Divitec HDB-M120 Original operating instructions

1
INSTALLATION / OPERATION
USER’S MANUAL
HDB-M120
Full HD NETWORK CAMERA

2
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO RAIN OR
MOISTURE. DO NOT INSERT ANY METALLIC OBJECTS THROUGH THE VENTIL ATION GRILLS OR
OTHER OPENINGS ON THE EQUIPMENT.
CAUTION
EXPLANATION OF GRAPHICAL SYMBOLS
The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert
the user to the presence of uninsulated "dangerous vo ltage" within the product's enclosure
that may be of sufficient magnitude to constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user to the
presence of important operating and main tenance (servicing) instructions in the literature
accompanying the product.
PRECAUTIONS
Safety ---------------------------------- Installation -----------------------------
Cleaning ----------------------------------
CAUTION
RISK OF ELECTRNIC SHOCK
DO NOT OPEN
CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
Should any liquid or solid object fall into the cabinet,
unplug the unit and have it checked by the qualified
personnel be fore operating it any further.
Unplug the unit from the wall oulet if it is not going to
be used for several days or more. To disconnect the
cord, pull it out by the plug. Never pull the cord itself.
Allow adequate air circulation to prevent internal heat
build -up. Do not place the unit on surfaces (rugs,
blankets, etc.) or near materials(curtains, draperies)
that may block the ventilation holes.
Height and vertical linearity controls located at the rear
panel are for special adjustments by qualified
personnel only.
Do not install the unit in an extremely hot or humid place
or in a place subject to excessive dust, mechanical
vibration.
The unit is not desi gned to be waterproof.
Exposure to rain or water may damage the unit.
Clean the unit with a slightly da mp soft cloth.
Use a mild household detergent. Never use strong
solvents such as thinner or benzene as they might
damage the finish of the unit.
Retain the original carton and packing materials for safe
transport of this unit in the future.

3
FCC COMPLIANCE STATEMENT
CE COMPLIANCE STATEMENT
FCC INFORMATION: THIS EQUIPMENT HAS BEEN TESTED AND FOUND TO
COMPLY WITH THE LIMITS FOR A CLASS A DIGITAL DEVICE, PURSUANT TO PART 15 OF THE FCC
RULES. THESE LIMITS ARE DESIGNED TO PROVIDE REASONABLE PROTECTION AGAINST
HARMFUL INTERFERENCE WHEN THE EQUIPMENT IS OPERATED IN A COMMERCIAL
ENVIRONMENT. THIS EQUIPMENT GENERATES, USES, AND CAN RADIATE RADIO FREQUENCY
ENERGY AND IF NOT INSTALLED AND USED IN ACCORDANCE WITH THE INSTRUCTION MANUAL,
MAY CAUSE HARMFUL INTERFERENCE TO RADIO COMMUNICATIONS. OPERATION OF THIS
EQUIPMENT IN A RESIDENTIAL AREA IS LIKELY TO CAUSE HARMFUL INTERFERENCE IN WHICH
CASE THE USER WILL BE REQUIRED TO CORRECT THE INTERFERENCE AT HIS OWN EXPENSE.
CAUTION: CHANGES OR MODIFICATIONS NOT EXPRESSLY APPROVED BY THE PARTY
RESPONSIBLE FOR COMPLIANCE COULD VOID THE USER'S AUTHORITY TO OPERATE THE
EQUIPMENT.
THIS CLASS A DIGITAL APPARATUS COMPLIES WITH CANADIAN ICES-003.
CET APPAREIL NUMÉRIQUE DE LA CLASSE A EST CONFORME À LA NORME NMB-003 DU
CANADA.
WARNING
This is a Class A product. In a domestic environment this product may cause radio interference in
which case the user may be required to take adequate measures.
CAUTION
RISK OF EXPLOSION IF BATTERY IS REPLACED BY AN INCORRECT TYPE.
DISPOSE OF USED BATTERIES ACCORDING TO THE INSTRUCTIONS

