DLV Jewel Jackpot User manual

Jewel Jackpot
Setup and Service Menu Manual
Revision 1.3
Applicable to:
1) Jewel Jackpot 1.6.1.0 and higher;

Jewel Jackpot - Setup and Service Menu Manual 1.3.doc 2
1 Table of Contents
1.1 Sections
1 Table of Contents ....................................................................................................................2
1.1 Sections............................................................................................................................2
1.2 Figures.............................................................................................................................3
1.3 Tables ..............................................................................................................................4
2 Revision History......................................................................................................................5
3 RAM Clear ..............................................................................................................................6
4 DIP Switches Configuration....................................................................................................8
5 Navigation and Access ............................................................................................................9
5.1 Initial Setup and Service Menus......................................................................................9
5.2 Input Dialogs ...................................................................................................................9
5.3 Digital and Mechanical Keys ..........................................................................................9
6 Activation ..............................................................................................................................11
7 Initial Setup Menu.................................................................................................................12
7.1 Initial Regional Setup....................................................................................................12
7.2 Initial Machine Setup ....................................................................................................13
7.3 Initial Jackpot Setup ......................................................................................................15
7.4 Initial Games Setup .......................................................................................................16
7.5 Initial Hardware Setup...................................................................................................17
7.5.1 Bill Acceptor .........................................................................................................17
7.5.2 Coin Acceptor........................................................................................................18
7.5.3 Coin Hopper ..........................................................................................................19
7.5.4 Hardware Meters ...................................................................................................20
7.6 Summary........................................................................................................................21
7.6.1 Software.................................................................................................................21
7.6.2 Machine.................................................................................................................22
7.6.3 Jackpot...................................................................................................................22
7.6.4 Regional.................................................................................................................23
7.6.5 Hardware ...............................................................................................................23
8 General Service and Setup Menu ..........................................................................................24
8.1 Summary........................................................................................................................24
8.2 Statistics.........................................................................................................................24
8.2.1 General Statistics...................................................................................................24
8.2.2 Accounting Statistics.............................................................................................24
8.2.3 Bill Acceptor Statistics..........................................................................................25
8.2.4 Coin Acceptor Statistics ........................................................................................25
8.2.5 Access Statistics ....................................................................................................25
8.2.6 Main Game Statistics.............................................................................................25
8.2.7 Jackpot Client Statistics.........................................................................................26
8.2.8 Jackpot Server Statistics........................................................................................26
8.3 History...........................................................................................................................26
8.3.1 Bill Log..................................................................................................................26
8.3.2 Coin Log................................................................................................................26
8.3.3 Remote Input Log..................................................................................................27
8.3.4 Payout Log.............................................................................................................27

Jewel Jackpot - Setup and Service Menu Manual 1.3.doc 3
8.3.5 Access Log ............................................................................................................27
8.3.6 Error Log ...............................................................................................................28
8.3.7 Jackpot Log ...........................................................................................................28
8.4 Diagnostics ....................................................................................................................28
8.4.1 Coin Acceptor Test................................................................................................28
8.4.2 Bill Acceptor Test..................................................................................................29
8.4.3 Ticket Printer Test.................................................................................................30
8.4.4 Coin Hopper Test ..................................................................................................30
8.4.5 Buttons and Lamps Test........................................................................................31
8.4.6 Display and Touch Screen Test.............................................................................32
8.4.7 Hardware Monitoring............................................................................................33
8.4.8 Sound Test.............................................................................................................33
8.5 Setup..............................................................................................................................33
8.5.1 Limits Setup...........................................................................................................33
8.5.2 Game Setup ...........................................................................................................35
8.5.3 Machine Setup.......................................................................................................36
8.5.4 Remote Input Setup...............................................................................................37
8.5.5 Date and Time Setup .............................................................................................38
8.5.6 Bill Acceptor Setup ...............................................................................................38
8.5.7 Coin Acceptor Setup..............................................................................................38
8.5.8 Coin Hopper Setup ................................................................................................39
8.5.9 Touch Screen Setup...............................................................................................39
8.5.10 Digital Keys Setup.................................................................................................40
8.5.11 SAS Setup..............................................................................................................41
8.5.12 Jackpot Client Setup..............................................................................................42
8.5.13 Jackpot Server Setup .............................................................................................42
9 Game Menu ...........................................................................................................................44
9.1 General Statistics...........................................................................................................44
9.2 Game Log......................................................................................................................44
9.3 Win Log.........................................................................................................................45
9.4 Main Game Statistics.....................................................................................................45
10 Remote Input and Payout ..................................................................................................46
10.1 Remote Input Menu.......................................................................................................46
10.2 Hand pay Dialog............................................................................................................47
10.3 Coin Hopper Payout Window........................................................................................48
11 Error Messages..................................................................................................................49
11.1 Error Screen...................................................................................................................49
11.2 Table of Error Codes .....................................................................................................50
1.2 Figures
Figure 1: Ram Clear confirmation screen........................................................................................7
Figure 2: General purpose DIP switches.........................................................................................8
Figure 3: Date Input Dialog.............................................................................................................9
Figure 4: Activation.......................................................................................................................11
Figure 5: Initial Setup, Regional tab..............................................................................................12
Figure 6: Initial Setup, Jackpot tab................................................................................................15
Figure 7: Initial Setup, Games tab.................................................................................................17

