Directed Electronics VIPER 5701 User manual

© 2008 Directed Electronics, Vista, CA
Responder LE Model 5701
Security and Remote Start
Owner’s Guide

Limited lifetime consumer warranty
Directed Electronics. (“Directed”) promises to the original purchaser to repair or replace (at Directed’s
election) with a comparable reconditioned model any Directed unit (hereafter the “unit”), excluding with-
out limitation the siren, the remote transmitters, the associated sensors and accessories, which proves to
be defective in workmanship or material under reasonable use during the lifetime of the vehicle provided
the following conditions are met: the unit was purchased from an authorized Directed dealer, the unit
was professionally installed and serviced by an authorized Directed dealer; the unit will be professionally
reinstalled in the vehicle in which it was originally installed by an authorized Directed dealer; and the
unit is returned to Directed, shipping prepaid with a legible copy of the bill of sale or other dated proof of
purchase bearing the following information: consumer’s name, telephone number and address; the autho-
rized dealers name, telephone number and address; complete product description, including accessories;
the year, make and model of the vehicle; vehicle license number and vehicle identification number. All
components other than the unit, including without limitation the siren, the remote transmitters and the
associated sensors and accessories, carry a one-year warranty from the date of purchase of the same. ALL
PRODUCTS RECEIVED BY DIRECTED FOR WARRANTY REPAIR WITHOUT PROOF OF PURCHASE WILL BE DENIED.
This warranty is non-transferable and is automatically void if: the original purchaser has not completed the
warranty card and mailed it within ten (10) days from the date of purchase to the address listed on the
card; the unit’s date code or serial number is defaced, missing or altered; the unit has been modified or
used in a manner contrary to its intended purpose; the unit has been damaged by accident, unreason-
able use, neglect, improper service, installation or other causes not arising out of defects in materials or
construction. The warranty does not cover damage to the unit caused by installation or removal of the
unit. Directed, in its sole discretion, will determine what constitutes excessive damage and may refuse the
return of any unit with excessive damage.
TO THE MAXIMUM EXTENT ALLOWED BY LAW, ALL WARRANTIES, INCLUDING BUT NOT LIMITED TO EXPRESS
WARRANTY, IMPLIED WARRANTY, WARRANTY OF MERCHANTABILITY, FITNESS FOR PARTICULAR PURPOSE AND
WARRANTY OF NON-INFRINGEMENT OF INTELLECTUAL PROPERTY, ARE EXPRESSLY EXCLUDED; AND DIRECTED
NEITHER ASSUMES NOR AUTHORIZES ANY PERSON OR ENTITY TO ASSUME FOR IT ANY DUTY, OBLIGATION OR
LIABILITY IN CONNECTION WITH ITS PRODUCTS. DIRECTED DISCLAIMS AND HAS ABSOLUTELY NO LIABILITY
FOR ANY AND ALL ACTS OF THIRD PARTIES INCLUDING ITS AUTHORIZED DEALERS OR INSTALLERS. DIRECTED
SECURITY SYSTEMS, INCLUDING THIS UNIT, ARE DETERRENTS AGAINST POSSIBLE THEFT. DIRECTED IS NOT
OFFERING A GUARANTEE OR INSURANCE AGAINST VANDALISM, DAMAGE OR THEFT OF THE AUTOMOBILE, ITS
PARTS OR CONTENTS; AND HEREBY EXPRESSLY DISCLAIMS ANY LIABILITY WHATSOEVER, INCLUDING WITH-
OUT LIMITATION, LIABILITY FOR THEFT, DAMAGE AND/OR VANDALISM. THIS WARRANTY DOES NOT COVER
LABOR COSTS FOR MAINTENANCE, REMOVAL OR REINSTALLATION OF THE UNIT OR ANY CONSEQUENTIAL DAM-
AGES OF ANY KIND. IN THE EVENT OF A CLAIM OR A DISPUTE INVOLVING DIRECTED OR ITS SUBSIDIARY, THE
VENUE SHALL BE SAN DIEGO COUNTY IN THE STATE OF CALIFORNIA. CALIFORNIA STATE LAWS AND APPLI-