4
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in accordance with the
manufacturer’s instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves,
or other apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug.
A polarized plug has two blades with one wider than the other. A grounding
type plug has two blades and a third grounding prong. The wide blade or the
third prong are provided for your safety. If the provided plug does not fit into
your outlet, consult an electrician for replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs
convenience receptacles, and the point where they exit from the apparatus.
11. Only use attachments/accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the apparatus.
When a cart is used, use caution when moving the
cart/apparatus combination to avoid injury from tip-over.
13. Unplug this apparatus during lightning storms or when
unused for long periods of time.
14. Refer all servicing to qualified service personnel. Servicing is
required when the apparatus has been damaged in any way, such as power-
supply cord or plug is damaged, liquid has been moisture, does not operate
normally, or has been dropped.
15. CAUTION – THESE SERVICING INSTRUCTIONS ARE FOR USE BY
QUALIFIED SERVICE PERSONNEL ONLY. TO REDUCE THE RISK
OF ELECTRIC SHOCK DO NOT PERFORM ANY SERVICING OTHER
THAN THAT CONTAINED IN THE OPERATING INSTRUCTIONS
UNLESS YOU QRE QUALIFIED TO DO SO.
16. Use satisfy clause 2.5 of IEC60950-1/UL60950-1 or Certified/Listed Class
2 power source only.
17. ITE is to be connected only to PoE networks without routing to the outside plant.

5
CONTENTS
DESCRIPTION ----------------------------------------------------------------------------------------------------9
Key Features --------------------------------------------------------------------------------------------9
Components --------------------------------------------------------------------------------------------10
Camera Layout ----------------------------------------------------------------------------------------11
INSTALLATION ---------------------------------------------------------------------------------------------------13
Before Installation -------------------------------------------------------------------------------------13
Starting Installation ------------------------------------------------------------------------------------13
DC Auto Iris Lens Installation & Adjustment -------------------------------------------------------13
Audio Connection --------------------------------------------------------------------------------------15
Alarm Connection --------------------------------------------------------------------------------------15
OPERATION -------------------------------------------------------------------------------------------------------16
Minimum conditions for using web browser -------------------------------------------------------16
Accessing the IP camera ------------------------------------------------------------------------------16
Main Menu ----------------------------------------------------------------------------------------------17
LIVE VIEW --------------------------------------------------------------------------------------------------------18
Live Video Page Icons ---------------------------------------------------------------------------------18
PLAYBACK ---------------------------------------------------------------------------------------------------------19
Playback View ------------------------------------------------------------------------------------------19
SETUP --------------------------------------------------------------------------------------------------------------23
Users -----------------------------------------------------------------------------------------------------24
Network -------------------------------------------------------------------------------------------------27
Image ----------------------------------------------------------------------------------------------------29
Audio -----------------------------------------------------------------------------------------------------31
Date & Time --------------------------------------------------------------------------------------------33
Live View – Source ------------------------------------------------------------------------------------35
Image – Basic ------------------------------------------------------------------------------------------37
Image – AE & AWB ------------------------------------------------------------------------------------40
Image – Day & Night ----------------------------------------------------------------------------------42
Image – WDR & 3D-DNR -----------------------------------------------------------------------------43
Image – Privacy Mask ---------------------------------------------------------------------------------47
Video & Image – Stream1 ----------------------------------------------------------------------------49
Video & Image – Stream2 ----------------------------------------------------------------------------51
Video & Image – Stream3 ----------------------------------------------------------------------------53
Video & Image – Stream4 ----------------------------------------------------------------------------56
Video & Image – Webcasting ------------------------------------------------------------------------59
Audio – Basic -------------------------------------------------------------------------------------------60
Event In – Alarm-In ------------------------------------------------------------------------------------62
Event In – Manual Trigger ----------------------------------------------------------------------------64
Event In – VMD Stream1 -----------------------------------------------------------------------------65

