Directed Electronics READY REMOTE 24927 Quick start guide

MMooddeell2244992277
➤
OOwwnneerr’’ss//IInnssttaallllaattiioonnGGuuiiddee

3
© 2007 Directed Electronics
LLiiffeettiimmeeCCoonnssuummeerrWWaarrrraannttyy
For a period of one calendar year from the date of purchase of this auto-security, remote
start or keyless entry device, as applicable (hereinafter "Unit"), Directed Electronics
("Directed") promises to the ORIGINAL PURCHASER to repair or replace (at
Directed's election) with a comparable, reconditioned Directed DIY Unit (excluding
without limitation, the siren, remote transmitters and associated sensors and accessories)
which proves to be defective in workmanship or material under reasonable use PROVID-
ED the following conditions are met: (i) the Unit was purchased from an authorized
Directed dealer, (ii) the Unit is returned (shipping prepaid) to Directed's warranty depart-
ment at: Directed Electronics, Attn: Warranty, One Viper Way, Vista, CA 92081, along
with a cashier's check or money order made payable to Directed Electronics in the amount
of $20 for postage and handling, and (iii) a bill of sale or other dated proof of purchase
bearing the following information is included: Date of purchase, name and location of
merchant who sold the Unit and product description. This warranty does not cover labor
costs for the removal or reinstallation of the Unit. This warranty is non-transferable and
does not apply to any Unit that has been modified or used in a manner contrary to its
intended purpose, and this warranty does not cover damage to any Unit caused by instal-
lation or removal of the Unit. This warranty is void if the Unit has been damaged by acci-
dent or unreasonable use, negligence, Acts of God, improper service or other causes not
arising out of defects in materials or workmanship. If this Unit is an auto-security device,
then the Unit may be a deterrent against possible theft, however Directed makes no war-
ranty against vandalism, damage or theft of a vehicle or its parts or contents and Directed
expressly disclaims any liability whatsoever, including without limitation, liability for
theft, damage and/or vandalism. ALL UNITS RECEIVED BY DIRECTED FOR WAR-
RANTY REPAIR WITHOUT PROOF OF PURCHASE WILL BE DENIED.
THE FOREGOING WARRANTY IS THE EXCLUSIVE PRODUCT WARRANTY,
OTHERWISE, ALL WARRANTIES, INCLUDING BUT NOT LIMITED TO
EXPRESS WARRANTY, IMPLIED WARRANTY, WARRANTY OF MER-
CHANTABILITY FOR FITNESS FOR A PARTICULAR PURPOSE ARE EXPRESS-
LY EXCLUDED AND DISCLAIMED TO THE MAXIMUM EXTENT ALLOWED
BY LAW, AND DIRECTED NEITHER ASSUMES NOR AUTHORIZES ANY PER-
SON TO ASSUME FOR IT ANY LIABILITY IN CONNECTION WITH THE SALE
OF THE PRODUCT. DIRECTED HAS ABSOLUTELY NO LIABILITY FOR ANY
AND ALL ACTS OF THIRD PARTIES INCLUDING ITS AUTHORIZED DEAL-
ERS OR INSTALLERS. SOME STATES DO NOT ALLOW LIMITATIONS ON
HOW LONG AN IMPLIED WARRANTY WILL LAST OR THE EXCLUSION OR
LIMITATION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE
LIMITATIONS HEREIN MAY NOT APPLY TO YOU.

4© 2007 Directed Electronics
Consumer's remedy is limited to repair or replacement of the Unit, and in no event shall
Directed's liability exceed the purchase price of the Unit. IN ANY EVENT, DIRECT-
ED SHALL NOT BE LIABLE FOR ANY DAMAGES, INCLUDING, BUT NOT
LIMITED TO, ANY DIRECT, INDIRECT, INCIDENTAL, SPECIAL, PUNITIVE
OR CONSEQUENTIAL DAMAGES, LOST PROFITS, DAMAGE TO VEHICLE,
LOST SAVINGS, OR, TO THE EXTENT ALLOWED BY APPLICABLE LAW, DAM-
AGES RESULTING IN DEATH OR INJURY ARISING OUT OF OR IN CON-
NECTION WITH THE INSTALLATION, USE, IMPROPER USE, OR INABILITY
TO USE THE PRODUCT, EVEN IF THE PARTY HAS BEEN ADVISED OF THE
POSSIBILITY OF SUCH DAMAGES. The consumer consents and agrees that all dis-
putes between the consumer and Directed shall be resolved in accordance with California
laws in San Diego County, California. This warranty is only valid for the sale of prod-
uct(s) within the United States of America. Product(s) sold outside of the United States
of America are sold "AS-IS" and shall have NO WARRANTY, express or implied.
IIMMPPOORRTTAANNTTNNOOTTEE::
This product warranty is automatically void if its date code or serial number is defaced,
missing, or altered. This warranty will not be valid unless you have completed the war-
ranty card and mailed it to Directed within 10 days after purchase to the address listed on
the warranty registration card.
Make sure you have all of the following information from your dealer:
A clear copy of the sales receipt, showing the following:
➤Date of purchase
➤Authorized dealer's company name and address
➤Item number
920-0005-2007-08