© 2008 Directed Electronics—all rights reserved iii
CABLE FEDERAL LAWS SHALL APPLY AND GOVERN THE DISPUTE. THE MAXIMUM RECOVERY UNDER ANY CLAIM
AGAINST DIRECTED SHALL BE STRICTLY LIMITED TO THE AUTHORIZED DIRECTED DEALER’S PURCHASE PRICE
OF THE UNIT. DIRECTED SHALL NOT BE RESPONSIBLE FOR ANY DAMAGES WHATSOEVER, INCLUDING BUT
NOT LIMITED TO, ANY CONSEQUENTIAL DAMAGES, INCIDENTAL DAMAGES, DAMAGE TO VEHICLE, DAMAGES
FOR THE LOSS OF TIME, LOSS OF EARNINGS, COMMERCIAL LOSS, LOSS OF ECONOMIC OPPORTUNITY AND THE
LIKE. NOTWITHSTANDING THE ABOVE, THE MANUFACTURER DOES OFFER A LIMITED WARRANTY TO REPLACE
OR REPAIR THE CONTROL MODULE SUBJECT TO THE CONDITIONS AS DESCRIBED HEREIN. THIS WARRANTY IS
VOID IF THE UNIT HAS NOT BEEN PURCHASED FROM DIRECTED, OR AN AUTHORIZED DIRECTED DEALER, OR
IF THE UNIT HAS BEEN DAMAGED BY ACCIDENT, UNREASONABLE USE, NEGLIGENCE, ACTS OF GOD, NEGLECT,
IMPROPER SERVICE, OR OTHER CAUSES NOT ARISING OUT OF DEFECT IN MATERIALS OR CONSTRUCTION.
Some states do not allow limitations on how long an implied warranty will last or the exclusion or limita-
tion of incidental or consequential damages. This warranty gives you specific legal rights and you may also
have other rights that vary from State to State.
This warranty is only valid for sale of product(s) within the United States of America. Product(s) sold
outside of the United States of America are sold “AS-IS” and shall have NO WARRANTY, express or implied.
This product may be covered by a Guaranteed Protection Plan (“GPP”). See your authorized Directed dealer
for details of the plan or call Directed Customer Service at 1-800-876-0800.
Make sure you have all of the following information from your authorized Directed dealer:
A clear copy of the sales receipt, showing the following:
o Date of purchase
o Your full name and address
o Authorized dealer’s company name and address
o Type of alarm installed
o Year, make, model and color of the automobile
o Automobile license number
o Vehicle identification number
o All security options installed on automobile
o Installation receipts
920-0003 06-06

© 2008 Directed Electronics—all rights reserved
iv
Government Regulations
This device complies with Part 15 of FCC rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interfer-
ence, and (2) This device must accept any interference received, including
interference that may cause undesirable operation.
This equipment has been tested and found to comply with the limits for a
class B digital device, pursuant to Part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in
a residential installation. This equipment generates and can radiate radio
frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communica-
tions. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to
radio or television, which can be determined by turning the equipment OFF
and ON, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antenna.
• Increase the separation between the equipment and receiver.
• Connect the equipment into an outlet on a circuit different from that to
which the receiver is connected.
• Consult the dealer or an experienced radio / TV technician for help.
This device complies with the Industry Canada Radio Standards Specifica-
tion RSS 210. Its use is authorized only on a no-interference, no-protection
basis; in other words, this device must not be used if it is determined that
it causes harmful interference to services authorized by IC. In addition, the
user of this device must accept any radio interference that may be received,
even if this interference could affect the operation of the device.
Warning:
Changes or modifications not expressly approved by the party responsible
for compliance could void the user’s authority to operate this device.

© 2008 Directed Electronics—all rights reserved v
Table of contents
Limited lifetime consumer warranty . . . . . . . . . . . . . . . . . . . . . ii
GovernmentRegulations..............................iv
Whatisincluded ...................................1
Importantinformation...............................1
Yourwarranty ..................................2
Replacementremotes .............................2
Caution.......................................2
ResponderLE2-Way.................................3
ResponderLE1-way.................................4
Transmitter configuration . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Systemmaintenance ............................ 10
Lowbatteryindicator............................ 10
BatteryReplacement............................. 10
Remote control programming . . . . . . . . . . . . . . . . . . . . . . . 11
Multi-car control capability . . . . . . . . . . . . . . . . . . . . . . . . 13
Adjusting the onboard shock sensor . . . . . . . . . . . . . . . . . . 13
What’sNew......................................16
Usingthesystem..................................19
Warning!Safetyfirst............................. 19
Armingthesystem.............................. 21
While the system is armed. . . . . . . . . . . . . . . . . . . . . . . . . 22
ModifiedArmingModes........................... 24
DisarmingtheSystem............................ 25
Systemoverride................................ 26
Usingtheremotestart..............................27
Before using your Remote Start . . . . . . . . . . . . . . . . . . . . . 27
Remote starting your vehicle . . . . . . . . . . . . . . . . . . . . . . . 27

