Diamondback 58477 Assembly instructions

Visit our website at: http://www.harborfreight.com
Email our technical support at: [email protected] 58477
Owner’s Manual & Safety Instructions
Save This Manual Keep this manual for the safety warnings and precautions, assembly,
operating, inspection, maintenance and cleaning procedures. Write the product’s serial number in the
back of the manual near the assembly diagram (or month and year of purchase if product has no number).
Keep this manual and the receipt in a safe and dry place for future reference. 22d
When unpacking, make sure that the product is intact
and undamaged. If any parts are missing or broken,
please call 1-888-866-5797 as soon as possible.
Copyright©2021 by Harbor Freight Tools®. All rights reserved.
No portion of this manual or any artwork contained herein may be reproduced in
any shape or form without the express written consent of Harbor Freight Tools.
Diagrams within this manual may not be drawn proportionally. Due to continuing
improvements, actual product may differ slightly from the product described herein.
Tools required for assembly and service may not be included.
Read this material before using this product.
Failure to do so can result in serious injury.
SAVE THIS MANUAL.

Page 2 For technical questions, please call 1-888-866-5797. Item 58477
Important Safety Information
Assembly Precautions
1. Assemble only according to these
instructions. Improper assembly
can create hazards.
2. Wear ANSI-approved safety goggles
and heavy-duty work gloves
during assembly.
3. Keep assembly area clean and well lit.
4. Keep bystanders out of the
area during assembly.
5. Do not assemble when tired
or when under the influence
of drugs or medication.
Use Precautions
1. Follow all warnings and instructions
in the Tile Saw’s manual that
this Stand is used with.
2. Use only on level, flat, hard surface
able to support weight of stand,
saw, and workpiece.
3. This product is not a toy. Do not allow
children to play with or near this item.
4. Use as intended only. Use with 7″ and
10″ Diamondback Tile Saws only.
5. Turn the Power Switch of the tile saw
to its “OFF” position, remove its key,
and unplug the tool from its electrical
outlet before mounting to stand.
6. Inspect before every use; do not use
if parts are loose or damaged.
7. Maintain product labels and
nameplates. These carry
important safety information.
If unreadable or missing, contact
Harbor Freight Tools for a replacement.

Page 3For technical questions, please call 1-888-866-5797.Item 58477
Assembly Instructions
Read the ENTIRE IMPORTANT SAFETY INFORMATION section at the
beginning of this document including all text under subheadings therein
before set up or use of this product.
Note: Tile Saw sold separately.
1. Slide a Lock Washer (10), Wheel
(7), Flat Washer (9) and Lock Nut
(8) onto the Axle. Tighten securely.
Repeat with other Wheel.
Flat
Washer (9)
Axle
Lock
Washer (10)
Lock
Nut (8)
Wheel
(7)

Page 4 For technical questions, please call 1-888-866-5797. Item 58477
Mounting Instructions
Mounting 10″ Saw to Stand
WARNING! TO PREVENT SERIOUS
INJURY: Turn the Power Switch of the tile
saw to its “OFF” position, remove its key,
and unplug the tool from its electrical
outlet before mounting to stand.
1. Lock the Toggle Table Stop by
pulling up on it and turning it until
the slot in the center of the Stop
is horizontal (left to right).
2. Pull the Table to the front of the Frame.
From under the right side of the Table,
align the hole in the rail with the pin
in the Table Lock Lever. Push the
pin into the rail, locking the Table.
3. With assistance, place Saw on Stand.
Align the holes on the Water Tray
Frame with the holes on the Stand.
4. Secure Saw to Stand with two
Washers M8 (3) and two
Bolts M8x20 (4), tighten Bolts securely.
WARNING! TO PREVENT SERIOUS
INJURY: If the Saw does not mount
securely and completely to this Stand,
do not use it with this Stand.
Bolt
M8 x 20 (4)
Washer
M8 (3)
Toggle
Table
Stop
Table
Lock
Lever
Power Switch
& Key