Jewel Jackpot - Setup and Service Menu Manual 1.3.doc 4
Figure 8: Initial Setup, Summary tab.............................................................................................21
Figure 9: Coin Acceptor Diagnostics ............................................................................................29
Figure 10: Bill Acceptor Diagnostics............................................................................................30
Figure 11: Coin Hopper Diagnostics.............................................................................................31
Figure 12: Input/Output Diagnostics.............................................................................................32
Figure 13: Display and Touch Screen Diagnostics .......................................................................33
Figure 14: Digital Key Setup.........................................................................................................40
Figure 15: Digital Key Reader Dialog...........................................................................................40
Figure 16: Game Log.....................................................................................................................45
Figure 17: Remote Input Menu .....................................................................................................47
Figure 18: Handpay Dialog ...........................................................................................................47
Figure 19: Coin Hopper Payout Window......................................................................................48
Figure 20: Error Screen .................................................................................................................50
1.3 Tables
Table 1: DIP switch functions.........................................................................................................8
Table 2: Digital and Mechanical Key Access Levels....................................................................10
Table 3: Error codes ......................................................................................................................52

Jewel Jackpot - Setup and Service Menu Manual 1.3.doc 5
2 Revision History
Version Date Author Description
1.0 Maxim Radugin Initial document release
1.1 Maxim Radugin Added jackpot server/client selection DIP
switch description
1.2 Maxim Radugin Added jackpot initial starting value description
1.3 2010.06.18 Maxim Radugin Added jackpot initial values deviation
Added jackpot log
Added jackpot summary
Added touchscreen device automatic and
manual type selection

Jewel Jackpot - Setup and Service Menu Manual 1.3.doc 6
3 RAM Clear
RAM Clear operation can performed by using special “RAM Clear” CompactFlash card or by
turning DIP switch 8 on the I/O board to ON position.
RAM Clear using “RAM Clear” CompactFlash card
1. Open the main door;
2. Power down the machine;
3. Open the logic box door;
4. Remove the game CompactFlash card from the upper socket on the motherboard;
5. Insert “RAM Clear” CompactFlash card into the first (upper) socket on the motherboard;
6. Close the logic box door;
7. Power up the machine;
8. After software initialization press “START” button or touch “YES” button on the screen
(if touch screen is connected) to perform complete RAM clear;
9. Wait for confirmation message to appear on the screen;
10. Power down the machine;
11. Replace “RAM Clear” CompactFlash card with game CompactFlash card;
12. Close logic box door;
13. Close main door;
14. Power up the machine;
15. After software initialization game will automatically switch to “Initial Setup” menu.
RAM Clear using DIP switch 8 on the I/O board
1. Open the main door;
2. Power down the machine;
3. Open the logic box door;
4. Turn DIP switch 8 to ON position;
5. Close the logic box door;
6. Power up the machine;
7. After software initialization press “START” button or touch “YES” button on the screen
(if touch screen is connected) to perform complete RAM clear;
8. Wait for confirmation message to appear on the screen;
9. Power down the machine;
10. Turn DIP switch 8 to OFF position;
11. Close logic box door;
12. Close main door;
13. Power up the machine;
14. After software initialization game will automatically switch to “Initial Setup” menu.
NOTE: RAM Clear operation can be canceled without loosing any data stored in RAM by
pressing “BET” button, touching “NO” button on the screen (if touch screen is connected) or by
powering down the machine.
WARNING: RAM Clear operation will permanently erase all the settings, accounting and
statistical data from the RAM!

