DLS DD31T User manual

OWNER`S MANUAL
DD-SERIES
DD31T
600W /3 Channel Class D Full Digital Amplifer
This product must be returned to the
separate collection system for electronic
products. Do not dispose this product
together with general household waste.
DLS amplifiers are designed and engineered by:
DLS Svenska AB
P.O. Box 13029 - SE-40251 Göteborg - Sweden
Tel: [phone] - Fax: [phone]
E-mail: [e-mail]
www.dls.se

Thank you and congratulations
Thank you for your decision to purchase a DLS amplifier!
Your DLS amplifiers must be installed correctly to
perform at its best. This manual will show you how to
install the amplifier like a pro. Please read the entire
manual before beginning the installation. Install the
amplifier yourself if you feel confident with our
instructions and if you have the proper tools.
However if you feel unsure, turn over the installation
job to someone better suited to it.
Warranty Service
This amplifier is covered by warranty, depending on
the conditions in the country where it is sold. If the
amplifier is returned for service, please include the
original dated receipt with the product.
Technical Assistance
For technical assistance ask the shop where the
product was sold or the distributor in your very coun-
try. Information can also be found on our WEB-site
www.dls.se
We follow a policy of continuous advancement in
development. For this reason all or part of specifica-
tions & designs may be changed without prior notice.
DECLARATION OF CONFORMITY
DLS amplifiers for vehicles are manufactured in
accordance with the EU directive EEC 95/54 (72/245/
EEC) and are marked with the approval number. They
are also marked in accordance with the WEEE-directive
2012/19/EU.
The products are also produced in accordance with the
EU RoHS directive 2011/65/EU.

MOUNTING THE AMPLIFIER
Fig.1 Mounting Amplifier
To keep your DLS amplifier running at top performance, choosing the proper location is of utmost
importance. Both Thermal and Overload protection are built in.
In the event of overheating, the amplifier will turn off and only restart when cooled. For this reason the amplifier should be
mounted in a location which will allow air to circulate freely. The compact size of the DLS DD Series amplifier allows greater
flexibility in mounting.
CAUTION: Not water or mud proof. Cannot be submerged or it will void the warranty!
The models include the following
features:
- FRD (Full Range Class-D)
- AUX Input
- Low profile design
- Digital Sound Optimization Circuitry
- High level input with auto start
- Powerful cable terminals
- Built-in active crossovers
- Remote sub level control
- High Damping Control Circuit
- Quiet Switching
- Advanced Protection Circuitry
- Virtual Silence Turn On/Off Mute
- 24 Volt

DD31T CONTROL PANEL LAYOUT
Fig. 2-3 Channel Panel Layout
1. SUBWOOFER INPUT Connector
This is both a Low and High Level Input port. Using the supplied wiring harness for low level RCA inputs or as
instructed on Fig.9 High Level (speaker level) input.
2. SUBWOOFER GAIN Control
This control is used to match the input sensitivity of the amplifier to the particular source unit that you are using up to 250mV to 5
volts.
3. LPF (Low Pass Filter)
This control is continuously adjustable from 50Hz to 150Hz at 12dB per octave.
4. AUX Input Jack
This 1/8-inch (3.5mm) mini jack can be used to accept an MP3, iPOD or smartphone as the source unit from that devices
headphone (3.5mm) output.
NOTE: INPUT switch needs to be in the 2CH setting when using AUX Input to provide signal for both front and sub amp
section.
The AUX input is internally paralell to the ordinary front input. Turn off or disconnect the source not used to avoid
mixing.
5 . BASS EQ Control
This equalization circuit is used to enhance the low frequency response of the vehicle’s interior. With up to 18dB of boost
centered at 45Hz, the BASS EQ can be adjusted to meet your own personal taste.

