DiabloSport Predator User manual

HEMI GAS
GAS AND DIESEL TUNING SYSTEMS
USER MANUAL

End User License Agreement, Warranty and
Disclaimer
THIS END USER LICENSE AGREEMENT (the “Agreement”) is an agreement
between you, as the purchaser (the “Purchaser”) of either the Diablo
Module (the “Module”) or the hand-held computer unit (the “Unit”),
and as the manufacturer of the Product. The Product and the Unit shall
be referred to collectively herein as the“Product.”
1. Acknowledgment And Acceptance Of Agreement. If you do not agree
to the terms and conditions of this Agreement, do not use the Product.
Instead, promptly contact the distributor from which you purchased the
Product in writing, requesting a refund of the purchase price. Any use
of the Product by you will constitute your agreement to the terms and
conditions contained herein.
2. Grant Of License. The parties hereto acknowledge that DiabloSport
Inc. is granting a non-transferable restricted license to Purchaser to use
the Product for the sole purpose of installation in Purchaser’s vehicle.
DiabloSport Inc. shall retain all title, ownership rights and intellectual
property rights in and to the Product. Purchaser agrees that Purchaser
shall not, directly or indirectly, modify, translate, reverse engineer, de-
compile, disassemble, or create derivative works based on the Product.
Purchaser further agrees not to permit any third parties to modify,
translate, reverse engineer, decompile, disassemble, or create derivative
works based on the Product.
3. Disclaimer. The Product is being sold with no warranties of any kind,
express or implied. The Product is not endorsed by the manufacturer of
your vehicle and there is no affiliation between DiabloSport Inc. and
the manufacturer of your vehicle. Installation of the Product in your
vehicle or use of the Product with your vehicle may limit or void your
rights under any warranty provided by the manufacturer of your vehicle,
and DiabloSport Inc. assumes no responsibility in such event. Any war-
ranty not provided herein, and any remedy which, but for this provision,
might arise by implication or operation of law, is hereby excluded and
disclaimed. The implied warranties of merchantability and of fitness for
any particular purpose herein are expressly disclaimed.
4. No Liability For Damages, Injuries Or Incidental, Special Or Conse-
quential Damages. Under no circumstances shall DiabloSport Inc., or
any other party related to DiabloSport Inc., be liable to Purchaser or
any other person for any damage to Purchaser’s vehicle, loss of use of
Purchaser’s vehicle, or for personal injuries suffered by any person, or
for any incidental, special or consequential damages, whether arising
out of negligence, breach of warranty, breach of contract, or otherwise.
DiabloSport Inc.’s liability for any damages, loss and/or claims associated
with the Product shall be limited to the price of the Product paid by
purchaser. Purchaser hereby releases DiabloSport Inc. from all liability,
claims and damages associated with the Products, with the sole exception
of DiabloSport Inc.’s liability for the refund of the purchase price of the
Product to Purchaser in the event that a court of competent jurisdiction
determines the Purchaser suffered damages directly resulting from the
malfunction of the Product.
5.Warranty. Notwithstanding the provisions of the End User License
Agreement, DiabloSport warrants the Product to be free from all defects
in material and workmanship for 2 years from the date of original
purchase. This limited warranty applies only to the original Purchaser
of the Product. This limited warranty does not cover damage caused by
modification, alteration, repair or service of the Product by anyone other
than DiabloSport, physical abuse, misuse, use in a manner contrary to the
instructions, which accompany the Product, or any damage caused by acts
of God. Contacting your Distributor or Dealer may make claims for repair
service or replacement of the Product pursuant to this limited warranty.
The Chip will either be repaired or replaced, at the option of DiabloSport,
at no cost to Purchaser, if the defective Product is covered by this limited
warranty. DiabloSport’s liability pursuant to this limited warranty and
for any damages, loss and/or claims associated with the Product shall be
limited to the price of the Product paid by Purchaser, or, at DiabloSport’s
option, repair or replacement of the Product.
Warranty Information
a. DiabloSport offers a 30 day satisfaction guarantee on all products.
b. DiabloSport products carry a 2 year warranty against defects in materi-
als or workmanship.
i. DiabloSports liability under this warranty shall be limited to the cor-
rection or replacement of any defective part or product in question
which DiabloSport determines to be necessary.
ii. Warranty freight charges are the responsibility of the dealer dis-
tributor and/or customer.
iii. This warranty is to the original purchaser and is non transferable.
iv. This warranty is void unless proof of purchase is submitted.
v. Removal of serial numbers and/or alteration of product or packaging
will also void all warranties.
c. DiabloSport shall not be held responsible for direct or indirect failures
due to our product.

