Overview
Key
Features
▪
Support Intel 8th Generation Intel Atom
®
processor X series and Intel
®
Celeron® J series
▪Max. 32GB DDR4 supported
▪
Dual display of HDMI and DVI-I
▪2 x 3.5” SATA HDD support RAID 0, 1
▪1 x 2.5” SATA SSD/HDD, 1 x M.2 2242 SATA SSD
▪
1 x 10/100/1000 Intel
®
Ethernet
▪
1 x 2.5G Intel
®
Ethernet
▪
16
x
10/100
PoE
(240W
max
PSE)
▪Support TPM 2.0 onboard
▪Support eMMC onboard (option)
Chapter
1:
Product
Introduction
2
Hardware Specifications
CPU
Support
▪Intel 8th Gen Intel® Celeron® J6412, Quad Core, 2.0GHz base frequency,
2.6 GHz burst frequency (compatible with other Intel 8
th
Gen Intel Atom
®
(Elkhart Lake) processor X Series and Intel
®
Celeron
®
J Series)
Main Memory
▪Dual channel DDR4 3200 MHz SDRAM, max. 32GB
I/O Interface-Front
▪2 x USB 2.0 ports
▪
Power
&
HDD
status
LED
▪
PoE 16 ports status LED
I/O Interface-Rear
▪
2 x RJ45 (1 x 1GbE + 1 x 2.5GbE)
▪2 x USB 3.1 Gen1 ports
▪2 x USB 2.0 ports
▪
1
x
HDMI
2.0b
(supports
max.
resolution
4096
x
2160
@
60Hz)
▪
1 x DVI-I
▪
1
x
UART
port
(RS-232/485
setting
from
BIOS)
▪1 x Min-in & 1 x Line-Out & 1 x MIC
▪
Power
on/off
switch
▪
16 x Ethernet PoE port
-
802.3af/at
compliance
with
total
240W
max
(PSE)
-
802.3af
support
16
ports
@
15W
-
802.3at
support
8
ports
@30W
▪1 x 4DI/2DO (relay type) terminal block or 4DI/4DO GPIO DB15 port
(option)
Storage
▪2 x 3.5” SATA HDD support RAID 0,1
▪1 x 2.5” SATA HDD or SSD
▪1 x M.2 2242 Key B SATAIII
▪1 x eMMC 32GB (option)
Power Input
▪AC 100V~240V 410W power supply
Dimensions
▪
430mm
(W)
x
44.5mm
(H)
x
348mm
(D)
Environment
▪
Operating
Temperature:
Ambient with air flow: 0°C to 40°C
▪
Storage
temperature:
-20°C
to
70°C
▪
Relative
humidity:
10%
to
90%
(non-condensing)
Certifications
▪CE approval
▪FCC Class A
▪UL 62368 compliance
Chapter
1:
Product
Introduction
3
Knowing Your NRP14162
Series
Front
Panel
LED
Indicators
Indicates the power status of the system.
Indicates the status of the hard drive.
Dual
USB
Ports
Used
to
connect
USB
2.0
devices.
PoE LAN LED Indicators
Indicates the status of the LAN ports.
LED Indicators
PoE LAN
LED
Indicators
2x USB 2.0 Ports
Chapter
1:
Product
Introduction
4
NRP14162
Rear
Panel
1x
COM
(RS232/RS485)
Port
1x
COM
(RS232/RS485)
Port
(BIOS
Support)
Supports
RS232
and
RS485
compatible
serial
devices.
DVI-I
Used to connect a digital LCD panel.
HDMI
Used
to
connect
a
high-definition
display.
1.0 GbE RJ45/2.5 GbE RJ45
Used
to
connect
the
system
to
a
local
area
network.
2x USB3.1 Ports (Under 2.5GbE) & 2x USB2.0 Ports (Under 1GbE)
Four
USB
ports
to
connect
the
system
with
USB
devices.
Audio
Connectors
(Line
in/Line
out/MIC
in)
Line in: Receives audio signal input
Line out: Provides audio signal output
MIC-in:
Used
to
connect
an
external
microphone
16x
PoE
LAN
Ports
RJ45
Connectors
Enables communication among network clients and delivers power using
the same RJ45 to PoE-enabled edge devices.
Power
Switch/Power
Supply
SW
Press
to
power
on
the
device/Press
for
power
from
power
source.