6. INPUT Switch
Matches the input from the Source Unit to that of the amplifier, either 2 or 3 Channel with separate subinput. This eliminates the
use of “Y” adapters and provides a cleaner input signal. When the 2-Channel mode is selected, both front and sub outputs will
operate from front low level RCA / high level input.
When the 3-CH MODE is selected, both the front and subwoofer inputs will be used. This will allow balancing level between the
front and subwoofer outputs.
7. HPF (High Pass Filter)
This control is continuously adjustable from 40Hz to 400Hz at 12dB per octave when the x-over switch is set to HPF.
8. X-OVER Switch for FULL/HPF
Activates the built-in electronic crossover network. Works in conjunction with the HPF adjustable control. When set to FULL
the amplifier run full range and the electronic crossover circuitry is bypassed.
9. REMOTE LEVEL INPUT Connector
Connector port for the remote level controller. By this the subwoofer output level can be adjusted from the driver’s
seat.
10. FRONT GAIN Control
This control match the input sensitivity of the amplifier to the source unit from 250mV up to 5 volts.
11. FRONT INPUT Connector
This is both a Low and High Level input port. Using the supplied wiring harness for low level RCA inputs or High Level (speaker
level) input.
12. POWER/STATUS Indicator
This clear LED lights Blue when the power is on, or turns Red constantly when the built-in protection circuitry is activated. Red
indicates a problem with the system in relation to the amplifier /see troubleshooting tips).
13. SUBWOOFER OUTPUT
Set screw subwoofer output terminal. Be sure to observe the correct speaker polarity and follow the speaker wiring diagrams
starting on page 21.
14. FRONT SPEAKER OUTPUT
This 4-pin Molex style connector is where the speaker output harness plugs in. Be sure to observe the correct speaker polarity
and follow the speaker wiring diagrams starting on page 21.
15. BATT+ (Power Input Connection)
This terminal is the main power input for the amplifier and must be connected directly to the positive (+) terminal of the car
battery. The solderless terminal block is designed to accommodate up to 4-gauge power wire.
FUSE-IMPORTANT
Due to the limited space on the DD amplifier chassis they do NOT come with internal fusing! use an in-line fuse holder that can be
connected directly to the BATT+ input on the amplifier. Please note the proper ampere fuse for each model. Never replace a fuse
with a higher rating then what is listed.
16. REM (Remote Input Connection)
This terminal must be connected to a switched +12-24V source. Typically, remote turn-on leads are provided at the source unit
that will turn on and off like the ACC, +12-24V.
17. GND (Ground Input Connection)
A good quality ground is required for your DD31T amplifier to operate at peak performance. A short length of cable the same
gauge as your power cable should be used to attach the ground terminal directly to the chassis of the vehicle. Make sure that all
of the paint is sanded or scraped away to ensure a quality ground connection.
NOTE: If installing in a boat, UTV or motorcycle make sure your ground wire is connected to the negative ( - ) terminal of
the battery.

POWER WIRING AND SIGNAL CONNECTIONS
Your DLS DD amplifier requires unrestricted current to deliver peak performance, so do not “starve”
your amplifier by using small power cable. Using under sized power cable can result in unnecessary over-heating of the amplifier,
distortion at high volume levels and might even cause the thermal protection circuitry to shut off the amplifier.
Remember, bigger wire is better!
• Use rubber grommets when running cables through any metal or sharp plastic, to prevent accidental shorting or shearing.
Make sure the cables do not interfere with normal operation of the vehicle.
• The audio signal cables (RCA interconnects) should be kept far away from any potential sources of electrical interference
such as electronic vehicle management systems (relays, engine computers etc.), wiring harnesses, fuel pumpsetc.
Fig.4 Power Input Connection
These amplifiers are designed to work within a 20 to 28 volt DC range. Before any wires are connected, the vehicles electrical
system should be checked for correct voltage supply with the help of a voltmeter.
First, check the voltage at the battery with the ignition in the OFF position. The voltmeter should read no less than 20v. If your
vehicles electrical system is not up to these specifications, we recommend having it checked by an auto electrician before any
further installation. Once the vehicle is checked, make certain the correct cable gauge is used. The DD amplifier terminals are
capable of accepting up to 8 gauge power and ground
cable. We recommend using as large a gauge cable as possible, use the Power Cable Selection Chart to cal culate the
correct power wire size for your application.
*** WARNING ***
Disconnect the negative (-) battery terminal before you start any wiring
work! The battery of your car audio system must be disconnected until the
entire wiring installation is completed.

