Divis CH03202 User manual

CH 03202
Day & Night Vandal DOME Camera
Diagram
Caution
1. Do not attempt to disassemble the camera.
In order to prevent electric shock, do not remove screws or cover.
2. Handle the camera with care.
The camera could be damaged by improper handling or storage
3. Do not expose the camera to rain or moisture, or try to operate in wet
areas.
Take immediate action if the camera becomes wet. Turn the power off and
request service to qualified personnel. Moisture can damage the camera and
also create a risk of electric shock.
4. Do not use strong or abrasive detergents when cleaning the camera body.
Use a dry cloth to clean the camera when dirty. In case the dirt is hard to
remove, use a mild detergent and wipe gently.
5. Never point the camera toward the sun.
Whether the camera is used outdoor or not, never point it toward the sun. Use
with caution when operating the camera in the vicinity of spot lights or other
bright lights and light reflecting objects.
6. Do not operate the camera beyond its temperature, humidity, or power
source ratings.
Do not use the camera in an extreme environment where high temperature or
high humidity exists. Use the camera under conditions where temperatures are
between 14 F~122 F (-10 C~+50 C), and humidity is below 85%,
SA 1965
The symbol is intended to alert the user to the presence of uninsulated "dangerous voltage" within the
product's enclosure that may be sufficient magnitude to constitute a risk of electric shock to persons.
To prevent electric shocks and risk of fire hazards,
DO NOT use other than specified power source.
CAUTION:
!
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE
COVER OR BACK. NO USER SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
To prevent fire or shock hazard, do not expose the unit to rain or moisture. The symbol is intended to alert
the user to the presence of important operating and maintenance (servicing) instructions in the literature
accompanying the appliance.
SA 1966
!
WARNING
CAUTION
This equipment has been tested and found to comply with the limits for a Class A. Digital
device. Pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with
the instruction manual, it may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be required
to correct the interference at own expense.
Any changes or modifications in construction of this device which are not expressly
approved by the party responsible for compliance could void the user's authority to operate the equipment.
oooo
Installation & Connection
1. Place a camera to installation on
the wall / ceiling.
2. Drill three holes accordingly to insert
anchors into the drilled holes.
3. Draw out power /video wires to the
connecting places.
4. Fix the housing base by screws on
the ceiling.
5. Adjust desired focus and scene by
turning and moving the hemisphere
by hand.
6. Put the dome cover over the base.
7. Fix the dome cover on the base
using L-Wrench.
L-Wrench
SCREW M4x20 3EA
SCREW TP1 4x30 3EA
P.C.D Ø115
Plastic Anchor
#
1
#
2
No.
#1
#2
Function
Video Output
Power Input
Remark
1.0 Vp-p
Terminal Color
Yellow
B & R
Video
(Yellow)
Power -DC12V
(Black & Red)
Video Output
GND
Built-in camera bracket will make
it much easier to rotate in any direction.
4
-
axis
Connecting to Monitor and Power
- The wire is polarized.
- Use DC 12V power source.
Installation
Owner's Manual
Mounting Screw Plastic Anchor
Focus Driver
Dome Camera
L-Wrench
Composition
4
3
2
1
VIDEO
AC 24V
J503
LR
UP
DOWN
Function Selection Switch
Moving Selection Switch
[LEFT, RIGHT, UP, DOWN]
Service Monitor Connector:
Use service monitor
connector to set camera
angle & focus when installing
DC12V ±15%
1
1
2
3
2
3
4
-
axis
IP 65

Summary
Setup Menu
Lens DC / Manual DC: Auto iris lens, Manual: Fixed iris lens
Shutter Auto / Fixed /
Manual / FLK
AUTO: Brightness adjustable
(Only for manual mode)
FIXED: 1/60,1/100,1/250,
1/500,1/2,000, 1/5,000,1/10,000,
1/100,000sec selectable
MANUAL: 1/60 ~ 1/100,000sec(256steps)
FLK: Flickerless
OSD Menu Structure 1
Mode
BLC
ON Mode - BLC AREA : 64 areas selectable
- BLC RATIO : 64 steps adjustable
Off / On
AGC
256 steps adjustable
On / Off
White Bal.
