de barandilla pequeña T1009960
KPie central de barandilla pequeña T1009970
LPie derecho de barandilla pequeña T1009980
MTravesaño inferior de barandilla pequeña T1009990
NTravesaño superior de barandilla pequeña T1010000
OTravesaño superior de barandilla grande T1010010
PRiel lateral (con 4 agujeros) T1010020
QRiel lateral (con 1 agujero) T1010030
RTravesaño inferior de barandilla grande T1010040
SListón T1010050
TLado izquierdo de la escalera T1010060
UPeldaño de escalera T1010070
VLado derecho de la escala T1010080
Table of contents
Other DHP Indoor Furnishing manuals

DHP
DHP Ava Metal Daybed TWIN 5508096 User manual

DHP
DHP 4162639WE User manual

DHP
DHP Finlay User manual

DHP
DHP Brooklyn 3291196 User manual

DHP
DHP DOREL Living DL8747-16 User manual

DHP
DHP 4146419N User manual

DHP
DHP 4190429N User manual

DHP
DHP Manila User manual

DHP
DHP 4176249N User manual

DHP
DHP 4120229WE User manual
Popular Indoor Furnishing manuals by other brands

Regency
Regency LWMS3015 Assembly instructions

Furniture of America
Furniture of America CM7751C Assembly instructions

Safavieh Furniture
Safavieh Furniture Estella CNS5731 manual

PLACES OF STYLE
PLACES OF STYLE Ovalfuss Assembly instruction

Trasman
Trasman 1138 Bo1 Assembly manual

Costway
Costway JV10856 manual
