Digital Projection TITAN XG-500 User manual

TITAN XG-500
High Brightness Digital Video Projector
4:3 widescreen display
User Manual
106-615C

Digital Projection TITAN XG-500 User Manual
Declaration of Conformity
Directives covered by this Declaration
89/336/EEC Electromagnetic Compatibility Directive, amended by 92/31/EEC and 93/68/EEC.
73/23/EEC Low Voltage Equipment Directive, amended by 93/68/EEC.
Products covered by this Declaration
Large screen video projector type TITAN XG-500
Basis on which Conformity is being declared
The products identified above comply with the protection requirements of the above EU directives, and the
manufacturer has applied the following standards.
EN 55022:1998 - Limits and Methods of Measurement of Radio Disturbance Characteristics of Information
Technology Equipment.
EN 55024:1998 - Limits and Methods of Measurement of Immunity Characteristics of Information Technology
Equipment.
EN 55103:1997 - Product family Standard for Audio, Video, Audio-Visual and Entertainment Lighting Control
apparatus for Professional Use.
EN 60950:2000 - Specification for Safety of Information Technology Equipment, including Electrical Business
equipment.
The technical documentation required to demonstrate that the products meet the requirements of the Low Voltage
directive has been compiled by the signatory below and is available for inspection by the relevant enforcement
authorities. The CE mark was first applied in July 2006.
Signed:
Authority: D.J. Quinn, Product Development Director
Date: 28 July 2006
Attention!
The attention of the specifier, purchaser, installer, or user is drawn to special measures and limitations to use which
must be observed when these products are taken into service to maintain compliance with the above directives.
Details of these special measures are available on request, and are also contained in the product manuals.

Rev C March 2008 Page iii
Please read this user manual carefully before using the projector, and keep
the manual handy for future reference.
A serial number is located on the side of the projector. Record it here:
Symbols used in this guide
Warnings
ELECTRICAL WARNING: this symbol indicates that there is a danger of
electrical shock unless the instructions are closely followed.
WARNING: this symbol indicates that there is a danger of physical
injury to yourself and/or damage to the equipment unless the
instructions are closely followed.
NOTE: this symbol indicates that there is some important information that
you should read.
Trademarks
IBM is a registered trademark of International Business Machines Corporation.
Macintosh and PowerBook are registered trademarks of Apple Computer, Inc.
Other product and company names mentioned in this user’s manual may be the
trademarks of their respective holders.
Product revision
Because we at Digital Projection continually strive to improve our products, we
may change specifications and designs, and add new features without prior
notice. Projectors built prior to this revision of the User Manual may therefore not
include all the features described.
Manual revision
Date Description Revision
08/2006 Rev A
02/2007 Rev B
03/2008 Resolution menu, new rigging
frame, Connections update
Rev C
•
•
•
•
Important Information

Page iv Rev C March 2008
Important Information Digital Projection TITAN XG-500 User Manual
General precautions
Do not open the cabinet. There are no user serviceable parts inside.
Use only the power cable provided.
Ensure that the power outlet includes a Ground connection, as this
equipment MUST be earthed.
Take care to prevent small objects such as paper or wire from falling
into the projector. If this does happen, switch off immediately, and have
the objects removed by authorised service personnel.
Do not expose the projector to rain or moisture, and do not place any
liquids on top of the projector.
Unplug before cleaning, and use a damp, not wet, cloth.
Do not touch the power plug with wet hands.
Do not touch the power plug during a thunder storm.
Handle the power cable carefully and avoid sharp bends. Do not use a
damaged power cable.
There are no user-serviceable parts inside the lamp module. The whole
module should be replaced.
Take care when removing the lamp module.
NEVER touch the lamp or reflector.
Take care not to touch the glass surface of the lamp module. If you
do accidentally touch the glass, it should be cleaned before use. (see
section 5. Maintenance.)
Do not use the lamp for more than 1500 hours, as this may cause
serious lamp failure, damage the lamp module and cause extra cost on
replacement.
HID lamps produce high intensity light. Do not look directly at the light
coming from the lamp housing, or the lens, or allow items such as
magnifying lenses to be placed in the light path. This could result in
serious eye damage.
Do not touch the ventilation outlets, as they will become hot in use.
Do not cover or obstruct the ventilation outlets or inlets.
Do not cover the lens whilst the projector is switched on. This could
cause a fire
Always allow the projector to cool for 5 minutes before disconnecting
the power, moving the projector or changing the lamp.
Never use strong detergents or solvents such as alcohol or thinners to
clean the projector and lens.
Notes