5
© 2007 Directed Electronics
TTaabblleeooffCCoonntteennttss
LLiiffeettiimmeeCCoonnssuummeerrWWaarrrraannttyy......................................................................................33
IInnssttaallllGGuuiiddee..........................................................................
......................................77
What Is Included . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Installation Tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Important Information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
System Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
FCC/Id Notice . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Warning! Safety First . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
WWiirriinnggQQuuiicckkRReeffeerreenncceeGGuuiiddee............................
......................................................1111
H1 Harness - 6 pin connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
H2 Harness - 8 pin connector . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
H3 harness - 3 pin connector. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Relay Heavy Gauge Wires . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Installation Overview . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Step 1, Heavy Gauge Wire Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Step 2, H1, Main Harness Connections. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Step 3, H3 Door Lock Connections . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Step 4, H2 Harness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
Step 5, Mounting the Receiver/Antenna . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Step 6, Immobilizer Bypass Modules . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Step 7, Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
System Diagnostics. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 63
Remote Start Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 65
Testing the System . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
OOwwnneerr’’ssGGuuiiddee............................
..............................................................................7755
Transmitter Button Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 76
Remote Start Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Alarm and Security Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Convenience Features. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
Glossary of Terms. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
NNootteess............
..............................................................................................................9911
QQuuiicckkRReeffeerreenncceeGGuuiiddee::.................................................................
.............................9933

6© 2007 Directed Electronics

7
© 2007 Directed Electronics
Install Guide
What Is Included
Control Module
6-Pin Main H1 Harness
8-Pin H2 Secondary Harness
Heavy Gauge Wires
Antenna and Cable
Two 5-button Remotes
Crash Code Card
3-pin Keyless Entry Harness
Combination Momentary Switch and LED
Hood Pin Switch
Hardware Kit
DVD—Do-It-Yourself Installation Video
Additional parts may be required (such as relays or a bypass
module).
Installation Tools
Digital Multi-Meter
Drill
1/4Drill Bit (for hood pin switch)
Screwdrivers (Phillips and Flathead)
Wire Stripper
Solder Iron
Electrical Tape
Pliers
Crimping Tool
Safety Glasses
Note: The installation tools listed above may be
optional. The required tools will vary depending on
your vehicle.

8© 2007 Directed Electronics
Important Information
Congratulations on the purchase of your remote start keyless entry
system. This system will allow convenient access to your vehicle
with the push of a button, as well as remote start and other
optional features. Properly installed, this system will provide years
of trouble-free operation.
Please take the time to carefully read this User’s Guide in its
entirety and watch the READY REMOTE Do-It-Yourself
Installation Video (DVD) prior to installing your system.
You can print additional or replacement copies of this manual
by accessing the Directed web site at www.readyremote.com.
Guide Translations
If you want a Spanish or French version of the Installation/Owners
Guide, please download it from www.readyremote.com and click on
On-Line Tech Support.
Estimado Cliente:
Si buscas los guías de instalación/del usario, por favor de bajar lo
del Soporte Técnico en-línea en el sitio www.readyremote.com
Cher consommateur:
Si vous désirez une version française ou espagnole du guide d'util-
isateur ou d'installation, veuillez s.v.p. le télécharger à l'adresse
suivante: www.readyremote.com en appuyant sur l'icône <<On-line
Tech Support>>.
Important! If you are not comfortable working with
electronics or unfamiliar with the tools required,
please contact your local dealer for advice or ask to
have the remote start professionally installed to avoid
costly damages. Failure to properly install the remote
starter may result in property damage, personal injury,
or both.