© 2008 Directed Electronics—all rights reserved
vi
Pointstoremember ............................. 28
RuntimeCheck................................. 28
Manualtransmission............................. 29
Timermode................................... 30
Turbotimermode............................... 30
Cabintemperature .............................. 31
Safetyfeatures ...................................33
Starter anti-grind circuitry. . . . . . . . . . . . . . . . . . . . . . . . . 33
Disabling the remote start system. . . . . . . . . . . . . . . . . . . . 33
Diagnostics......................................34
Arming ..................................... 34
Disarming ................................... 35
Systemstatuschirps ............................ 35
Tableofzones................................. 36
Interpreting zone diagnostics. . . . . . . . . . . . . . . . . . . . . . . 36
Nuisance prevention® circuitry . . . . . . . . . . . . . . . . . . . . . . 37
Ownerrecognition .................................38
Rapidresumelogic.................................38
Powersavermode..................................38
System...................................... 38
2-wayremote.................................. 39
Programmingoptions...............................40
Security & convenience expansions . . . . . . . . . . . . . . . . . . . . . 42
GlossaryofTerms..................................44
QuickReferenceGuide..............................47

© 2008 Directed Electronics—all rights reserved 1
What is included
■ The control module with Stinger™DoubleGuard®two-stage shock
sensor
■Control center (installed out of sight on your vehicle) with
integrated status LED and Valet override switch
■ One five-button/2-way Supercode Responder LE Remote Control
■One five-button/ 1-way Supercode remote
■ Revenger™Soft Chirp™six-tone siren
■ A shut-down toggle switch
■Window decals
■ Your warranty registration
Important information
Congratulations on the purchase of your state-of-the-art remote
start and alarm system. Due to the complexity of this system, it
must be installed by an authorized dealer only. Installation of this
product by anyone other than an authorized dealer voids the war-
ranty. All dealers are provided with a preprinted dealer certificate
to verify authorization.
By carefully reading this Owner’s Guide prior to using your system,
you will maximize the use of this system and its features. You can
print additional or replacement copies of this manual by accessing
our web site at www.directed.com.
��

© 2008 Directed Electronics—all rights reserved
2
Your warranty
Your warranty registration must be completely filled out and re-
turned within 10 days of purchase. Your product warranty will not
be validated if your warranty registration is not returned. Make sure
you receive the warranty registration from your dealer. It is also
necessary to keep your proof of purchase, which reflects that the
product was installed by an authorized dealer.
Replacement remotes
Your system comes with one Responder LE remote control (P/N
7251V) and one companion remote control (P/N 7152V). If ad-
ditional remotes are desired, please see your authorized dealer or
visit www.directedstore.com to order.
Caution
This product is designed for fuel injected vehicles only. Use of this
product in a standard transmission vehicle must be in strict
accordance with this guide.

© 2008 Directed Electronics—all rights reserved 3
Responder LE 2-Way
1
3
4
5
6
7
2
A U X
Feature Description
1Transmit indicator
2LED indicators Blinks indicate function confirmation
3Lock button Press for one second to arm.
4Unlock button Press for one second to disarm.
5Remote start
button
Press for one second to activate remote
start.
6Auxiliary
button
Press and hold for 1.5 second to activate
optional trunk release.
7Function
button
Allows access to programming and modi-
fies operation of the other buttons.
82 WAY Label Back of remote has label to identify the
remote as 2-way or 1-way.
9Battery Door Remove to access batteries when neces-
sary. For more details, see p.10
Note: If Keypad Lock is On, press and then press
1
3
4
5
6
2
A U X
to exit.
8
9

© 2008 Directed Electronics—all rights reserved
4
Responder LE 1-way
Feature Description
1Transmit indicator
2Lock button Press for one second to arm.
3Unlock button Press for one second to disarm.
4Remote start
button
Press for one second to activate remote
start.
5Auxiliary
button
Press and hold for 1.5 second to activate
trunk release.
6Function
button
Allows access to programming and
modifies operation of the other buttons.
71 WAY Label Back of remote has label to identify the
remote as 2-way or 1-way
8Battery Door Remove to access batteries when neces-
sary. For more details, see p.10
Note: If Keypad Lock is On, press and then press
1
3
4
5
6
2
A U X
to exit.
1
3
4
5
6
2
A U X
8
7

