DM Group AVR-1612 User manual

MODEL: AVR-1612
Model Information
INTEGRATED NETWORK AV RECEIVER
I/R Codes
Product Specifications
Upgrades/Updates
Accessories
Reset Procedure
Warranty
Remote Control
Rear Panel
Front Panel
1
Model Information
Index
MI093015E3-1
NOTE:
This edition is missing the FAQ’s content (pages 12 and 13) ……………………………………………………….11/16/2016
This edition is missing the link to the IR Codes…………………………………………………….………………….11/16/2016
Protection History
Display Mode

Front Panel
HOME Display 1 2
 Power operation button
(ON/STANDBY)
Turns power to this unit on and off (standby).
Power indicator
Headphones jack (PHONES)
When the headphones are plugged into this jack,
audio will no longer be output from the connected
speakers or from the PRE OUT connectors.
NOTE: To prevent hearing loss, do not raise the
volume level excessively when using headphones.
QUICK SELECT buttons
iPod play button (iPod )
iPod system buttons
• Stop button ()
• Skip buttons ( )
Remote control sensor
 Tuner Preset channel buttons
(TUNER PRESET CH+,-)
SHIFT button
TUNER button
Input source select button (SOURCE)
 RESTORER button
 SLEEP button
 DIMMER button
 STATUS button
 PORTABLE IN jack
V.AUX INPUT connectors
Remove the cap covering the connectors
when you want to use them.
 SETUP MIC jack
 MASTER VOLUME control knob
Master volume indicator
 Display·

HOME REAR PANEL
Buttons and Connectors Behind the
Compartment Door (2 of 2) 3
Display (1 of 2)
Decoder indicators
These light when the respective decoders are operating.
Input signal indicators
Information display
The input source name, surround mode, setting values and other
information are displayed here.
Master volume indicator
Sleep timer indicator
This lights when the sleep mode is selected
MUTE indicator
This lights when the mute mode is selected
Audyssey® indicators
Lights up as follows, depending on the setting of “MultEQ® XT”,
When “MultEQ® XT”, “Dynamic EQ®” and
“Dynamic Volume®” are “ON”.
When “MultEQ® XT” and “Dynamic EQ®” are “ON”
and “Dynamic Volume®” is “OFF”.
When “MultEQ® XT” is “ON” and “Dynamic EQ®”
and “Dynamic Volume®” are “OFF”.
Surround back indicator
This lights when audio signals are being output from the surround
back speakers (vpage 86).
Input mode indicators
Set the audio input modes for the different input sources
AUDYSSEY
MULTEQ XT
DYN VOL
AUDYSSEY
MULTEQ XT
DYN EQ
AUDYSSEY
MULTEQ XT

HOME
Buttons and Connectors Behind the
Compartment Door (2 of 2) 4
Display (2 of 2)
RESTORER indicator
This lights when the RESTORER mode is selected (vpage 83).
HDMI indicator
This lights when playing using HDMI connections.
 Tuner reception mode indicators
These light according to the reception conditions when the input
source is set to “TUNER”.
STEREO : In the FM mode, this lights up when receiving stereo
broadcasts.
TUNED : Lights up when the broadcast is properly tuned in.
AUTO : Lights up when in the auto tuning mode.
REAR PANEL

HOME
DISPLAY 5
FM/AM antenna terminals
Analog audio connectors
Speaker terminals
S-VIDEO/VIDEO connector
Power cord
 HDMI connectors
PRE OUT connectors
Digital audio connector
DOCK CONTROL jack
8
9
12345
6
7
Rear Panel
REMOTE CONTROL 1

HOME
Signal transmission indicator
Input source select buttons
QUICK SELECT buttons
 AMP button
Channel buttons
(CH +, –)
 Muting button
MENU button
Cursor buttons
()
 SEARCH button
 System buttons
• Search buttons ( )
• Skip buttons ( )
• Play button ()
• Pause button (II)
• Stop button ()
Tuner system buttons
• FM/AM band switching button (BAND)
• Tuning mode button (MODE)
• Tuning up / Tuning down buttons
(TUNING )
REMOTE CONTROL 2REAR PANEL 6
Remote Control (1 of 2)

HOME
Character buttons
MEMORY button
Number buttons
SHIFT button
 TV operation buttons
(TV I / O/ INPUT)
 Remote control signal transmitter
 Power buttons
(ON / STANDBY)
 SOURCE SELECT button
Master volume control buttons
( )
Channel level button (CH LEVEL)
 RETURN button
 ENTER button
 Surround mode buttons
• MOVIE button
• MUSIC button
• GAME button
• DIRECT button
 SLEEP button
DEVICE power buttons
(DEVICE O/ DEVICE I)
WarrantyREMOTE CONTROL 1 7
Remote Control (2 of 2)

