DYGSM Alarm System User Manual
Preface
Esteemed Guests：
Thank you for using our GSM Alarm System. For a better understanding
of this product, pls. read this user manual thoroughly before using it.
In addition , keep this instruction manual so that you may read it at anytime
when necessary
Copyright:
zThe device is protected by patent right at home and abroad.
zthe Company reserves all the right to interpret.
www.deltasecurity.cn

DYGSM Alarm System User Manual
————————————————————————————————————— 1 ———————————————————————————————————————
Cautions
To avoid personal Injury and the damage to the product, Please take the following preventive measures.
z【Input voltage】：DC12V 1A;
z【Using the professional tools for Assembling to avoid the damage to the main Panel】.
z【Press the touch keypad lightly】
z【Keep it away from the moist environment】
z【This product should not be place in flammable explosive environment】.
z【Keep the Product dry & clean】.
z【Keep the product in a well-ventilated place】.
【Functions & Advantages】:Features (as short as possible)
1: Ultra-thin design with Unique Touch keypad ,stylish appearance。
2: Arm/Disarm by RFID Card , which can be Named easily.and the main panel will Send SMS to the preset phone numbers when the setting is completed.
3: Easy to operate with in-built input systems.
4: Easy to control the Host by your mobile with In-Built Bluetooth function up to100 meters In open place, (it works may up to 60 meters in the house )
5. Adjustable Volume of the Main Panel up to 8 levels..
6: Up to 50 Defense Zones，each defense zone can be coded with Remote Controller or other sensors/detectors, also they Can be named individually.
7: With the function ofAutomatic detection for the Doors/Windows ,the Main Panel Keeps Indicating while arming the system if any Door/Window is
open ,100% Security Guaranteed.
8: With the wireless Siren indicating, You will know the status of the alarm System
9：In order to operate the Alarm system quickly, you can set one preset telephone number as the owner’s number , which can access to the Main Panel without
Password.
10: No need to replace the battery up to 3 years for the Ultra-low power consumption.
11: With the self-checking function, Reminder will be sent when the battery is low and should be replaced.
12: Support CID
13: New feature of Voice Prompt: The music goes on from the Main Panel when someone opens the door.
14: In-built USB Slot: Easy to update the software for the latest functions and services.
15: In-built Engineering model：Easy for the malfunction examination & better maintenance.
www.deltasecurity.cn

DYGSM Alarm System User Manual
————————————————————————————————————— 2 ———————————————————————————————————————
Chapter 1: Alarm Host Diagram
【GSM Signal Indicator】：No SIM card or searching network: flashes once every second ;GSM Signal in normal: Flashes once every 3 seconds
【RF Signal Indicator】: Flashes while sending or receiving RF signals
【LCD Screen】：Display System Menu & Information.
【RFID Card Reader】：for the RFID card reading。
【Menu Operation Buttons】：To adjust the settings in the Options menu.
【Out Arm】: Press the [Out Arm] button, then input the password to Arm the System.
【Home Arm】: Press the [Home Arm] button, then input the password to Make the system into Home Mode.
【Disarm】: Press the [Disarm] button, then input the password to disarm the system.
【Emergency/SOS】: Press the [Emergency/SOS] button, the Host alarms and calls the preset phone numbers.
【Land Wire Slot】: For the A/C power cord.
【MIC】For a better effect, speak at 35cm away from the Host.
【Tamper Switch】：Fix the backplane firstly, then Hang up the Host .
【SIM Card Slot】：To insert SIM Card before using.
【Debugging Interface】：For the Collecting information from the host and Correction Program by Manufacturer as well.
【Battery Case】: For the back-up batteries.
【Upgrading switch】：Turn on the switch before updating the alarm system.
www.deltasecurity.cn

DYGSM Alarm System User Manual
————————————————————————————————————— 3 ———————————————————————————————————————
【Power switch】: Power on / off the back-up batteries.
【USB Slot】: For A/C adapter and upgrading system as well.
【Interface for the wired Defense Zones】:2 inputs for wired sensors.(2 Wired Defense Zones)
【Loudspeaker】.
Chapter 2：Operation Instructions
Note: Please follow the instructions on the LCD screen, then press the button accordingly.
MUTE Switch off the sound VOL+ Turn the volume up VOL- Turn the volume Down
MENU Menu BACK Return DOWN Page down
UP Page Up ENTER OK SAVE Save
ABC/abc/123 Switching the Input method DELETE Delete the setting
Note: You can NOT make any settings until into the set up state, here are the steps as belows:
MENU→Select Program→ENTER→Input the password（888888）→into setup state→Making settings
1. Alarm Phone number/SMS Receiving Number Settings
①In Setup state→Select [DOWN] →Select Phone Numbers/SMS Numbers→select [ENTER]。
②Select [Add] →Select [ENTER]
③Input the phone number→select[SAVE]→“SET Successful” displays on screen,which indicates the number is set successfully.
④Select [BACK] to Exit.
www.deltasecurity.cn

DYGSM Alarm System User Manual
————————————————————————————————————— 4 ———————————————————————————————————————
No:1
No:2
2. Coding of Remote Controllers & Sensors/Detectors
①In Setup state→Select [Remote Controllers/Sensors] →select [ENTER]
②Select [Add] →Select [ENTER]
③Press any button on Remote Controller or Trigger the Sensor/Detector for coding→Series Code of the sensor displays on the screen→Select [Save]
④Name the Remote Controller or Sensor/Detector→Select [SAVE] to next step
⑤Select [RECORD] to Record the name of the Remote Controller or Sensor/Detector，also the position where it is.
→“SET Successful” displays on screen, which indicates the coding successfully.
⑥Select [BACK] to Exit
No:1
www.deltasecurity.cn