Jewel Jackpot - Setup and Service Menu Manual 1.3.doc 7
Figure 1: Ram Clear confirmation screen

Jewel Jackpot - Setup and Service Menu Manual 1.3.doc 8
4 DIP Switches Configuration
I/O board contains DIP switches for machine configuration.
1 2 3 4 5 6 7 8
ON
OFF X X X X X X X X
Figure 2: General purpose DIP switches
“X” corresponds to default switch position
Switch Function
1 Primary monitor selection (OFF – primary DVI monitor, ON – primary VGA
monitor)
2 Jackpot client/server selection (OFF – client, ON – server)
3 Reserved
4 Reserved
5 Reserved
6 Reserved
7 Reserved
8 RAM Clear (OFF – Normal Operation, ON – RAM Clear)
Table 1: DIP switch functions

Jewel Jackpot - Setup and Service Menu Manual 1.3.doc 9
5 Navigation and Access
System supports two methods of navigating through menus – using game panel buttons or using
touch screen (if applicable).
Currently selected tab/list is highlighted with red color or border around the button.
5.1 Initial Setup and Service Menus
Button/Key Function
START BUTTON Enter into currently selected tab, press selected button or
change the state of the checkbox.
BET BUTTON Exit currently selected tab – go level up.
HOLD1 BUTTON Select previous value in list
HOLD2 BUTTON Select next value in the list
HOLD3 BUTTON Select previous component or tab
HOLD4 BUTTON Select next component or tab
TEST BUTTON Exit Initial Setup or Service Menu
OWNER KEY Exit Initial Setup
5.2 Input Dialogs
Button/Key Function
START BUTTON When input field is active – confirm changes and close the
dialog, or when button is active – press current button
BET BUTTON Previous character in current position of the input field
MAXBET BUTTON Next character in current position of the input field
HOLD1 BUTTON Delete current or previous character in the input field
(depending on position of cursor)
HOLD2 BUTTON Move to next position in input field
HOLD3 BUTTON Move between input field and buttons
HOLD4 BUTTON Move between input field and buttons
Figure 3: Date Input Dialog
5.3 Digital and Mechanical Keys

Jewel Jackpot - Setup and Service Menu Manual 1.3.doc 10
Digital and mechanical can have 4 different access levels.
Access Level Description
OWNER Owner key gives access to the setup and service menu – overall and period
statistics; period meter reset function, history, diagnostics and setup.
NOTE: Setup and overall meters are available only when number of
available credits is zero.
RENTIER Rentier key gives access to the limited number of functions in service menu
– period meters, history and diagnostics.
CASHIER Cashier key provides access to enter remote input menu, reset handpays and
reset errors.
CROUPIER Croupier key can only be used to enter remote input menu.
Table 2: Digital and Mechanical Key Access Levels

Jewel Jackpot - Setup and Service Menu Manual 1.3.doc 11
6 Activation
After performing RAM Clear operation, machine can request the activation code.
To activate the machine, Request code should be sent directly to the manufacturer or another
official representative or distributor via e-mail or SMS. In reply to request code, activation code
will be sent. Activation code should be entered in “Activation Code” field.
After code is entered, “Activate” button should be pressed. If the code is valid, “OK” button will
appear. After pressing “OK” button, Initial Setup Menu will appear.
NOTE: If the activation code is not valid or entered incorrectly, machine will generate new
request code, and the new activation code should be requested from the manufacturer as
described above. Previous activation code will not work!
NOTE: Initial setup should be completed and confirmed before switching off the machine,
otherwise on the next startup machine will request activation code again.
Rent Mode Yes if machine is rented, no – regular operation.
Time Remaining Displays number of days, hours and minutes machine can be
operated.
When rent time runs out, Activation screen will be shown.
Figure 4: Activation