BATT+ (Power)
POWER WIRING
This amplifier should be wired directly to the vehicle battery using the appropriate size cable. Start at the vehicle battery and run
the power cable through to the amplifier. Avoid running the power cable over engine components and near heater cores.
The use of an inline fuse or circuit breaker is a must; this will prevent the risk of a potential fire caused by a short in your
power cable. Connect the fuse holder or circuit breaker as close to the battery positive (+) terminal as possible (within 18” from the
battery). You may now connect the cable to the battery, but remember to leave the fuse out or circuit breaker “off” until all other
cable connections are made.
GND (Ground)
When grounding your amplifier, locate a metal area close to the amplifier that is good source of ground (preferable the floor pan).
Use a short length of cable the same gauge as your power cable. Once again, investigate the area you wish to use for electrical
wires, vacuum lines, and brake or fuel lines. Use either a wire brush or sandpaper to eliminate unwanted paint for better contact
of the ground.
NOTE: If installing in a boat, UTV or motorcycle make sure your ground wire is connected to the negative ( - ) terminal
of the battery. See Fig. 5
Fig.5 Proper Chassis Ground
Connection For Cars And Trucks
Secure the ground cable to the body using a bolt, star washer and nut. Spread silicon over the screw and bare metal to
prevent rust and possible water leaks.
For Power Sport applications such as UTVs, motorcycles and boats it is highly recommended to wire both the Ground (GND)
and Positive (BATT+) cables from the amplifier directly to the battery. NOTE: The Ground must be capable of carrying the
same amount of current as the positive wire.
Now it’s time to connect the power and ground cables to the amplifier. Cut both cables to length. Strip o 1/2 inch (12mm) of
the insulation so that the bare wire fits all the way in the terminal block on the side panel of the amplifier, seating it firmly so no
bare wire is exposed. Use a hex screw driver to lose the BATT+ and the GND connection on the amplifier. Insert the ground first,
and then the +24V and please make sure that you place them into the correctly marked terminals. Hand tighten the set screws
and make sure the connection is secure to prevent possible arcing due to lose screws.

REM (Remote Trigger)
This terminal must be connected to a switched +12v-+24v source. Typically, remote turn-on leads are provided at the source
unit that will turn on and off the amplifier in correspondence with the source. If the source unit does not have a remote turn-on
lead, then a switched +12-24V supply must be used, like the ACC, +12-24V.
Run a minimum of 18 gauge wire from the amplifier location to the source of the switched +12-24V lead. If possible, route this
wire on the same side of the vehicle as your power cable. Connect the source remote output to the wire. Go back to the amplifier
and cut the wire to length. Loosen the screw terminal marked REM on the amplifier using an Allen wrench. Insert the stripped
(bare) portion of the wire into the terminal and tighten the screw securely.
NOTE: It is highly recommended that an Hex wrench is used to tighten the
set screws in the terminal blocks by hand and NOT a power drill. This will
prevent stripping or other possible damage to the amplifier.
Amplifier features specially tooled sorderless terminals for power (Batt +),
ground , remote and speaker connection. For maximum transfer of
voltage and signal the bare wire needs to be inserted as far as possible
into the terminal before tightening the set screw.
Hand tighten the set screw and make sure the connection is secure to
prevent possible arcing due to loose screws.

FUSE REQUIREMENTS
Due to the small size of the DLS DD series amplifiers, no fuses are incorporated into the panels that normally protect the unit
from excessive current. Use an in-line fuse holder and fuse for this purpose.
Remember this fuse also protect the vehicle/vessel from a dangerous short circuit.
It is absolutely vital that the main power lead to the amplifier(s) in the system be fused within 18-inches (45cm) of the connection
to the battery.
Proper Ground Connection For UTVs, Motorcycles or Boats
Fig.6 Proper Ground Connection For UTVs, Motorcycles or Boats

SOURCE INTERCONNECT
Single RCA / Low Level Input
Choose the correct length and style of RCA interconnects for your needs. Always use high quality RCA audio
cables (not supplied) for signal connections—those with multiple layers of shielding or a twisted pair variety
for better noise rejection. Be extra careful when routing your RCA audio interconnect cables. Car
environments are notorious for poorly insulated wires. This means that hiss, engine noise, and fan noise can
easily be picked up through RCA cables if run incorrectly. Make sure that the cables for power and audio
signal are not on the same side of the vehicle and that they do not cross each other; this will help reduce any
noise that may radiate from the power cable and the signal cable. If an audio cable is too close to a power
cable, it may pick up the magnetic field generated by the power cable, which could lead to a loss of quality
in your signal.
NOTE: A side panel AUX Input is available for use with portable MP3 players or an iPod ®* Use
of this input will not override (defeat) the
RCA low level inputs.
*NOTE* The Aux input sensitivity is reduce when RCA/High level input is connected. If higher sensitivity is required please
disconnect front input from other source. AUX input note: When Aux input is connected to a phone it will attenuate RCA/HL inputs,
please disconnect the Aux source plug (phone) to have full volume from other source.
HLC harness: With the special high level adapter the front input can be used with speaker input signals.
Fig.7a Input using Single RCA or
3.5mm AUX Cable

