DLS Effects Ultra Chorus II User manual

Input A
Input B
Stereo
OUT A OUT B
+9vdc
Chorus 2 Rate
DLS  Effects
Blend
Chorus 2 Depth Chorus 1 Depth
Chorus 1 Rate
4
5
6
7
3
2
1
Delay
Chorus2 / Chorus1 On/Off
U
ltra
C
horus
I
I
TM
E
lectronics:
Technology: Custom hybrid consisting of analog
circuitry combined with and 16bit digital electronics.
This unique circuitry has allowed the warmth of
analog to be blended with the power of digital!
Sample rate: 44.1KHZ, 256x over sample
Power: 9vdc, 130ma, 2.1mm jack
(DC adapter included)
*Our internal circuit will accommodate any polarity
of input jack.
Outputs: Output A (Normal)
Output B (Slightly Brighter sound)
Mechanical:
Enclosure: Solid heavy gauge steel
5.5”W x 4.9”D x 2.4”H
Weight: 2½ lbs.
Ultra ChorusII User Manual By DLS  Effects
DLS has once again designed one of the warmest chorus effects in the industry! The Ultra ChorusII is two chorus units in one.
The musician can preset both chorus channels and switch between the two on the fly! A Blend control allows the musician to
mix as much analog instrument with our wonderful chorusing sound. As with all DLS Effects, the analog instrument always stays
analog! Choose from any hookup option (Mono in-Mono Out, or Mono in-Stereo Out, or Stereo in-Stereo Out). Internal trim pots
allow the musician to dial in levels of InputA-OutputA, InputB-OutputB, and Chorus Regeneration (Regen) to taste.
The Ultra ChorusII is truly one of the sweetest sounding and most powerful chorus effects on the market today. It’s quiet,
pristine, versatile, and allows the musician to dial in the sound they are after. DLS effects are extremely well constructed using a
heavy steel enclosure, steel switches, steel pots, and a beautiful powder coating to withstand every road environment.
Features:
• Blend: Controls the blending of Chorus effects with straight instrument (straight instrument stays analog)
• Chorus1 Rate, Chorus1 Depth: Controls rate and depth of Chorus 1 section
• Chorus2 Rate, Chorus2 Depth: Controls rate and depth of Chorus 2 section
• Chorus1 LED: Blinks at to the Chorus1 Rate
• Chorus2 LED: Blinks at to the Chorus2 Rate
• Chorus2/Chorus1 Footswitch: Selects between Chorus 2 and Chorus 1
sections
• Delay Scale: 7 delay selections to widen or narrow the chorusing sound
• Two inputs and two outputs for : Mono in-Mono Out, or Mono in-Stereo
Out, or Stereo in-Stereo Out (all ¼” steel jacks)
• True Bypass On/Off Switch: Engages the effect when On (green LED will
light), True bypass when Off.
• Internal INA Pot: Adjusts the gain level of Input A
• Internal OUTA Pot: Adjusts the volume of OUTA
• Internal INB Pot: Adjusts the gain level of Input B
• Internal OUTB Pot: Adjusts the volume of OUTB
• Internal CHORUS REGEN Pot: CCW for swirly chorus, CW for dry chorus
• 9vdc input, any polarity (Worry free if using your 9volt pedal board
supply)
• 9vdc transformer included
• All steel enclosure, steel pots, and steel jacks
• Analog instrument signal is mixed with the Chorus effect.
Operation:
Power Up: The Ultra Chorus II powers up using the Chorus1 channel. The red LED will blink according to the rate Chorus1
is set to.
Switching to Chorus1 and Chorus2: Simply push and release the Chorus2/Chorus1 switch and the effect will toggle
between Chorus1 and Chorus2 channels. The appropriate LED will light and blink for the active channel. The unused
channel LED will un-light.
TM

**Note 1: Warning; proper grounding and electrical hookup are required when hooking up any electrical products. In-correct grounding can cause
injury or even death. If in doubt concerning grounding or electrical hookup, consult with a qualified electrician or qualified dealer.
Delay: The Delay 1-7 controls how wide or condensed the chorusing is. Delay setting 7 is the widest chorus down to Delay
setting one is the most condensed chorus.
Note: As the delay setting gets higher (5, 6, 7), it may be necessary to reduce the Depth to 12:00 or less if pitch warble is not
desired. If you want pitch warble, keep it past 12:00.
Chorus1 & Chorus2 Rate: This controls the speed of the chorusing sweep (Turn CW for faster speeds). Turn past 12:00
for Vibrato.
Chorus1 & Chorus2 Depth: This controls how deep and intense the chorusing is. (Turn CW to get deeper).
Note about OUTA & OUTB: Output A is designed to sound slightly different to Output B. Output B is slightly brighter. The
musician can experiment with both outputs while the instrument is plugged into INA. This also gives a nicer stereo sound
spread when used in stereo.
Internal Adjustments: InputA, InputB, OUTA, OUTB, REGEN(see below)
***Warning*** Static can destroy electronic parts. Discharge yourself by touching a metal surface such as a water
pipe before opening the Ultra ChorusII.
DLS
 Effects www.dlseffects.com © 1/07
Several settings are below (these just scratch the surface)
REGEN (R48)
Turn CCW for more swirly chorus,
CW for dryer chorus.
INPUTA Gain (R29)
Turn CCW for more gain, CW for less.
Factory setting (turn full CCW, then CW 1/3 turn)
INPUTB Gain (R16)
Turn CCW for more gain, CW for less.
Factory setting (turn full CCW, then CW 3/4 turn)
OUTA Volume (R49)
Turn CW for higher volume, CWW for less volume
Factory setting (turn full CCW, then CW 3/4 turn)
OUTB Volume (R66)
Turn CW for higher volume, CWW for less volume
Factory setting (turn full CCW, then CW 1/4 turn)
Blend
Chorus 1 or 2 Depth
Chorus 1 or 2 Rate
4
5
6
7
3
2
1
Delay
Analog Chorus Blend
Chorus 1 or 2 Depth
Chorus 1 or 2 Rate
4
5
6
7
3
2
1
Delay
Vibrato
Blend
Chorus 1 or 2 Rate
4
5
6
7
3
2
1
Delay
Chorus 1 or 2 Depth
Wide Sparkling Chorus
Blend
Chorus 1 or 2 Depth
Chorus 1 or 2 Rate
4
5
6
7
3
2
1
Delay
Ultra Deep Chorus Blend
Chorus 1 or 2 Rate
4
5
6
7
3
2
1
Delay
Chorus 1 or 2 Depth
Phaser tone Chorus Blend
Chorus 1 or 2 Depth
Chorus 1 or 2 Rate
4
5
6
7
3
2
1
Delay
Note Bending Chorus