d. DiabloSport shall not credit or repair any units that are not properly
restored to the original backup upon time of return or may be VIN
locked.
i. VIN locked units, or improperly restored units, will be returned to
customer.
ii. It is the customers responsibility to check any and all DiabloSport
product to make sure the original backups have been restored to
vehicles before the product shall be returned.
e. Technical Support
i. DiabloSport customers should maintain adequate knowledge of the
DiabloSport product line to be able to properly sell, and to service the
needs of their customers.
ii. DiabloSport will provide technical assistance and advice directly to
the dealer/distributor to enable them to answer and field technical
questions.
iii. It is the responsibility of the dealer distributor to handle their own
technical issues with customers, and not to direct them to DiabloS-
port.
f. Product updates
i. DiabloSport shall inform all customers of the latest product as soon
as they are available.
ii. DiabloSport cannot be held accountable for any or all damages
caused by using outdated product.
iii. Products that need updates will be handled in the following fash-
ion:
1. DiabloSport will charge a labor and handling fee for products that
are internet updateable or remotely updateable.
2. DiabloSport will not charge a fee for products that are not internet
updateable or remotely updateable.
iv. All products returned for update purposes must have a correspond-
ing DiabloSport RMA number for processing.
g. Returns and RMA/RGA policies and procedures
i. DiabloSport will not warranty, credit, or exchange any product
returned without a valid RMA number.
1. All RMA numbers are issued by DiabloSport RMA department.
2. Defective units shall be repaired and returned in like kind. All units
that must be re-furbished to like new condition are subject to labor
and parts charges to be determined by DiabloSport.
ii. Customers are subject to a 20% restocking fee for all product re-
turned for credit.
iii. All units on RMA MUST have conditions for which they were
returned clearly labeled on the box, or given to a DiabloSport RMA
representative at the time the RMA is issued.
6. State Law. Some states do not allow limitations of implied warran-
ties, or the exclusion or limitation of incidental, special or consequential
damages, so the above limitations may not apply to you. In such states, li-
ability shall be limited to the greatest extent permitted by applicable law.
7. Governing Law & Venue. This Agreement shall be governed by and
construed in accordance with the laws of the State of Florida, and venue
for any legal proceeding or action at law arising out of or construing
this Agreement shall lie in the state or federal courts of Orange County,
Florida, and the parties specifically waive any other venue.
DISCLAIMER Not legal for sale or use on any pollution controlled motor
vehicles. Legal in California only for racing vehicles which may never be
used upon a highway.