6
Event In – VMD Stream3 -----------------------------------------------------------------------------67
Event In – VMD Stream4 -----------------------------------------------------------------------------69
Event Out – SMTP --------------------------------------------------------------------------------------71
Event Out – FTP& JPEG -------------------------------------------------------------------------------73
Event Out – HTTP Server -----------------------------------------------------------------------------76
Event Out – Audio Alert -------------------------------------------------------------------------------76
Event Out – Audio Alert – Audio Recorder -------------------------------------------------------77
Event Out – PTZ Preset--------------------------------------------------------------------------------78
Event Out – Record ------------------------------------------------------------------------------------80
Event Map -----------------------------------------------------------------------------------------------81
Event Map – Add ---------------------------------------------------------------------------------------82
Device – PTZ --------------------------------------------------------------------------------------------84
Device – RS485 -----------------------------------------------------------------------------------------85
Security – Users ----------------------------------------------------------------------------------------86
Security – HTTPS -------------------------------------------------------------------------------------89
Security – IP Filtering --------------------------------------------------------------------------------91
Date & Time ------------------------------------------------------------------------------------------ 92
Network – Basic ---------------------------------------------------------------------------------------94
Network – DDNS --------------------------------------------------------------------------------------96
Network – RTP ----------------------------------------------------------------------------------------97
Network – UPnP --------------------------------------------------------------------------------------99
Network – QoS ----------------------------------------------------------------------------------------100
Language ----------------------------------------------------------------------------------------------101
Maintenance -------------------------------------------------------------------------------------------102
Support -------------------------------------------------------------------------------------------------104
About ---------------------------------------------------------------------------------------------------105
Technical Specifications ---------------------------------------------------------------------------------------106
Image --------------------------------------------------------------------------------------------------106
Electrical / Connector --------------------------------------------------------------------------------106
Mechanical ---------------------------------------------------------------------------------------------106
Video ---------------------------------------------------------------------------------------------------106
Audio ---------------------------------------------------------------------------------------------------107
System Integration -----------------------------------------------------------------------------------107
Environmental -----------------------------------------------------------------------------------------108
Physical ------------------------------------------------------------------------------------------------108
Troubleshooting -------------------------------------------------------------------------------------------------109
Upgrading the Firmware -----------------------------------------------------------------------------109
General Troubleshooting ----------------------------------------------------------------------------109

