Divio NBF232P User manual

Full HD Extreme WDR
Box Network Camera
NBF232P
User Manual
Version 1.3

http://www.diviotec.com
1
Table of Contents
1. Overview ................................................................................................................................ 2
1.1 Features ...................................................................................................................... 2
1.2 Package Contents ....................................................................................................... 3
1.3 Dimensions .................................................................................................................. 3
1.4 Connectors .................................................................................................................. 4
2. Camera Cabling ..................................................................................................................... 5
2.1 Power Connection ....................................................................................................... 5
2.2 Ethernet Cable Connection .......................................................................................... 5
2.3 Lens Mounting ............................................................................................................. 6
2.4 Alarm I/O Connection .................................................................................................. 6
2.5 RS485 Connection (for DC12V/AC24V/PoE Model) .................................................... 6
3. System Requirements........................................................................................................... 8
4. Access Camera ..................................................................................................................... 9
5. Setup Video Resolution ...................................................................................................... 12
Appendix A: Technical Specifications....................................................................................... 14
Appendix B: Delete the Existing DC Viewer .............................................................................. 16
Appendix C: Setup Internet Security ......................................................................................... 17
Appendix D: Back Focus Adjustment (Non-ABF) ..................................................................... 18

http://www.diviotec.com
2
1. Overview
The Full HD Multiple Streams Ultra-WDR Box IP Camera supports H.264 and
MJPEG standard. The performance of the H.264 encoder is up to 1080P 60fps.
Also, the camera supports Dual Full HD 1080P real-time streaming. With more
computing power, the camera can provide more flexibility for users and system
managers. In addition, the camera is equipped with Shutter WDR function,
which can provide better image quality under extreme light contrast scenarios or
changing lighting environments.
1.1 Features
 Sony Progressive Scan CCD/CMOS Sensor
 720P / 1.3M / 2M Resolution*
 C/CS Mount Lens
 Quad Streams support
 Dual Streams, Full HD 1080P Real-time + Full HD 1080P Real-time
 Quad Stream Compression- H.264 Baseline / Main / High Profile + MJPEG
 Multi-language Support
 Tampering Alarm
 Ultra Dynamic Range
 Motion Detection
 Privacy Masks
 3D Noise Reduction / 2D Noise Reduction
 Network Failure Detection
 Day / Night (ICR)
 Digital Image Stabilization (DIS)
 Auto Iris Lens Support
 Micro SD Support
 BNC Analog Output
 RS-485 Support*
 ONVIF Support
(*) Optional

http://www.diviotec.com
3
1.2 Package Contents
Please check the package contains the following items listed below.
Full HD Multiple Streams
Ultra-WDR Box IP Camera
Back focus adjuster
CD
(bundled software and
documentation)
Quick Guide
1.3 Dimensions
The IP camera’s dimensions are shown below.

http://www.diviotec.com
4
1.4 Connectors
The diagram below shows the IP Camera’s reset button and various connectors.
Definition for each connector will be given as follows.
DC 12V / PoE DC 12V / AC 24V / PoE
No.
Connectors
Definition
1
Audio I/O
Two-way audio transmission
2
Power LED
For power connection indication (green light)
3 Default Button Press the button with a proper tool for at least 20
seconds to restore the system.
4
Auto Iris
For auto iris lens connection
5
RJ
-
45
For network and PoE connections
6
Network LEDs
For network connection and activity indication
7 Alarm I/O
1 Output+ 5 GND
2 Output- 6 D-
3 Input+ 7 D+
4 Input-
8
BN
C
For analogue video output
9 microSD Card Slot
Insert the microSD card into the card slot to store
videos and snapshots. Do not remove the
microSD card when the camera is powered on.
10
Power (DC12V / AC 24V)
(AC 24V Model)
＋ DC 12V AC 24V 1
DC 12V Reserved AC 24V GND
－ DC 12V GND AC 24V 2
NOTE: It is not recommended to record with the microSD card for 24/7
continuously, as it may not be able to support long term continuous data
read/write. Please contact the manufacturer of the microSD card for
information regarding the reliability and the life expectancy.