DiabloSport Inc. Predator Satisfaction Guaran-
tee / Return Policy
All DiabloSport products have a satisfaction guarantee. If in the
first 30 days from date of purchase you are not satisfied with
the results the Predator generates in your vehicle, simply restore
the factory tune to your vehicle and return the Predator to the
selling dealer. Pending examination of the tool by DiabloSport,
you will receive a refund from your selling dealer. Under no
circumstances will DiabloSport accept the return of a Predator
unit that does not have a performance tune remaining in it.
Predator Revisions:
In an effort to keep the Diablosport Predator at the forefront of
technology, Diablosport will offer revisions to the Predator when
necessary. Updates are available via the web or you can return
the Predator for a revision update. Please contact Diablosport
for a Return Merchandise Authorization Number (RMA) and an
address to ship to. Predators shipped without an RMA number
clearly on the outer box will be refused. The updates will be
provided free of charge. The customer is responsible for all
freight expenses.
IMPORTANT PLEASE READ
TUNE INFORMATION
DiabloSport Performance - For stock to mildly modified applica-
tions - NOT FOR USE WITH SMALLER UPPER AND/OR LARGER
DIAMETER LOWER PULLEY APPLICATIONS
AFTERMARKET PARTS
Use of the DiabloSport Predator with aftermarket products is
at the owners risk; some aftermarket products create rich or
lean conditions based on design by the products manufacturer.
It is impossible to test every possible product so please proceed
with caution when using any product related to adding airflow
like throttle bodies, filters and cold air intake kits or boost in
the form of pulleys, or blower upgrades, changes in exhaust
systems or exhaust components, even rear end gear changes
(which make rate of acceleration changes can affect air fuel
ratio). Customers with these modifications may need a custom
tune from Diablosport or one of its CMR dealers. DiabloSport
recommends the use of a dyno and air fuel meter to monitor
data when adding aftermarket products to make the proper
tune changes with Predator.
*Premium grade unleaded fuel must be used for all PREDA-
TOR applications; AMOCO, MOBIL, SUNOCO fuels are recom-
mended.

Preparing to install
the Diablosport Performance Tune

Predator Applications
U7135-5.7L and 6.1 L Hemi V8 Engines
2006-2007 Jeep Grand Cherokee SRT-8
2005-2007 LX Magnum/Charger/300C
2005-2007 SRT-8 Magnum/Charger/300C
Preparing to
Install the
Diablosport
Performance
Tune

OBD II Diagnostic Port Location
Please read through the manual before in-
stalling any tune into your vehicle - failure to
follow proper instructions can result in a dam-
aged or disabled ECU (Engine Control Unit).
User must ensure that the original vehicle
Factory Tune is in the vehicle’s ECU before
installing the DiabloSport tune. (original
dealer reflashes are the same as Factory Tune).
Serious engine damage can occur if the
Predator tune is installed over a non-factory/
aftermarket performance tune.
Preparing to
Install the
Diablosport
Performance
Tune

Display and Keypad Description
ESC Key:
Jump back to previous menu
or jump to top of menu selection
Right arrow:
Set gauge value right
Up arrow:
Scroll up the menu
Enter Key/Continue:
Select the highlighted item
Left arrow:
Set gauge value left
Down arrow:
Scroll down the menu
Preparing to
Install the
Diablosport
Performance
Tune

Very important!
Do not perform any operations on Predator (except live data
diagnostics) while vehicle is running. The vehicle must be parked
and engine OFF.
• Always have all the doors closed while installing the DiabloS-
port Performance Tune, and keep them closed until the process
is complete.
• Do not activate any electrical accessories while installing
the DiabloSport Performance Tune. Ensure that there are no
electronic Aftermarket accessories* wired or plugged into the
vehicle that can cause a substantial voltage drop. Please contact
DiabloSport if you are uncertain about the effect of devices that
are on your vehicle.
• Certain cellular phones or radio equipment might also cause
interference. Please remove or turn such devices off.
• Do not try to install any tune on a vehicle with a
low battery voltage - charge your battery if necessary.
• Unless instructed, never turn the ignition key OFF while the
Predator is plugged into diagnostic port.
• Do not unplug the Predator while it is installing the DiabloS-
port Performance Tune or the Original Backup.
*Important Note:
All electronic aftermarket add-on parts can create a potential
power draw.
• tachometer
• electrical fans
• shift light
• audio/video equiptment
• gauges
• trailer/ tow equiptment
Any change in voltage during flash programming procedures
WILL interrupt the writing process.
Please disconnect or disable any such add on part.
In the event of such an occurrence, unplug the tool, wait 5
seconds and then plug it back in. The tool will recognize that a
interrupted writing error has occurred and will automatically in-
stall the original back up. The vehicle is now in its original state.
Please attempt to locate the voltage draw before Predator is
used again.
Please feel free to contact DiabloSport directly at any time with
questions related to this process. 18005315484
IT IS NOT NECESSARY TO CONTACT THE VEHICLE MANUFAC-
TURER SHOULD SUCH ERRORS OCCUR. ANY AND ALL COSTS
RELATED TO SUCH ACTIONS ARE THE RESPONSIBILITY OF THE
END USER - NOT DIABLOSPORT OR ITS DEALERS.
Preparing to
Install the
Diablosport
Performance
Tune

