Digital Projection E-Vision Laser 7500 Series User manual

Rev D August 2017
E-Vision Laser 7500 Series
E-Vision Laser 8500 Series
E-Vision Laser 10K Series
High Brightness Digital Video Projector
4INSTALLATION AND QUICK-START GUIDE
4CONNECTION GUIDE
4OPERATING GUIDE
4REFERENCE GUIDE
117-919D

page i
Digital Projection E-Vision Laser 7500, 8500 & 10K Series
Rev D August 2017
About This Document
Follow the instructions in this manual carefully to ensure safe and long-lasting use of the projector.
Symbols used in this manual
Many pages in this document have a dedicated area for notes. The information in that area is accompanied by the following symbols:
WARNING: this symbol indicates that there is a danger of physical injury to yourself and/or damage to the equipment unless
the instructions are closely followed.
ELECTRICAL WARNING: this symbol indicates that there is a danger of electrical shock unless the instructions are closely
followed.
LASER WARNING: this symbol indicates that there is a potential hazard of eye exposure to laser radiation unless the
instructions are closely followed.
NOTE: this symbol indicates that there is some important information that you should read.
Product revision
Because we at Digital Projection continually strive to improve our products, we may change specications and designs, and add new features
without prior notice.
Legal notice
Trademarks and trade names mentioned in this document remain the property of their respective owners.
Digital Projection disclaims any proprietary interest in trademarks and trade names other than its own.
Copyright © 2017 Digital Projection Ltd. All rights reserved.
Notes