9
© 2007 Directed Electronics
System Maintenance
The system requires no specific maintenance. Your transmitter
is powered by a miniature 12-volt battery (type 23A) that will
last approximately one year under normal use. When the
battery begins to weaken, the operating range will be
reduced.
FCC/Id Notice
This device complies with Part 15 of FCC rules. Operation is
subject to the following conditions: (1) This device may not
cause harmful interference, and (2) This device must accept
any interference received, including interference that may
cause undesirable operation.
Changes or modifications not expressly approved by the party
responsible for compliance could void the user's authority to
operate this device.
Warning! Safety First
The following safety warnings must be observed at all times:
When properly installed, this system can start the vehicle
via a command signal from the remote control trans-
mitter. Therefore, never operate the system in an area
that does not have adequate ventilation. The following
precautions are the sole responsibility of the user;
however, the following recommendations should be made
to all users of this system:
1. Never operate the system in an enclosed or partially
enclosed area without ventilation (such as a garage).
➜
➜

10 © 2007 Directed Electronics
2. When parking in an enclosed or partially enclosed
area or when having the vehicle serviced, the remote
start system must be disabled by placing the system
into Valet Mode.
3. It is the user's sole responsibility to properly handle
and keep out of reach from children all remote control
units to assure that the system does not uninten-
tionally remote start the vehicle.
4. The user must install a carbon monoxide detector in
or about the living area adjacent to the vehicle. All
doors leading from adjacent living areas to the
enclosed or partially enclosed vehicle storage area
must remain closed at all time.
Use of this product in a manner contrary to its intended mode of
operation may result in property damage, personal injury, or death.
Except when performing the Safety Check outlined in this user’s
guide, (1) Never remotely start the vehicle with the vehicle in gear,
and (2) Never remotely start the vehicle with the keys in the igni-
tion.
After the remote start module has been installed, test the remote
start module in accordance with the Safety Check outlined in this
installation guide. If the vehicle starts when performing the
Neutral Safety Shutdown Circuit test, the remote start unit has not
been properly installed. The remote start module must be removed
or properly reinstalled so that the vehicle does not start in gear.
OPERATION OF THE REMOTE START MODULE IF THE VEHICLE STARTS
IN GEAR IS CONTRARY TO ITS INTENDED MODE OF OPERATION.
OPERATING THE REMOTE START SYSTEM UNDER THESE CONDITIONS
MAY RESULT IN PROPERTY DAMAGE OR PERSONAL INJURY. IMMEDI-
ATELY CEASE THE USE OF THE UNIT AND REPAIR OR DISCONNECT THE
INSTALLED REMOTE START MODULE. DIRECTED WILL NOT BE HELD
RESPONSIBLE OR PAY FOR INSTALLATION OR REINSTALLATION
COSTS.

11
© 2007 Directed Electronics
Wiring Quick Reference Guide
Heavy Gauge
Wires
BLUE WHITE (+)
YELLOW
PINK
PINK
GREEN (+) output to ign/acc2 circuit
YELLOW/RED (-) lock or (+) unlock output
WHITE/RED (-) unlock or (+) lock output
MOMENTARY SWITCH PORT
ANTENNA CABLE PORT
SENSOR PORT
Fused light
flash jumper Black (-)
Heavy gauge
ground wire
YELLOW (+/-) parking light output
BROWN/WHITE (-) factory alarm disarm output
VIOLET (-) negative hood pin shutdown output
ORANGE (+) brake input
WHITE/BLACK (-) 400mA status output
RED/WHITE (-) remote start activation
GREEN Tachometer input
BLUE (-) 400mA horn/siren output
RED/BLACK (-) wait-to-start input
YELLOW/GREEN (+) ignition output
GREEN/WHITE (-) 400mA trunk release output
BROWN (-) 400mA RAP, Dome light, Starter kill output
YELLOW/BROWN (-) 400mA Headlight output
GRAY/BLACK (-) Door trigger input
H1
H2

12 © 2007 Directed Electronics
H1 Harness - 6 pin connector
___
___
___
___
___
___
Pin # Color Note
H1/1
Yellow
Selectable positive or negative parking light output
H1/2
Brown/White
Use this wire if the vehicle is equipped with a
factory alarm. Connect to disarm wire listed on your
sheet.
H1/3
Violet
Connect this wire to supplied hood pin switch
H1/4
Orange
Connect this to wire in vehicle that shows 12 volts
when brake is pressed
H1/5
White/Black
Provides a ground during remote start. This wire is
normally connected to a bypass module if your
vehicle needs one.
H1/6
Red/White
This wire will start the vehicle when it sees two
negative pulses. Only used when incorporating into
existing alarm or for testing purposes.
RED/WHITE (-) remote start activation input
WHITE/BLACK (-) 400mA status output
ORANGE (+) brake switch shutdown input
VIOLET (-) hood pin shutdown input
BROWN/WHITE (-) factory disarm output
YELLOW (+/-) parking light output
HH11//11
HH11//22
HH11//33
HH11//44
HH11//55
HH11//66

