Divis CH 03204 User manual

CH 03204
Day & Night Vandal DOME Camera
Diagram
Caution
1. Do not attempt to disassemble the camera.
In order to prevent electric shock, do not remove screws or cover.
2. Handle the camera with care.
The camera could be damaged by improper handling or storage
3. Do not expose the camera to rain or moisture, or try to operate in wet
areas.
Take immediate action if the camera becomes wet. Turn the power off and
request service to qualified personnel. Moisture can damage the camera and
also create a risk of electric shock.
4. Do not use strong or abrasive detergents when cleaning the camera body.
Use a dry cloth to clean the camera when dirty. In case the dirt is hard to
remove, use a mild detergent and wipe gently.
5. Never point the camera toward the sun.
Whether the camera is used outdoor or not, never point it toward the sun. Use
with caution when operating the camera in the vicinity of spot lights or other
bright lights and light reflecting objects.
6. Do not operate the camera beyond its temperature, humidity, or power
source ratings.
Do not use the camera in an extreme environment where high temperature or
high humidity exists. Use the camera under conditions where temperatures are
between 14 F~122 F (-10 C~+50 C), and humidity is below 85%,
SA 1965
The symbol is intended to alert the user to the presence of uninsulated "dangerous voltage" within the
product's enclosure that may be sufficient magnitude to constitute a risk of electric shock to persons.
To prevent electric shocks and risk of fire hazards,
DO NOT use other than specified power source.
CAUTION:
!
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
CAUTION:
TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE
COVER OR BACK. NO USER SERVICEABLE PARTS INSIDE. REFER
SERVICING TO QUALIFIED SERVICE PERSONNEL.
To prevent fire or shock hazard, do not expose the unit to rain or moisture. The symbol is intended to alert
the user to the presence of important operating and maintenance (servicing) instructions in the literature
accompanying the appliance.
SA 1966
!
WARNING
CAUTION
This equipment has been tested and found to comply with the limits for a Class A. Digital
device. Pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy, and if not installed and used in accordance with
the instruction manual, it may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference in which case the user will be required
to correct the interference at own expense.
Any changes or modifications in construction of this device which are not expressly
approved by the party responsible for compliance could void the user's authority to operate the equipment.
oooo
Installation & Connection
1. Place a camera to installation on
the wall / ceiling.
2. Drill three holes accordingly to insert
anchors into the drilled holes.
3. Draw out power /video wires to the
connecting places.
4. Fix the housing base by screws on
the ceiling.
5. Adjust desired focus and scene by
turning and moving the hemisphere
by hand.
6. Put the dome cover over the base.
7. Fix the dome cover on the base
using L-Wrench.
L-Wrench
SCREW M4x20 3EA
SCREW TP1 4x30 3EA
P.C.D Ø115
Plastic Anchor
#
1
#
2
No.
#1
#2
Function
Video Output
Power Input
Remark
1.0 Vp-p
Terminal Color
Yellow
B & R
Video
(Yellow)
Power -DC12V
(Black & Red)
Video Output
GND
Built-in camera bracket will make
it much easier to rotate in any direction.
4
-
axis
Connecting to Monitor and Power
- The wire is polarized.
- Use DC 12V power source.
Installation
Owner's Manual
Mounting Screw Plastic Anchor
Focus Driver
Dome Camera
L-Wrench
Composition
4
3
2
1
VIDEO
AC 24V
J503
LR
UP
DOWN
Function Selection Switch
Moving Selection Switch
[LEFT, RIGHT, UP, DOWN]
Service Monitor Connector:
Use service monitor
connector to set camera
angle & focus when installing
DC12V ±15%
1
1
2
3
2
3
4
-
axis
IP 65
All manuals and user guides at all-guides.com
all-guides.com

Special Menu Menu Default Set
OSD Menu Structure 2
Privacy
Area Select : Area1 ~ Area12
Mode : On/Off
Mask Color : Green/Red/Blue/Black/White/Gray
Mask Tone : Level Adjustable
Top/Bottom/left/Right : Position Adjustable
Off
Language
English/Japanese/Spanish/Korean/
French/Portuguese/Taiwanese
English
Return
Return to the SETUP menu-
COMM ADJ
Cam ID : ID Selectable
