Divis MPG12004 User manual

Rev. 1.2
Digital Video Security System
Digital Video Recorder
www.DiViSdvr.com
Chance-iUSA Corp.
*All contents of this document may change without prior notice.
DiViS DVR – MPG Series
Hardware Installation Guide

1DiViS
CHANCE-
i
USA Cor
p
www.DiViSDVR.com
1. Specification of DiViS  3
2. Products and components  5
2-1. DVR Board  5
2-2. Accessories  5
3. Board Description  6
3-1. DiViS MPG12004  6
3-2. DiViS MPG24008  6
3-3. DiViS MPG48016  7
4. Installation  8
4-2. DiViS MPG12004 Installation  8
4-3. DiViS MPG24008 Installation  9
4-3-1. Pigtail type  9
4-3-2. Back panel type  10
4-4. DiViS MPG48016 Installation  11
4-4-1. Pigtail type  11
4-4-2. Back panel type  12
5. Accessories  13
5-1. Back panel  13
5-2. Pigtail for MPG12004  14
5-3. Pigtail for MPG24008  14
5-4. Sensor Board  14
5-5. RS-232 to RS-485 Converter  15
5-6. PORT Converter  16
5-6-1. Specification  16
5-6-2. Layout Description  16
5-6-3. Baud Rate  17
5-6-4. Jumper Selection  17
INDEX

2DiViS
CHANCE-
i
USA Cor
p
www.DiViSDVR.com
This is a guide book that explains the hardware components and provides you the step by
step installation of DVR board.
For the software explanation, please refer to “Installation and User’s Guide”.
This guide book is applicable to, among DiViS products, DiViS MPG12004, DiViS MPG24008,
and DiViS MPG48016 board.
The pictures and names of the products are subject to change depending on hardware
upgrade. However, the usages may be similar.
For any question you have, please contact to the following address. When you are sending
your concerned matter, please include your company name and phone number with detail
description.
E-mail: [email protected]
Tel: [phone]
Fax: [phone]
www.divisdvr.com
Preface

3DiViS
CHANCE-
i
USA Cor
p
www.DiViSDVR.com
1~16 Camera Inputs / Output
Up to 16 camera inputs are available on screen for digital handling.
Normal input condition: 75 Ohm, 1 Volt ( p-p )
1~16 Sensor Inputs
Up to 16 sensors can be linked to the system.
External DC 12 Volt power must be provided to the sensor input from outside.
1~8 Digital Outputs (Relay Outputs)
Digital Outputs can be used to activate things like shutters and sirens, and activation can be linked to sensor
and motion detection.
Sound Recording and Two-Way Communication Capabilities
Sound can be recorded with video images. Two-way communication is possible between DiViS main and
DiViS Net.
Display Features (w/ Multi-Viewing)
Multi-Viewing allows 1, 4, 6, 9, or 16 different camera shots to be displayed onscreen at the same time.
Other display features include enlarging all displayed cameras or just one.
PAN/TILT/ZOOM/FOCUS Capabilities
Each connected camera can be manipulated through the DiViS main program as long as each camera
supports such capabilities.
Auto Rebooting System
When DiViS detects an error or malfunction within the system, it will automatically reboot the system in order
to correct it.
Motion Detection and Sensor Trigger
Detection features make it possible to record images only when movement is detected, preserving volume
space and maximizing the use of physical storage space.
1. S
p
ecification of DiViS

