DM TECH D9000 Series User manual

Manufacturer: “DMTech” Ltd., 58 Kliment Ohridski Str., Pleven 5800, Bulgaria, EU, http://dmtech-ltd.com
INSTRUCTION MANUAL
CONVENTIONAL DETECTORS
D9000 series
Type
Characteristics
Sensitivity / Class
D9000 SR
Optical smoke fire detector
EN 54-7
D9000 T/A1R
Rate of rise heat detector
A1R, EN 54-5
D9000 T/A1S
Fixed temperature heat detector
A1S, EN 54-5
D9000 MSR
Combined optical smoke and heat detector
A1R, EN 54-5 / EN 54-7
Caution : Read this manual before attempting to install the detector.
1. TECHNICAL DATA
–Supply voltage 10-30 V DC
–Current consumption in Standby mode ≤ 130 µА
–Current consumption in Alarm condition 20 mА/ 24V DC
–Time to enter standby mode after reset up to 35s
–Reset time 2s
–Degree of protection IP 43
–Type of the connecting line to the base 0,5÷1,5 mm2 / two-wire
–Output in Alarm condition (term. 3) limited to 2 kΩ, negativ
–Operating temperature range minus 10ºС ÷ plus 50ºС
–Humidity (93 ± 3)% at 40ºС
–Dimensions with base Ø100mm h ≤ 52mm
–Weight ≤ 100g
2. INSTALLATION
–Choose the place (according to the plans of the project) for the installation of the detector;
–Mount the base with appropriate fixings;
–Connect the electrical cables according to the attached diagram ( Figure 1);
Fig.1
–Place the detector base and rotate clockwise till matching markers;
–If you want to lock detector:
Pre remove the key from the base ( Figure 2).
Break the plastic at the specified location on the bottom of the sensor ( Figure 3 ).

Manufacturer: “DMTech” Ltd., 58 Kliment Ohridski Str., Pleven 5800, Bulgaria, EU, http://dmtech-ltd.com
Fig.2 Fig.3 Fig.4
Place the detector on the base and rotate it .
–If the detector is locked to the base, to unlock it , insert first the key to the specified location
(Fig. 4) and rotate the detector counterclockwise;
–Test the detector to check the correct operation of the LED indication;
–During normal operation, the LEDs blink every 16 seconds.
3. TESTING AND SERVICE SCHEDULE
Testing
–Apply power;
–Wait about a minute or until the detector begins to blink;
–Operate the detector test spray and / or temperature sourse. The two red LEDs must illuminate
permanently.
Service schedule
–Visual inspection for mechanical damage and pollution - once a year;
–Verification of performance - once a year;
–Prophylactic cleaning - depending on the environment in which it is located.
Optical detectors D9000 SR/MSR are software tested and when the detector is contaminated, it is signaled
by flashing LEDs for 2 seconds to 2 seconds.
D9000 Series detectors are compatible with all conventional power panels, that have met the requirements
of a standards EN54.
The detectors are available with three types of bases:
–B 9000 - Standard base;
–B 9000D - Standard base with mounted diode for fault detection - removed detector;
–B 9000R - Standard base with relay output 12V for security panels.
4. Warranty obligations
The warranty period is 36 months from the date of sale, provided that:
–the conditions of storage and transport have been followed;
–release is performed by authorized persons;
–the requirements for operation stated in this instruction have been abode;
–defects are not caused by natural phenomena and accidents of the plug socket.
