DM Group AVR-1912 User manual

MODEL: AVR-1912
Model Information
INTEGRATED NETWORK AV RECEIVER
I/R Codes
Product Specifications
Upgrades/Updates
Accessories
Reset Procedure
Warranty
Remote Control
Rear Panel
Front Panel
1
Model Information
Index
MI092915E3-1
NOTE:
This edition is missing the FAQ’s content (pages 13 and 14) ………………………………………………………..9/29/2015
This edition is missing the link to the IR Codes………………………………………………………………………....9/29/2015
Protection History
Display Mode

Front Panel
USB/iPod port
V.AUX INPUT connectors
Remove the cap covering the connectors
when you want to use them.
 SETUP MIC jack
 MASTER VOLUME control knob
Master volume indicator
 Display·
HOME Display 1 2
 Power operation button
(ON/STANDBY)
Turns power to this unit on and off (standby).
Power indicator
Headphones jack (PHONES)
When the headphones are plugged into this jack,
audio will no longer be output from the connected
speakers or from the PRE OUT connectors.
NOTE: To prevent hearing loss, do not raise the
volume level excessively when using headphones.
QUICK SELECT buttons
INTERNET RADIO button
PRESET CHANNEL buttons (1 – 3)
Remote control sensor
 Tuner Preset channel buttons
(TUNER PRESET CH+,-)
ZONE SELECT button
ZONE2 ON/OFF button
Input source select button
iPod play button (iPod 1 )
STATUS button

HOME REAR PANEL
Buttons and Connectors Behind the
Compartment Door (2 of 2) 3
Display (1 of 2)
Decoder indicators
These light when the respective decoders are operating.
Input signal indicators
Information display
The input source name, surround mode, setting values and other
information are displayed here.
Front speaker indicator
This lights according to the setting of the front A and B speakers.
Multi-zone indicators
This lights up when ZONE2 (separate room) power is turned on
Master volume indicator
Sleep timer indicator
This lights when the sleep mode is selected
MUTE indicator
This lights when the mute mode is selected
Audyssey® indicators
Lights up as follows, depending on the setting of “MultEQ® XT”,
When “MultEQ® XT”, “Dynamic EQ®” and
“Dynamic Volume®” are “ON”.
When “MultEQ® XT” and “Dynamic EQ®” are “ON”
and “Dynamic Volume®” is “OFF”.
When “MultEQ® XT” is “ON” and “Dynamic EQ®”
and “Dynamic Volume®” are “OFF”.
Surround back indicator
This lights when audio signals are being output from the surround
back speakers (vpage 86).
Input mode indicators
Set the audio input modes for the different input sources
AUDYSSEY
MULTEQ XT
DYN VOL
AUDYSSEY
MULTEQ XT
DYN EQ
AUDYSSEY
MULTEQ XT

HOME
Buttons and Connectors Behind the
Compartment Door (2 of 2) 4
Display (2 of 2)
RESTORER indicator
This lights when the RESTORER mode is selected (vpage 83).
HDMI indicator
This lights when playing using HDMI connections.
 Tuner reception mode indicators
These light according to the reception conditions when the input
source is set to “TUNER”.
STEREO : In the FM mode, this lights up when receiving stereo
broadcasts.
TUNED : Lights up when the broadcast is properly tuned in.
AUTO : Lights up when in the auto tuning mode.
REAR PANEL

HOME
DISPLAY 5
FM/AM antenna terminals
Analog audio connectors
PRE OUT connectors
S-VIDEO?VIDEO connector
COMPONENT VIDEO connector
 Speaker terminal
Power cord
HDMI connectors
Digital audio connectors
ETHERNET connector
DOCK CONTROL jack
8
9
10
11
1234567
Rear Panel
REMOTE CONTROL 1

HOME
ZONE SELECT button
Zone mode indicators
Input source select buttons
QUICK SELECT buttons
INTERNET RADIO button
Preset channel buttons
(PRESET 1 – 3)
 AMP button
Channel buttons
(CH +, –)
Muting button ()
MENU button
 Cursor buttons
()
 SEARCH button
REMOTE CONTROL 2REAR PANEL 6
Remote Control (1 of 3)