DENON LIMITED WARRANTY (1 of 2)
This warranty will be honored only in the U.S.A.
Length of Non-Transferable Warranty
This warranty on your DENON product which is distributed and warranted by DENON ELECTRONICS (USA), LLC remains in effect
for the following periods from the date of the original consumer purchase from an AUTHORIZED DENON ELECTRONICS (USA),
LLC DEALER.
DENON ELECTRONICS (USA), LLC
(a D&M Holdings Company)
100 Corporate Drive
Mahwah, NJ 07430-2041
[phone]
www.usa.denon.com
DENON FACTORY SERVICE by PANURGY OEM
701 Ford Road (South Dock)
Rockaway, NJ 07866-2053
[phone]
[phone] Fax
http://www.panurgyoem.com/Denon/Denonrepair.html
See the next page for more information about the Denon limited warranty
HOME
2 years for units purchased new
1 year for refurbished (B-Stock) units
WARRANTY 2REMOTE CONTROL 2 8

Warranty (2 of 2)
What is Covered
Except as specified below, this Warranty covers all defects in material and workmanship in this product occurring during the above warranty periods.
The following are not covered by the Warranty: (1) Any product which is not distributed in the U.S.A. by DENON ELECTRONICS (USA), LLC. (2) Any
product which is not purchased in the U.S.A. from an authorized DENON dealer. (Note: AUTHORIZED DENON DEALERS can be identified by
DENON AUTHORIZED DEALER sticker displayed in the stores. If you are uncertain as to whether a dealer is a DENON AUTHORIZED DEALER,
please contact DENON as listed below). (3) Any product on which the serial number has been defaced, modified or removed. (4) Damaged
deterioration or malfunction resulting from: a) Accident, act of nature, abuse, misuse, neglect, unauthorized product repair, opening of or modification
or failure to follow instructions supplied with the product. b) Repair or attempted repair by anyone not authorized by DENON. c) Any shipment of the
product (claim must be presented to carrier). (5) Items subject to wear from normal usage (tape heads, cartridges, stylus, battery, etc.). (6) Periodic
check-ups which do not disclose any defect. (7) Use of the product outside the U.S.A. (8) Damaged magnetic tape or CD/DVD/BD discs. (9) Use in
industrial, commercial, and/or professional applications. (10) Any installation or removal charges resulting from product failure.
What We Will Pay For
If during the applicable warranty period from the date of original consumer purchase your DENON product is found to be defective by DENON,
DENON will repair, or at its option, replace with new, reconditioned or equivalent model, such defective product without charge for parts or labor.
How to Obtain Warranty Performance
If your unit ever needs service, it may be taken or shipped to any authorized DENON service station or DENON ELECTRONICS (if you are uncertain
as to whether a service station is DENON authorized, please visit our website at http://usa.denon.com/us/Support/Pages/ServiceCenterSearch.aspx or
contact DENON as listed below.) In all other cases, the following procedures apply whenever your unit must be transported for warranty service;
You are responsible for transporting your unit or arranging for its transportation.
If shipment of your unit is required;
You must pay the initial shipping charges, but we will pay the return shipping charges if the repairs are covered by the Warranty.
WHEN RETURNING YOUR UNIT FOR WARRANTY SERVICE, A COPY OF THE ORIGINAL SALES SLIP MUST BE ATTACHED.
You should include the following: your name, address, daytime telephone number, model and serial number of the product and a description of
the problem. In the case of a CD/DVD/BD Player, please enclose ONE (1) disc that the unit has failed with for test reasons. It will be returned
with the unit.
THIS WARRANTY IS VALID IN THE U.S.A. ONLY.
If your product does not require service, but you have questions regarding its operation, please contact our Customer Support Department as listed
below.
THIS WARRANTY IS EXPRESSLY MADE IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING WITHOUT LIMITATION,
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
OUR LIABILITY IS LIMITED TO THE REPAIR OR REPLACEMENT, AT OUR OPTION, OF ANY DEFECTIVE PRODUCT AND SHALL IN NO EVENT
INCLUDE INCIDENTAL OR CONSEQUENTIAL COMMERCIAL OR PROPERTY DAMAGES OF ANY KIND. WE ARE NOT RESPONSIBLE FOR
PRODUCTS LOST, STOLEN AND/OR DAMAGED DURING SHIPPING.
SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS AND/OR DO NOT ALLOW THE
EXCLUSION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS AND EXCLUSIONS MAY NOT APPLY TO
YOU.
This warranty gives you specific legal rights, but you may also have other rights which vary from state to state. This Warranty may not be altered other
than in a writing signed by an officer of Denon Electronics USA, LLC.
HOME RESETWARRANTY 1 9