Baudrate : 2400/4800/9600/19200/38400/57600
Parity : 8-N-1/8-E-1/8-O-1
Ret Pkt : Enable/Disable
Disp Cam ID : Off
Protocol : STW(SPD)/PELCO-D/PELCO-P/SEC/
BOSCH/HONEYWELL/VICON/PANASONIC
Cam ID : 1
Baudrate : 9600
Parity : 8-N-1
Ret Pkt : Enable
Disp Cam ID : Off
Protocol : STW(SPD)
Return
Sensitivity : Area1 ~ Area8
Area Mode : On/Off
Sel Pos : L_TOP / R_TOP / L_BOTTOM / R_BOTTOM
XPOS / YPOS : Position adjustable
FILL SET
Return
Motion Det
Off
Sync
INT (Phase : 0 ~ 359 Level Selectable)
INT
Camera ID Off On / Off
Image Adj
V-Rev : Off
H-Rev : Off
D-Zoom : Off
Dis : Off
Font Color : Blue
Sharpness : On
V-Rev : On / Off
H-Rev : On / Off
D-Zoom : On / Off (X1 ~ X16)
Dis : On / Off
Font Color : White, Yellow, Green, Red, Blue
Sharpness : On / Off (Level : 1~20Leveladjustable)
Return
Monitor LCD
LCD / CRT / USER
Gamma (Level : 0.2 ~ 1.0 Gamma Selectable)
PED Level (Level : 0 ~ 70 Level Adjustable)
Color Gain (Level : 0 ~ 70 Level Adjustable)
Reset
uneMuneMputeS
Lens DC DC / Manual
Exposure
Brightness : 25
Shutter : Manual
AGC : High
Sens_up : -
Brightness: 1 ~ 70 Level Selectable
Esc : Min/Max (Level Adjustable)
Manual : X512 ~ 1/120K
A.FLK
---
AGC : Off / Low / High
Sens-up : Off / Auto (X2~X512 Level Adjustable)
Return
OSD Menu Structure 1
Default Set
White Bal
ATW / Indoor / Outdoor / AWC / Manual
(R Gain / B Gain: Level adjustable)
ATW
Day/Night
Auto/External(NOT SUPPORT)/Color/B/W
-Color B/W : Duration(Fast/Slow), Dwell Time
-B/W COLOR:Duration(Fast/Slow), Dwell Time
-Return
Auto
DNR3 On / Off (Level : 1 ~ 32 Level Selectable)On
SSDR
On/Off (Limit : 1~15 Level Adjustable)
Off
Special
Refer to below
-
Exit
Save, Not Save, ResetSave
Backlight Off
Off
BLC : Level (Low/Middle/High)
/Top/Down/Left/Right
HLC : Level (Low/Middle/High)/Limit/Mask
Color/Mask Tone/Top/Down/Left/Right
Function Condition
Special Function
Day & Night
BLC
SSDR
DIS
Blemish Compensation
Sens-up
OSD Language
Motion Detection
DNR
Digital Zoom
Privacy
Mirror(H-REV)
Flip(V-REV)
Freeze
Sharpness
Color/BW/Auto/EXT(Built in Dc Motor Driver)
BLC/HLC/Off
On/Off
On/Off
256 Point(Even 128 point, Odd 128 point)
On/Off(x2 ~ x512)
English/Korean/Spanish/Japanese/
French/Portuguese/Taiwanese
On/Off (8 Zone)
On/Off (2D+3D)
On/Off (x1~x16)
On/Off(12 Zone)
On/Off(Horizontal)
On/Off(Vertical)
On/Off(Stop)
On/Off(Level Adjustable)
Day & Night Vandal Dome Camera
1/3" Sony SUPER HAD II CCD
768(H) x 494(V)
6.35µm(H) x 7.4µm(V)
HORI. Color 600 TV Line, B/W : 700 TV Line
NTSC
Internal
2:1 Interlace
15.734 KHz
59.94
1.0 Vp-p (Sync. Negative) Termination 75
= 0.45 typ.
0.1 Lux at Color(F1.2)
52dB or More (AGC OFF, Weight ON)
ATW / OUTDOOR / INDOOR / MANUAL / AWC
(1,700°K~11,000°K)
Off / Low / High
1/60 ~ 1/120,000 sec
AVERAGE TEST ILLUMINANCE BY FRONT VIEW
200mA Max.
Regulated DC 12V
± 15%
Yes
2.8~11mm
-10 ~ 50 °C / 30% to 80% RH
-20 ~ 60 °C / 20% to 90% RH
153mm(W) X 105.2mm(H)
Approx. 1.2kg
Model CH 03204
Specification
Type
Image Sensor
Effective Pixel
Cell Size
Resolution
TV Type
Sync. Type
Scanning System
Scanning Frequency H.
Scanning Frequency V.
Video Out
Gamma Characteristic
Min. Illumination
S/N Ratio
AWB
Gain Control
Shutter
Test Illumination Area
Current Consumption
Supplied Voltage
Reverse Polarity Protection
Lens
Operation Temp / Humidity
Preservation Temp / Humidity
Dimension
Weight
Troubleshooting
If you have a trouble operating your camera, refer to the following.
If the guidelines do not enable you to solve the problem, contact an authorized technician.
The image does not
appear on the screen.
Check the power source for the monitor and camera
and assure that the voltage and polarity are properly
connected and being supplied correctly.
The image on the
screen is dim.
Check if the lens is stained. If dirty, clean the lens
with a soft, clean cloth.
Adjust the Back Focus of the lens again.
The surface of the
camera case is hot and
a black line appears on
the screen.
Check if you have connected the camera to a proper
power source and if there is no problem with the power,
turn the unit off immediately and seek assistance from
our After Service department.
Check if the camera is pointed toward the sun or a
fluorescent lamp.
Adjust the angle or location of the camera if too much
light is coming into the screen.
The screen blinks a lot.
=>
=>
(RS485 IS NOT
SUPPORTED)
Hz