Installing the Diablosport
Performance Tune

Installing the Performance Tune
Predator contains several predefined DiabloSport Tunes. These
are thoroughly tested and approved by DiabloSport. You have a
choice of either installing the DiabloSport Tune “as-is” into your
vehicle, or customizing it to your personal taste.
If you are satisfied with your factory tuned vehicle and only
have a desire to modify a parameter or two (example: change
gear ratio), you might want to read the chapter ‘Customizing
the Factory Tune’.
Before you install any tune into your vehicle, when you use
the Predator for the first time, it will read the Original Factory
Tune out of your vehicle and permanently store it in its memory.
This process takes a minute or two. For safety reasons, there
is no way to overwrite this backup and therefore the Predator
becomes ‘married’ to, and only to, your vehicle until original
backup is restored.
If there is ever a need to send the Predator back to DiabloSport,
for any reason, the Original Backup must be put back into your
vehicle, as described in the section Reinstalling the Original
Factory Backup’, otherwise your Predator will not be accepted
back by the reseller. To find out, which tune was last written to
your vehicle, go to ‘Predator Options / Show Last Tune Written’
in the Predator.
Hemi Tune Information
Performance Tune:
Designed to add power and torque using premium fuel, this
tune can be used with minor bolt-ons and aftermarket exhaust
systems.
Performance CAI Tune: (cars only)
Designed to add power and torque using premium fuel and a
CAI (cold air intake), this tune can be used with minor bolt-ons
and aftermarket exhaust systems.
Performance 91 oct. Tune: (cars only)
Designed to add power and torque using 91 octane fuel, this
tune can be used with minor bolt-ons and aftermarket exhaust
systems.
Performance 91 oct. CAI Tune: (cars only)
Designed to add power and torque using 91 octane fuel and a CAI (cold
air intake), this tune can be used with minor bolt-ons and aftermarket
exhaust systems.
Modify Stock Tune:
Modify Stock tune settings where user can adjust any of the adjustable
parameters available for the application.
Original Backup:
Stock tune, installing this will reset the Predator and allow it to be used
on another vehicle.
NOTE: WHEN CHANGING HP TUNES, THERE IS NO NEED TO RESTORE
FACTORY TUNE BEFORE INSTALLING A NEW(DIFFERENT) HP TUNE. YOU
WILL BE PROMPTED TO RESET PARAMETERS PRESS YES OR NO AS YOU
DESIRE.
*Premium grade unleaded fuel must be used for all predator applica-
tions; AMOCO, MOBIL, SUNOCO fuels are recommended.
Installing
the
Diablosport
Performance
Tune

