Disc NSM4000 User manual

__________________________________________________________
143715-F NSM /DISCx000 Version 2.0 QickInstallatinsGuide
Rev. C 1
Quick Installations Guide
NSM3000
NSM4000
NSM7000
and
DISC1000
DISC3000
DISC4000
DISC7000

__________________________________________________________
143715-F NSM /DISCx000 Version 2.0 QickInstallatinsGuide
Rev. C 2

__________________________________________________________
143715-F NSM /DISCx000 Version 2.0 QickInstallatinsGuide
Rev. C 3
Table of Contents
Table of Contents 3
Copyrights and Trademarks 5
Safety Instructions 8
Setup 13
Checking the Delivery 14
Removing the Transportation Fixtures 15
Mounting the Stands 16
Placing the Optical Library 17
Operation Modes 18
RS232 mode 18
SCSI mode 19
SCSI Cable Requirements 19
SCSI cable length 19
Setting the SCSI ID´s for the Drives 20
Connecting to a Host Computer 21
Connecting the serial robotic interface 21
Connecting the SCSI Interface 22
The User Interface 25
The User Interface 26
User Interface Modes 27
Activating the User Interface 28
PIN Codes 28
Enter Admin PIN 28
Enter Service PIN 28
Change Admin PIN 28
Change Service PIN 28
Alarm 29
Mute Alarm Signal 30

__________________________________________________________
143715-F NSM /DISCx000 Version 2.0 QickInstallatinsGuide
Rev. C 4
Settings 31
Machine Defaults 31
Auto DISC 31
Auto Start 31
Event Logging 32
Event Logging Functions 32
Technical Data 33
NSM3-7000 34
DISC1-7000 35
Slot Upgrade 37
Agency Approvals 38
FCC Declaration 39
Declaration of Conformity NSM3000 40
Declaration of Conformity NSM4000 41
Declaration of Conformity NSM7000 42
Declaration of Conformity DISC1000 43
Declaration of Conformity DISC3000 44
Declaration of Conformity DISC4000 45
Declaration of Conformity DISC7000 46

_________________________________________________________
143715-F NSM /DISCx000 Version 2.0 QickInstallatinsGuide
Rev. C 5
COPYRIGHTS and
TRADEMARKS
■ Notice of Copyright
■ Disclaimer
■ Trademarks
■ Contacting DISC

_________________________________________________________
143715-F NSM /DISCx000 Version 2.0 QickInstallatinsGuide
Rev. C 6
NOTICE OF COPYRIGHT
All rights reserved. Copyright © 2004 by DISC GmbH. No part of this
publication may be reproduced, stored in a retrieval system, or traDISCitted in
any form or by any means, electronic, mechanical, photocopying, recording or
otherwise, without the prior written consent of:
DISC GmbH
Schultheiss-Kollei-Straße 5
D-55411 Bingen
Germany.
Disclaimer
DISC GmbH (DISC GmbH and all of its subsidiaries) takes no responsibility
and offers no warranty with respect to the adequacy of this documentation, or
the procedures which it describes for any particular purpose, or with respect to
its adequacy to produce any particular result. In no event shall DISC GmbH, its
employees, its contractors or the authors of this documentation be liable for
special, direct, indirect or consequential damages, losses, costs, charges,
claims, demands, or claim for lost profits, fees or expenses of any nature or
kind.
CHANGES
The following paragraph does not apply where such provisions are inconsistent
with local law. Some states do not allow disclaimer of express or implied
warranties in certain transactions. Therefore, this statement may not apply to
you: The material in this documentation is for information only and is subject to
change without notice. While reasonable efforts have been taken in the
preparation of this manual to assure its accuracy, DISC GmbH assumes no
liability resulting from any errors or omissions in this manual, or from the use of
the information contained herein.
DISC GmbH reserves the right to make changes in the product design without
reservation and without notification to its users.