© 2008 Directed Electronics—all rights reserved 5
Transmitter configuration
Level
Button
x 0 x 1 x 2 x 3 x 4
LOCK
ARM SILENT
ARM
SENSOR
BYPASS
ARMED
(SILENT
SENSOR)
ARMED
(SILENT
TRIGGER)
UNLOCK
DISARM SILENT
DISARM VALET MODE CAR FINDER —
REMOTE START
REMOTE
START
RUNTIME
RESET TIMER MODE SMART START REAR DEFOGGER
AUX
TRUNK
RELEASE AUX 1 AUX 2 AUX 3 —
FUNCTION
FUNCTION
SHIFT
CABIN
TEMPERATURE
REQUEST
(2-way Only)
ARM STATUS
(2-way Only)
RUNTIME
CHECK
(2-way Only)
LAST
TRIGGER
REQUEST
(2-way Only)
REMOTE CONTROL FUNCTIONS TABLE
Note: button must be pressed and finally held to access state.
Button Command Confirmation Feedback
(2-way remote only)
Notes
Arm
Press one time to Arm Lock LED blink for one
second with 1 Beep and
siren tone
Press/hold for 1.5 seconds
to Arm the system and then
activate the Panic output
1
3
4
5
6
2
A U X
Disarm
Press one time to
Disarm
Unlock LED blink for one
second with 2 Beeps
Remote
Start
Press one time to acti-
vate Remote Start
Remote start LED blinks
for 3 seconds, Remote
Start tones.
A U X
AUX
Press and hold for 1.5
seconds to activate the
Trunk Release.
The AUX LED comes on
for 3 seconds, and AUX
activation tone sounds.
This is an optional
feature. See your sales
rep/installer for details.
Function
Shift
Press 1 to 4 times.
( See Function shift
table.)
LED indicators turn on
(according to the feature
command.)
Each Press then release,
shifts the function of the
command button.
Pressing more than one button simultaneously generates an Error tone and the F-Shift
LED turns ON.

© 2008 Directed Electronics—all rights reserved
6
Feature Command Confirmation
Feedback
Notes
Silent Arm
Press one- time
and then press .
Arm/Lock LED
on, no audio
Arms the system without
chirps
Silent Disarm
Press one- time
and then press
1
3
4
5
6
2
A U X
.
Disarm/Lock
LED on, no
audio
Disarms the system without
chirps
Runtime
reset Press one-time
and then .
Remote start
ON tones.
Re-starts the remote start
runtime counter if remote start
is active. Note: If remote
start is not active, the 2-WAY
remote will respond with error
tone.
Aux 1
Press one time
and then press
A U X
.
The AUX LED
comes on
for 3 seconds,
and AUX
activation tone
sounds.
This is an optional
feature. See your sales rep/in-
staller for details.
Cabin
temperature
Press one time,
then Hold for 1.5
seconds.
Multiple LEDs
blink, and 1
beep
Cabin temperature is displayed
on the remote. LED lights
up to indicate a range. (See
page 30.)
Sensor
Bypass Press two-
times and then .
Arm/Lock LED
on, 1 beep
Available when armed only:
bypasses warn triggers. Send
again to bypass Warn & Full
Trigger; Send again to turn
bypass off and monitor sensors
normally. For more informa-
tion, see Modified Arming
Modes on page 24

© 2008 Directed Electronics—all rights reserved 7
Feature Command Confirmation
Feedback
Notes
Valet Mode
Press two-
times and then
1
3
4
5
6
2
A U X
.
UnLock LED on
and beeps 1 or
2 times
To enter or exit Valet mode,
even if Armed.
When entering Valet Mode the
unlock LED blinks, and the
remote beeps one time. When
exiting Valet Mode the unlock
LED blinks and the remote
beeps two-times.
Timer mode
Press two-
times and then
.
Remote start
LED on.
Enables or disables the remote
start timer mode.
Aux 2
Press two times
and then press
A U X
.
The AUX LED
comes on
for 3 seconds,
and AUX
activation tone
sounds.
This is an optional
feature. See your sales rep/in-
staller for details.
Armed status
Press two-
times and then
Hold for 1.5
seconds.
If system is
Armed:
Lock LED blink
for one
second with 1
Beep
If system is
Disarmed:
Unlock LED
blink for one
second with 2
beeps
Replays last Arm /Disarm
status message received.