Rev C March 2008 Page v
Digital Projection TITAN XG-500 User Manual Important Information
Installation precautions
Connect the LAN cable only to a computer LAN connection. Other
similar connectors may have a dangerously high voltage source.
The projector must be installed only by suitably qualified personnel, in
accordance with local building codes.
The projector should be installed as close to the power outlet as
possible.
The power connection should be easily accessible, so that it can be
disconnected in an emergency.
Ensure that there is at least 30cm (12in) of space between the
ventilation outlets and any wall, and 10cm (4in) on all other sides.
Do not install the projector close to anything that might be affected by
its operational heat, for instance, polystyrene ceiling tiles, curtains etc.
The projector weighs approximately 27 kg (50 lbs). Use safe handling
techniques when lifting the projector.
When stacking projectors, the stack MUST be vertical, to ensure that
the stresses are distributed to all frame couplings.
Before installation, make sure that the surface, ceiling or rigging that is
to support the projector is capable of supporting the combined weight
of the projector and lens (see specification for exact weights).
Separate backup safety chains or wires should always be used for each
projector.
Do not place heavy objects on top of the projector chassis. Only the
chassis corners and the rigging frame are capable of withstanding the
weight of another projector.
Do not stack more than 3 projectors.
Do not drop or jarr the projector.
Place the projector in a dry area away from sources of dust, moisture,
steam, smoke, sunlight or heat.
Do not tilt the projector more than ±12° from side to side when in use,
as this may cause serious lamp failure, damage the lamp module and
cause extra cost on replacement. The projector my be tilted forwards
and backwards as necessary.
Operation and configuration precautions
Do not make changes to the networking configuration unless you
understand what you are doing, or have taken advice from your
Network Manager. If you make a mistake, it is possible that you will lose
contact with the projector. Always double-check your settings before
pressing the APPLY button. Always keep a written note of the original
settings, and any changes you have made.
Software update should NOT be carried out except by, or with the
supervision of, Digital Projection Service personnel.
Notes
±12°
360°

Page vi Rev C March 2008
Important Information Digital Projection TITAN XG-500 User Manual
Compliance with international standards
Noise
GSGV Acoustic Noise Information Ordinance
The sound pressure level is less than 70 dB (A) according to ISO 3744 or ISO 7779.
RF Interference
FCC
The Federal Communications Commission does not allow any modifications or
changes to the unit EXCEPT those specified by Digital Projection in this manual.
Failure to comply with this government regulation could void your right to operate
this equipment.
This equipment has been tested and found to comply with the limits for a Class A
digital device, pursuant with Part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference when the equipment is
operated in a commercial environment. This equipment generates, uses, and can
radiate radio frequency energy and, if not installed and used in accordance with
the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area may cause harmful interference, in
which case the user will be responsible for correcting any interference.
This equipment contains an FCC approved RF transmitter module with FCC ID:
R68WIPORT.
European Waste Electrical and Electronic Equipment
(WEEE) Directive
Digital Projection Ltd is fully committed to minimising Waste Electrical and
Electronic Equipment. Our products are designed with reuse, recycling
and recovery of all components in mind. To this end, at end of life, your
projector may be returned to Digital Projection Ltd or its agent so that the
environmental impact can be minimised.
Notes

Rev C March 2008 Page vii
Digital Projection TITAN XG-500 User Manual Important Information
Digital Projection Contact details
Digital Projection Limited,
Greenside Way, Middleton, Manchester M24 1XX, UK.
Registered in England No. 2207264, Registered Office: as above
Tel [phone]
Fax [phone]
Email [email protected], [email protected]
Web Site www.digitalprojection.co.uk
Digital Projection Inc.
55 Chastain Road, Suite 115, Kennesaw, GA 30144. USA
Tel (USA) 770 420 1350
Fax (USA) 770 420 1360
Email [email protected]
Web Site www.digitalprojection.com
Notes

Page viii Rev C March 2008
Important Information Digital Projection TITAN XG-500 User Manual