_________________________________________________________
143715-F NSM /DISCx000 Version 2.0 QickInstallatinsGuide
Rev. C 7
Additional Information may be obtained from:
DISC GmbH
Schultheiss-Kollei-Straße 5
55411 Bingen
Germany
TRADEMARKS USED IN THIS MANUAL
DISC, and the DISC logo are registered trademarks of DISC Group

_________________________________________________________
143715-F NSM /DISCx000 Version 2.0 QickInstallatinsGuide
Rev. C 8
CHAPTER 2:
SAFETY INSTRUCTIONS
■ Intended Use
■ Residual Risks
■ Safety

_________________________________________________________
143715-F NSM /DISCx000 Version 2.0 QickInstallatinsGuide
Rev. C 9
RAPID METHOD
DISCx000: DICC1000 NSMx000: NSM3000
DISC3000 NSM4000
DISC4000 NSM7000
DISC7000
INTENDED USE
The NSMx000 and DISCx000 Optical Libraryes are controlled by a host
computer or combined server unit (NAS). The Optical Libraryes were
designed exclusively to read and write bare media, especially the Blue Laser
(PDD, PD, BD) media, CD/DVD media and are not intended for any other
use.
Improper use of the Optical Libraryes may cause residual risks if they are
used or operated by unauthorized individuals. Any person who uses the
Optical Libraryes should read and understand the user´s manual and
especially the safety instructions.
Residual Risks
Disregarding the safety messages can cause damage to the unit or result in
personal injury. Ban of Arbitrary Reversions and Changes The Optical
Libraryes may not be altered due to applicable safety regulations.
BAN ON ARBITRARY REVERSIONS AND
CHANGES
The Optical Library must not be altered or changed in any way that does not
comply with applicable safety regulations.
REPAIRS
Repairs must be carried out only by DISC staff, or DISC authorized service
providers.
DISC will not be liable for any damage caused from repair by unauthorized
individuals. Repair by unauthorized individuals may void your warranty.

_________________________________________________________
143715-F NSM /DISCx000 Version 2.0 QickInstallatinsGuide
Rev. C 10
Fire Damages
To reduce fire or shock hazard, do not expose the units to rain or moisture.
OPENING THE UNIT
To prevent electrical shock, remove line cord before opening the unit!
Do not leave one of the side walls open while the Optical Library is
powered on! Beside danger of injury, incidence of light will disturb the
media detection and incomming dust may affect the read/write ability of
the media!
SAFETY
This product is in the used way a Laser Class 1 device. Disc access is
accomplished via a laser beam. The laser beam does not represent any risk for
the user.
This product complies with the DHHS Rules 21 CFR chapter 1, sub chapter J,
accession number 9520184, applicable at the date of manufacture.
Caution:
The built in drives become under Laser Class 2M and 3B radiation if they get
opened! This includes the risk of injury if you stare into the beam or expose
something to the beam. You must not remove and open an optical drive of
this Optical Library!

_________________________________________________________
143715-F NSM /DISCx000 Version 2.0 QickInstallatinsGuide
Rev. C 11
DVD-RAM, DVD-R and Blue Laser Media
These media, specifically DVD RAM and Blue Laser bare media (e.g. BluRay
Disc or HD DVD), are very sensitive to scratches and fingerprints. Please
handle writeable media with care. Damaged or polluted media might end in a
loss of data.
All bare media shall be handled outsite of the Optical Library within a certain
cover! To export bare media best use the DISC SmartPacks
TM
(removable
front site 15 pcs media magazines).
Even if the used DVD multirecorder drives support several types of DVD
recording, only DVD - R (’minus R’) general type media are certified for
professional data archiving on DVD. CD-R Media
The CD-R drives used in NSM Optical Libraryes support 12 X or higher CD
recording. Please take care, that the CD-R media you use support your
selected recording speed.
To ensure the compatibility of media, DISC recommends to setup the library
managing application to use the max. recording speed of
12x for CD-R recording,
8x for DVD-R Disc-at-Once recording,
2x for DVD-R incremental recording
2x for DVD-RAM recording
Professional Disc Media (PDD and BD)
These Blue Laser bare media are very sensitive to scratches and
fingerprints. Please handle writeable media with care. Damaged or polluted
media might end in a loss of data.
All bare media shall be handled outsite of the Optical Library within a certain
cover! To export bare media best use the DISC SmartPacks
TM
(removable
front site 15 pcs media magazines).
DISC has qualified only writing and reading of media within the DISC
libraries. Externally recorded media have to get tested for functionality.
Same is valid for media that are recorded within the DISC libraries and shall
get read externally utilizing different systems and drives.
For qualification of certain drive/media compatibilities DISC offers its
MediaWatch
TM
services.
Please ask your sales contact for this DISC service.