7
LIST of ILLUSTRATIONS
Figure 1. 4-pin iris driver connector ---------------------------------------------------------------------------14
Figure 2. DC auto iris Lens connection -----------------------------------------------------------------------14
Figure 3. Audio connection -------------------------------------------------------------------------------------15
Figure 4. Alarm connector --------------------------------------------------------------------------------------15
Figure 5. Main menu ---------------------------------------------------------------------------------------------17
Figure 6. Main Live View Page ---------------------------------------------------------------------------------18
Figure 8. Playback View -----------------------------------------------------------------------------------------20
Figure 9. Basic Configuration -----------------------------------------------------------------------------------23
Figure 10. Basic Configuration / Users ------------------------------------------------------------------------24
Figure 11. Basic Configuration / Users / Add User ----------------------------------------------------------25
Figure 12. Basic Configuration / Users / Modify User -------------------------------------------------------26
Figure 13. Basic Configuration / Network ------------------------------------------------------------------- 27
Figure 14. Basic Configuration / Image -----------------------------------------------------------------------29
Figure 15. Basic Configuration / Audio ------------------------------------------------------------------------31
Figure 16. Basic Configuration / Date & Time ---------------------------------------------------------------33
Figure 17. Live View / Source ----------------------------------------------------------------------------------35
Figure 18. Video & Image / Image – Basic ------------------------------------------------------------------37
Figure 19. Video & Image / Image – AE & AWB ------------------------------------------------------------40
Figure 20. Video & Image / Image - Day & Night ----------------------------------------------------------42
Figure 21. Video & Image / Image – WDR & 3D-DNR -----------------------------------------------------43
Figure 22. Video & Image / Image – Privacy Mask ---------------------------------------------------------47
Figure 23. Video & Image / Stream1 -------------------------------------------------------------------------49
Figure 24. Video & Image / Stream2 -------------------------------------------------------------------------51
Figure 25. Video & Image / Stream2 ROI setting -----------------------------------------------------------52
Figure 26. Video & Image / Stream3 -------------------------------------------------------------------------53
Figure 27. Video & Image / Stream3 ROI setting -----------------------------------------------------------55
Figure 28. Video & Image / Stream4 -------------------------------------------------------------------------56
Figure 29. Video & Image / Stream4 ROI setting -----------------------------------------------------------58
Figure 30 Video & Image / Webcasting ----------------------------------------------------------------------59
Figure 31. Audio / Basic ----------------------------------------------------------------------------------------60
Figure 32. Event / Event In – Alarm In -----------------------------------------------------------------------62
Figure 33. Event / Event In – Manual Trigger ---------------------------------------------------------------64
Figure 34. Event / Event In – VMD Stream1 -----------------------------------------------------------------65
Figure 35. Event / Event In – VMD Stream3 -----------------------------------------------------------------67
Figure 36. Event / Event In – VMD Stream4 -----------------------------------------------------------------69
Figure 37. Event / Event Out – SMTP (Email) ---------------------------------------------------------------71
Figure 38. Event / Event Out – FTP & JPEG -----------------------------------------------------------------73
Figure 39. Event / Event Out – HTTP Server ----------------------------------------------------------------76
Figure 40. Event / Event Out – Audio Alert ------------------------------------------------------------------76
Figure 41. Event / Event Out – Audio Alert / Audio Recorder----------------------------------------------77
Figure 42. Event / Event Out – Audio Alert / ARecorder window -----------------------------------------77
Figure 43. Event / Event Out – Audio Alert / Encode setup -----------------------------------------------78
Figure 44. Event / Event Out – PTZ Preset ------------------------------------------------------------------78
Figure 45. Event / Event Out – SD Record -------------------------------------------------------------------80

8
Figure 46. Event / Event Map ----------------------------------------------------------------------------------81
Figure 47. Event / Event Map – Add --------------------------------------------------------------------------82
Figure 48. Device / PTZ------------------------------------------------------------------------------------------84
Figure 49. Device / RS485---------------------------------------------------------------------------------------85
Figure 50. System / Security – Users -----------------------------------------------------------------------86
Figure 51. System / Security – Users / Add User ----------------------------------------------------------87
Figure 52. System / Security – Users / Modify User -------------------------------------------------------88
Figure 53. System / Security – HTTPS ----------------------------------------------------------------------89
Figure 54. System / Security – IP Filtering -----------------------------------------------------------------91
Figure 55. System / Date & Time ----------------------------------------------------------------------------92
Figure 56. System / Network – Basic ------------------------------------------------------------------------94
Figure 57. System / Network – DDNS -----------------------------------------------------------------------96
Figure 58. System / Network – RTP -------------------------------------------------------------------------97
Figure 59. System / Network – UPnP ------------------------------------------------------------------------99
Figure 60. System / Network – QoS -------------------------------------------------------------------------100
Figure 61. System / Language --------------------------------------------------------------------------------101
Figure 62. System / Maintenance ----------------------------------------------------------------------------102
Figure 63. System / Support ----------------------------------------------------------------------------------104
Figure 64. About ------------------------------------------------------------------------------------------------105