page ii
Digital Projection E-Vision Laser 7500, 8500 & 10K Series
Rev D August 2017
Laser Information
Caution-useofcontrolsoradjustmentsorperformanceofproceduresotherthanthosespeciedhereinmayresultin
hazardous radiation exposure.
Complies with FDA performance standards for laser
products except for deviations pursuant to Laser
Notice No. 50, dated June 24, 2007
LASER RADIATION
AVOID DIRECT EYE EXPOSURE
CLASS 3R LASER PRODUCT
Emitted wavelength : 450-460 nm
Max. Pulse energy: 0.253 mJ, Pulse duration: 0.5 ms
激光輻射 避免眼睛受到直接照射 3R 激光產品
波長 : 450-460 nm
最大脈衝能量: 0.253 mJ, 脈衝時間: 0.5 ms
RAYONNEMENT LASER
EXPOSITION DIRECTE DANGEREUSE POUR LES YEUX
APPAREIL À LASER DE CLASSE 3R
longueur d'onde : 450-460nm
maximum énergie de impulsion : 0.253 mJ,
durée de impulsion : 0.5 ms
GB 7247.1-2012 / IEC/EN 60825-1:2007
CLASS 1 LASER PRODUCT
IEC/EN 60825-1:2014
PRODUIT LASER DE CLASSE 1
IEC/EN 60825-1:2014
DLP Projector / Projecteur DLP
(
數位投影機/數字投影機
)
Model/Modèle/( 型號 / 型號 ) : E-Vision Laser 10K
AC INPUT/Entrée CA( 輸入 / 輸入 ) : 100-130 VAC 13.4A 50/60Hz
AC INPUT/Entrée CA( 輸入 / 輸入 ) : 200-240 VAC 6.2A 50/60Hz
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
CAN ICES-3(A) /NMB-3(A)
Caution : Do not open the cover. No user-serviceable parts inside
Avertissement : ne pas ouvrir le couvercle. Le produit ne contient
aucune pièce interne réparable par l’utilisateur.
警 告 : 請勿打開外殼,設備內無服務性維修之元件
警 告 : 請勿打開外殼,設備內無服務性維修之元件
警告: 此為A級產品，在生活環境中，該產品可能會造成無線電干擾。
在這種情況下，可能需要用戶對干擾採取切實可行的措施。
XXXXXXXXXX XX XXXX
製造商:Digital Projection Limited
Greenside Way Middleton
Manchester, M24 1XX UK
(製造地:中國/製造地:中國) Made in China
Part No.: CCC-CCC
*XXXXXXXXXXXXX*
MANUFACTURED YYYY.WW
Code 39 or 128 of serial no
Complies with FDA performance standards for laser
products except for deviations pursuant to Laser
Notice No. 50, dated June 24, 2007
LASER RADIATION
AVOID DIRECT EYE EXPOSURE
CLASS 3R LASER PRODUCT
Emitted wavelength : 450-460 nm
Max. Pulse energy: 0.376 mJ, Pulse duration: 0.74 ms
激光輻射 避免眼睛受到直接照射 3R 激光產品
波長 : 450-460 nm
最大脈衝能量: 0.376 mJ, 脈衝時間: 0.74 ms
RAYONNEMENT LASER
EXPOSITION DIRECTE DANGEREUSE POUR LES YEUX
APPAREIL À LASER DE CLASSE 3R
longueur d'onde : 450-460nm
maximum énergie de impulsion : 0.376 mJ,
durée de impulsion : 0.74 ms
GB 7247.1-2012 / IEC/EN 60825-1:2007
CAUTION
Possibly hazardous optical radiation emitted
from this product.
Do not stare at operating lamp.
May be harmful to the eyes.
ATTENTION
Ce produit peut émettre des rayonnements
optiques dangereux.
Ne pas fixer la lampe en fonctionnement.
Peut être nocif pour les yeux.
RISK GROUP 2
DLP Projector / Projecteur DLP
(
數位投影機/數字投影機
)
Model/Modèle/( 型號 / 型號 ) :
AC INPUT/Entrée CA( 輸入 / 輸入 ) : 100-130 VAC 9.5A 50/60Hz
AC INPUT/Entrée CA( 輸入 / 輸入 ) : 200-240 VAC 4.5A 50/60Hz
This device complies with part 15 of the FCC rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired operation.
CAN ICES-3(A) /NMB-3(A)
Caution : Do not open the cover. No user-serviceable parts inside
Avertissement : ne pas ouvrir le couvercle. Le produit ne contient
aucune pièce interne réparable par l’utilisateur.
警 告 : 請勿打開外殼,設備內無服務性維修之元件
警 告 : 請勿打開外殼,設備內無服務性維修之元件
警告: 此為A級產品，在生活環境中，該產品可能會造成無線電干擾。
在這種情況下，可能需要用戶對干擾採取切實可行的措施。
3264621200
製造商:Digital Projection Limited
Greenside Way Middleton
Manchester, M24 1XX UK
(製造地:中國/製造地:中國) Made in China
Part No.: CCC-CCC
*XXXXXXXXXXXXX*
MANUFACTURED YYYY.WW
Code 39 or 128 of serial no
E-Vision Laser 8500 WUXGA
Explanatory label: E-Vision Laser 10KExplanatory label: E-Vision Laser 8500 Laser warning symbol
Notes

page iii
Digital Projection E-Vision Laser 7500, 8500 & 10K Series
Rev D August 2017
Introduction
Congratulations on your purchase of this Digital Projection product.
Your projector has the following key features:
• Support for most 3D formats.
• HDBaseT® for transmission of uncompressed High Denition Video up to 100 m from the source.
• 3G-SDI with loop-through.
• Edge Blend.
• Blanking control for custom input window sizing.
• Cornerstone, Vertical & Horizontal Keystone, Pincushion & Barrel, and Image Rotation.
• Separate control of screen and source aspect ratio.
• Control via LAN and RS232.
• Motorised lens mount.
A serial number is located on the side of the projector. Record it here:
Notes