http://www.diviotec.com
5
2. Camera Cabling
Please follow the instructions below to complete IP camera installation.
2.1 Power Connection
Please refer to section Connectors. Alternatively, users can power up the
camera by PoE if a Power Sourcing Equipment (PSE) switch is available. Refer
to the section below for Ethernet cable connection.
NOTE: If PoE is used, make sure PSE is in used in the network.
2.2 Ethernet Cable Connection
To have best transmission quality, cable length shall not exceed 100 meters.
Connect one end of the Ethernet cable to the RJ-45 connector of the camera,
and the other end of the cable to the network switch or PC. The RJ-45 port
networks without routing to the outside plant.
NOTE: In some cases Ethernet crossover cable might be needed when
connecting the camera directly to the PC.
Check the status of the link indicator and the activity indicator LEDs. If the LEDs
are unlit, please check the LAN connection.
Green Link Light indicates good network connection.
Orange Activity Light flashes for network activity indication.

http://www.diviotec.com
6
2.3 Lens Mounting
If use C-Mount lens, after removing the camera’s plastic cover, users need to
mount the C/CS Mount adapter to the camera. Then attach the lens onto the
C/CS Mount adapter, as the illustrations shown below.
C/CS Mount Adapter Completion
2.4 Alarm I/O Connection
The camera equips one alarm input and one relay output for alarm application.
Refer to alarm pin definition below to connect alarm devices to the IP camera if
needed.
DC 12V / PoE
PIN 1: Output+
PIN 2: Output-
PIN 3: Input+
PIN 4: Input-
DC 12V / AC 24V / PoE
2.5 RS485 Connection (for DC12V/AC24V/PoE Model)
The RS-485 connector is the interface for connecting with the pan & tilt
positioning system.

http://www.diviotec.com
7
PIN 6: D-
PIN 7: D+

http://www.diviotec.com
8
3. System Requirements
To perform the IP Camera via web browser, please ensure the PC is in good
network connection, and meet system requirements as described below.
Items System Requirement
Personal Computer
1. Intel® Pentium® M, 2.16 GHz or
Intel® CoreTM2 Duo, 2.0 GHz
2. 2 GB RAM or more
Operating System Windows VISTA / Windows XP / Windows 7
Web Browser Microsoft Internet Explorer 6.0 or later
Firefox
Chrome
Safari
Network Card 10Base-T (10 Mbps) or 100Base-TX (100 Mbps) operation
Viewer ActiveX control plug-in for Microsoft IE

http://www.diviotec.com
9
4. Access Camera
For initial access to the IP camera, users can search the camera through the
installer program: DeviceSearch.exe, which can be found in “DeviceSearch”
folder in the supplied CD.
Accessing the Camera by Device Search Software
Step 1: Double click on the program Device Search.exe.
Step 2: After its window appears, click on the <Device Search> button on the
top. All the finding IP devices will be listed in the page.
Step 3: Find the camera in the list by its IP address and click on it. The default
IP address of the camera is: 192.168.0.250.
Step 4: The default IP address of the camera may not be in the same LAN as
the IP address of the PC. If so, the IP address of the camera needs to
be changed. Right click on the camera and click <Network Setup>.
Meanwhile, record the MAC address of the camera, for future
identification.
Step 5: The <Network Setup> page will come out. Select <DHCP> and click
<Apply> down the page. The camera will be assigned with a new IP
address.
Step 6: Click <OK> on the Note of setting change. Wait for one minute to
re-search the camera.
Step 7: Click on the <Device Search> button to re-search all the devices. Find
the camera in the list by its MAC address. Then double click or right
click and select <Browse> to access the camera directly via a web
browser.
