Disney PRINCESS DKS7100-P User manual

1
Lights when the power is on
Lights/blinks to indicate Repeat mode
Rotate to select CD/CD+G or to turn the power off
Rotate to adjust the Echo when using a CD+G disc
Slide to the ON position to
turn the microphone on
Lights when a CD+G disc is playing
Blinks to indicate Program mode
Rotate to adjust the volume
Rotate to adjust the AVC when using a CD+G disc
Slide to the ON position to
turn the microphone on
Press to start playback. Press again to pause playback.
Press to Skip or Search backwards
Press to stop CD playback
Press once for Repeat One playback,
press twice for Repeat All playback
Insert Mic 1 into this jack
Rotate to adjust mic volume
Press to Skip or Search forwards
Press to activate Intro feature
Press to program tracks into the memory
Insert Mic 2 into this jack
Press to open/close CD compartment
Rotate to adjust the vertical hold
Rotate to adjust the contrast
Rotate to adjust the brightness
Slide to turn the monitor on or off
Video Out jack
Audio Out jacks
Insert AC power here, see page 8
QUICK REFERENCE

PLAYING COMPACT DISCS
1. Rotate the Function switch to the CD/CD+G position to
turn the unit on; the POWER indicator will light.
2. Press the OPEN/CLOSE button to open the CD
compartment door. Place a CD on the center spindle, with
the printed label side facing up. Close the CD
compartment door.
3. Slide the MONITOR switch on the rear of the unit to the
OFF position.
4. Press the PLAY/PAUSE (¨p) button to begin playback
on Track 1.
5. Adjust the MASTER VOLUME control as desired.
Playback will continue until all of the tracks on the disc
have been played.
6. To stop playback before the disc ends, press the STOP
(■) button. The disc will stop and the display will show the
total number of tracks.
PAUSE
1. During CD playback, if you wish to pause the disc
momentarily, press the PLAY/PAUSE (¨p) button.
Playback stops but the disc continues to spin.
2. Press the PLAY/PAUSE (¨p) button again to release
pause and resume normal CD playback.
SKIP
1. After you insert the disc into the CD player and the total
number of tracks appear on the display, you may press
either the SKIP/SEARCH o or n button to select a
specific track for playback.
2. When the desired track number blinks in the display,
within five seconds, press the PLAY/PAUSE (¨p) button.
Playback will begin on the track you selected.
SEARCH (CD ONLY)
1. During playback, depress and hold either the
SKIP/SEARCH nor obutton to move the player forward
or backward within a track to locate a specific musical
passage. The player will move forward or backward at
high speed as long as the button is depressed. When you
release the SKIP/SEARCH nor o button, normal
playback will resume.
REPEAT
1. To repeat a single track, press the REPEAT button once;
the REPEAT indicator will blink. Press the SKIP/SEARCH
o or n button to select the specific track that you wish to
repeat. When the desired track number blinks in the
display, press the PLAY/PAUSE (®p) button to begin
playback. The specific track you selected will be repeated
continuously.
2. To repeat all of the tracks on a disc continuously, press
the REPEAT button twice; the REPEAT indicator will light
solid. Press the PLAY/PAUSE (¨p) button to repeat all
tracks.
3. To cancel Repeat Playback, press the REPEAT button
until the REPEAT indicator goes out. You can also cancel
Repeat Playback by pressing the STOP (■) button.
PROGRAMMED PLAYBACK (UP TO 20 TRACKS)
1. Rotate the Function switch to the CD/CD+G position to
turn the unit on; the POWER indicator will light.
2. Press the OPEN/CLOSE button to open the CD
compartment door. Place a CD on the center spindle, with
the printed label side facing up. Close the CD
compartment door.
3. Press the PROGRAM button; “0” will blink in the display
and the PROGRAM indicator will blink.
4. Press the SKIP/SEARCH o or n button to select the first
track that you wish to program. When the desired track
number appears in the display, press the PROGRAM
button again.
5. Repeat step 4 until you have programmed the desired
track numbers (up to 20 tracks) into the CD Program
Memory.
6. Press the PLAY/PAUSE (¨p) button to begin
programmed playback. The PROGRAM indicator will blink
and playback will begin on the first track that you
programmed. The player will continue to play all of the
tracks that you programmed in the order in which you
programmed them. When the last programmed track has
been played, the player will stop and the display will again
show the total number of tracks on the disc.
INTRO PLAYBACK
1. During playback, press the INTRO button; the unit will
then play the first 10 seconds of each track and then stop.
If you hear a song you want to hear in its entirety, press
the INTRO button again.
PLAYING A CD+G
1. Rotate the Function switch to the CD/CD+G position to
turn the unit on; the POWER indicator will light.
2. Slide the MONITOR switch to the ON position.
3. Press the PLAY/PAUSE (¨p) button to start CD+G
playback and the image and lyrics will appear on the
monitor and/or external TV and the CD+G indicator will
light.
4. Rotate the AUTO VOICE control clockwise to suppress
the vocal tracks on the CD being played when singing into
the microphone. Rotate the AUTO VOICE control
counterclockwise to have the vocal tracks on the CD play
at normal volume.
5. Adjust the MIC VOLUME control as desired. Increasing
this control will increase the volume of the microphone.
Adjust the ECHO control to add an echo effect to your
voice. The ECHO control is variable so add as much or as
little reverb as desired. Sing or talk into the microphone
and you will hear both the CD+G and the microphone.
MONITOR CONTROLS:
V-HOLD: If the picture moves up and down or rolls, rotate to
adjust the vertical hold.
BRIGHTNESS: If the picture is too light or too dark, rotate to
adjust the brightness.
CONTRAST: If the picture is too strong or too weak, rotate to
adjust the contrast and clearly define the shades of blacks,
grays and whites.
2
QUICK REFERENCE (CONTINUED)