page iv
Digital Projection E-Vision Laser 7500, 8500 & 10K Series
Rev D August 2017
CONTENTS
INSTALLATION AND QUICK-START GUIDE ..............................1
WHAT’S IN THE BOX? ................................................................... 3
CONNECTING THE POWER SUPPLY ............................................. 4
Voltage selection................................................................................... 4
PROJECTOR OVERVIEW ............................................................... 5
Front and rear views ............................................................................. 5
Control panel......................................................................................... 6
Projector indicators ................................................................................ 7
REMOTE CONTROL....................................................................... 8
Infrared reception................................................................................ 11
POSITIONING THE SCREEN AND PROJECTOR........................... 12
Roll and pitch ...................................................................................... 13
CHANGING THE LENS................................................................. 14
Inserting a new lens ............................................................................ 14
Removing the lens .............................................................................. 14
OPERATING THE PROJECTOR.................................................... 15
Switching the projector on................................................................... 15
Switching the projector off................................................................... 15
Selecting an input signal ..................................................................... 16
Selecting a test pattern ....................................................................... 16
Adjusting the lens................................................................................ 17
Adjusting the image............................................................................. 17
CONNECTION GUIDE ............................................................................19
SIGNAL INPUTS .......................................................................... 21
Digital inputs and outputs.................................................................... 21
Analog inputs and outputs................................................................... 22
EDID on the DVI and VGA inputs........................................................ 23
Using HDMI/DVI switchers with the projector ..................................... 23
3D connections ................................................................................... 24
3D sources up to 60Hz requiring frame doubling and left/right interleaving.......... 24
Frame sequential 3D sources up to 120Hz ................................................. 24
Dual Pipe 3D ...................................................................................... 24
3D Sync............................................................................................... 25
3D Sync in ......................................................................................... 25
3D Sync out ....................................................................................... 25
CONTROL CONNECTIONS........................................................... 26
LAN connection examples .................................................................. 27
RS232 connection example ............................................................... 28

page v
Digital Projection E-Vision Laser 7500, 8500 & 10K Series
Rev D August 2017
OPERATING GUIDE ................................................................................29
USING THE MENUS ..................................................................... 31
Opening the OSD................................................................................ 31
Opening a menu.................................................................................. 31
Exiting menus and closing the OSD.................................................... 31
Inside a menu...................................................................................... 32
Accessing sub-menus........................................................................... 32
Executing commands............................................................................ 32
Editing projector settings..................................................................... 33
Using a slider to set a value.................................................................... 33
Editing numeric values .......................................................................... 33
USING THE PROJECTOR............................................................. 34
Main menu .......................................................................................... 34
Lens menu .......................................................................................... 35
Lens Control....................................................................................... 35
Lens Memory...................................................................................... 36
Image menu ........................................................................................ 37
Noise Reduction .................................................................................. 38
Position and Phase .............................................................................. 38
Color menu.......................................................................................... 39
Color Space ....................................................................................... 39
Color Mode ........................................................................................ 40
Geometry menu .................................................................................. 45
Aspect Ratio....................................................................................... 45
Digital Zoom & Shift (E-Vision Laser 7500 and 8500) .................................... 47
Digital Zoom (E-Vision Laser 10K)............................................................ 47
Overscan........................................................................................... 48
Blanking ............................................................................................ 49
Keystone ........................................................................................... 50
4 Corners .......................................................................................... 52
Rotation ............................................................................................ 53
Pincushion / Barrel............................................................................... 54
Geometry menu continued from previous page ........................................... 55
Arc (E-Vision Laser 10K) ....................................................................... 55
Edge Blend menu................................................................................ 56
Blend Width........................................................................................ 57
Black Level Uplift ................................................................................. 58
3D menu.............................................................................................. 59
3D types............................................................................................ 60
Some 3D settings explained ................................................................... 61
Frame rate multiplication in 3D images ...................................................... 62
Laser menu ......................................................................................... 63
Setup menu......................................................................................... 64
ColorMax Setting ................................................................................. 66
Power On/Off...................................................................................... 67
Clock Adjust ....................................................................................... 68
OSD Settings...................................................................................... 69
Memory............................................................................................. 69
Network menu..................................................................................... 70
PIP menu ............................................................................................ 71
Information menu ................................................................................ 72
Signal Format ..................................................................................... 72
System Status .................................................................................... 73
Thermal Status.................................................................................... 73
Factory Reset ..................................................................................... 74
CONTENTS (continued)