13
© 2007 Directed Electronics
H2 Harness - 8 pin connector
___
___
___
___
___
___
___
___
Pin # Color Note
H2/1
Green
Use this wire if the vehicle fails to start correctly in
voltage mode.
H2/2
Blue
Negative output to horn or siren circuit. If your horn is
positive, use a relay.
H2/3
Red/Black
Used on diesel engines only. Connects to wait-to-start
wire.
H2/4
Yellow/Green
Ignition output. Connect this wire to the ignition input
of an aftermarket alarm system.
H2/5
Green/White
Trunk release wire. Connect this wire to trunk release
wire listed on your vehicle specific printout.
H2/6
Brown
Retained accessory shutdown or factory rearm output.
Connect this wire to factory arm wire if equipped, or to
door trigger wire if your vehicle’s accessories stay on
after remote start finishes cycle.
H2/7
Yellow/Brown
Headlight output. Connect this wire to (-) headlight
wire in car. If headlights are positive, a relay is required.
H2/8
Gray/Black
Door trigger input. This wire connects to the door trig-
ger wire in your car to set off the alarm when system is
armed and door is opened.
GRAY/BLACK (-) door trigger input
YELLOW/BROWN (-) 400mA headlight output
BROWN (-) 400mA RAP, Domelight, Starter Kill
GREEN/WHITE (-) 400mA trunk release output
YELLOW/GREEN (+) ignition output
RED/BLACK (-) wait-to-start input
BLUE (-) 400mA horn/siren output
GREEN Tachometer input
HH22//11
HH22//22
HH22//33
HH22//44
HH22//55
HH22//66
HH22//77
HH22//88

14 © 2007 Directed Electronics
H3 harness - 3 pin connector
___
___
___
Relay Heavy Gauge Wires
___
___
___
___
___
___
BLACK (-) ground
YELLOW (+) starter output
PINK (+) 12 volt input
WHITE (+) accessory output
BLUE (+) ignition 1 output
PINK (+) 12 volt input
GREEN (+) Ign2 or Acc2 output
11
22
33
44
55
66
WHITE/RED (-) unlock/(+) lock
EMPTY
YELLOW/RED (-) lock/(+) unlock
HH33//11
HH33//22
HH33//33

15
© 2007 Directed Electronics
Installation Overview
Be sure to read this section thoroughly and view the Do-It-
Yourself Installation DVD video in its entirety before starting the
installation. Pay special attention to all warnings to prevent per-
sonal injury or damage to your vehicle.
Visit our 24-hour technical web site (www.readyremote.com) to
get a vehicle-specific wiring guide prior to starting this installa-
tion.
Have your crash code number handy when contacting tech support
or visiting the web site. During the installation if you are unable
to find answers to your questions on the web site, call 1-800-477-
1382 for live technical assistance. Please note that live technical
support is available Monday-Friday 6am-6pm PST, and Saturday-
Sunday 7am-3:30pm PST.
WARNING!
➤ Verify that the transmission is set to park and that
the parking brake is set before beginning installation.
➤ On vehicles with air bags or supplemental restraint
systems (SRS) you may notice a bright yellow tube
with small wires in it, marked SRS, underneath the
steering column near the key cylinder. DO NOT tamper
or unplug these for any reason to prevent costly dam-
ages to your vehicle or personal injury. Tampering
may cause unintended deployment of airbags.
➤ This system is intended for automatic, fuel-injected
vehicles only. Installation in any other vehicle is con-
trary to its intended use.

16 © 2007 Directed Electronics
Step 1, Heavy Gauge Wire Connections
Ground Wire
The BLACK wire connects to the pin next to the light flash jumper
fuse. First strip back a ¾-inch section of the insulation off the
BLACK wire and crimp a ring terminal (not provided) to that wire.
Locate a clean, paint-free metal surface in the drivers kick panel
(DO NOT GROUND ON DASH). Using a self-tapping screw, drill the
screw with the ring terminal to the kick panel. Once screwed down,
pull on the wire to ensure a good connection.
Constant Power and Ignition Wires
Almost all your power and ignition wires can be found behind the
key cylinder under the lower driver's side dash panel. Using the
appropriate hand tools, remove the lower dash panel taking care
not to break any parts. If the panel does not come off easily, check
for any additional screws you may have missed.
SELF-TAPPING
BOLT OR SCREW
RING
TERMINAL
GROUND
WIRE
NOTE: REMOVE ANY PAINT
BELOW RING CONNECTOR
DIA-591