Rev C March 2008 Page ix
continued
Titan XG-500 User Manual
Contents
Declaration of Conformity ....................................................................................................................ii
Important Information
Symbols used in this guide................................................................................................................. iii
Warnings............................................................................................................................................. iii
Trademarks......................................................................................................................................... iii
Product revision..................................................................................................................................... iii
Manual revision...................................................................................................................................... iii
General precautions..............................................................................................................................iv
Installation precautions ........................................................................................................................v
Operation and configuration precautions ........................................................................................v
Compliance with international standards........................................................................................vi
Noise..................................................................................................................................................vi
RF Interference....................................................................................................................................vi
European Waste Electrical and Electronic Equipment (WEEE) Directive ...................................................vi
Digital Projection Contact details..................................................................................................... vii
1. Introduction
What’s in the box?.............................................................................................................................. 1.2
Key features of the projector........................................................................................................... 1.3
Getting to know the projector.......................................................................................................... 1.4
Front panel, – lens and power............................................................................................................ 1.4
Rear panel – lamp and air filter........................................................................................................... 1.4
Side panel – connection and control ................................................................................................... 1.5

Page x Rev C March 2008
Table of Contents Digital Projection TITAN XG-500 User Manual
continued
2. Installation
Screen requirements ......................................................................................................................... 2.2
Aspect ratio...................................................................................................................................... 2.2
Positioning the screen and projector ................................................................................................... 2.5
Choosing a lens .................................................................................................................................. 2.6
Choosing a lens using the lens charts................................................................................................. 2.7
Choosing a lens by calculation ........................................................................................................... 2.9
Useful lens calculations.................................................................................................................. 2.10
Fitting the lens....................................................................................................................................2.11
Shifting the image............................................................................................................................. 2.12
Mounting the projector.................................................................................................................... 2.13
Chassis adjustment......................................................................................................................... 2.13
Fitting the optional rigging frame....................................................................................................... 2.13
Stacking projectors.......................................................................................................................... 2.15
Connecting the projector................................................................................................................ 2.16
Signal Inputs .................................................................................................................................. 2.16
Control connection examples ........................................................................................................... 2.17
Power connection ........................................................................................................................... 2.18
3. Getting Started
Switching the projector on............................................................................................................... 3.2
Selecting an input or test pattern ................................................................................................... 3.2
Input................................................................................................................................................ 3.2
Test pattern ...................................................................................................................................... 3.2
Adjusting the lens............................................................................................................................... 3.3
Focus .............................................................................................................................................. 3.3
Zoom............................................................................................................................................... 3.3
Shift................................................................................................................................................. 3.3
Adjusting the projected image ........................................................................................................ 3.4
Picture settings................................................................................................................................. 3.4
Geometry settings............................................................................................................................. 3.4
Switching the projector off............................................................................................................... 3.4

Rev C March 2008 Page xi
Digital Projection TITAN XG-500 User Manual Table of Contents
continued
4. Controlling the projector
Overview............................................................................................................................................... 4.4
Controlling the projector..................................................................................................................... 4.4
Input modes and settings................................................................................................................... 4.5
Indicators.............................................................................................................................................. 4.7
Input status indicators ....................................................................................................................... 4.7
The control panel................................................................................................................................ 4.8
Keypad layout................................................................................................................................... 4.8
Projector status indicators.................................................................................................................. 4.8
The remote control............................................................................................................................. 4.9
Layout ............................................................................................................................................. 4.9
Timeout............................................................................................................................................ 4.9
Using the control keys .................................................................................................................... 4.10
Power............................................................................................................................................ 4.10
Shutter........................................................................................................................................... 4.10
On-Screen-Display.......................................................................................................................... 4.10
Focus ............................................................................................................................................ 4.10
Zoom............................................................................................................................................. 4.10
Shift............................................................................................................................................... 4.10
Auto-detect input mode ....................................................................................................................4.11
Source information...........................................................................................................................4.11
Input...............................................................................................................................................4.11
Input Presets.................................................................................................................................. 4.12
Red, Green and Blue....................................................................................................................... 4.13
Test pattern .................................................................................................................................... 4.13
Picture settings............................................................................................................................... 4.13
Geometry settings........................................................................................................................... 4.13
Magnify and pan ............................................................................................................................. 4.14
On-screen-display size.................................................................................................................... 4.14
Remote control address................................................................................................................... 4.14
Remote control backlight ................................................................................................................. 4.14
Using the menus............................................................................................................................... 4.15
Navigating menus and submenus..................................................................................................... 4.15
Menu controls................................................................................................................................. 4.17
Input menu ......................................................................................................................................... 4.18
Input Source................................................................................................................................... 4.18
Presets .......................................................................................................................................... 4.19