100~240V
AC
Input
Used to plug a AC power cord.
1.0 GbE RJ45
2.5 GbE RJ45
16x PoE LAN Ports
1x PWR SW
Power
Supply
SW
DVI-
I
HDMI
Audio
Connectors
100~240V
AC
Input
2x
USB3.1
Ports
,
2x
USB2.0
Ports
Chapter
1:
Product
Introduction
5
430.00
478.00
92.00
92.00
22.00
106.00
Mechanical
Dimensions
Rackmount
Model
6.15
15.85
15.85
465.50 6.50
44.50
49.50
Chapter
1:
Product
Introduction
6
348.00
347.00
430.00
49.50
44.50
430.00
Mechanical
Dimensions
Desktop
Model
Chapter
1:
Product
Introduction
7
50.50
44.50
Mechanical
Dimensions
Wallmount Model
430.00
60.00
348.00
160.00
347.00
60.00
86.00
106.00
443.80
457.80
Chapter
2:
Jumpers
and
Connectors
8
C
HAPTER
2:
J
UMPERS
AND
C
ONNECTORS
This chapter describes how to set the jumpers and connectors on the
NRP14162 series motherboard.
Before You Begin
▪
Ensure you have a stable, clean working environment. Dust and dirt can
get into components and cause a malfunction. Use containers to keep
small components separated.
▪Adequate lighting and proper tools can prevent you from accidentally
damaging the internal components. Most of the procedures that follow
require only a few simple tools, including the following:
–
A Philips screwdriver
–
A flat-tipped screwdriver
–
A
set
of
jewelers
screwdrivers
–
A grounding strap
–
An
anti-static
pad
▪Using your fingers can disconnect most of the connections. It is
recommended that you do not use needle-nosed pliers to disconnect
connections as these can damage the soft metal or plastic parts of the
connectors.
▪
Before working on internal components, make sure that the power is off.
Ground yourself before touching any internal components, by touching
a metal object. Static electricity can damage many of the electronic
components. Humid environments tend to have less static electricity than
dry environments. A grounding strap is warranted whenever danger of
static electricity exists.
Precautions
Computer components and electronic circuit boards can be damaged by
discharges of static electricity. Working on computers that are still connected
to a power supply can be extremely dangerous.
Follow
the
guidelines
below
to
avoid
damage
to
your
computer
or
yourself:
▪Always disconnect the unit from the power outlet whenever you are
working inside the case.
▪
If possible, wear a grounded wrist strap when you are working inside the
computer case. Alternatively, discharge any static electricity by touching
the bare metal chassis of the unit case, or the bare metal body of any
other grounded appliance.
▪Hold electronic circuit boards by the edges only. Do not touch the
components on the board unless it is necessary to do so. Don’t flex or
stress the circuit board.
▪
Leave all components inside the static-proof packaging that they shipped
with until they are ready for installation.
▪
Use
correct
screws
and
do
not
over
tighten
screws.
Chapter
2:
Jumpers
and
Connectors
9
Jumper
Settings
A jumper is the simplest kind of electric switch. It consists of two metal
pins and a cap. When setting the jumpers, ensure that the jumper caps are
placed on the correct pins. When the jumper cap is placed on both pins, the
jumper is short. If you remove the jumper cap, or place the jumper cap on
just one pin, the jumper is open.
Refer to the illustrations below for examples of what the 2-pin and 3-pin
jumpers look like when they are short (on) and open (off).
Two-Pin Jumpers: Open (Left) and Short (Right)
Three-Pin Jumpers: Pins 1 and 2 are Short
Chapter
2:
Jumpers
and
Connectors
10
Locations
of
the
Jumpers
and
Connectors
The
figure
below
shows
the
location
of
the
jumpers
and
connectors.