17
© 2007 Directed Electronics
Once the lower dash panel has been removed, locate the ignition
harness at the back of the key cylinder. This is usually a group of
heavy gauge wires (approximate 14ga.).
Place the black lead of the LED tester to a clean metal surface in
the kick panel area and secure it. Probe one of the thicker gauge
wires. The ignition wire colors of your specific vehicle can be
obtained at www.readyremote.com.
Testing for Constant Power Wires
WARNING!Before making any connection to constant
battery power, make sure that the two 30 amp fuses
are removed from the fuse holders on the two pink 12
VOLT wires. Failure to do so may cause fire or short-
ing of sensitive electrical components.
Note! More problems are attributed to poor ground
connections than any other cause. Take extra care
to ensure the ground is a clean metal-to-metal
contact and secure.

18 © 2007 Directed Electronics
With the key in the off position, test the suspect wire. The
constant power wire will read 12V on the multimeter. Once the
constant power wire has been identified, solder the two heavy
gauge 12 VOLT wires (PINK) from the control module to it and
wrap the connection with electrical tape.
Testing for Ignition Wires
With the multimeter lead still connected in the kick panel, locate
the suspected ignition wire. It will test differently than constant
12 volts. Place the red lead of the multimeter on the suspected
wire. With the key in the off position the multimeter will read 0.
Turn the key to the on position and the multimeter will read 12
volts. Now, watching your multimeter, turn the key to the crank
position. If the 12 volts stays on, then you have found your igni-
tion wire. If the wire tests correctly, solder the BLUE heavy gauge
wire to it and wrap the connection with electrical tape.
If the vehicle requires more than one ignition as per the web site
information, follow the same test procedure and solder the GREEN
heavy gauge wire to it then wrap the connection with electrical
tape. If your vehicle has only one ignition wire, secure the GREEN
wire and dress it out of the way.
Note! If the vehicle has more than one constant
power wire, use two of them. Connect one of the
heavy gauge PINK wires to one of the constant
power wires, and the other heavy gauge PINK wire
to the other constant power wire.

19
© 2007 Directed Electronics
If your vehicle requires more than two ignitions, an additional
relay (not provided) is required. Refer to the diagram below.
87
87A
86 85
30
+12 VDC CONSTANT (FUSED 20A)
GROUND
GREEN (+) OUTPUT
TO 2nd IGNITION
TO 2nd IGNITION
TO 3rd IGNITION
3rd IGNITION RELAY
(NOT PROVIDED)
87
87A
86 85
30
+12 VDC CONSTANT (FUSED 20A)
GROUND
TO 2nd IGNITION
2nd IGNITION RELAY
(NOT PROVIDED)

20 © 2007 Directed Electronics
Accessory and Starter Wires
The starter and accessory wires will be located in the same harness
as the ignition and constant power.
To find the accessory wire, leave the multimeter’s black lead
connected to ground. Take the red lead and probe the wire
suspected to be the accessory wire. With the key off, your multi-
meter should read 0 volts. Turn the key to the on position The
multimeter should read 12 volts. Now turn the key to the crank
position. If you have the correct accessory wire, the multimeter
will read 0 volts while the starter is cranking, and 12 volts once
the key returns to the on position. If the wire tests correctly, strip
some insulation off and solder the WHITE heavy gauge wire and
wrap it with electrical tape.
If your vehicle requires more than one accessory then the GREEN
igniton 2 wire can be programmed to function as an accessory
output.

21
© 2007 Directed Electronics
If the GREEN wire is being used for Ignition 2, an additional relay
(not provided) is required for a 2nd accessory. Refer to the
diagram below.
Now that the accessories have been located, find the suspected
starter wire according to the web information. Leave the black
lead of your tester on ground and place the red lead of your multi-
meter on this wire. The multimeter should read 0 volts in all key
positions except the crank position. In the crank position your
multimeter should read 12 volts, and will go to 0 volts when the
starter disengages.
87
87A
86 85
30
+12 VDC CONSTANT (FUSED 20A)
GROUND
TO 2nd ACCESSORY
WHITE (+) 30A OUTPUT TO
ACCESSORY CIRCUIT
TO ACCESSORY
2nd ACCESSORY RELAY
(NOT PROVIDED)
87
87A
86 85
30
+12 VDC CONSTANT (FUSED 20A)
GROUND
TO ACCESSORY
ACCESSORY RELAY
(NOT PROVIDED)