HOME
System buttons
• Search buttons ()
• Skip buttons ()
• Play button ()
• Pause button (II)
• Stop button ()
Tuner system buttons
• FM/AM band switching button (BAND)
• Tuning mode button (MODE)
• Tuning up / Tuning down buttons
(TUNING )
Character buttons
MEMORY button
Number buttons
SHIFT button
 TV operation buttons
(TV I / O/ INPUT)·
REMOTE CONTROL 3REMOTE CONTROL 1 7
Remote Control (2 of 3)

HOME
Remote control signal transmitter
 Power buttons
(ON / STANDBY)
 SOURCE SELECT button
 Master volume control buttons
()
 Channel level button (CH LEVEL)
 RETURN button
 ENTER button
 Surround mode buttons
• MOVIE button
• MUSIC button
• GAME button
• DIRECT button
 SLEEP button
 PARTY button
 ZONE/DEVICE power buttons
NOTE:
The DVR and PHONO buttons cannot be used.
Warranty 1REMOTE CONTROL 2 8
Remote Control (3 of 3)

DENON LIMITED WARRANTY (1 of 2)
This warranty will be honored only in the U.S.A.
Length of Non-Transferable Warranty
This warranty on your DENON product which is distributed and warranted by DENON ELECTRONICS (USA), LLC remains in effect
for the following periods from the date of the original consumer purchase from an AUTHORIZED DENON ELECTRONICS (USA),
LLC DEALER.
DENON ELECTRONICS (USA), LLC
(a D&M Holdings Company)
100 Corporate Drive
Mahwah, NJ 07430-2041
[phone]
www.usa.denon.com
DENON FACTORY SERVICE by PANURGY OEM
701 Ford Road (South Dock)
Rockaway, NJ 07866-2053
[phone]
[phone] Fax
http://www.panurgyoem.com/Denon/Denonrepair.html
See the next page for more information about the Denon limited warranty
HOME
2 years for units purchased new
1 year for refurbished (B-Stock) units
WARRANTY 2REMOTE CONTROL 3 9

Warranty (2 of 2)
What is Covered
Except as specified below, this Warranty covers all defects in material and workmanship in this product occurring during the above warranty periods.
The following are not covered by the Warranty: (1) Any product which is not distributed in the U.S.A. by DENON ELECTRONICS (USA), LLC. (2) Any
product which is not purchased in the U.S.A. from an authorized DENON dealer. (Note: AUTHORIZED DENON DEALERS can be identified by
DENON AUTHORIZED DEALER sticker displayed in the stores. If you are uncertain as to whether a dealer is a DENON AUTHORIZED DEALER,
please contact DENON as listed below). (3) Any product on which the serial number has been defaced, modified or removed. (4) Damaged
deterioration or malfunction resulting from: a) Accident, act of nature, abuse, misuse, neglect, unauthorized product repair, opening of or modification
or failure to follow instructions supplied with the product. b) Repair or attempted repair by anyone not authorized by DENON. c) Any shipment of the
product (claim must be presented to carrier). (5) Items subject to wear from normal usage (tape heads, cartridges, stylus, battery, etc.). (6) Periodic
check-ups which do not disclose any defect. (7) Use of the product outside the U.S.A. (8) Damaged magnetic tape or CD/DVD/BD discs. (9) Use in
industrial, commercial, and/or professional applications. (10) Any installation or removal charges resulting from product failure.
What We Will Pay For
If during the applicable warranty period from the date of original consumer purchase your DENON product is found to be defective by DENON,
DENON will repair, or at its option, replace with new, reconditioned or equivalent model, such defective product without charge for parts or labor.
How to Obtain Warranty Performance
If your unit ever needs service, it may be taken or shipped to any authorized DENON service station or DENON ELECTRONICS (if you are uncertain
as to whether a service station is DENON authorized, please visit our website at http://usa.denon.com/us/Support/Pages/ServiceCenterSearch.aspx or
contact DENON as listed below.) In all other cases, the following procedures apply whenever your unit must be transported for warranty service;
You are responsible for transporting your unit or arranging for its transportation.
If shipment of your unit is required;
You must pay the initial shipping charges, but we will pay the return shipping charges if the repairs are covered by the Warranty.
WHEN RETURNING YOUR UNIT FOR WARRANTY SERVICE, A COPY OF THE ORIGINAL SALES SLIP MUST BE ATTACHED.
You should include the following: your name, address, daytime telephone number, model and serial number of the product and a description of
the problem. In the case of a CD/DVD/BD Player, please enclose ONE (1) disc that the unit has failed with for test reasons. It will be returned
with the unit.
THIS WARRANTY IS VALID IN THE U.S.A. ONLY.
If your product does not require service, but you have questions regarding its operation, please contact our Customer Support Department as listed
below.
THIS WARRANTY IS EXPRESSLY MADE IN LIEU OF ALL OTHER WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING WITHOUT LIMITATION,
WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE.
OUR LIABILITY IS LIMITED TO THE REPAIR OR REPLACEMENT, AT OUR OPTION, OF ANY DEFECTIVE PRODUCT AND SHALL IN NO EVENT
INCLUDE INCIDENTAL OR CONSEQUENTIAL COMMERCIAL OR PROPERTY DAMAGES OF ANY KIND. WE ARE NOT RESPONSIBLE FOR
PRODUCTS LOST, STOLEN AND/OR DAMAGED DURING SHIPPING.
SOME STATES DO NOT ALLOW LIMITATIONS ON HOW LONG AN IMPLIED WARRANTY LASTS AND/OR DO NOT ALLOW THE
EXCLUSION OF INCIDENTAL OR CONSEQUENTIAL DAMAGES, SO THE ABOVE LIMITATIONS AND EXCLUSIONS MAY NOT APPLY TO
YOU.
This warranty gives you specific legal rights, but you may also have other rights which vary from state to state. This Warranty may not be altered other
than in a writing signed by an officer of Denon Electronics USA, LLC.
HOME RESETWARRANTY 1 10