page vi
Digital Projection E-Vision Laser 7500, 8500 & 10K Series
Rev D August 2017
POSSIBLE COMBINATIONS OF SETTINGS.................................. 75
REFERENCE GUIDE................................................................................77
THE DMD™.................................................................................. 79
CHOOSING A LENS ..................................................................... 81
Basic calculation ................................................................................. 82
Basic calculation example................................................................... 83
Full lens calculation............................................................................. 84
Introducing TRC .................................................................................. 84
Calculating TRC .................................................................................. 85
Calculating the throw ratio with TRC ......................................................... 86
Full lens calculation example .............................................................. 87
SCREEN REQUIREMENTS........................................................... 88
Fitting the image to the DMD™........................................................... 88
WUXGA images displayed full width ......................................................... 88
WUXGA images displayed with a height of 1080 pixels.................................. 89
WUXGA images displayed full height ........................................................ 90
Diagonal screen sizes......................................................................... 91
Fitting the image to the screen............................................................ 92
Positioning the screen and projector................................................... 93
POSITIONING THE IMAGE........................................................... 94
FRAME RATES AND PULLDOWNS EXPLAINED........................... 96
Interlaced and progressive scan ......................................................... 96
Frame rates of image sources ............................................................ 96
Pulldowns - conversion into destination formats................................. 97
2:3 (normal) pulldown ........................................................................... 97
2:3:3:2 (advanced) pulldown................................................................... 98
APPENDIX A: LENS PART NUMBERS.......................................... 99
APPENDIX B: SUPPORTED SIGNAL INPUT MODES.................. 100
2D formats......................................................................................... 100
3D formats......................................................................................... 102
APPENDIX C: WIRING DETAILS ................................................ 104
RS232 ............................................................................................... 104
Trigger 1 & Trigger 2 ......................................................................... 105
Wired remote control......................................................................... 105
3D Sync IN and 3D Sync OUT.......................................................... 105
APPENDIX D: GLOSSARY OF TERMS ....................................... 106
CONTENTS (continued)

Digital Projection E-Vision Laser 7500, 8500 & 10K Series
This page is intentionally left blank.

Rev D August 2017
E-Vision Laser 7500 Series
E-Vision Laser 8500 Series
E-Vision Laser 10K Series
High Brightness Digital Video Projector
INSTALLATION AND QUICK-START GUIDE
4

Digital Projection E-Vision Laser 7500, 8500 & 10K Series
Installation and Quick-Start Guide
IN THIS GUIDE
Rev D August 2017
IN THIS GUIDE
What’s In The Box?............................................................................................. 3
Connecting The Power Supply........................................................................ 4
Voltage selection.........................................................................................................4
Projector Overview............................................................................................. 5
Front and rear views...................................................................................................5
Control panel...............................................................................................................6
Projector indicators ........................................................................................................... 7
Remote Control.................................................................................................... 8
Infrared reception......................................................................................................11
Positioning The Screen And Projector....................................................... 12
Roll and pitch ............................................................................................................13
Changing The Lens........................................................................................... 14
Inserting a new lens..................................................................................................14
Removing the lens ....................................................................................................14
Operating The Projector ................................................................................. 15
Switching the projector on.......................................................................................15
Switching the projector off.......................................................................................15
Selecting an input signal..........................................................................................16
Selecting a test pattern.............................................................................................16
Adjusting the lens.....................................................................................................17
Adjusting the image..................................................................................................17