Page xii Rev C March 2008
Table of Contents Digital Projection TITAN XG-500 User Manual
continued
Picture menu...................................................................................................................................... 4.21
Brightness...................................................................................................................................... 4.21
Contrast......................................................................................................................................... 4.21
Saturation ...................................................................................................................................... 4.21
Hue ............................................................................................................................................... 4.21
Gamma Correction.......................................................................................................................... 4.22
Parametric Gamma......................................................................................................................... 4.22
Phase............................................................................................................................................ 4.22
Aspect Ratio................................................................................................................................... 4.23
Sharpness...................................................................................................................................... 4.23
Geometry menu................................................................................................................................. 4.24
Horizontal Position.......................................................................................................................... 4.24
Vertical Position .............................................................................................................................. 4.24
Aspect Ratio................................................................................................................................... 4.24
User Horizontal Aspect Ratio ........................................................................................................... 4.25
User Vertical Aspect Ratio ............................................................................................................... 4.25
Keystone........................................................................................................................................ 4.25
Phase............................................................................................................................................ 4.25
Resolution...................................................................................................................................... 4.26
Blanking......................................................................................................................................... 4.27
Colour menu ...................................................................................................................................... 4.28
Colour Mode................................................................................................................................... 4.29
Colour Temperature ........................................................................................................................ 4.29
RGB Lift......................................................................................................................................... 4.29
RGB Gain ...................................................................................................................................... 4.29
Component Type ............................................................................................................................ 4.29
Trim............................................................................................................................................... 4.30
Setup menu........................................................................................................................................ 4.31
Projector ........................................................................................................................................ 4.32
Global Colourimetry ........................................................................................................................ 4.34
Lamp ............................................................................................................................................. 4.36
On Screen Display.......................................................................................................................... 4.38
Password....................................................................................................................................... 4.39
Communication............................................................................................................................... 4.40
Network ......................................................................................................................................... 4.41
Restore Defaults............................................................................................................................. 4.46
Information menu ............................................................................................................................. 4.47
Projector Information....................................................................................................................... 4.47
Source Information.......................................................................................................................... 4.47
Digital Projection Information ........................................................................................................... 4.48

Rev C March 2008 Page xiii
Digital Projection TITAN XG-500 User Manual Table of Contents
5. Userware
6. Maintenance
Changing the lamp module .............................................................................................................. 6.2
Changing the air filter........................................................................................................................ 6.3
Cleaning................................................................................................................................................ 6.4
Projector .......................................................................................................................................... 6.4
Lens ................................................................................................................................................ 6.4
Lamp module ................................................................................................................................... 6.4
7. Appendix
Troubleshooting.................................................................................................................................. 7.2
Specifications...................................................................................................................................... 7.4
Part numbers.................................................................................................................................... 7.4
Optical ............................................................................................................................................. 7.4
Electrical .......................................................................................................................................... 7.5
Physical ........................................................................................................................................... 7.5
Lens Data ........................................................................................................................................ 7.6
Dimensions .......................................................................................................................................... 7.8
Input modes supported..................................................................................................................... 7.9
Input connections............................................................................................................................. 7.10
1. RGB1 input................................................................................................................................. 7.10
2. RGB2 input................................................................................................................................. 7.10
3. DVI-D input..................................................................................................................................7.11
4. (not used in this projector)............................................................................................................ 7.12
5. Composite video input ................................................................................................................. 7.12
6. S-Video input.............................................................................................................................. 7.12
7. Component video input................................................................................................................ 7.12
Control connections ........................................................................................................................ 7.13
LAN connection .............................................................................................................................. 7.13
Serial control input .......................................................................................................................... 7.14
Remote communications protocol............................................................................................... 7.15
Introduction .................................................................................................................................... 7.15
Message Structure.......................................................................................................................... 7.15
Operation Command examples........................................................................................................ 7.18
Quick Reference chart..................................................................................................................... 7.23

Page xiv Rev C March 2008
Table of Contents Digital Projection TITAN XG-500 User Manual

