DIVEPRO CL4200R User manual

CL4200R 180°Movable Cable Canister Light Operation Manual
Features
Model: DIVEPRO CL4200R 180°Movable Cable Canister Light
LED: CREE XHP70.2LED ( Max 4200lumen )
Color temperature: Cool white 6500K
Runtime: 4200lumen, About 200mins / 2000lumen, About 420mins/ 40LM : About 60hours.
Output levels: Mid > High, Stepless Dimming from 100% ~ 1%
Lens: 4mm PC
Switch: Waterproof button
Body material: Durable aircraft-grade aluminum
Surface treatment: Premium Type III hard-anodizing
Body Color: Black
Battery: 1* 14.4V 6800mah battery pack(built-in battery pack)
Waterproof: IPX-8( Max 100 meters)
Weight: 1189grams ( with battery pack); Underwater: 580grams( with battery pack)
With Short-circuit protection, Overcharge protection, over-discharge protection, low voltage protection, high
temperature protection Impact resistance: 1.5 meters
Package List: 1*Canister Light+2*O-rings+1*Battery Charger+1*Quick-release Glove +1*Goodman Handle+ 2*Battery
Ring+ 1*Hex Wrench+1*User Manual.
Battery Installation and Operation Instruction
Battery Installation: Tighten the battery pack by turning it clockwise until secure
A long button-press (about 2 seconds) to turn on/off the light.
Short press the button to switch the output Mid-High.
Triple-click the button to enter into Quick Flash and SOS lighting mode.
Double Press Into Stepless Dimming: Brightness cycles automatically from 100% to 1%. Single press the button to lock
the brightness and then switch off, the light will remember the last used brightness and starts with the remembered
brightness when you turn it on again.

Low Voltage Protection
When the battery voltage is less than 10%, the flashlight will flash three times and automatically jump into the low (10%
brightness). When the battery voltage is less than 2%, the flashlight automatically shut down to prevent the battery over
discharge.
Battery Indicator
There’s battery indicator light on switch , it’s light blue when power more than 70%; Light green when power at 70%-30%;
Light red when power less than 30%; Light red and slow flash when power less than 5%.
Battery Charging
When the battery power is low, it will automatically jump to low mode, please replace the battery in time; Twist the
flashlight body, cover the battery protection cover, with charger directly into the charging port,
Usage and Maintenance
If the flashlight will not be used for a long time, twist loose or remove the battery, cover the battery protection cover ,
stored in dry and ventilated place.
CL4200R powerful flashlight with strong heat, it’s underwater use only.
Please replace the O-rings if they are damaged after prolonged use and regularly the O-rings so as to not erode the
rubber. Doing so will keep the flashlight properly sealed against water.
Avoiding the possibility of seeping water, we suggest you tighten the flashlight before diving.
Please immerse the diving flashlight in the fresh water for few minutes after diving every time and clean the flashlight
after immersing, and put lubricating oil on the O-rings.
Please don’t drop or place your diving flashlight in sands, in case the sands go into the switch parts or screw threads
parts.
Please periodically clean the conductive contact surfaces, ensure the flashlight work normally.
Warning
The flashlight is high-intensity lighting device and capable of causing eye damage, please avoid shining the light directly into
the eyes, especially for children. Please charge it 1-2 times per every month if you don’t use it for a long time.
Warranty Service
All DIVEPRO flashlight are warranted for quality. Defective DIVEPRO flashlight will be repaired free of charge for a period of
24 months from the date of purchase.
The warranty is nullified in all of the following situations:
The product(s) is /are broken down, reconstructed and/or modified by unauthorized parties.
The product(s) is /are damaged through improper use.
The product(s) is /are damaged by leakage of batteries.