page 3
Digital Projection E-Vision Laser 7500, 8500 & 10K Series
Installation and Quick-Start Guide
WHAT’S IN THE BOX?
Rev D August 2017
What’s In The Box? Notes
Make sure your box contains
everything listed. If any pieces are
missing, contact your dealer.
You should save the original box
and packing materials, in case you
ever need to ship your projector.
The projector is shipped without a
lens.
Only one power cable - dependent
on the destination territory - will be
supplied with the projector.
Remote control
(117-780)
2x AAA batteries
User Manual on disc Important Information (117-440)
Power cable, Europe Power cable, North America
Projector
Power cable, United Kingdom
Pic Mute
OFF ON
MENU
EXIT INFO
HDMI1
OK
OFF ON
ALT
LENS
FOCUS ZOOM
IN
OUT
IN
OUT
SHIFT
21 3
HDMI2 DVI
DISPLAYPORT
HD-T 3GSDI
VGA COMP1 COMP2
BRI
TEST
CON GAMMA
R G B ALL
3D EYE PIP SWAP
456
7 8 9 0
ALT
ADDR
OSD
OFF ON
DEFAULT
FREEZE RE-SYNC
A B C D
USER PRESET

page 4
Digital Projection E-Vision Laser 7500, 8500 & 10K Series
Installation and Quick-Start Guide
CONNECTING THE POWER SUPPLY
Rev D August 2017
Connecting The Power Supply
Adjust the VOLTAGE SELECT switch 1to
the required voltage, then rmly push the mains
connector into the socket 2.
Voltage selection
The VOLTAGE SELECT switch must be set to match the power supply you are using:
Voltage of power supply used Position of VOLTAGE SELECT switch
AC100-139V outlet
AC200-240V (single phase) outlet
Notes
Use only the power cable
provided.
Ensure that the power outlet
includes a ground connection as
this equipment MUST be earthed.
Handle the power cable carefully
and avoid sharp bends. Do not
use a damaged power cable.
1
2

page 5
Digital Projection E-Vision Laser 7500, 8500 & 10K Series
Installation and Quick-Start Guide
PROJECTOR OVERVIEW
Rev D August 2017
Projector Overview
Front and rear views
1Connection panel
2Control panel
3Front infrared window
4Indicators
5Lens mount
6Voltage selector
7Power switch and power connection
8Air inlet
9Air inlets
10 Rear infrared window
11 Air outlets
12 Adjustable feet
Notes
Front view
6 7
5
12
8
34
Rear view
12
11
910

page 6
Digital Projection E-Vision Laser 7500, 8500 & 10K Series
Installation and Quick-Start Guide
PROJECTOR OVERVIEW
Rev D August 2017
Control panel
1POWER
Switches the projector on and off
(STANDBY).
2INPUT
Switches to the next input source.
3AUTO SYNC
Re-synchronises with the current input
signal.
4ASPECT
Changes the aspect ratio.
5CENTER LENS
Centers the lens.
6PIC MUTE
Shows and hides the projected image.
When OFF, the light source is completely
switched off and the screen is black.
7MENU
Displays and exits the OSD.
8Arrow buttons & ENTER
Navigation buttons used to highlight menu
entries in the OSD.
Press ENTER to open or execute the
highlighted menu entry.
9EXIT
Exits the current OSD page and enters the
level above.
10 LENS SHIFT arrow buttons
Each of these buttons moves the lens in the
specied direction.
11 FOCUS plus and minus buttons
Used to move the focus in and out.
12 ZOOM plus and minus buttons
Used to zoom in and out.
POWER
INPUT AUTO
SYNC ASPECT CENTER
LENS PIC MUTE
1 2 3 4 5 6
7 8 9 10 11 12
Notes

page 7
Digital Projection E-Vision Laser 7500, 8500 & 10K Series
Installation and Quick-Start Guide
PROJECTOR OVERVIEW
Rev D August 2017
Projector indicators
TEMP. Off = no problem
Flashing red = temperature error
LIGHT Off = light is switched off
Flashing green = light is preparign to switch on
Flashing red (cycles of six ashes) = light module failure
On, red = light module has reached end of life
On, green = light is switched on
STATUS Off = no problem
Flashing red (continuously) = cover error
Flashing red (cycles of four ashes) = fan error
On, red = system error
POWER Off = the projector is switched off
Flashing green = the projector is warming up
Flashing amber = the projector is cooling down
On, red = STANDBY mode
On, green = the projector is switched on
Notes
POWERSTATU SLIGHTTEMP.

