SSttaannddaarrddCCoonnffiigguurraattiioonn
controls the AArrmm//PPaanniiccOONN//PPaanniiccOOFFFFfunction.
controls the DDiissaarrmmfunction.
controls SSiilleennttMMooddee™™and an AAuuxxiilliiaarryyOOuuttppuutt.
controls RReemmootteeSSttaarrtt.
+controls TTiimmeerrmode.
+controls TTuurrbboo//SShhoorrttRRuunn.
+controls CChhaannnneell44output.
++ controls RReeaarrDDeeffrroosstteerr.

33
©2005 Directed Electronics—all rights reserved
WWhhaattiissIInncclluuddeedd
■The control module
■An HX receiver/antenna
■Two four-button transmitters
■The red status LED indicator light
■A push-button Valet button
■Your warranty registration
■A shut-down toggle switch
IImmppoorrttaannttIInnffoorrmmaattiioonn
Congratulations on the purchase of your remote start keyless entry
system. Due to the complexity of this system, it must be installed
by an authorized dealer only. Installation of this product by any-
one other than an authorized dealer voids the warranty. All deal-
ers are provided with a preprinted dealer certificate to verify that
they are authorized.
By carefully reading this Owner's Guide prior to using your system,
you will maximize the use of this system and its features.
You can print additional or replacement copies of this manual by
accessing the Directed Electronics internet website at
www.directed.com .

44©2005 Directed Electronics—all rights reserved
The system requires no specific maintenance. Your remote is powered
by a small, lightweight 3-volt lithium battery that will last approx-
imately one year under normal use. When the battery begins to weaken,
operating range will be reduced and the LED on the remote will dim.
Your warranty registration must be completely filled out and
returned within 10 days of purchase. Your product warranty
will not be validated if your warranty registration is not returned.
Make sure you receive the warranty registration from your dealer.
It is also necessary to keep your proof of purchase, which reflects
that the product was installed by an authorized dealer.
This device complies with Part 15 of FCC rules. Operation is subject
to the following conditions: (1) This device may not cause harmful
interference, and (2) This device must accept any interference re-
ceived, including interference that may cause undesired operation.
Changes or modifications not expressly approved by the party responsible
for compliance could void the user's authority to operate this device.
This product is designed for fuel injected, automatic transmission
vehicles only. Use of this product in a standard transmission vehi-
cle is dangerous and contrary to the product's intended use.
CCaauuttiioonn
FFCCCC//IIDDNNoottiiccee
YYoouurrWWaarrrraannttyy
SSyysstteemmMMaaiinntteennaannccee

55
©2005 Directed Electronics—all rights reserved
TTrraannssmmiitttteerrFFuunnccttiioonnss
The receiver uses a computer-based learn routine to learn the
transmitter buttons. This makes it possible to assign any specific
transmitter button, or combination of buttons, to any receiver
function. The transmitter initially comes programmed with the
Standard Configuration, but may also be customized by an autho-
rized dealer. The transmitter buttons indicated in all of the
instructions in this manual correspond to a Standard Configuration
transmitter.
BBuuttttoonn
The arming and panic functions are controlled by pressing on
the transmitter for one second.
BBuuttttoonn
The disarm function is controlled by pressing on the trans-
mitter for one second.
BBuuttttoonn
Silent Mode™and an optional auxiliary function are controlled
by pressing . Silent Mode works by pressing for less
than one second. An optional auxiliary function, such as
trunk release, is controlled by pressing and holding for
1.5 seconds.
SSttaannddaarrddCCoonnffiigguurraattiioonn

66©2005 Directed Electronics—all rights reserved
BBuuttttoonn
The remote start function of your system is controlled by pressing
this button twice within 3 seconds.
and Buttons
An optional auxiliary convenience or expansion function that you
have added to your system can be activated by pressing these but-
tons simultaneously.
The auxiliary output controls __________________________.
BBuuttttoonnss++
When simultaneously pressed these buttons control the rear win-
dow defogger during remote starting.
UUssiinnggYYoouurrSSyysstteemm
The following safety warnings must be observed at all times:
■Due to the complexity of this system, installation of this
product must only be performed by an authorized Directed
Electronics dealer.
■When properly installed, this system can start the vehicle via
a command signal from the remote control transmitter.
Therefore, never operate the system in an enclosed area or
WWaarrnniinngg!!SSaaffeettyyFFiirrsstt