_________________________________________________________
143715-F NSM /DISCx000 Version 2.0 QickInstallatinsGuide
Rev. C 12
Air Filter and Temperature Control
All DISCx000 Optical Libraryes are equipped with a fan and an air filter for
the cooling air flow and prevention of incoming dust.
Do not cover the air intake grill!
The air filter shall be checked for dust pollution at least once all half year!
If ’Temperature’ or ’FAN’ alarm ist dispayed, please check and if necessary
clean or replace the airfilter at the right hand cabinet side!

_________________________________________________________
143715-F NSM /DISCx000 Version 2.0 QickInstallatinsGuide
Rev. C 13
CHAPTER 4:
SETUP
Checking the Delivery
Removing the Transportation Fixtures
Mounting the Stands
Placing the Optical Library
Operation Modes
SCSI CABLE REQUIREMENTS
Setting the Drive SCSI IDs
Connecting to a Host Computer
Connecting Line Voltage

_________________________________________________________
143715-F NSM /DISCx000 Version 2.0 QickInstallatinsGuide
Rev. C 14
CHECKING THE DELIVERY
Review the following table to ensure that you have all the required equipment.
Equipment
Quantity
Power Cord
1 or 2
Power Cord USA (only
USA)
1 or 2
Ferrite 1( 2 by dual
redundant
power supply unit)
RS232 Cable
1
SCSI terminator* 1 per SCSI bus
Quick Installation Guide
1
User Manual CD
1
Allen type screw driver 1
Allen type screws 4-6 (missig screws to
fully fix the right side
cover)
Stands 4 (only by
NSM/DISC
3-7000)
Optical Library
1
* Units that are equipped with LVD SCSI bus technology are internally
terminated and therefore shipped without SCSI terminators.

_________________________________________________________
143715-F NSM /DISCx000 Version 2.0 QickInstallatinsGuide
Rev. C 15
Transportation
Fixtures
REMOVING THE TRANSPORTATION FIXTURES
▼Removing the Transportation Fixtures NSM/DISC3-7000
1. Remove the two screws that affix the right cabinet cover of the Optical
Library.
2. Remove the right cabinet cover.
3. Remove the transportation fixtures inside the Optical Library.
▼Removing the Transportation Fixtures DISC1000
1. Remove the 14 screws that affix the right cabinet cover of the Optical
Library.
2. Remove the right cabinet cover.
3. Remove the transportation fixtures inside the Optical Library.
A more detailed information how to remove the transportation fixtures can be
found directly at the machine.
Powering up the Optical Library with transportation fixtures inside can cause
damage to the robotic!
Do not leave one of the side walls open while the Optical Library is powered
on ! Besides danger of injury, incidence of light will disturb the media
detection!

_________________________________________________________
143715-F NSM /DISCx000 Version 2.0 QickInstallatinsGuide
Rev. C 16
MOUNTING THE STANDS
For safety reasons, the NSM/DISC 3-7000 Optical Libraryes must not be
operated without the stands. To mount the stands of the
NSM/DISC 3-7000 Optical Libraryes two persons are needed.
•Tilt the Optical Library a little bit to the left and push the two stands for the
right side into the holes at the bottom of the Optical Library until the stands
„click“ in.
•Tilt the Optical Library a little bit to the right and push the two stands for the
right side into the holes at the bottom of the Optical Library until the stands
„click“ in.
•Take care to mount the stands of the NSM/DISC7000 angled to the right
side! The feet have to stand to the outside (see photo):

_________________________________________________________
143715-F NSM /DISCx000 Version 2.0 QickInstallatinsGuide
Rev. C 17
PLACING THE OPTICAL LIBRARY
The NSMx000 and DISCx000 Optical Libraryes are intended for use in office
and computer networks.
After delivery the temperature of the Optical Library should be adapted
slowly to the temperature of the room before powering up the Optical Library.
Avoid places with
•extreme temperatures or excessive sun exposure
•high humidity
•contact with water or chemicals
•extreme vibrations
The right location
• has a stable, even support
• has sufficient space to pull out the unit
• has at least 10 cm of free space beside each side of the Optical Library
• has sufficient space or possibility to access the air filter module at the right
side of the machine