Reset
HOME
Reset procedure:
With the power off, press and hold the “PRESET
CHANNEL 2” button, “PRESET CHANNEL 3”
button, and “POWER” button simultaneously on
the AVR for a few seconds until the display starts
flashing at intervals of about 1 second.
Resetting the micro is a procedure used to "reboot" the microprocessor to restore its normal operation when it temporarily freezes, locks
up, or behaves erratically. Resetting the microprocessor, erases any saved settings you may have previously programmed into the unit
Issues that can affect the performance of the microprocessor:
•A jolt of static electricity
•Current surge through an input
Before resetting the microprocessor;
•Check all connections carefully
•Check for setup errors
•Back up your settings. You may also want to write down your preferred settings for easier task of setting up the AVR after reset.
Note: The Web (Browser) Control feature can be used to back up your settings by saving a configuration file on your hard drive. For this
feature, we recommend using one of the following web browsers: Internet Explorer 10 and above, Mozilla Firefox 24 and above, Google
Chrome 29 and above, and Safari 5.x and above.
Note: If you had an installer setup your system, please first contact your installer to see if they can reset and then setup your system again
as there may be specific EQ calibrations (Audyssey) that the installer will need to perform.
Important: Back up the settings before resetting the microprocessor. Most settings are reset to the factory default values after performing
this procedure. This means that all the settings data will be completely lost if it’s not previously saved.
WARRANTY 2
Power/Standby
button
“PRESET
CHANNEL 3”
button
“PRESET
CHANNEL 2”
button
11
ACCESSORIES

Accessories
HOME
307010087002D $49.99 324010001003D $24.48
90M-ZA000260R
or 963116100070S
$8.99 00D9600187308
or 963116100080S
$7.79
NA
RESET
Remote Control
(RC1156)
Power Cord)
Sound
Calibration
Microphone
(ACM1HB)
Sound
Calibration
Microphone
Stand
External
Antennas For
Bluetooth/Wire
less
Connectivity
AM Loop
Antenna
FM Indoor
Antenna
CD ROM
Owner’s
Manual
Notes on Radio
Quick Start
Guide
Safety
Instructions
Warranty
(For North
America Only)
12
FAQs