4DiViS
CHANCE-
i
USA Cor
p
www.DiViSDVR.com
Scheduled Recording
Scheduling allows the administrator to record images only during designated time periods, if so desired.
Every combination of scheduling is available in the DiViS program.
Manual and Auto Backup
Data can be preserved through various formats (DAT, CD, or DVD) and data from specific cameras and/or
time periods can be specifically isolated for backup as well. Much like scheduled recording, backup of data
can be scheduled as well.
Digitalized Video Search
Recorded data features digital playback for each camera simultaneously or one at a time. Playback features
include advanced search features and image extracting, which allows portions of existing video to be
extracted and saved as a separate file.
Network Support (PSTN, TCP/IP, LAN , Modem Protocol Support)
DiViS supports network access, which allows administrators to login to DiViS main and remotely access all
the features provided locally.
POS, Access Control, ATM Support
Data from external devices (POS, Access Control, ATM, etc) can be recorded with DVR video images. Text
Search allows to search data from external devices with DVR video image when event occurs. This will raise
the level of integrity and security.
Feature MPG Series
Camera Input 1~16Port(NTSC/PAL)
Sound Input 1~16 Port
Sensor Input 1~16 Port
Relay Output 1~8Port
Composite Output 1 Port (NTSC/PAL, 1 Channel Switching)
Image Format Hardware MPEG-4
Recording Mode Watch, Normal, Motion Detection, Sensor, Scheduled Recording
Remote Control Full remote control PSTN, ISDN,ADSL, LAN and TCP/IP
Back-up DAT, CD, DVD
PAN/TILT/ZOOM/FOCUS RS-232/422/485 Interface
* Note: MPG48016 consists of 2 of MPG24008 boards.

5DiViS
CHANCE-
i
USA Cor
p
www.DiViSDVR.com
2.1 DiViS MPG Series Board
DiViS MPG12004 DiViS MPG24008 DiViS MPG48016
(2 of MPG24008)
2.2 Accessories
Video Pigtail Cable Audio Pigtail Cable RS-485 Board RS-232C Cable
Sensor Port Sensor Cable Back Panel (Optional) Video Cable (Optional)
Reset Cable
2. Products and Com
p
onents

6DiViS
CHANCE-
i
USA Cor
p
www.DiViSDVR.com
3-1. DiViS MPG12004
3-2. DiViS MPG24008
3. Board Descri
p
tion

7DiViS
CHANCE-
i
USA Cor
p
www.DiViSDVR.com
3-3. DiViS MPG48016
Master
Slave

8DiViS
CHANCE-
i
USA Cor
p
www.DiViSDVR.com
4-1. DiViS MPG12004
1) Connect video pigtail cable to the port.
2) Connect audio pigtail cable to the port.
3) Sensor cable connects to Sensor port.
4) The other side of sensor cable connects to IO socket on the DVR board.
5) Connect Watchdog cable. Make Watchdog cable connection as shown below
.
4. Installation
1
2
3
5
4

9DiViS
CHANCE-
i
USA Cor
p
www.DiViSDVR.com
4-2. DiViS MPG24008
4-2-1. Pigtail Type
1) Connect video pigtail cable to the port.
2) Connect audio pigtail cable to the port.
3) Sensor cable connects to Sensor port.
4) The other side of sensor cable connects to IO socket on the DVR board.
5) Connect Watchdog cable. Make Watchdog cable connection as shown below
.
1
2
3 4
5

10 DiViS
CHANCE-
i
USA Cor
p
www.DiViSDVR.com
4-2-2. Back Panel Type
1) Back panel.
2) Sensor Cable.
3) When connect cable to back panel make sure to leave one pin from right end.
White cable should be facing up.
4) Connect video cable with BNC2 label.
5) Connect another group of cable from video cable with BNC2 label.
6) Connect Watchdog cable. Make Watchdog cable connection as shown below
1
2
1
4 6
3
1
5

11 DiViS
CHANCE-
i
USA Cor
p
www.DiViSDVR.com
4-3. DiViS MPG48016
4-3-1. Pigtail Type
1) ~ 4) Connect video & audio pigtail cable to the port.
5) ~ 8) Sensor cables connect between Sensor boards and IO socket on the DVR boards.
9) Connect Watchdog cable.
10) Connect between Master and Slave. Without this connection, only master gives TV-out.
1 2 5 6
9
3 4 7 8
10
10