DYGSM Alarm System User Manual
————————————————————————————————————— 5 ———————————————————————————————————————
No:2
3. Wireless Siren Setting
①In Setup state→Select [Wireless Sirens] →Select [ENTER]。
②Select [Add] →Select [ENTER]
③The Wireless siren will be named Sirens 1 by the Host→Select [ENTER]
④“Put Siren In setting Mode” displays on screen →Switch on the Wireless siren ,and then press the [add remote] on the siren.
⑤Select [ENTER] →The Siren emits a Long Beep →“SET Successful” displays on screen, which indicates the coding successfully.
⑥Select [Back] to Exit.
4. Coding of RFID Card
①In Setup state→Select [RFID] →Select [ENTER]
②Select[Add] →Select [ENTER]
③Have the RFID card close to the RFID Card Reader Zone→Series Code of the sensor displays on the screen→Select [Enter] to next step
④Name the RFID Card ,Select the [Save] to store the Name→“SET Successful” displays on screen, which indicates the coding successfully.
⑤Select [Back] to Exit.
www.deltasecurity.cn

DYGSM Alarm System User Manual
————————————————————————————————————— 6 ———————————————————————————————————————
5. Pair the Host with your Mobile phone Via Bluetooth
①Install the APP provided by Manufacturer (Please refer to your mobile user manual for installing)
②Enabling The APP on your Mobile, input the Alarm Host information, including SIM card Number, Operation Password etc.(Please refer to the APP User
Manual)
③Click the Bluetooth Scanning button on your Mobile→The Host name displays on your mobile after scaning→Click the Host Name for pairing(Please refer
to the APP User Manual)→“Bluetooh Pair Request” Displays on the Host Screen →Click [Accept] on the Host
④Now you can control the Alarm Host by your mobile phone(Please refer to the APP User Manual)。
⑤Select [Back] to Exit.
Notes：
You will have to pair every mobile phone to the Host again if you format the system;
The Host can be paired up to 8 mobile phones;
To avoid the malicious interference, Please make the Host on the status of Invisible if there is no need to pair new mobile →Just Select【No】.
And when you need to pair new mobile, just select【Yes】to make the Host Visible.
With the function of Automatic detection for the Doors/Windows ,the Main Panel Keeps Indicating while arming the system if any Door/Window is
open ,100% Security Guaranteed.
6. To Enable the Auto Search Sensor
Notes:
www.deltasecurity.cn

DYGSM Alarm System User Manual
————————————————————————————————————— 7 ———————————————————————————————————————
a).Works for Door Sensors Only;
b).After Enabling the Function, You will have to Press & Hold the [Out Arm] or [Home Arm] button for 3 seconds to arm the system if any Door/Window is open.
Otherwise, you can not Arm the system;
c).For sure, you can arm the system easily without enabling the function.
①In setup state,→Select [Sensors] →Select [ENTER]
②Select [Edit] →Select [ENTER]
③Select [Auto Search Sensor] →Select [ENTER] →Triggering the Door Sensor you would like to Enable the function →Select [ENTER] when the Sensor’s
name displays on the Host screen;
④Select [DOWN] →Select [Chime Zone] →Select [ENTER]
⑤Select [UP] →Select [Yes] →Select 【SAVE】→Enable theAuto Search Sensor successfully when you see the 【√】on The Host Screen
⑥Select【BACK】to Exit.
7. Query the IMIE Code
①In Setup state→Select [Down] →Select [SystemAbout] →Select [ENTER]
②Select[DOWN] →Select [IMEI] →Select [ENTER]
③IMIE Code[15 digitals] will display on the Screen.
8. How To Use the CID Function?
The Standard ADMECO Contact ID Protocol was used in the Alarm System.
Firstly, You need to get a telephone number & User ID from your Service Provider .
www.deltasecurity.cn

DYGSM Alarm System User Manual
————————————————————————————————————— 8 ———————————————————————————————————————
And input them into the Alarm Host. In addition, Setting up the Host to upload Alarm Data & Arm/Disarm Data is needed.Now,your Service provider can
Monitor your alarm System for you.
8.1 Set up the Monitoring Center Number
①In set up state →Select [Monitoring Center] →Select [ENTER]
②Select [Monitoring Center Number] →Select [ENTER]
③Select [Add] →Select [ENTER]
④Select [Phone#1] or [Phone#2] →Select [ENTER]
⑤Input the Monitoring Center Phone number →Select [SAVE] →“SET Successful”
8.2 Set up the Contact ID
①In Setup State →Select [Monitoring Center] →Select [ENTER]
②Select [ADMECO Contact id] →Select [ENTER]
③Input ID number[4-digitals] →Select [SAVE] →“SET Successful”
8.3 Set up to upload theAlarm data to the Service Provider
①In Setup State →Select [Monitoring Center] →Select [ENTER]
②Select[Upload Alarm Data] →Select [ENTER]
③Select [Yes] →Select [SAVE] →“Set Successful”
④Select [BACK] to Exit.
www.deltasecurity.cn

DYGSM Alarm System User Manual
————————————————————————————————————— 9 ———————————————————————————————————————
8.4 Set up to upload theArm/Disarm Date to Service Provider
①In Setup State →Select [Monitoring Center] →Select [ENTER]
②Select [Upload Arm/Disarm Data] →Select [ENTER]
③Select [Yes] →Select [SAVE] →“Set Successful”
④Select [BACK] to Exit.
Chapter 3: Accessories
1. Wireless Remote Control