Jewel Jackpot - Setup and Service Menu Manual 1.3.doc 12
7 Initial Setup Menu
Initial setup is activated on the first power up of the machine or after the RAM clear operation
was performed.
Initial gaming machine setup provides options for performing configuration of critical gaming
machine parts.
NOTE: Some options are available for configuration only within the Initial Setup. Values of
these options will not be available for editing after the initial setup is completed.
After performing initial setup of the machine and reviewing selected options press TEST
BUTTON or turn mechanical OWNER KEY to save parameters and exit Initial Setup.
7.1 Initial Regional Setup
Figure 5: Initial Setup, Regional tab
Currency Options
Currency String Currency string to be displayed in accounting and games
Set Currency… Opens dialog to set currency string (3 characters)
No. of Digits after Decimal Number of decimal digits to be displayed for cash fields in
service, accounting menus and game screens

Jewel Jackpot - Setup and Service Menu Manual 1.3.doc 13
•0
•1
•2
•3
Date/Time
Date Format Date format to be used in service menus
•DD.MM.YYYY
Set Date… Opens dialog to set current date
Time Format Date format to be used in service menus
•HH:MM:SS
Set Time… Opens dialog to set current time
Language
Game Language Default game language
•English
Menu Language Language in setup and service menus
•English
7.2 Initial Machine Setup
General
Machine Number Machine number on the floor
Set Number... Opens machine number edit dialog
Credit Denomination
Base Denomination Base denomination unit used in accounting and statistics
•0.001
•0.005
•0.01
•0.02
•0.025
•0.05
•0.10
•0.20
•0.25
•0.50
•1.00
•2.00
•2.50
•5.00
•10.00
•20.00
•25.00
•50.00
•100.00
•200.00
•250.00
•500.00

Jewel Jackpot - Setup and Service Menu Manual 1.3.doc 14
•1000.00
Paylines
Reels Games Number of paylines available for selection in reels games
(except for “fruits” games).
•1..5
•1..9
Fruits Games Number of paylines available for selection in “fruits” games
•5
Bets
Bet per Line Selection Mode Selection mode for bet per line in reels and fruits games:
•Progressive (1..100)
•Progressive (1..30)
•Progressive (1..50)
•Progressive (10..1000)
Available Bets per Line Displays available bets per line in selected mode
Poker Bet Selection Mode Selection mode for bets in poker games (if applicable):
•Progressive (1..1000)
•Progressive (1..300)
•Progressive (1..500)
•Progressive (10..10000)
Available Poker Bets Displays available bets in poker games
Total Bet Limit Total bet limit for all games:
•100
•200
•300
•400
•500
•600
•700
•800
•900
•1000
•10000
Limits
Win Log Limit Games with winning that exceeds current value will be
registered in Win Log.
•Disabled
•1000
•10000
•100000
•1000000
•10000000
•100000000
Game Win Limit Winning limit in the game. If winning in the single game
exceeds selected value, hand pay window will appear.
•Disabled

Jewel Jackpot - Setup and Service Menu Manual 1.3.doc 15
•100.00
•1000.00
•10000.00
•100000.00
•1000000.00
•10000000.00
•100000000.00
7.3 Initial Jackpot Setup
Figure 6: Initial Setup, Jackpot tab
Information
Connected and Available Yes, if machine is connected and configured correctly in the
jackpot network;
NOTE: For jackpot to be available, following conditions
should be met:
1. Bet ranges for Reels Games, Fruits Games and Poker
Games (shown in Machine tab) should in range of
Allowed Bets;
2. If machine is configured as client, it should be registered
and accepted by the server machine; Client machine can
be registered on the server machine in Service Menu >

Jewel Jackpot - Setup and Service Menu Manual 1.3.doc 16
Setup > Jackpot Server by pressing “Accept” button next
to corresponding client machine entry;
Allowed Bets Range of allowed bets in currency, for machine to participate
in the jackpot.
Client Configuration Jackpot client configuration parameters
Floor Number Currently set floor number for this machine in the network
Set Floor Nr… Sets floor number in the network for this particular machine
General Configuration Jackpot server configuration
Multiplier Jackpot value multiplier:
•1
•10
•100
•1000
Restart Deviation Jackpot value deviation from restart values for the next
jackpot
•None – no deviation
•0.05 – ±5% deviation
•0.1 – ±10% deviation
•0.2 – ±20% deviation
•0.3 – ±30% deviation
Configuration Available configurations:
•Configuration 1
•Configuration 2
•Configuration 3
Contribution Displays contribution percentage from each total bet played
on the machine
Frequency Displays theoretical jackpot hit in cash
Restart Values Displays starting values of each progressive jackpot level
Initial Starting Values Setup for initial starting values for progressive levels
Initial Values Configuration Displays initial starting values of each progressive jackpot
level
Set Level 1… Allows to set initial starting value for progressive level 1
Set Level 2… Allows to set initial starting value for progressive level 2
Set Level 3… Allows to set initial starting value for progressive level 3
7.4 Initial Games Setup