Installing the Diablosport Tune
for the First Time
The very first time the Predator is used on a vehicle it will auto-
matically create a backup of the original factory tune.
(Installing the DiabloSport Performance Tune)
1. Plug the Predator into the Diagnostic Port of the vehicle,
located under the driver’s side dash.
2. The first screen you will see is the startup screen with the name of the
vehicle the predator supports (i.e.: Hemi )
3. Performance tune should be three choices:
• Performance Tune
• Diagnostics
• Options
4. Select “Performance Tune” by pressing the “Continue” key
5. Disclaimer will appear, - read & press “Continue”
6. Turn the ignition ON. DO NOT START Vehicle- press “continue”
(If selecting “modify Tune”see the section on changing parameters)
7. Select “Diablo Tunes”and press enter.
8. Highlight the tune you would like to install by using arrow keys. Press
“enter” to continue
9. Verification of the tune will appear. If this is correct, Highlight“Choose”
& press “Enter”.
10. The original Backup will now be saved.“press enter to continue”.
11. Follow the prompts to turn on & off the ignition (do not start the car
at any time) press“enter” if prompted.
12. A status bar will show progress on the backup process. This might
take several minutes.
13. When completed, a message saying “Original Backup has been
saved”will be displayed. Press “Continue”.
14. At this point you have the option of installing the Diablo tune or
modifying a tune. Highlight the appropriate choice by using the arrow
keys & press Enter.
For more on modify tune please see the modify tune section in the
manual.
15. Follow the prompts to turn on & off the ignition (do not start the car
at any time) press“enter” if prompted.
16. The tune should now be writing. Do not interrupt this process or
ECM damage can occur.
NOTE: You may be asked to cycle the key more than once after the tune
is written, this is normal.
17. When the Process is complete, the Message “ {xxxxxx} tune is now in
vehicle. You may drive it now. Please unplug the tool”
Unplug the predator from the Diagnostic port. Cycle the key, and start
the vehicle. You are now able to enjoy the force of the Predator!!
NOTE: During programming the head lights will come on and stay on
until process is complete.
On vehicles equipped with the rain sensing vipers it is recommened to
turn them to the “0” position on the stalk before programming as they
will engage if not turned to “0”.
Installing
the
Diablosport
Performance
Tune

Modifing Parameters & Quick Adjust menu

Modify Tune Procedures
1. When selecting the “Modify tune” function, a disclaimer will
appear. Read and press “Enter” to continue.
2. The “modify Performance Tune menu will appear. You will
have 2 choices:
• Modify Parameters
• Reset all Parameters
3. Highlight the appropriate choice by using the arrow keys &
press “Enter”
4. In the “Modify Parameters” Menu the following choices will
appear for your Hemi applicable vehicle:
• Speed Limiter
• Idle Speed
• WOT Spark Advance
• WOT Fuel Table
• Knock sensor Enable/Disable
• Cooling Fans
• Rev limiter
“Parameters/Features may not apply to all applications and may
not be available upon release. Check www.diablosport.com for
current parameters.
5. Highlight the appropriate choice by using the arrow keys &
press “Enter”
6. Modify the appropriate parameter by using the arrow keys
& press “Enter” to continue. [ These parameters should only be
changed is you have a understanding of tuning. Engine or ECM
damage can occur without proper knowledge.]
7. Verification will display “Are you sure?” press “Enter” to
continue
8. The display “this change will take effect next time you install
the tune”will appear – Press“Continue”
9. Use the “ESC” key to go back through the menus and either
continue to change parameters or go to the “install tune now?”
menu. Press “Enter “ to continue.
10. The tune should now be building. Do not interrupt this
process or PCM damage can occur.
11. Follow the prompts to turn on & off the ignition (do not
start the car at any time) press “enter” if prompted
12. The tune should now be writing. Do not interrupt this pro-
cess or ECM damage can occur.
During programming do not touch any buttons or open and
close doors, the theft light will blink rapidly and on some ve-
hicles the electric fans will come on during programming.
13. Follow the prompts to turn ON & OFF the ignition (do not
start the car at any time) press “Enter” if prompted
14. When the process is complete, the Message “ {xxxxxx} tune is now in
vehicle. You may drive it now. Please unplug the tool”Unplug the preda-
tor from the Diagnostic port. Cycle the key, and start the vehicle. You are
now able to enjoy the force of the Predator!
NOTE If tune is not installed at the prompt the adjusted parameters will
not be lost, they will be saved, just not installed in the vehicle.
To reset parameters, simply press“Reset Parameters”button.
When switching from Performance Tune, Stock tune or Custom tune you
will be prompted to keep or discard adjusted parameters.
Modifing
Parameters
&
Quick Adjust