9
DESCRIPTION
-------------------------------------------------------------------------------------------------------------------------------------
The HDB-M120 Series camera is an internet protocol based megapixel network camera with a built-
in web based viewer on Internet Explorer®. The camera has a connection feature for third-party
applications and compatible with supplied Utility software for easy installation and Client software to
search, configure, manage, live view, record and playback.
The camera supports dual compression formats and multiple streaming simultaneously. The two
standard compression formats include H.264 and MJPEG. The multiple streams can be configured to
a variety of resolutions, bit rates and frame rates.
The camera uses 1/2.8 inch CMOS sensor and complies with CS mount lens and also supports PoE
(Power over Ethernet), DC12V, and AC24V.
Key Features
- WDR / BLC
The HDB-M120 Series are capable of providing the Wide Dynamic Range / Back Light Compensation
function to view the object clearly in backlight conditions.
- 3D-DNR
3Dimensional-Digital Noise Reduction technology dramatically cleans up the noise in video frames
and solves the problem of low- light sensitivity where it can display high image resolution even in
extremely low light conditions.
- DIS
Digital Image Stabilization function minimizes the appearance of shaky images caused by low-
frequency vibration.
- Day and Night
The HDB-M120 Series provide clear monitoring images even in low light conditions using IR-cut
filter.
- HDTV Video Quality
The HDB-M120 Series are capable of providing the outstanding image quality with HDTV
performance and profiles (High, Main, and Baseline) in H.264 compression.
- Multiple Streaming
Each stream can be programmed independently and transmitted using different configurations.
- ROI (Region of Interest)
The ROI features that transmit specially selected area in the primary stream using different FPS,
Resolution, Bit Rates and Picture Quality.

10
- Easy Focus
Easy Focus helps to reduce the installation efforts especially video image focusing of the camera.
- Dual Codec (H.264, MJPEG)
The HDB-M120 Series supports two standard compressions formats H.264 and MJPEG.
- Digital PTZ
Supports maximum 10x digital zoom.
- Intelligent Video Motion Detection
The HDB-M120 Series offers intelligent & sophisticated video motion detection for each multiple
streams.
- Triple Power (Power over Ethernet, DC12V, AC24V)
This camera supports Power over Ethernet (PoE), which supplies power to the camera through the
network. If the network has not PoE, connect a DC12V or AC24V power connector.
- SD Local Recording
The HDB-M120 Series provides local video recording function. When camera detects video motion
or alarm events or manual trigger, it can record video stream by itself.
- Voice Alert Linked to Alarm Detection
The HDB-M120 Series can play the audio file stored in the camera in synchronization with alarm
detection by the sensor input or the motion detection function.
- Network Flow Control
The HDB-M120 Series provides a flow control function which enhances network efficiency by
significantly restricting user video streams with designating the maximum bandwidth.
- ONVIF Certificate
The HDB-M120 Series network camera complies with the ONVIF certificate. ONVIF (Open Network
Video Interface Forum) is an open industry forum for the development of a global standard for the
interface of network video products.
Components
Quantity Description
1 Camera
1 Installation CD
1 C- Mount Ring
1 Auto DC-Iris Connector

11
NOTE
Lens, installation hardware and Adapter for DC12V / AC24V are not supplied.
Camera Layout
RJ-45 connector: Supplies power to the camera through the network using PoE. If PoE is
not available, supplies DC12V or AC24V power source to the POWER connector.
ETHERNET link indication LED: Flashes green to indicate that data is being TX/RX by the
camera.
ETHERNET activity indication LED: Glows solid amber to indicate that a live connection is
established.
STATUS indication LED: Flashes amber about one time per second to indicate normally
working and flashes green about 2~3 time per second while upgrade.
POWER indication LED: Glows solid red if power is supplied properly.
SPEAKER connector: Connect external speaker for audio output.
MIC connector: Supplies external microphone as an audio input source.
POWER connection: Supplies DC12V or AC24V as the power source comply with Class2.