3
Dear Customer,
Please read this manual thoroughly before operating the unit to become more familiar with it and obtain the
performance that will bring you continued enjoyment for many years. Keep these instructions handy for
future reference.
PLEASE KEEP ALL PACKAGING MATERIAL FOR AT LEAST 90 DAYS IN CASE YOU
NEED TO RETURN THIS PRODUCT TO YOUR PLACE OF PURCHASE OR MEMOREX.
For future reference, record the serial number of the unit printed on the rear of the cabinet.
Serial Number _______________________________________
WARNING: TO PREVENT FIRE
OR SHOCK HAZARD, DO NOT
EXPOSE THIS UNIT TO RAIN
OR MOISTURE.
CAUTION: TO REDUCE THE RISK OF ELECTRIC
SHOCK, DO NOT REMOVE COVER (OR BACK). NO
USER-SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
DANGEROUS VOLTAGE:
The lightning flash with arrowhead symbol,
within an equilateral triangle is intended to alert
the user to the presence of uninsulated
dangerous voltage within the product’s
enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
ATTENTION:
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
DANGER:
Invisible and hazardous laser radiation
when open and interlock failed or defeated.
Avoid direct exposure to beam.
FCC WARNING:
This equipment may generate or use radio
frequency energy. Changes or modifications to
this equipment may cause harmful interference
unless the modifications are expressly
approved in the instruction manual. The user
could lose the authority to operate this
equipment if an unauthorized change or
modification is made.
LASER SAFETY: This unit employs a laser.
Only qualified service personnel should attempt
to service this device due to possible eye injury.
CAUTION: USE OF CONTROLS,
ADJUSTMENTS OR PERFORMANCE
PROCEDURE HEREIN MAY RESULT IN
HAZARDOUS RADIATION EXPOSURE.
INFORMATION
This equipment has been tested and found to
comply with the limits for a Class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide
reasonable protection against harmful
interference in a residential installation. This
equipment generates, uses and can radiate
radio frequency energy and, if not installed and
used in accordance with the instructions, may
cause harmful interference to radio
communications. However, there is no
guarantee that interference will not occur in a
particular installation. If this equipment does
cause harmful interference to radio or television
reception, which can be determined by turning
the equipment off and on, the user is
encouraged to try to correct the interference by
one or more of the following measures:
•Reorient or relocate the receiving antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet on a
circuit different from that to which the receiver
is connected.
• Consult the dealer or an experienced radio/TV
technician for help.
SURGE PROTECTORS:
It is recommended to use a surge protector for
AC connection. Lightning and power surges
ARE NOT covered under warranty for this
product.

4
Dear Customer:
Selecting fine audio equipment such as the unit you’ve just purchased is only the start of your
musical enjoyment. Now it’s time to consider how you can maximize the fun and excitement your
equipment offers. This manufacturer and the Electronic Industries Association’s Consumer
Electronics Group want you to get the most out of your equipment by playing it at a safe level. One
that lets the sound come through loud and clear without annoying blaring or distortion-and, most
importantly, without affecting your sensitive hearing.
Sound can be deceiving. Over time your hearing “comfort level” adapts to higher volumes of
sound. So what sounds “normal” can actually be loud and harmful to your hearing. Guard against
this by setting your equipment at a safe level BEFORE your hearing adapts.
To establish a safe level:
• Start your volume control at a low setting.
• Slowly increase the sound until you can hear it comfortably and clearly, and without distortion.
Once you have established a comfortable sound level:
•Set the dial and leave it there.
Taking a minute to do this now will help to prevent hearing damage or loss in the future. After all,
we want you listening for a lifetime.
We Want You Listening For A Lifetime
Used wisely, your new sound equipment will provide a lifetime of fun and enjoyment. Since hearing
damage from loud noise is often undetectable until it is too late, this manufacturer and the
Electronic Industries Association’s Consumer Electronics Group recommend you avoid prolonged
exposure to excessive noise. This list of sound levels is included for your protection.
Decibel
Level Example
30 Quiet library, soft whispers
40 Living room, refrigerator, bedroom away from traffic
50 Light traffic, normal conversation, quiet office
60 Air conditioner at 20 feet, sewing machine
70 Vacuum cleaner, hair dryer, noisy restaurant
80 Average city traffic, garbage disposals, alarm clock at two feet
THE FOLLOWING NOISES CAN BE DANGEROUS UNDER CONSTANT EXPOSURE:
90 Subway, motorcycle, truck traffic, lawn mower
100 Garbage truck, chain saw, pneumatic drill
120 Rock band concert in front of speakers, thunderclap
140 Gunshot blast, jet engine
180 Rocket launching pad
Information courtesy of the Deafness Research Foundation.
A
S
S
O
C
I
A
T
I
O
N
EST. 1924
E
L
E
C
T
R
O
N
I
C
I
N
D
U
S
T
R
I
E
S
EIA
We
LISTENING
For A Lifetime
Want You