_________________________________________________________
143715-F NSM /DISCx000 Version 2.0 QickInstallatinsGuide
Rev. C 18
OPERATION MODES
The NSM/DISCx000 Optical Libraryes offer several operation modes which
can be selected by the mode select switch at the back of the Optical Library.
The function of the ID switch depends on the selected mode. Which mode
has to be selected depends on the host application which is used to control
the robotic of the Optical Library.
Mod
e
Function Function of ID Switch
0 0 RS232 mode RS232 ID (robotik)
1 SCSI mode SCSI ID (robotik)
2-F DISC internal
use only -------------
RS232 MODE
The RS 232 mode has to be selected if the robotic of the Optical Library
should be controlled via the serial interface (RS 232). The factory default for
the RS 232 ID is 00. The ID needs to be changed only, if more than one
Optical Library should be connected to the serial bus.
Do not connect more than 3 Optical Libraryes to the serial bus. If more
than 3 Optical Libraryes are connected to the serial bus, the signal
might be disturbed.
The maximum cable length of the serial bus must not exceed 15 m.

_________________________________________________________
143715-F NSM /DISCx000 Version 2.0 QickInstallatinsGuide
Rev. C 19
SCSI MODE
The SCSI mode has to be selected if the Optical Library should be controlled
over the SCSI bus. In the SCSI mode the ID switch is used to select the
SCSI ID of the Optical Library robotic.
If SCSI mode is selected, the robotic of the Optical Library allocates a SCSI ID
on the SCSI bus.
The ID range for the robotic SCSI ID is 0 to 7, default setting is 0.
The SCSI mode must be selected if the Optical Library is controlled via the
SCSI
bus. The ID switch is used to select the robotics SCSI ID. The range for SCSI
IDs is 00 to 07.
SCSI CABLE REQUIREMENTS
The quality of the SCSI cables affects the reliability and usage of a SCSI
system. The SCSI - III standard defines the characteristics of good cables.
They are 100 % shielded round cables that contain 34 twisted pairs of wires.
Each pair should have a characteristic impedance between 90 and 110 ohms.
The wire gauge should be 26 or 28. Most SCSI cables do not meet these
requirements.
Connector plating, shielding, grounding, strain relief, and the way the wires are
routed in the seath all affect the quality of your connection. It is advisable to
use only high quality SCSI cables.
Only best shielded 34 pair high quality AWG33 universal LVD SCSI cables
that meet the European Directive 2002/EC, Issue 13.02.2003, for RoHS
compliance shall be used to connect the DISCx000 robotics and drives!
The max. cable lengh of the external library – host interconnecting LVD
SCSI cable may be 9 meters.
The DISC libraries do have for every internal LVD SCSI bus 1 screw able
female 68pin HD connector at the back panel of the machine.
Every library (Optical Library) SCSI bus requires its own HBA channel !
No other external or server-internal devices may be connected to the
same bus that is connected to the Optical Library robotic or drives!

_________________________________________________________
143715-F NSM /DISCx000 Version 2.0 QickInstallatinsGuide
Rev. C 20
SETTING DRIVE SCSI IDS
The ID switches on the rear of the Optical Library are used to set drive SCSI
Ids (only NSM/DISC 3-7000).
Use a small screw driver to change the ID setting.
The ID range for each drive is 00 to 07.
For additional information about the drive assignment of the Optical Library see
the configuration protocol which is attached to the Quick Installation guide.
Type Plate
Robotic Mode and ID Switch
RS232 Connections
Power Connector
Drive SCSI ID Sw.
SCSI Connections
SE SCSI=50pin Centronics
LVD SCSI=68pin HD
Most Optical Library managing applications require the ascending order of
SCSI drive IDs to be set from bottom to top! (D1 = lowest ID, Dn = highest
ID)
Power
Connector
RS232 ID and
Mode Select
Switches
(Rotate to select)
RS 232 Interfaces
Serial number plate
SCSI Connectors