FAQ’s ( 1 of 2)
HOME FAQ’s 2ACCESSORIES 13

FAQ’s (2 of 2)
HOME UPGRADEFAQ’s 1 14

Upgrades/Updates
HOME Specifications –Audio SectionFAQs 2
Firmware:
This unit has the ability to update its firmware over the internet if so is selected by the user. When connected to a network via Wi-Fi or Ethernet, the AVR
searches automatically for new updates and if any is found, a message appears on the screen for approx. 40 seconds with the options of updating the
firmware: “NOW”, “LATER”, or “IGNORE”. Note: This feature of displaying the update message, can be disable from the “Setup” menu
(Setup/General/Firmware/Notifications/Update or Upgrade/Off).
If the update process is interrupted, “Update retry” appears on the display and the unit tries repeatedly to continue the update until it either reconnects and
picks up where it left off and continue the update process or times itself out after trying several times. When the latter occurs, one of the following messages
will appear on the screen.
To Check for Firmware Update from the Denon server when the unit is connected to the internet via the Ethernet port (When Firmware Notification is
turned off).
Press “SETUP” and select “GENERAL” and then select “FIRMWARE” followed by “UPDATE” and finally, select “CHECK FOR UPDATE”.
Note: This will also check the time it will approximately take to complete the update.
To download the latest version of firmware for AVR-1912, click on the following Upgrade page:
www.usa.denon.com/US/Downloads/Pages/Product-Updates.aspx
To display the AVR’s current firmware version on the TV screen:
Press “SETUP” and select “GENERAL” and then select “INFORMATION” followed by “FIRMWARE”.
To check to see if an update or upgrade is available for your unit and also to see a list of “Recent Updates/Upgrades”, click on the following link:
http://usa.denon.com/us/downloads/productupdates?_ga=1.114028992.611911196.1430951505
Connection fail Download fail Updating fail Server is busy Login failed
15

Specifications –Audio Section
HOME
Audio section
Power amplifier
Rated output
Front
90 W + 90 W (8 Ω/ohms, 20 Hz –20 kHz with 0.05 % T.H.D.)
125 W + 125 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Center 90 W (8 Ω/ohms, 20 Hz –20 kHz with 0.05 % T.H.D.)
125 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Surround
90 W + 90 W (8 Ω/ohms, 20 Hz –20 kHz with 0.05 % T.H.D.)
125 W + 125 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Surround back
90 W + 90 W (8 Ω/ohms, 20 Hz –20 kHz with 0.05 % T.H.D.)
125 W + 125 W (6 Ω/ohms, 1 kHz with 0.7 % T.H.D.)
Output connector 6 – 16 Ω/ohms
Analog
Input sensitivity/Input impedance 200 mV/47 kΩ/kohms
Frequency response 10 Hz –100 kHz —+1, –3 dB (DIRECT mode)
S/N 100 dB (IHF–A weighted, Direct mode)
Upgrades/Updates SPECIFICATIONS -
DIMENSIONS -WEIGHT
SPECIFICATIONS -
VIDEO –TUNER -
GENERAL
16

Specifications -Video section,Tuner Section, General Section
HOME
Video section
Standard video connectors Input/output level and impedance 1 Vp-p, 75 Ω/ohms
Frequency response 5 Hz -10MHz, 0, -3dB
Tuner section
(ANTENNA input –MEDIA PLAYER
OUT)
FM AM
Note: µV at 75 Ω/ohms, 0 dBf = 1x10-15 W
Reception frequency range 87.5 MHz -107.9 MHz 520 KHz -1710 KHz
Usable sensitivity 1.2 µV (12.8 dBf)18µV
50 dB Quieting Sensitivity Mono 2.8 µV (20.2 dBf)
S/N (IHF-A) Mono 70 dB (DIRECT Mode)
Stereo 67 dB (DIRECT Mode)
Total harmonic distortion (At 1 kHz) Mono 0.7 %
Stereo 1.0 %
SPECIFICATIONS -
AUDIO
SPECIFICATIONS -
DIMENSIONS -WEIGHT
SPECIFICATIONS VIDEO
–TUNER -GENERAL 17
General section
Power supply AC 120V, 60Hz
Power consumption 460W
Power consumption in standby mode 0.1W
Power consumption in network standby mode 3W
Remote control unit (RC-1156)
Batteries R6/AA Type (two batteries)
Maximum external dimensions 2-3/32” (W) x 8-13/16” (H) x 1-7/64” (D) (53 x 224 x 28 mm)
Weight 5.6 oz (160 g, including batteries)
For purpose of improvement, specifications and design are subject to change without notice.

Specifications –Dimensions, Weight
HOME
Dimensions section (Unit : inch/mm)
Weight: 22 lbs 7.8 oz (10.2 kg)
SPECIFICATIONS -
AUDIO
SPECIFICATIONS -
DIMENSIONS -WEIGHT
SPECIFICATIONS VIDEO
-TUNER -GENERAL 18

The End
HOME 19
NOTE:
This edition is missing the FAQ’s content (pages 13 and 14) ………………………………………………………..9/29/2015
This edition is missing the link to the IR Codes………………………………………………………………………....9/29/2015