Adjustable Parameter description:
Timing table 1000-3800rpm (+10/- 10deg)
This will allow user to adjust timing in the lower rpm ranges.
Timing table 4000-4800rpm (+10/- 10deg)
This will allow user to adjust timing at peak torque where the
engine is most prone to detonation.
Timing table 5000-7000rpm (+10/- 10deg)
This will allow user to adjust timing at high rpm past peak
torque for peak horse power.
Fuel table 1000-3800rpm (+/- 20%)
This will allow user to adjust fueling in the lower rpm ranges.
Fuel table 4000-4800rpm (+/- 20%)
This will allow user to adjust fuel for peak torque, a little more
fuel can cure detonation issues at peak torque.
Fuel table 5200-7000rpm (+/- 20%)
This will allow user to adjust fueling at high rpm past peak
torque for peak horse power.
Idle rpm in drive: (+ 400rpm / -400rpm)
This will allow user to adjust desired idle rpm when vehicle is
in drive.
Idle rpm in park/neutral: (+ 400rpm / -400rpm)
This will allow user to adjust desired idle rpm when vehicle is in
park and neutral.
Rev limiter in drive:
This will allow user to adjust the rev limit in drive.
Rev limiter in park/neutral:
This will allow user to adjust the rev limit in park/neutral.
Vehicle speed limiter:
This will enable you to adjust the electronic speed limiter.
Fan control:
AC off high MPH high speed fan on temp
AC off high MPH low speed fan on temp
AC off high MPH medium speed fan on temp
AC off low MPH high speed fan on temp
AC off low MPH low speed fan on temp
AC off low MPH medium speed fan on temp
AC on high speed fan on temp
AC on medium speed fan on temp
AC on low speed fan on temp
Knock Sensors:
This will allow user to enable or disable long term and short term knock
sensors.
NOTE: Poor quality fuel can cause severe damage to your engine with
the knock sensors disabled, should only be done with high quality high
octane fuels.
Modifing
Parameters
&
Quick Adjust

Modifing
Parameters
&
Quick Adjust
Quick Adjust parameters:
ESP:
ESP enable/disable, this will enable or disable your ESP system
This system is enabled until user disables it here.
NOTE: When the ESP is disabled the ABS will not function and the Brake,
ESP BAS and ABS lights will stay lit on the dash.
The ESP disable also gets enabled each time the vehicle is flashed.
Tire Size:
This will allow user to adjust for aftermarket rims and tires.
Transmission:
Autostick Auto Upshift:
This will enable or disable the automatic upshift when in manual
shift mode, it is enabled from the factory, when disabled the tran-
mission will NOT shift to the next gear automatically when in manual
mode, it will rev until it reaches the rev limiter.
Reset TCM adaptation:
This will reset the learned transmission adaptation.
Shift Points:
This will enable you to raise the shift points by a set value.
5.7L 1-2 shift 5800rpm, 2-3 & 3-4 shifts at 6000rpm
6.1L SRT8 1-2, 2-3 & 3-4 shifts at 6400rpm
Shift Firmness:
This will increase shift firmness to a preset value.
Not available for SRT vehicles.
Quick Adjust
This menu has select items that do not require a tune to be
written to the vehicke in order to take effect, they only require
a simple key cycle.
These parameters can be adjusted at any time with any tune
installed in the vehicle. These items (except for ESP) are also
available in the modify parameters menu.
Each Quick Adjust change will ask you to cycle the ignition key
after changing them. Once ignition key is cycled the parameter
has changed and you can unplug the Predator.