© 2008 Directed Electronics—all rights reserved
8
Feature Command Confirmation
Feedback
Notes
Armed
(Silent
Sensor mode)
Press three-
times and then .
LED on, 1 beep
& 3 error tone
Arms the system; sensor Full
Trigger will ONLY page the
remote and will not activate
the siren/lights. Wired inputs
will page and activate the
siren/lights.
Car Finder
Press three-
times and then
1
3
4
5
6
2
A U X
.
On Remote
Control:
Unlock LED on
with 1 short
beep
On Vehicle:
1 long siren
chirp and park-
ing lights flash
10 times.
Arm/Disarm cancels the light
flashes.
Smart Start
Press three-
times and then
press .
Remote Start
LED on, with 1
(for enable) or
2 (For disable)
beeps
Enables or disables the Smart-
Start feature.
Aux 3
Press three
times and then
press
A U X
.
The AUX LED
comes on
for 3 seconds,
and AUX
activation tone
sounds.
This is an optional
feature. See your sales rep/in-
staller for details
Runtime
check Press three-
times, and then
Hold for 1.5
seconds.
Remote Start
ON tones.
Runtime remaining is displayed
on the remote. (See page 28).

© 2008 Directed Electronics—all rights reserved 9
Feature Command Confirmation
Feedback
Notes
Armed
(Silent
Trigger
mode)
Press four-
times and then .
Lock LED on, 1
beep & 4 error
tone
Arms the system; sensor and
hardwire Full Triggers will ONLY
page the remote and will not
activate the siren/lights. For
more details see Silent Mode 2
section on page 25.
Rear
Defogger Press four
times, and then
. (Only after
remote start is
on.)
Remote start
LED ON, 1
beep.
Automatically turns on during
remote start.
Last Trigger
Press four-
times and then
hold for 1.5
seconds.
Replays the
last trigger
message
received.
Trigger refers to the remote
tones and LED pattern gener-
ated by the last alarm trigger
event.
Out of Range Notification
If a command is issued from the remote, but the remote is beyond the
range of the vehicle to receive the command, the remote will respond
with an Out of Range notification. If this occurs, the remote will Blink
rapidly the transmit indicator, turn on the F indicator and play the
error tone.
Since conditions will vary in different areas (ie: Weather, RF interfer-
ence, etc) range may be affected and require you to be closer to the
vehicle for successful transmission.

© 2008 Directed Electronics—all rights reserved
10
System maintenance
The system requires no specific maintenance. Your remotes are pow-
ered by small coin cell lightweight 3-volt lithium batteries that will
last approximately one year under normal use. The 2-way remote
uses two CR2016 cell batteries and the 1-way remote uses one
CR2032 cell battery. When the battery begins to weaken, the oper-
ating range will be reduced.
Low battery indicator
When the batteries are low on the 2-way remote it will emit two
groups of beeps, the LED will flash, and the alarm will emit an
additional chirp to let you know its time to change the battery.
When the battery is low on the 1-way remote, the remote responds
the same, but without the LED flash.
Note: The Arm/Disarm chirps should be programmed ON for the
alarm to emit any additional chirps during disarm. Ask your
authorized dealer if you have any questions.
Battery Replacement
Slide the door up to expose the battery beneath the holder. Remove
the expired battery. Place the new battery into the remote control.
When power is returned the remote control is ready for use.

© 2008 Directed Electronics—all rights reserved 11
Remote control programming
The Responder LE 2 way remote control has menus for programming the
remote to the system control module including adjusting the control
module onboard shock sensor, and for configuring the remote control
user features.
To program the remote user features:
Press and hold the button for 12 seconds: (at 3 seconds ignore
the Car number indicator.)
The remote emits one long beep, and the Transmit LED turns on.
This indicates the Main menu.
Press and hold the
1
3
4
5
6
2
A U X
button for 1.5 seconds:
The remote beeps two-times, and the Transmit LED blinks
two-times and stays on. You are now in the Remote Configuration
menu.
The Arm, Disarm, Remote Start & Aux LEDs will turn ON, and/or
blink to indicate the current remote feature configuration. When
the LED is ON, the feature is ON.
To configure the remote control features press and release the
command button. The LED next to the button will turn On then OFF.
The remote beeps to indicate the feature configuration.
Button: Auto-Button Lock.
When Arm LED is OFF, buttons will not lock.
LED ON: The buttons automatically lock 60 seconds after the last
button operation to avoid accidental Command operations. When
locked, if any command button is pressed the remote will emit an error
output.
If button lock is ON, press , and then
1
3
4
5
6
2
A U X
buttons.
1.
2.
3.