page 8
Digital Projection E-Vision Laser 7500, 8500 & 10K Series
Installation and Quick-Start Guide
REMOTE CONTROL
Rev D August 2017
Remote Control
1Power ON / OFF
Turns power on and off.
2Pic Mute ON / OFF
Shows and hides the projected image.
When OFF, the light source is completely switched off and the screen is black.
2OSD ON / OFF
Enable and disable screen timeout messages and control whether to show the OSD
during projection.
4MENU
Access the OSD. If the OSD is open, press this button to go back to the previous menu.
5Navigation (arrows and OK)
Navigate through the menus with the arrows, conrm your choice with OK.
In lens adjustment modes, the arrows are used to move, zoom or focus the lens. See 11
below.
In lens adjustment modes, or when the OSD is not showing, the OK button switches
between modes: Shift Adjustment and Zoom / Focus Adjustment.
6EXIT
Go up one level in the OSD. When the top level is reached, press to close the OSD.
7FREEZE
Freeze the current frame.
8DEFAULT
When editing a parameter, press this button to restore the default value.
9INFO
Access information about the projector.
10 RE-SYNC
Re-synchronise with the current input signal.
continues on next page...
Pic Mute
OFF ON
MENU
EXIT INFO
HDMI1
OK
OFF ON
ALT
LENS
FOCUS ZOOM
IN
OUT
IN
OUT
SHIFT
21 3
HDMI2 DVI
DISPLAYPORT HD-T 3GSDI
VGA COMP1 COMP2
BRI
TEST
CON GAMMA
R G B ALL
3D EYE PIP SWAP
456
7 8 9 0
ALT
ADDR
OSD
OFF ON
DEFAULT
FREEZE RE-SYNC
A B C D
USER PRESET
1
2
5
6
8
4
9
7
3
10
Notes
Remote control

page 9
Digital Projection E-Vision Laser 7500, 8500 & 10K Series
Installation and Quick-Start Guide
REMOTE CONTROL
Rev D August 2017
11 LENS adjustment
FOCUS IN / OUT: adjust focus.
SHIFT: press and hold this button, then use the Navigation arrow
buttons to move the lens.
ZOOM IN / OUT: adjust zoom.
12 USER PRESET A, B, C, D
Load user presets.
13 ALT
Press and hold this button to access alternative functions for all
buttons with a green label.
14 DVI / GAMMA / numeric input 3
Select the DVI input.
Use with ALT to switch to the next Gamma value:
...1.0, 1.8, 2.0, 2.2, 2.35, 2.5...
15 HDMI 2 / CON / numeric input 2
Select the HDMI 1 input.
Use with ALT to bring up the Contrast control, then adjust the value
with the LEFT and RIGHT arrow buttons.
16 HDMI 1 / BRI / numeric input 1
Select the HDMI 1 input.
Use with ALT to bring up the Brightness control, then adjust the
value with the LEFT and RIGHT arrow buttons.
17 TEST / SWAP / numeric input 0
Show a test pattern. Press again to show the next test pattern:
...Off, White, Black, Red, Green, Blue, CheckerBoard,
CrossHatch, V Burst, H Burst, ColorBar...
When PIP mode is on, use this button with ALT to swap the main and
sub images.
continues on next page...
Notes
Remote control
Pic Mute
OFF ON
MENU
EXIT INFO
HDMI1
OK
OFF ON
ALT
LENS
FOCUS ZOOM
IN
OUT
IN
OUT
SHIFT
21 3
HDMI2 DVI
DISPLAYPORT HD-T 3GSDI
VGA COMP1 COMP2
BRI
TEST
CON GAMMA
R G B ALL
3D EYE PIP SWAP
456
7 8 9 0
ALT
ADDR
OSD
OFF ON
DEFAULT
FREEZE RE-SYNC
A B C D
USER PRESET
13
11
12
14
15
16
17