77
©2005 Directed Electronics—all rights reserved
partially enclosed area without ventilation (such as a garage).
When parking in an enclosed or partially enclosed area or
when having the vehicle serviced, the remote start system
must be disabled using the installed toggle switch. It is the
user's sole responsibility to properly handle and keep out of
reach from children all remote control transmitters to assure that
the system does not unintentionally remote start the vehicle.
TTHHEEUUSSEERRMMUUSSTTIINNSSTTAALLLLAACCAARRBBOONNMMOONNOOXXIIDDEEDDEETTEECCTTOORRIINN
OORRAABBOOUUTTTTHHEELLIIVVIINNGGAARREEAAAADDJJAACCEENNTTTTOOTTHHEEVVEEHHIIC
CLLEE..AALLLL
DDOOOORRSSLLEEAADDIINNGGFFRROOMMAADDJJAACCEENNTTLLIIVVIINNGGAARREEAASSTTOOTTHHEE
EENNCCLLOOSSEEDDOORRPPAARRTTIIAALLLLYYEENNCCLLOOSSEEDDVVEEHHIICCLLEESSTTOORRA
AGGEEAARREEAA
MMUUSSTTAATTAALLLLTTIIMMEESSRREEMMAAIINNCCLLOOSSEEDD..These precautions are
the sole responsibility of the user.
■Use of this product in a manner contrary to its intended mode
of operation may result in property damage, personal injury,
or death. (1) Never remotely start the vehicle with the vehi-
cle in gear, and (2) Never remotely start the vehicle with the
keys in the ignition. The user must also have the neutral safe-
ty feature of the vehicle periodically checked, wherein the
vehicle must not remotely start while the car is in gear. This
testing should be performed by an authorized Directed
Electronics dealer in accordance with the Safety Check out-
lined in the product installation guide. If the vehicle starts in
gear, cease remote start operation immediately and consult
with the authorized Directed Electronics dealer to fix the
problem.
■After the remote start module has been installed, contact your
authorized dealer to have him or her test the remote start

88©2005 Directed Electronics—all rights reserved
module by performing the Safety Check outlined in the prod-
uct installation guide. If the vehicle starts when performing
the Neutral Safety Shutdown Circuit test, the remote start unit
has not been properly installed. The remote start module must
be removed or the installer must properly reinstall the remote
start system so that the vehicle does not start in gear. All
installations must be performed by an authorized Directed
Electronics dealer. OOPPEERRAATTIIOONNOOFFTTHHEERREEMMOOTTEESSTTAARRTTMMOODDUULLEE
IIFFTTHHEEVVEEHHIICCLLEESSTTAARRTTSSIINNGGEEAARRIISSCCOONNTTRRAARRYYTTOOIITTSSIINNTTEENNDD--
EEDDM
MOODDEEOOFFOOPPEERRAATTIIOONN..OOPPEERRAATTIINNGGTTHHEERREEMMOOTTEESSTTAARRTTSSYYSS--
TTEEMMUUNNDDEERRTTHHEESSEECCOONNDDIITTIIOONNSSMMAAYYRREESSUULLTTIINNPPRROOPPEERRTTYY
D
DAAMMAAGGEEOORRPPEERRSSOONNAALLIINNJJUURRYY..YYOOUUMMUUSSTTIIMMMMEEDDIIAATTEELLYY
CCEEAASSEETTHHEEUUSSEEOOFFTTHHEEUUNNIITTAANNDDSSEEEEKKTTHHEEAASSSSIISSTTAANNCCEEOOFF
AANN
AAUUTTHHOORRIIZZEEDDDDIIRREECCTTEEDDEELLEECCTTRROONNIICCSSDDEEAALLEERRTTOORREEPPAAIIRROORR
DDIISSCCOONNNNEECCTTTTHHEEIINNSSTTAALLLLEEDDRREEMMOOTTEESSTTAARRTTMMOODDUULLEE.
.DDIIRREECCTT--
EEDDEELLEECCTTRROONNIICCSSWWIILLLLNNOOTTBBEEHHEELLDDRREESSPPOONNSSIIBBLLEEOORRPPAAYYFFOORR
IINNSSTTAALLLLAATTIIOONNOORRRREEIINNSSTTAALLLLAATTIIOONNCCOOSSTTS
S..
Pressing for one second arms the system by activating the
starter kill and locking the doors (if the door locks are connected).
The horn will honk (if connected) and the parking lights will flash
once to confirm arming of the system. While the system is armed,
the status LED will flash once per second. The Failsafe®Starter Kill
(if installed) will also prevent the vehicle’s starter from cranking.
The system can also be programmed to arm the optional Failsafe®
Starter Kill automatically (called Passive Mode). If the system has
AArrmmiinngg