© 2008 Directed Electronics—all rights reserved
12
1
3
4
5
6
2
A U X
button: Remote Beeps
Disarm LED OFF: The remote will not emit beeps except when pro-
gramming.
Disarm LED ON: The remote will emit beeps normally.
Disarm LED blinking: The remote will emit beeps only for alarm
trigger messages from the alarm system.
button: Runtime Low Alert feature
Note: This feature is not available on the 1-way remote.
Remote Start LED OFF: The remote will ignore Runtime Low Alert
messages.
Remote Start LED ON: The remote will emit feedback output for
Runtime Low Alert messages.
These messages will be automatically sent while Remote Start is ON to
alert you when the runtime remaining is at 3 minutes, and again at 1
minute before shut down.
Note: This feature is not available on the 1-way remote
A U X
button: Page mode/Power saver
Note: This feature is not available on the 1-way remote.
Aux LED OFF: The remote will not wake up and listen for messages
from the system to extend battery life. Note: This means the remote
will not receive alarm trigger pages.
Aux LED ON: the remote will wake up to listen for messages from the
system
Aux LED blinking: Power saver mode (see note below)
Note: Power saver automatically turns off the remote pager if a but-
ton on the remote has not been pressed for more than 72 hours and
will be restored after any button on the remote is pressed.
▀
▀
▀
▀
▀
▀
▀
▀

© 2008 Directed Electronics—all rights reserved 13
Multi-car control capability
You can operate the Responder LE 2-way remote control system for two
cars, with full command capability for both vehicles.
While holding a command button and transmitting, the Amber LED at
the top of the remote control will blink in groups to indicate which Car
is being controlled.
Car 1: 1 blink
Car 2: 2 blinks
To change the Car to be operated:
Press/hold the button for 3 seconds or until the remote beeps and
the and/or
1
3
4
5
6
2
A U X
LEDs turn on. This will indicate which car the remote
currently operates.
Car 1: 1 beep and Arm LED on
Car 2: 2 beeps and Arm & Disarm LEDs on
Change Car: While the LEDs are on Press and release the button. The
LEDs will change to indicate the car that can be operated. Once the car
number is selected you can press any command button to operate the
system. The selected car remains selected until the setting is changed.
Adjusting the onboard shock sensor
The new Responder LE system has an onboard shock sensor that is
remote adjustable. Adjusting the onboard sensor can be performed
by an authorized dealer (recommended) or by a programmed remote
transmitter.
Transmitter adjustment:
Disarm the unit and exit Valet Mode if ON. Turn the ignition off and
close all entry points (door, hood, trunk).
Use the following steps to put the control module into sensor
▀
▀
▀
▀

© 2008 Directed Electronics—all rights reserved
14
adjust mode:
Press/hold the button of the remote control for 8 seconds or
until the Amber LED turns on and you hear one long beep.
Press/hold the button 1.5 seconds or until the amber led flashes
once:
The control module will emit one long chirp, enter adjust mode, and
send the current level of information back to the transmitter. The
remote will beep once and the button LEDs will turn on to indicate the
current level.
Press the Arm, Disarm, or Remote Start buttons to adjust the sensor
level.
Arm button: Pressing the button will increase the sensitivity one
level. The siren chirps twice, the remote beeps twice and the LEDs
increase in level.
Disarm button: Pressing the
1
3
4
5
6
2
A U X
button will decrease the sensitivity
one level. The siren chirps once, the remote beeps once and the LEDs
decrease in level.
Remote Start button: Pressing the button will reset to default
level 7. The siren chirp three times, the remote beeps three times and
the LEDs reset.
To exit the adjust shock sensor mode from the remote control:
Press the button. The control module is exited.
To exit the adjust shock sensor mode from the control module:
Open an entry point or turn on the ignition, the control module will
emit one long chirp and tell the remote to exit adjust mode.
To exit programming:
▀
▀
▀
▀