ATW : One Push
AWB : 2,500K ~ 9,500K
FIXED : 2,500K ~ 6,500K ( Mode 1 ~ 4)
ATW / AWB /
FIXED /
MANUAL
Function
(Structure 2)
Refer to the
next Table
Exit
Saves all the SETUP Menu and then exits-
Adjust Contrast /
Sharpness /
CB_Gain /
CR_Gain
CONTRAST : 256 steps adjustable
SHARPNESS : 32 steps adjustable
B/W 550TV LINE
Model CH 03202
Specification
1/3" CCD [Sony SUPER HAD II CCD]Image Sensor
768(H) x 494(V) PIXELEffective Pixel
6.35μm(H) x 7.4μm(V)
Cell Size
HORI. Color 530TV LINE
Resolution
NTSC
TV Type
INTERNAL
Sync. Type
2:1 Interlace
Scanning System
15.734 KHz
Scanning Frequency H.
59.94 Hz
Scanning Frequency V.
1.0 Vp-p (Sync. Negative) Termination 75
Video Out
0.1 Lux at Color (F1.2)
Min. Illumination
45dB or More (AGC OFF)
S/N Ratio
Auto
Gain Control
1/60 ~ 1/100,000 sec
Shutter
AVERAGE TEST ILLUMINANCE BY FRONT VIEWTest Illumination Area
140mA MaxCurrent Consumption
Regulated DC12V
± 15%
Supplied Voltage
YES
Reverse Polarity Protection
2.8~11mm
Lens
-10 ~ 50 °C
Operation Temp / Humidity
-20 ~ 60 °C
Preservation Temp / Humidity
153mm(W) X 105.2mm(H)
Dimension
Approx. 1.2kg
Weight
Troubleshooting
If you have a trouble operating your camera, refer to the following.
If the guidelines do not enable you to solve the problem, contact an
authorized technician.
The image does not
appear on the screen.
Check the power source for the monitor and camera
and assure that the voltage and polarity are properly
connected and being supplied correctly.
The image on the
screen is dim.
Check if the lens is stained. If dirty, clean the lens
with a soft, clean cloth.
Adjust the Back Focus of the lens again.
The surface of the
camera case is hot and
a black line appears on
the screen.
Check if you have connected the camera to a proper
power source and if there is no problem with the power,
turn the unit off immediately and seek assistance from
our After Service department.
Check if the camera is pointed toward the sun or a
fluorescent lamp.
Adjust the angle or location of the camera if too much
light is coming into the screen.
The screen blinks a lot.
Setup Menu Summary
Camera ID
English capital letter,
Numeral 0~9, 28
special letters with
blank
Maximum length for display is limited to 15
letters
Position is selectable
Mirror Off / On Set a horizontal image inversion
OSD Menu Structure 2
Mode
Day & Night
ON AUTO Mode
- DELAY,START LEVEL,END LEVEL :
adjustable
- MANUFACTUR VALUE : START 1.5Lux,
END 7Lux
COLOR: COLOR fixed
B/W : B/W fixed - BURST signal is
removable on B/W mode
Auto / Color / B/W
Motion
ON Mode
- 64 area selectable
- Push the set button for seconds after
areas select
- THRESHOLD : Audjust Motion detect
sibility (256steps)
- MOTION TRACE : ON/OFF
Off / On
Gamma Default value is 0.45
0.05 ~ 1.00
Adjustable
Privacy
ON Mode: 4 Programable zones
(Size,Position,Contrast)
Off / On
Language
Set the language on setup menu
English/Korean/
Japanese/Chinese
Reset
Return to the factory mode
-
Return
Save the function menu and return to the
SETUP menu
-
= 0.45typ.
Gamma Characteristic
Ȗ
Day & Night Vandal Dome CameraType
CB_GAIN : 256 steps adjustable
CR_GAIN : 256 steps adjustable