99
©2005 Directed Electronics—all rights reserved
been programmed for Passive Mode, the Failsafe®Starter Kill will
automatically activate 30 seconds after the ignition has been
turned off. After the ignition has been turned off, the status LED
will flash rapidly to indicate that the system is in Passive Mode.
If Passive Mode has been programmed on, then it is also possible
to program the system for Passive Locking. With Passive Locking,
the vehicle doors lock automatically at the same time that the Failsafe®
Starter Kill is activated. If Passive Locking is programmed on, care
must be taken to prevent the keys from being locked in the vehicle.
NNOOTTEE::For Passive Mode to be effective, the Failsafe®Starter Kill relay
must be installed.
Pressing for one second disarms the system and unlocks the
doors (if connected). The horn will honk twice (if connected) and
the parking lights will flash twice to confirm disarming of the sys-
tem. The optional Failsafe®Starter Kill will be deactivated. The sta-
tus LED will turn off, unless the system is programmed for Passive
Mode. In Passive Mode, the status LED will flash rapidly when the
system is disarmed. This indicates that the system will re-engage
the starter kill and re-lock the doors (if Passive Locking has been
programmed) in 30 seconds unless the ignition is turned on.
DDiissaarrmmiinngg

1100©2005 Directed Electronics—all rights reserved
If your remote transmitter is lost or damaged, you can manually
override the starter kill. To do this, you must have the vehicle's
ignition key and know where the Valet button is located. Be sure
to check with the installer for the location of the Valet button.
To override the starter kill, turn
the ignition on and press the
Valet button within 10 seconds.
The status LED will stop flashing
and the vehicle should start. If it does not start,
you may have waited too long; turn the ignition off and repeat the
process.
LLOOCCAATTIIOONNOOFFVVAALLEETTBBUUTTTTOONN_____________________________
You can prevent your system from automatically activating the
Failsafe®Starter Kill and locking the doors by using Valet Mode.
This is very useful when washing the vehicle or having it serviced.
In Valet Mode, the starter kill cannot be activated, even with the
transmitter, but all convenience functions (door locks, remote
start, etc.) will continue to work normally.
VVaalleettMMooddee
DRW-35
DDiissaabblliinnggtthheeSSttaarrtteerrKKiillllWWiitthhoouuttaaTTrraannssmmiitttteerr

1111
©2005 Directed Electronics—all rights reserved
TTooeenntteerroorreexxiittVVaalleettMMooddee::
1. Turn the ignition on.
2. Turn the ignition off.
3. Press and release the Valet
button within 10 seconds.
The status LED will light steadily if you are entering Valet Mode
and will turn off if you are exiting Valet Mode.
If you are threatened in or near your vehicle, you can attract
attention by triggering the system with your transmitter. Just
press for 1.5 seconds to enter Panic Mode. In Panic Mode, the
horn will honk and the parking lights will flash for 30 seconds. To
stop Panic Mode at any time, press , or on the
transmitter.
NNOOTTEE::In order for Panic Mode to be effective, the vehicle’s horn (or
optional siren) as well as the vehicle's parking lights must be
connected.
PPaanniiccMMooddee
DRW-35

1122©2005 Directed Electronics—all rights reserved
This feature allows you to remotely start and run your vehicle for
a programmable period of time. This makes it possible to warm up
the engine, as well as adjust the interior temperature of the vehi-
cle with the climate control system. If interior heating or cooling
is desired, the climate controls must be preset, and the fan blower
must be set to the desired level prior to remote starting the
vehicle.
IIMMPPOORRTTAANNTT!!(1) Never remotely start the vehicle with the vehicle
in gear, and (2) Never remotely start the vehicle with the key in the
ignition.
TToorreemmootteessttaarrtttthheevveehhiiccllee::
1. Press the button twice within 3 seconds on the trans-
mitter.
2. The parking lights will flash to confirm that the vehicle will
attempt to start.
3. Release the button as soon as the parking lights flash.
(In gasoline vehicles, the engine will start 4 seconds after
the parking lights flash. In diesel vehicles, the engine will
start when the WAIT-TO-START indicator on the vehicle's dash
goes out or the timer has expired.)
4. Once the vehicle has started, it will run for the pre-program-
med period of time (12, 24, or 60 minutes) or until a shut-
down input is triggered.
RReemmootteeSSttaarrtt