Jewel Jackpot - Setup and Service Menu Manual 1.3.doc 17
Figure 7: Initial Setup, Games tab
Games tab contains list of games and available percentages for main game for selection (w/o
jackpot).
Jewels Jackpot Jewel Jackpot payout percentage
Average Theoretical Payout Average payout percentage for all games (including jackpot)
7.5 Initial Hardware Setup
7.5.1 Bill Acceptor
General
Enable Bill Acceptor Enables bill acceptor support.
•Disabled
•Enabled
Autodetect… Auto detects currently connected bill acceptor device.
NOTE: Currently software supports only JCM EBA/WBA
ID-003 protocol compatible devices.
Bill Configuration
Query Device… Read pre-programmed bill table from the bill acceptor device.
Pressing this button will override values in Bill Table.
Bill Table

Jewel Jackpot - Setup and Service Menu Manual 1.3.doc 18
Channel 0…15 Enable/disable individual channels
•Disabled
•Enabled
Value 0…15 Contains values of the bills on the corresponding channel.
Even is channel is enabled, bill on channels that are equal to
zero will not be accepted.
•0.00
•1.00
•2.00
•2.50
•5.00
•10.00
•20.00
•25.00
•50.00
•100.00
•200.00
•250.00
•500.00
•1000.00
•2000.00
•2500.00
•5000.00
•10000.00
•20000.00
•25000.00
•50000.00
•100000.00
•200000.00
•250000.00
•500000.00
•1000000.00
7.5.2 Coin Acceptor
General
Enable Coin Acceptor Enables coin acceptor support
•Disabled
•Enabled
Type Type of coin acceptor device
•NOT INSTALLED Coin Acceptor is not installed
•NRI G-13 MFT NRI G-13 MFT Coin Acceptor
Coin Table
Channel 0…5 Enable/disable individual channels
•Disabled
•Enabled
Value 0…5 Contains values of the coins on the corresponding channel

Jewel Jackpot - Setup and Service Menu Manual 1.3.doc 19
•0.00
•0.01
•0.02
•0.025
•0.05
•0.10
•0.20
•0.25
•0.50
•1.00
•2.00
•2.50
•5.00
•10.00
•20.00
•25.00
•50.00
•100.00
•200.00
•250.00
•500.00
•1000.00
•2000.00
•2500.00
•5000.00
•10000.00
•20000.00
•25000.00
•50000.00
•100000.00
•200000.00
•250000.00
•500000.00
•1000000.00
7.5.3 Coin Hopper
General
Enable Coin Hopper Enables coin hopper support
•Disabled
•Enabled
Type Type of coin hopper device
•NOT INSTALLED Coin hopper is not installed
•SUZO CUBE HOPPER
MKII SUZO CUBE HOPPER MKII
•
MONEY CONTROLS MONEY CONTROLS UNIVERSAL

Jewel Jackpot - Setup and Service Menu Manual 1.3.doc 20
UNIVERSAL
•MONEY CONTROLS
UNIVERSAL MK4 MONEY CONTROLS UNIVERSAL MK4 with presence
control.
Coin Configuration
Coin Value Value of single coin in currency
•0.01
•0.02
•0.025
•0.05
•0.10
•0.20
•0.25
•0.50
•1.00
•2.00
•2.50
•5.00
•10.00
•20.00
•25.00
•50.00
•100.00
•200.00
•250.00
•500.00
•1000.00
•2000.00
•2500.00
•5000.00
•10000.00
•20000.00
•25000.00
•50000.00
•100000.00
•200000.00
•250000.00
•500000.00
•1000000.00
7.5.4 Hardware Meters
General
High Speed Speed of mechanical meters
•Disabled
•Enabled
Meter Configuration