Page 5For technical questions, please call 1-888-866-5797.Item 58477
Mounting 7" Saw to Stand
WARNING! TO PREVENT SERIOUS
INJURY: Turn the Power Switch of the tile
saw to its “OFF” position, remove its key,
and unplug the tool from its electrical
outlet before mounting to stand.
1. Lock the Toggle Table Stop by
pulling up on it and turning it until
the slot in the center of the Stop
is horizontal (left to right).
2. Pull the Table to the front of the Frame.
From under the right side of the Table,
align the hole in the rail with the pin
in the Table Lock Lever. Push the
pin into the rail, locking the Table.
3. Attach two Stand Brackets, from Tile
Saw hardware, to ends of Water Tray
using two ST4.8 x13 Screws, from
Tile Saw hardware, per Bracket.
4. With assistance, place Saw on Stand.
Align the holes on the Water Tray
Frame with the holes on the Stand.
5. Secure Stand Brackets to
Stand with two Bolts M8x20 (4),
two Washers M8 (3),
two Flat Washers M10 (9),
and two Lock Nuts M8 (12).
Tighten Lock Nuts securely.
WARNING! TO PREVENT SERIOUS
INJURY: If the Saw does not mount
securely and completely to this Stand,
do not use it with this Stand.
Washer
M8 (3)
Bolt
M8x20 (4)
Power Switch
& Key
Toggle
Table
Stop
Table
Lock
Lever
Stand Bracket
(from Tile Saw
hardware)
Lock Nut
M8 (12)
ST4.8 x 13
Screw (from
Tile Saw
hardware)

Page 6 For technical questions, please call 1-888-866-5797. Item 58477
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY
DIAGRAM IN THIS DOCUMENT AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER
OR DISTRIBUTOR MAKES ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE
BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR
THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT. IN FACT, THE
MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY STATES THAT ALL REPAIRS AND PARTS
REPLACEMENTS SHOULD BE UNDERTAKEN BY CERTIFIED AND LICENSED TECHNICIANS,
AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY ARISING OUT OF
HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS THERETO,
OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Parts List
Part Description Qty
1 Hex Bolt M8x55 2
2 Insert 2
3 Flat Washer M8 6
4 Hex Socket Bolt M8x20 2
5 Front Support Leg 1
6 Feet 2
7 Wheel 2
8 Locknut M10 2
9 Flat Washer M10 2
10 Lock Washer M12 2
11 Rear Support Leg 1
12 Locknut M8 4
Record Serial Number Here:
Note: If product has no serial number, record month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not available
individually as replacement parts. Specify UPC 193175440068 when ordering parts.

Page 7For technical questions, please call 1-888-866-5797.Item 58477
Assembly Diagram

Limited 90 Day Warranty
Harbor Freight Tools Co. makes every effort to assure that its products meet high quality
and durability standards, and warrants to the original purchaser that this product is free from
defects in materials and workmanship for the period of 90 days from the date of purchase.
This warranty does not apply to damage due directly or indirectly, to misuse, abuse, negligence
or accidents, repairs or alterations outside our facilities, criminal activity, improper installation,
normal wear and tear, or to lack of maintenance. We shall in no event be liable for death,
injuries to persons or property, or for incidental, contingent, special or consequential damages
arising from the use of our product. Some states do not allow the exclusion or limitation of
incidental or consequential damages, so the above limitation of exclusion may not apply to you.
THIS WARRANTY IS EXPRESSLY IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR
IMPLIED, INCLUDING THE WARRANTIES OF MERCHANTABILITY AND FITNESS.
To take advantage of this warranty, the product or part must be returned to us with transportation
charges prepaid. Proof of purchase date and an explanation of the complaint must accompany
the merchandise. If our inspection verifies the defect, we will either repair or replace
the product at our election or we may elect to refund the purchase price if we cannot readily
and quickly provide you with a replacement. We will return repaired products at our expense,
but if we determine there is no defect, or that the defect resulted from causes not within
the scope of our warranty, then you must bear the cost of returning the product.
This warranty gives you specific legal rights and you may also
have other rights which vary from state to state.
26677 Agoura Road • Calabasas, CA 91302 • 1-888-866-5797
