VA200 2ND MONITOR ADAPTER
© 2001 Directed Electronics, Inc.
The VA200 is a video signal splitter. It
takes the MCB1000 zone output DIN
cable and splits the video and IR signal
so additional monitors can be added to
that output zone.
The master monitor will still have full IR
control of all MCB1000 programming
menus. The slave monitor has IR control
of its screen settings menus and basic
operations of the video source units. The
slave monitor will receive its audio input
from the audio RCA zone outputs. Other
audio output options include wireless
headphones (RFM100 and WHS100).
INSTALLATION
1. Connect the VA200 DIN cable to
the DIN output of the MCB1000.
2. Connect the VDC100 DIN-DIN
cable to the VA200 DIN out and
route it to the master monitor.
3. Connect the VDC200's video RCA
(YELLOW) to the video output RCA
of the VA200.
4. Connect the VDC200's IR plug to
the IR connector of the VA200.
5. Connect the VDC200's Audio RCA's
(RED and WHITE) to the RCA
audio outputs of the MCB1000.
6. Route the DIN plug end of the
VDC200 to the slave monitor.