page 10
Digital Projection E-Vision Laser 7500, 8500 & 10K Series
Installation and Quick-Start Guide
REMOTE CONTROL
Rev D August 2017
17 DISPLAYPORT / R / numeric input 4
Select DisplayPort input.
18 HD-T / G / numeric input 5
Select the HDBaseT input.
19 3GSDI / B / numeric input 6
Select the 3G-SDI input.
20 VGA / 3D / numeric input 7
Select the VGA input.
Use with ALT to toggle the 3D Format setting between Off and Auto.
21 COMP1 / EYE / numeric input 8
Select the Component 1 input.
Use with ALT to switch between left and right eye 3D dominance.
22 COMP2 / PIP / numeric input 9
Select the Component 2 input.
Use with ALT to switch on Picture In Picture (PIP) mode.
23 ADDR / ALL (with red indicator at the top)
Assign and unassign an IR remote address.
To assign an address:
1. Press and hold this button until the indicator starts ashing.
2. Release this button and while the indicator is still ashing, enter
a two-digit address using the numeric input buttons. The indicator
will ash three times quickly to conrm the change.
To unassign an address and return to the default address 00,
• Press and hold ALT and this button simultaneously until the
indicator ashes to conrm the change.
Notes
Remote control bottom
Pic Mute
OFF ON
MENU
EXIT INFO
HDMI1
OK
OFF ON
ALT
LENS
FOCUS ZOOM
IN
OUT
IN
OUT
SHIFT
21 3
HDMI2 DVI
DISPLAYPORT HD-T 3GSDI
VGA COMP1 COMP2
BRI
TEST
CON GAMMA
R G B ALL
3D EYE PIP SWAP
456
7 8 9 0
ALT
ADDR
OSD
OFF ON
DEFAULT
FREEZE RE-SYNC
A B C D
USER PRESET
23
18
19
17
20
21
22
Pic Mute
OFF ON
MENU
EXIT INFO
HDMI1
OK
OFF ON
ALT
LENS
FOCUS ZOOM
IN
OUT
IN
OUT
SHIFT
21 3
HDMI2 DVI
DISPLAYPORT HD-T 3GSDI
VGA COMP1 COMP2
BRI
TEST
CON GAMMA
R G B ALL
3D EYE PIP SWAP
456
7 8 9 0
ALT
ADDR
OSD
OFF ON
DEFAULT
FREEZE RE-SYNC
A B C D
USER PRESET
Remote control top

page 11
Digital Projection E-Vision Laser 7500, 8500 & 10K Series
Installation and Quick-Start Guide
REMOTE CONTROL
Rev D August 2017
Infrared reception
The projector has infrared sensors at the front and back.
The angle of acceptance is 40°. Make sure that the remote control is within the angle of
acceptance when trying to control the projector.
40°
40°
Infrared reception
Notes

page 12
Digital Projection E-Vision Laser 7500, 8500 & 10K Series
Installation and Quick-Start Guide
POSITIONING THE SCREEN AND PROJECTOR
Rev D August 2017
Positioning The Screen And Projector
1. Install the screen, ensuring that it is in the best position for viewing by your audience.
2. Mount the projector, ensuring that it is at a suitable distance from the screen for the image to ll the screen. Set the adjustable feet so that
the projector is level, and perpendicular to the screen.
The drawing below shows the positions of the feet for table mounting, and the xing holes for ceiling mounting.
1Four adjustable feet
2Six M4 holes for ceiling mount
The screws should not penetrate
more than 15 mm into the body of
the projector.
1
2
1
1
1
2
2
2
2
2
Notes
Always allow the projector
to cool for 5 minutes before
disconnecting the power or
moving the projector.
Ensure that there is at least 50
cm (19.7 in) of space between the
ventilation outlets and any wall,
and 30 cm (11.8 in) on all other
sides.
Do not stack more than 3
projectors.