12
RESET button: Restores the camera’s factory default settings. This button is recessed. Use a
small tool, such as a paper clip, to press the reset button.
Please take steps as follows:
1. Power off
2. Press and hold the RESET button
3. Supply the camera with power
4. Hold the RESET button for 15 seconds
ALARM connection: Connect one or two physical alarm input signal into the device and one
alarm output signal that can be used to control an external alarm circuit.
BNC connector: Connect BNC cable for composite video output.
INSTALLATION TOP STAND connector: 0.25 Inch (0.64cm) UNC-20 screw, top of camera
housing.
INSTALLATION BOTTOM STAND connector: 0.25 Inch (0.64cm) UNC-20 screw, bottom
of camera housing.
FOCUS ADJUSTING / FIXING screw: Tighten this screw after focus the lens of a camera.
AUTO IRIS LENS connector: Connect the DC auto iris lens 4-pin connector into this
connector to control the amount of light allowed through the lens.
CS MOUNT LENS: connection: Attach the CS type lens.
RS485 connection: Connect RS485 compatible device for PTZ control.
SD Card: Insert SD card for local recording.
INSTALLATION

13
-------------------------------------------------------------------------------------------------------------------------------------
Before Installation
Before installing the camera, thoroughly familiarize yourself with the information in this section of
the manual.
- Recommends connecting the camera to a network that use a DHCP (Dynamic Host Configuration
Protocol) server to address devices.
- To ensure secure access to the IP camera, place the camera behind a firewall when it is
connected to a network.
NOTES
- Use megapixel lens for higher image quality.
- Megapixel lenses are designed and tested to deliver optimal image quality to the HDB-M120 Series
megapixel cameras.
- If the standard definition lens was installed on megapixel camera, the image quality will be poor
than expected.
- Recommend to install the megapixel lens from the following lens manufactures.
-- TAMRON
-- COMPUTAR
-- FUJINON
Starting Installation
1. Install the Lens
- Be careful the lens does not touch camera sensor when installer try to enter the lens into camera.
- Install manual lens or DC auto iris lens.
- If DC auto iris lens needs to install, connect DC auto iris 4-pin connector into iris drive connector
located on the side of the camera.
2. Mount the camera
The camera can be mounted from both top side and bottom side.
3. Connect other peripheral devices
Connect the other peripheral devices such as Alarm, Audio and BNC connector.
4. Supply the camera with power.
- If PoE is not available, connect DC12V or AC24V wires to the camera power connector. Be careful
when DC12V wiring especially the direction of positive and negative. Use power supply compatible
with FCC Class2.
- This camera complies with IEEE802.3af standard. It means that the power for this camera can be
supplied from Ethernet cabling without additional power supply. This can be reducing the
installation efforts.
- The camera will complete a configuration processing within approximately 40 seconds. The amber
LED flashes one time per second after the configuration processing are complete.
5. View the camera image

14
View the camera image using BNC connector or built-in web browser or supplied Client software.
NOTE
This camera will autosense and work with either a straight Ethernet cable or crossover Ethernet
cable.
DC Auto Iris Lens Installation & Adjustment
The camera supports DC-type auto iris lenses. Perform the following steps to install and adjust a
DC-type auto iris lens.
- Solder the lens control wires to the connector supplied with the camera.
Figure 1. 4-Pin iris driver connector
- Attach the DC-type auto iris lens to the lens mount on the front of the camera.
- Plug the connector into the auto iris jack on the side of the camera. The connector is polarized
and can be inserting into the iris jack one way.
Figure 2. DC auto iris Lens connection
Audio Connection

15
This camera supports bidirectional audio. Install the microphone and speaker which has an amplifier
capability.
Figure 3. Audio connection
External Speaker
External Microphone
Alarm Connection
The camera provides two alarm input for external signaling devices and one alarm output for
activating external device. Both Normally Open and Normally Closed devices are supported. Be
consult before alarm device installation how to wire between the camera and alarm devices.
Figure 4. Alarm connector
Alarm Input 1
Alarm Ground
Alarm Input 2
Alarm Output
Alarm Ground
RS485 -
RS485 +
OPERATION