Reset
HOME
Reset procedure:
With the power off, press and hold the “, “”
buttons, and “POWER” button simultaneously on
the AVR for a few seconds until the display starts
flashing at intervals of about 1 second.
Resetting the micro is a procedure used to "reboot" the microprocessor to restore its normal operation when it temporarily freezes, locks
up, or behaves erratically. Resetting the microprocessor, erases any saved settings you may have previously programmed into the unit
Issues that can affect the performance of the microprocessor:
•A jolt of static electricity
•Current surge through an input
Before resetting the microprocessor;
•Check all connections carefully
•Check for setup errors
WARRANTY 2
Power/Standby
button
“” button“” button
10
ACCESSORIES

Accessories
HOME
307010088005D $35.62 324010001003D $24.48
943116009500S $4.51 90M-ZA000230R $7.79
NA
RESET
Remote Control
(RC1157)
Power Cord)
Sound
Calibration
Microphone
(ACM1HB)
Sound
Calibration
Microphone
Stand
External
Antennas For
Bluetooth/Wire
less
Connectivity
AM Loop
Antenna
FM Indoor
Antenna
CD ROM
Owner’s
Manual
Notes on Radio
Quick Start
Guide
Safety
Instructions
Warranty
(For North
America Only)
11
FAQs

FAQ’s ( 1 of 2)
HOME FAQ’s 2ACCESSORIES 12

FAQ’s (2 of 2)
HOME UPGRADEFAQ’s 1 13

Upgrades/Updates
HOME Specifications –Audio SectionFAQs 2 14
No update available for this unit

Specifications –Audio Section
HOME
Audio section
Power amplifier
Rated output
Front
75 W + 75 W (8 Ω/ohms, 20 Hz –20 kHz with 0.05 % T.H.D.)
120 W + 120 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Center 75 W (8 Ω/ohms, 20 Hz –20 kHz with 0.05 % T.H.D.)
120 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Surround
75 W + 75 W (8 Ω/ohms, 20 Hz –20 kHz with 0.05 % T.H.D.)
120 W + 120 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Surround back
75 W + 75 W (8 Ω/ohms, 20 Hz –20 kHz with 0.05 % T.H.D.)
120 W + 120 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Output connector 6 – 16 Ω/ohms
Analog
Input sensitivity/Input impedance 200 mV/47 kΩ/kohms
Frequency response 10 Hz –100 kHz —+1, –3 dB (DIRECT mode)
S/N 98 dB (IHF–A weighted, Direct mode)
Upgrades/Updates SPECIFICATIONS -
DIMENSIONS -WEIGHT
SPECIFICATIONS -
VIDEO –TUNER -
GENERAL
15

Specifications -Video section,Tuner Section, General Section
HOME
Video section
Standard video connectors Input/output level and impedance 1 Vp-p, 75 Ω/ohms
Frequency response 5 Hz -10MHz, 0, -3dB
Tuner section
(ANTENNA input –MEDIA PLAYER
OUT)
FM AM
Note: µV at 75 Ω/ohms, 0 dBf = 1x10-15 W
Reception frequency range 87.5 MHz -107.9 MHz 520 KHz -1710 KHz
Usable sensitivity 1.2 µV (12.8 dBf)18µV
50 dB Quieting Sensitivity Mono 2.8 µV (20.2 dBf)
S/N (IHF-A) Mono 70 dB (DIRECT Mode)
Stereo 67 dB (DIRECT Mode)
Total harmonic distortion (At 1 kHz) Mono 0.7 %
Stereo 1.0 %
SPECIFICATIONS -
AUDIO
SPECIFICATIONS -
DIMENSIONS -WEIGHT
SPECIFICATIONS VIDEO
–TUNER -GENERAL 16
General section
Power supply AC 120V, 60Hz
Power consumption 360W
Power consumption in standby mode 0.1W
Power consumption in network standby mode 3W
For purpose of improvement, specifications and design are subject to change without notice.

Specifications –Dimensions, Weight
HOME
Dimensions section (Unit : inch/mm)
Weight: 20 lbs 8 oz (9.3 kg)
SPECIFICATIONS -
AUDIO
SPECIFICATIONS -
DIMENSIONS -WEIGHT
SPECIFICATIONS VIDEO
-TUNER -GENERAL 17

The End
HOME 18
NOTE:
This edition is missing the FAQ’s content (pages 12 and 13) ………………………………………………………..9/30/2015
This edition is missing the link to the IR Codes………………………………………………………………………....9/30/2015