12 DiViS
CHANCE-
i
USA Cor
p
www.DiViSDVR.com
4-3-2. Back Panel Type
1) Back panel.
2) Sensor Cable connects to the back panel. (right below video connection)
3) The other side of sensor cable connects to IO socket on the DVR board.
4) When connect cable to back panel make sure to leave one pin from each end.
White cable should be facing up.
5) Connect video cable with BNC2 label.
6) Connect video cable with BNC9 label.
7) Connect between Master and Slave. Without this connection, only master gives TV-out.
8) Sensor Cable connects to the back panel. (left side of the other connection)
9) The other side of sensor cable connects to IO socket on the DVR board.
10) Connect Watchdog cable.
1
3
1
5 10
2
1
6
4
7
98
4
4

13 DiViS
CHANCE-
i
USA Cor
p
www.DiViSDVR.com
5-1. Back Panel
Camera I/O
Camera Ground 3, 5, ~ 31, 33
Camera Signal 4, 6, ~ 32, 34
TV Out Ground 1
TV Out Signal 2
Sensor & Relay (Digital I/O)
Sensor Input 9 ~ 16 1 ~ 8
Input Common 1, 2 17, 18
Relay Output 1 ~ 4 19 ~ 22
Output Common 1, 2 23, 24
Sensor & Relay (Digital I/O)
Sensor Input 1 ~ 8 1 ~ 8
Input Common 1, 2 17, 18
Relay Output 5 ~ 8 19 ~ 22
Output Common 1, 2 23, 24
5. Accessories

14 DiViS
CHANCE-
i
USA Cor
p
www.DiViSDVR.com
5-2. Pigtail for MPG12004
5-3. Pigtail for MPG24008
5-4. Sensor Board (8 channel)
Sensor port pin number
1 ~ 8: Signal input
G: Ground
4, 3, 2, 1: Relay output
Note: For MPG12004, signal input only available 1 ~ 4.
For MPG48016, use 2 sensor boards. Refer to the connection diagram on section 4-3.

15 DiViS
CHANCE-
i
USA Cor
p
www.DiViSDVR.com
5-5. RS232 to RS422/485 Converter
1) Connect to system’s Com port.
2) Connect to PTZ port converterRS-485.
3) These are power supply sockets. Need to connect only one of them.
Dip Switches
RS-485 Mode RS-422 Mode
1
2
3
3
5Si
g
nal
4
+ RxData3- RxData
2+ TxData1- TxData
* Use Rx+ and Rx-
for RS 485 method.

16 DiViS
CHANCE-
i
USA Cor
p
www.DiViSDVR.com
5-6. PORT Converter
5-6-1. Specification
RS-232 from POS DB9 Female
Input Parallel Port from POS DB25 Male
RS-232 to Printer DB9 Male
Serial RS-485(S) to DVR TX(+)(-), RX(+)(-), GND
Parallel Port to Printer DB25 Female
RS-232 to DVR DB9 Male
Output
Parallel
RS-485(P) to DVR TX(+)(-), RX(+)(-), GND
Power DC 5V
RS-232 from POS DB9 Female to DB9 Male Direct
RS-485(S) to DVR DB9 Female to DB9 Female Cross
Serial
RS-485(P) to DVR DB9 Female to DB9 Female Cross
Parallel Port from POS DB25 Male to DB25 Female Direct
Cable
Parallel Parallel Port to Printer DB25 Female to IEEE 1284
5-6-2. Layout Description
1, DC IN 5V
2, Rs-232 From POS : Connect to the serial port in POS
3, Baud rate : Select the Baud rate
4, Parallel Port from POS : Connect to the parallel port in POS
5, Parallel Port to Printer : Used by Parallelprinter
6,RS-232toDVR:UsedbySerialportinDVR
7, RS-485(P) to DVR : Used by RS-485 board in DVR
8, Rs-232 to Printer : Used by Serial Printer
9, Rs-485(S) to DVR : Used by RS-485 board in DVR

17 DiViS
CHANCE-
i
USA Cor
p
www.DiViSDVR.com
10, Terminal Block
11, SW1, SW2: Used in output of Parallel port 12, SW3, SW4: Used in output of Serial
5-6-3. Baud Rate
5-6-4. Jumper Selection
Output of parallel port Output of serial port
5Signal
4+ RxData3- RxData
2+ TxData1- TxData