16
-------------------------------------------------------------------------------------------------------------------------------------
Before starting the camera, installation must be complete. The camera completes a configuration
sequence within approximately 40 seconds when power is supplied. The amber LED of this
megapixel camera flash one time per second indicating the configuration sequence is complete.
NOTES
- If the DHCP is enabled but the camera is not connected to a DHCP server, the camera will be set
default IP 192.168.30.220 and try to get IP from DHCP server about every two seconds.
- Network and processor bandwidth limitations might cause the video stream to pause or appear
pixilated when an increased number of Web-interface users connection to the camera. Decrease
the images per second, resolution, compression, or bit rate settings of the Web-interface video
streams to compensate for network or processor limitations.
Minimum conditions for using web browser
The minimum system requirements to use a Web browser with this IP camera are as follows:
- CPU: Pentium® 4 microprocessor, 2.0GHz
- Operational System: Windows XP® or Windows Vista® or Windows7®
- System Memory: RAM 512 Mbyte
- Ethernet: 100 Mbit
- Video Resolution: 1024(Horizontal) x 768(Vertical) pixels or higher
- Internet Explorer® 7 or later
- ActiveX® 2.0.0.9 or later
Accessing the IP camera
1. Open Web browser
- Double click Internet Explorer® icon.
2. Type IP address
- Type the camera’s IP address in the Internet Explorer® address bar.
- The default IP address is 192.168.30.220
NOTES
- If you do not know the camera’s IP address, install the SmartManager® utility software available
on the CD supplied with the product. The utility software will locate the assigned Model name,
Host name, MAC address, IP address, Version and others.
- Refer to the SmartManager® utility software manual for more detail.
3. Log On to the camera
- Click the Live View icon for default live image view or the Setup icon to change the configuration
values.
Main Menu

17
Figure 5. Main Menu
The dialog box will be appears.
- Type User ID and Password in the dialog box. The default User ID and Password are admin .
NOTE
For security purposes, be sure to change the password after you log on for the first time.
LIVE VIEW

18
-------------------------------------------------------------------------------------------------------------------------------------
The Live View page provides you to select the properties of video source. You can view the live
image from this page and also access the Setup menu and operate the main functions.
Figure 6. Main Live View Page
Live Video Page Icons
Hide Main Icons: Hides main icons in the live view page.
Show Main Icons: Shows main icons in the live view page.
Live view: Displays live video stream.
Playback View: Enters playback menu.
Setup: Enters setup menu.
Help: Shows helpful information.
Source: Specify the viewable video stream source to display in live view page.

19
View Size: Specify the viewable video size to display in live view page.
Stream Type: Specify the internet protocol to display in live view page.
ROI View: Specify the specially selected area to transfer using different stream feature in the
primary video image. ROI is an abbreviation for “Region of Interest”.
Preset: Specify the Preset. This icon is inactivated if the PTZ settings are not set.
Pause: Pause the live video stream.
Snapshot: Take a picture of the video image currently on display. Supports the origin image
size view, Print, and Save feature.
Digital Zoom: Supports a digital zoom in live video image.
Full Screen: Expands video image to the entire screen area.
Manual Trigger: Activates the Alarm Out signaling manually.
PTZ: Activates a pop-up window for Pan, Tilt and Zoom control.
Speaker: Adjusts the volume of Speaker and switch the sound on / off.
Microphone: Adjusts the volume of Microphone and switch the sound on / off.
PLAYBACK

20
-------------------------------------------------------------------------------------------------------------------------------------
This Playback page provides current SD recorded file lists and information. It also supports easy
access and how to playback the recorded stream.
Playback View
User can access the recorded image in the web browser.
Figure 8. Playback View
Event List: Shows the recorded lists by Alarm, Trigger and Motion event.
Event Search: Select the start date and end date you want to playback, and then click the Go
button to show the list. In case of you want to list up according to event type, click the arrow
button and select event type.
Calendar: Shows the information about playback image.
Playback Control Buttons: Provides user favorite functions.
Go to the first.