SOURCE INTERCONNECT
Dual RCA / Low Level Input (Front and Subwoofer)
Fig.8 Input using two pairs of RCA cables

SOURCE INTERCONNECT
Single High Level / Speaker Input
Fig.9 High Level / Speaker Level Input
1) To use speaker level inputs please connect the HLC harness to connector,
2) Connect the wires from the speaker output of the radio to the white and grey wires of the amplifier input wires using the color
codes in above drawing.
3) If you are using both High Level / Speaker Inputs, make sure the MODE Selector switch is in the
3CH position
White (Solid) = Left +
White/Black(Striped)=Left-
Grey(Solid)=Right+
Grey / Black (Striped) = Right -

SET UP ADJUSTMENTS
INPUT Gain Adjustment
GAIN
Control Panel (3) and (11)
GAIN Control
This control allows you to match the input level of the amplifier to the output level of your head unit. Matching the input can be
accomplished in three simple steps:
1. Set the volume of GAIN on the amplifier to Min (completely counter clock wise).
2. Turn on the head unit and adjust volume to 2/3 maximum, and set the BASS to zero.
3. Adjust the GAIN control clockwise until the sound just begins to distort, then back o slightly to cut distortion and operate
at optimum gain.
Remember, the GAIN control is not a volume control . Ignoring the three steps above may leave you with damaged
speaker and/or a damaged amplifier.
Control Panel (8)
Bass EQ Control
BASS EQ Control
This special feature is designed to provide you more powerful sound quality, and it allows you to increase the bass output up to
+18dB at 45Hz (Sub Channel only). Keep in mind more is not always better. Setting the control to the max (18dB) may stress the
amplifier and woofer and could result in damage.
NOTE: More is not always better. By turning the BASS EQ all the way up to 18dB you can overwork the
amplifier and send the unit into thermal protection.
Control Panel (10)
Low Pass Control (LPF)
LPF (Low Pass Filter) Adjustment
50HZ250HZ
-
Adjust the LPF frequency for your subwoofer(s) operation. Using the LPF control, adjust the Low Pass Frequency to limit the
amount of midrange going to your subwoofers.
MIN
M AX

40HZ 400HZ
Control Panel (6)
High Pass Control (HPF)
HPF (High Pass Filter) Adjustment
When you are using coaxial or component speaker system, this allows you to adjust high-pass X-over frequency from 40Hz to
400Hz. To get better sound quality from coaxial or component speaker system, we recommend the frequency should be higher
than 80Hz. Make sure the X-OVER switch is positioned at “HPF”.
INPUT
DD31T
Fig.10 2-3 Channel Input Mode
Input Switch
Matches the input from the Source Unit to the amplifiers. This eliminates the use of “Y” adapters and provides a cleaner
input signal. When the 2-Channel mode is selected, both front and sub outputs will operate with only one pair of low level
RCA inputs.
AUX INPUT NOTE: The MODE switch must be in the 2CH position in order to use
the 3.5mm AUX input
1) Using the 2CH Mode on the DD31T requires input signal to the Front Input Connector.
2) Using the 3CH Mode on the DD31T requires both the Front Input and Subwoofer Input to be used. This will allow for fading
between the Front and Rear/Subwoofer Outputs.
3CH