Rev C March 2008 Page 1.1
1. Introduction
Contents
What’s in the box?.............................................................................................................................. 1.2
Key features of the projector........................................................................................................... 1.3
Getting to know the projector.......................................................................................................... 1.4
Front panel, – lens and power............................................................................................................ 1.4
Rear panel – lamp and air filter........................................................................................................... 1.4
Side panel – connection and control ................................................................................................... 1.5

Page 1.2 Rev C March 2008
1. Introduction Digital Projection TITAN XG-500 User Manual
What’s in the box?
Make sure your box contains everything listed. If any pieces are missing, contact
your dealer.
You should save the original box and packing materials, in case you ever need
to ship your Projector.
•
•
Notes
Lenses are optional. Order
lenses from your Digital
Projection dealer.
For more detailed information
about lenses, see Choosing a
lens, in section 2. Installation.
Only one power cable -
dependent on the destination
territory - will be supplied with
the projector.
Projector
(106-239)
Power cable 13A
North America
(102-165)
Power cable 10A
Europe
(102-163)
Important Information
(105-924B)
User manual on CD
(105-923C)
Remote control
(105-023)
Power cable 10A
United Kingdom
(102-180)
4x AAA batteries
(105-922)
Remote cable 5m
(102-162)

Rev C March 2008 Page 1.3
Digital Projection TITAN XG-500 User Manual 1. Introduction
Notes
Key features of the projector
Congratulations on your purchase of the Digital Projection Titan XG-500
projector.
Digital Projection International, Texas Instruments’ first DLP™ partner and the
original innovator of the 3-chip DLP™ projector, proudly introduces the Titan
XG. Incredibly bright, high resolution and high in contrast, the Titan XG offers a
radically new electronics configuration ideally suited for the staging and large-venue
permanent installation markets.
The Titan XG harnesses the power of the Texas Instruments’ 11024 x 768 pixel
HPO DMD’s™. Alongside the LIGHTNING and HIGHlite Pro, the Titan XG is to set
new standards for Staging and is destined to be the first choice of professionals
who stage prestigious events such as the Grammy® Awards and the Oscars®. With
a contrast of better than 1200:1 and awe-inspiring brightness of 4500 lumens, the
Titan XG is unmatched for applications as diverse as world class staged events,
commercial entertainment, major outdoor venues, large-scale simulation, gaming,
home theatre and houses of worship.
Key Features
High resolution, large venue projector
Applications: Large Screen; Fixed install and Rental
4,500 ANSI lumens ±20%
Contrast >1200:1 ±10%
1024 x 768 resolution
Precision mechanical design ensuring maximum amount of light from lamp
housing reaches optics, without any operator adjustment
750W single phase, 100-240VAC
Compact size, light weight - approximately 27 kg (50 lbs)
Motorised lens mount
Optional Rigging frame with Quick-lock stack system- 3 point pitch & roll
adjustment for accurate alignment
Ruggedised robust metal case
LAN & RS232 connection for network operation
Six selectable Digital and Analogue Video inputs for display of the latest as well
as legacy video standards.
DVI, RGBHV, Component, S-Video, Composite all as standard
Wi-ficonnection wireless remote control
IR/cable remote control for easy setup
LAN operation using control codes or Integrated Userware
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•
•

Page 1.4 Rev C March 2008
1. Introduction Digital Projection TITAN XG-500 User Manual
Getting to know the projector
Front panel, – lens and power
Notes
For more detailed information
about lenses, see
section 2. Installation
For information about how to
change the lamp or the filter,
see section 6. Maintenance.
Rear panel – lamp and air filter
Power
connection
Lens
Air outlet
Air inlet -
around lens
Front Infra-red window
(remote control)
Air filter
Lamp
compartment
Lamp
module
Screws x 3
Rear
door
Rear Infra-red window (remote control)

Rev C March 2008 Page 1.5
Digital Projection TITAN XG-500 User Manual 1. Introduction
Side panel – connection and control Notes
For information about how
to connect the projector, see
Connecting the projector in
section 2. Installation, and
Connections in section 7.
Appendix.
For information about how
to use the control panel, see
section 4. Controlling the
projector.
For information about how to
mount and stack projectors, see
section 2. Installation.
Input
connections
Control
connections
Control panel
Adjustable
foot

Page 1.6 Rev C March 2008
1. Introduction Digital Projection TITAN XG-500 User Manual