FAN2
CN3
CN1
CN2
PWR_SW1
CN14
CN15
CN12
CN11
CN10
CN9
CN8
CN7
CN6
CN5
CN4
JP1
Chapter
2:
Jumpers
and
Connectors
11
Jumpers
Clear
CMOS
Connector type: 1x3 3-pin header
Connector location: JP1
1 3
Pin
Settings
1-
2
Normal
2-
3
Clear CMOS
1-2 On: default
Chapter
2:
Jumpers
and
Connectors
12
Connector
Pin
Definitions
External I/O Interfaces
LAN1
Connector
and
USB
3.1
Ports
Connector
type:
RJ45
port
with
LEDs
Dual USB3.1 ports
Connector location: CON3
ACT LINK
LAN2
Connector
and
USB
2.0
Ports
Connector
type:
RJ45
port
with
LEDs
Dual USB2.0 ports
Connector location: CON4
ACT LINK
Link
Status
Steady
Green
1Gbps network link
Steady
Orange
100Mbps network link
Off
10Mbps or no link
Link
Status
Steady
Green
2.5Gbps network link
Steady
Orange
1000Mbps network link
Off
100Mbps or no link
Act
Status
Yellow
Data activity
Off
No activity
Act
Status
Yellow
Data activity
Off
No activity
Chapter
2:
Jumpers
and
Connectors
13
Pin
Definition
Pin
Definition
1
DVI_D2_N
2
DVI_D2_P
3
DVI_CHECK
4
NC
5
NC
6
DVI_DDC_SCL
7
DVI_DDC_SDA
8
VGA_VSYNC_C
9
DVI_D1_N
10
DVI_D1_P
11
GND
12
NC
13
NC
14
+DVI_5V
15
GND
16
DVI_HPD_C
17
DVI_D0_N
18
DVI_D0_P
19
GND
20
VGA_DDCCLK_C
21
VGA_DDCDATA_C
22
GND
23
DVI_CK_P
24
DVI_CK_N
25
SP1_DCD_N
26
SP1_RXD
27
SP1_TXD
28
SP1_DTR_N
29
GND
30
SP1_DSR_N
31
SP1_RTS_N
32
SP1_CTS_N
Pin
Definition
Pin
Definition
33
SP1_R1_N
C1
VGA_RED_C
C2
VGA_GREEN_C
C3
VGA_BLUE_C
C4
VGA_HSYNC_C
C5A
VGA_GND
C5B
GND
DVI-I
and
RS485
Connector
Connector
location:
CON1
25 29
30 33
1 8
17 24
C1 C2
C3 C4
Chapter
2:
Jumpers
and
Connectors
14
HDMI Connector
Connector type: HDMI
Connector location: CON2
Audio Connectors
Connector
location:
AUDIO1
Line-
in
19
1
Line-out
18 2
Mic-in
Pin
Definition
Pin
Definition
1
HDMI_TX2_DP_CM
2
GND
3
HDMI_TX2_DN_CM
4
HDMI_TX1_DP_CM
5
GND
6
HDMI_TX1_DN_CM
7
HDMI_TX0_DP_CM
8
GND
9
HDMI_TX0_DN_CM
10
HDMI_CLK_DP_CM
11
GND
12
HDMI_CLK_DN_CM
13
NC
14
NC
15
HDMI_RT_SCL_SNK
16
HDMI_RT_SDA_SNK
17
GND
18
V5P0_HDMI
19
HDMI_RT_HPD_SNK
Chapter
2:
Jumpers
and
Connectors
15
PoE
LAN
8
Ports
RJ45
Connector
Connector type: Phone Jack RJ45 2x4 Port PoE
Connector location: CON5
PoE
LAN
8
Ports
RJ45
Connector
Connector type: Phone Jack RJ45 2x4 Port PoE
Connector location: CON6
10
12
14
16
8 1
1 8
8
1
1
8
8
1
1
8
8
1
1
8
9
11
13
15
2
4
6
8
8
1
1
8
8 1
1 8
8
1
1
8
8
1
1
8
1
3
5
7
Chapter
2:
Jumpers
and
Connectors
16
Power SW Connector
Connector type: 1x2 2-pin header
Connector location: PWR_SW1
1 2
Pin
Definition
Pin
Definition
1
GND
2
PWRBTN_N
Chapter
2:
Jumpers
and
Connectors
17
Pin
Definition
Pin
Definition
1
P_GND_D
2
P_GND_D
3
DC JACK IN P
4
DC JACK IN P
Pin
Definition
Pin
Definition
1
5.0V
2
GND
3
GPIO80
4
GPIO84
5
GPIO81
6
GPIO85
7
GPIO82
8
GPIO86
9
GPIO83
10
GPIO87
Internal Connectors
54V Power In Connector
Connector type: 2x2 4-pin header
Connector location: CN11
GPIO
Connector
Connector type: 2x5 10-pin header
Connector location: CN5
10 9
2 4
1 3
21
Table of contents