Fig.11 Connection with RJ12 Jack
REMOTE LEVEL Controller Connection
Your DLS DD31T amp includes a Remote Level control module. To connect the Remote Level Control to the amplifier,
simply insert one end into the REMOTE LEVEL port. Plug the other end into the remote module. Install the module within
easy reach on or under your dash.
SPEAKER WIRING AND CONFIGURATIONS
Speaker Load
Keep in mind your DLS DD31T amplifier is a high power amplifier and not a high current amplifier. In other words this
amplifier requires a minimum impedance of 2 ohms STEREO and 4 ohms bridged (2-ohms MONO on SUB channel)
to operate trouble free Lower. impedance will send the amplifier into protection and possibly damage the electronics inside
and void the waranty.
NOTE: Know your total impedance load before you make any connections.
Speaker Wiring
Choose the correct speaker wire for your application. Most applications will require a minimum of 16 gauge wire. At the amplifier
end, splice the speaker wires to the properly marked output leads from the Molex style connector. Route these using the same
precautions as you did when you ran the power cable. Check to make sure you’ve maintained proper polarity and balance.
CAUTION:
Maintaining proper impedance is critical when wiring the Full Range Digital model amplifiers. Improper wiring can cause
severe damage to BOTH the speakers and the amplifier. Detailed wiring diagrams are supplied with all DLS woofers. IF
YOU ARE NOT EXPERIENCED OR UNCOMFORTABLE READING THE WIRING DIAGRAMS CONSULT YOUR
AUTHORIZED DLS DEALER BEFORE YOU ATTEMPT TO WIRE THE SYSTEM.

PLEASE OBSERVE POLARITY AS SHOWN ON WIRE MARKERS.
Speaker Output Connections 3 Channel Model
(DD31T)
1. 3-Channel Speaker Output Connection
Fig.12 3-CH Speaker Connection
(Do not connect total impedance under 2 ohms)

TROUBLESHOOTING TIPS
Problem
Solution
Power LED not ON
With a Volt Ohm Meter (VOM) check:
•
+24 Volt power terminal (should read +20 to +28V DC
• Remoteturn onterminal(should read +12 to+28V DC)
•
Ground Terminal
Power LED lights BLUE, no output
•
Check RCA connections
• Test speaker outputs with known goodspeaker
• Substitute known good Source Unit
• Check for signal on the RCA cable with VOM inAC position.
Power LED lights BLUE, but volume
•
Short circuit protection is engaged.Check for speaker
reduces automatically.
wires shorted to each other or the vehicle chassis.
Red Status Protection LED is ON, no
output and
1. Amp is VERY HOT
•
Advanced Protection Circuitry is engaging due to high
internal temperature of the amplifier. Amplifer requires
more air flow around the chassis. If this continues
choose a better ventilated mounting location.
2. Amp shuts down ONLY when the
•
Voltage protection engaged. Voltage to the amp is not
vehicle is running
within the 20-28 VDC operating range.
Have the battery/ charging system inspected.
3. Amp has no output
•
Possible short circuit. Check speaker wiring. Must
completely turn off amplifier and restart to resume play.
Alternator noise (varies with RPM)
•
Check for damaged RCA cable.
• Check routing of RCA cable
• Check Source Unit for good ground
• Check amp gain setting, turn down ifset too high
Poor Bass Response
•
Check speaker polarity, reverse the connection of one
speaker only.
NOTE: After using all the troubleshooting tips above, if the Status L.E.D. is activated and glows RED with no
speakers connected to the amplifier, and all the power connections are correct, this would indicate an
internal problem with the amplifier. Contact DLS Sweden or your local dealer.

Specifications
*REQUIRES EXTERNAL FUSE !
Important Notes:
-Due to continuing improvements these specifications are subject to change
without any notice.
-Do not attempt to fix or repair this unit. Unauthorized repairs will void the
manufacturer’s warranty
Number of channels
Amplifier class
Power output RMS, 2 ohm (1%THD)
Peak music power, 2 ohm
Power output RMS, 4 ohm (1%THD)
Signal to noise ratio, A-weighted
Damping factor
Frequency response
Input impedance, low level
Input sensitivity
Input impedance, high level
High level input with auto start
Filter low pass variable
Filter High pass variable
Bass boost
Remote sub level control
Power consumption, idle
Power consumption, max
Recommended Fuse
Dimensions HxWxD(mm)
Dimensions (inch)
Weight
Voltage
DD31T
3
D
125Wx2+350W
600 W
80Wx2+200 W
>90 dB
>80
10 Hz - 20 kHz
22 kohm
250mV - 5V
40 ohm
Yes
50-250 Hz
40-400 Hz
+0-18 dB
Yes
0,6 A
60A
40A
35 x 103 x 215
1,4 x 4,0 x 8,5
3 kg
20-28V