1133
©2005 Directed Electronics—all rights reserved
WWhheennyyoouuaarreerreeaaddyyttooddrriivveetthheevveehhiiccllee::
1. Insert the ignition key and
turn it to the ON (not the
START) position.
2. Press the brake pedal.
NNOOTTEE::If the brake pedal is pressed before the key is in the ON position,
the engine will shut down.
While the vehicle is running during remote start operation, the
system will monitor the vehicle and will automatically shut down the
engine if the system receives any of the following shut-down inputs:
■The brake pedal is pressed.
■The hood is opened.
■The shutdown toggle switch is put into the OFF position.
■The pre-programmed run time (12, 24, or 60 minutes) has elapsed.
■Transmitter button is pressed twice in 3 seconds to start
the vehicle.
To turn the rear defogger output OFF:
1. Simultaneously press & release the ++buttons
on the remote control.
2. The lights will flash 2 times.
3. The rear defogger output will no longer activate when the
vehicle is remote started.
NNOOTTEE::If the remote start is on the parking lights will turn off then flash
2-times before returning to their normal output and the defogger out-
put, if active, will cease.
RReeaarrDDeeffooggggeerr

1144©2005 Directed Electronics—all rights reserved
To turn the rear defogger output ON:
1. Simultaneously press & release the ++buttons
on the remote control.
2. The lights will flash 3 times.
3. The rear defogger output will once again activate when the
vehicle is remote started.
NNOOTTEE::If the remote start is on the lights will turn off then flash 3-times
before returning to their normal output and the defogger output will
activate as programmed.
The Valet Take-Over feature allows the vehicle to remain running
after the key has been removed from the ignition. This feature is
useful for occasions when you wish to exit and lock the vehicle for
short periods of time, but would like to leave the motor running
and the climate controls on.
TTooppeerrffoorrmmVVaalleettTTaakkee--OOvveerr::
1. Before turning off the engine, press and release on the
transmitter twice in 3 seconds (or press and release the
optional momentary switch).
2. Turn the ignition key to the OFF position. (The engine will
stay running.)
3. Once the vehicle has started, it will run for the pre-pro-
grammed
period of time (12, 24, or 60 minutes) or until a shutdown
VVaalleettTTaakkee--OOvveerr

input is triggered.
Short-run turbo mode keeps the engine running after arriving at
you destination for a programmable period of 1, 3 ,5 or 10 min-
utes. This allows the system’s timer to conveniently cool down the
turbo after you have left the vehicle.
To activate:
1. Park the vehicle and set parking brake.
2. Remove your foot from the brake pedal and leave the engine
running.
3. Press and release the and buttons at the same time.
4. The lights will flash to indicate the remote start has entered
short run turbo mode.
5. Turn off the key, the engine will keep running.
6. Exit and secure the vehicle.
7. The engine will turn off after the programmed run time.
By pressing the remote and buttons the parking lights
will flash 4 times and then start the vehicle and run for the set
duration. The remote start can be shut off by the transmitter by
pressing the remote start button and remain in timer mode,
but if any other shut down zones or the ignition becomes active
the timer mode will cancel.
TTiimmeerrMMooddee
SShhoorrtt--RRuunn//TTuurrbboo
1155
1155
©2005 Directed Electronics—all rights reserved

1166©2005 Directed Electronics—all rights reserved
1. Press Timer mode buttons.
2. The vehicle will confirm with 4 parking light flashes.
3. A 1-second delay will start.
4. The system will start the car and will run for the specified
duration, unless shut down by the remote start button
. If shut down with the remote start button the system
will remain in timer mode.
5. The system will start every 3 hours until canceled by the
brake, hood, or neutral safety shut-down wires.
To exit timer mode, turn the ignition switch on any time the
engine is running. The parking lights will flash 4 times, indicating
timer mode has been exited.
5. The system will start every 3 hours until canceled by the
brake, hood, or neutral safety shut-down wires.
IIMMPPOORRTTAANNTT!!Timer Mode should be used only
in open areas. Never start and run the vehicle
in an enclosed space such as a garage or
carport.
important!!Timer Mode should be used only in
open areas. Never start and run the vehicle in an
enclosed space such as a garage or carport.

Whenever the vehicle is remote started, advanced anti-grind cir-
cuitry prevents the starter from engaging, even if the key is
turned to the start position. This prevents damage to the starter
motor if the key is turned to the start position during remote start
operation.
NNOOTTEE::Anti-grind circuitry only works when the remote start system is
operating the motor and the Failsafe®Starter Kill relay is installed.
This feature allows your system's remote start unit to be tem-
porarily disabled to prevent the vehicle from being remote start-
ed accidentally. This feature is useful if the vehicle is being ser-
viced or stored in an enclosed area. To disable the remote start,
move the shutdown toggle switch to the OFF position. The switch
can be installed in a location of your choice. Check with your
installer for recommended locations.
LLOOCCAATTIIOONNOOFFSSHHUUTTDDOOWWNNSSWWIITTCCHH_________________________
DDiissaabblliinnggtthheeRReemmootteeSSttaarrttSSyysstteemm
SSttaarrtteerrAAnnttii--GGrriinnddCCiirrccuuiittrryy
1177
©2005 Directed Electronics—all rights reserved
