DM TECH Vitruvian CSMP175 Series User manual

Vitruvian™ Sound System for iPod® & iPhone®
Please read carefully before use/Läs noggrant före användning
For series / För serierna
CSMP175
Table of Contents ......................................................Page2
EN
Vitruvian™ ljudsystem för iPod® och iPhone®
Innehåll..................................................................Page20
SV

Page 2 Table Of Contents
English
Table of ContentsÂ
THANK YOU.....................................................................................................................................4
Package Contents ..........................................................................................................................4
Features............................................................................................................................................4
CSMP175 AT A GLANCE.................................................................................................................5
Main Unit ..........................................................................................................................................5
Remote Control ...............................................................................................................................7
About the Remote Control Battery ....................................................................................9
GETTING STARTED......................................................................................................................... 10
Connections ..................................................................................................................................10
Connecting Power.............................................................................................................10
Connecting an iPod®or iPhone®....................................................................................10
Connecting an Auxiliary Device...................................................................................... 11
Basic Controls ................................................................................................................................ 11
USING IPOD®/IPHONE®MODE..................................................................................................... 12
Controls ..........................................................................................................................................12
Browsing iPod/iPhone Menus with the Remote ..............................................................13
Rotating the Dock .........................................................................................................................13

English
Table Of Contents Page 3
USING AUX MODE........................................................................................................................ 14
Controls ..........................................................................................................................................14
SPECIFICATIONS........................................................................................................................... 15
SAFETY & REGULATORY STATEMENTS........................................................................................... 16

Page 4 Thank You
English
Thank You
Thank you for purchasing a CSMP175 Sound System for iPod® and iPhone®. Please read this manual
carefully before using this device and retain it for future reference.
Package Contents
CSMP175
Power adapter
Remote control
3.5mm auxiliary cable
Instruction manual
If any of the above items are missing, please
contact the dealer from whom you purchased this
product.
This package may contain plastic bags
or other materials that pose a hazard
to children. Be sure to safely dispose
of all packing materials after opening.
Features
Premium sound system designed for iPod®
& iPhone®
Built-in Universal dock charges and plays
your iPod/iPhone
One-touch dock rotation lets you browse
with Cover Flow or watch movies in land-
scape mode
Bass Boost circuitry for low end frequency
enhancement
Supports iPod shuffle and other portable
players with a 3.5mm audio connection
Adjustable ambient lighting

English
Csmp175 At A Glance Page 5
Csmp175 At A Glance Page 5
English
CSMP175 at a GlanceÂ
Main Unit
1[Rotate] Press to rotate the dock.
2 [Volume –] Press to decrease the volume level.
3 [Volume +] Press to increase the volume level
4[Standby] Press to turn the unit on or off.
5[AUX/iPod] Press to switch between AUX and
iPod modes.
6[Light] Press to increase or decrease the
intensity of the background light.

Page 6 Csmp175 At A Glance
English
7 AUX IN 3.5mm auxiliary connector. Use a
3.5mm auxiliary cable to connect
portable audio devices with a 3.5mm
headphone output ．
8 DC IN Power connector. Use the AC adapter
to connect to an AC 100-240V power
outlet.
9 Universal
Dock
Dock for iPod® and iPhone®.
Connector for your compatible iPod
or iPhone.

English
Csmp175 At A Glance Page 7
Remote Control
1 [Standby] Press to turn the unit on or off.
2 [ROTATE] Press to rotate the dock.
3 [LIGHT +] Press to increase the intensity of the
background light.
4 [LIGHT –] Press to decrease the intensity of the
background light.
5 [BASS] Press to turn the Bass Boost
enhancement on or off.
6 [LEFT] Press to skip to the previous track.
Hold to scan in reverse quickly
through the current track.
[RIGHT] Press to skip to the next track.
Hold to scan forward quickly through
the current track.
[UP] Use to browse iPod® or iPhone®
menus.
[DOWN]
7 [OK] Press to enter an iPod or iPhone
menu selection.

Page 8 Csmp175 At A Glance
English
8 [MUTE] Press to disable or enable speaker
output.
9 [VOL +] Press to increase the volume level.
10 [VOL –] Press to decrease the volume level.
11 [AUX/iPod] Press to switch between AUX and
iPod modes.
12 [Play/
Pause]
Press to start or pause iPod or iPhone
playback.
13 [M] Press to access the iPod or iPhone
menu, or to return to a previous
screen.

English
Csmp175 At A Glance Page 9
About the Remote Control Battery
The remote control is powered by one (1)
CR2025-type battery. Before using the remote,
be sure to remove the plastic protective tab from
the battery compartment.
To replace the battery:
Squeeze the tab of the battery compartment1.
to the right while drawing the compartment
out.
Remove the battery and replace it with a2.
new “CR2025” lithium battery.
Replace the compartment.3.

Page 10 Getting Started
English
Connections
Connecting Power
This unit is powered by an AC/DC adapter.
Connect one end of the included AC/DC adapter
to an AC 100-240V ~50/60Hz mains outlet.
Connect the other end to the DC IN connector
located on the rear of the unit.
Do not connect the power adapter to
a power outlet other than that which is
indicated here or on the label as this
may result in the risk of fire or electric
shock.
Do not handle the power plug with wet
hands. Doing so may cause electric
shock.
Connecting an iPod®or iPhone®
If you have a compatible iPod or iPhone,
you can play it through the speakers of the
CSMP175.
Compatible iPod/iPhone models are listed in
the Specifications section of this manual.
To connect your iPod/iPhone:
If you have a dock adapter cartridge, seat1.
the adapter firmly in the Universal Dock.
Plug your compatible iPod/iPhone into the2.
Universal Dock.
Getting Started

English
Getting Started Page 11
Dock adapters are provided by Apple
with their recent iPod models.
Compatible iPod or iPhone models will
be charged when connected.
Connecting an Auxiliary Device
If you have an audio device with a 3.5mm
headphone out or line-out jack, you can play it
through the speakers of the CSMP175.
To connect your auxiliary audio device:
Connect one end of a 3.5mm auxiliary cable1.
to the headphone out/line-out jack of the
audio device.
Connect the other end of the cable to AUX2.
IN connector located on the rear of the
CSMP175.
Basic Controls
To do this… …do this.
Turn the unit on or off Press [Standby]
Change between iPod/iPhone and
AUX playback mode
Press [AUX/iPod]
Adjust the volume level Press [VOL +] or
[VOL –]
Start, pause, or resume iPod/
iPhone playback
Press [Play/Pause]
Rotate the dock Press [ROTATE]
When the unit is in iPod mode, you
may use the controls of your iPod/
iPhone directly.

Page 12 Using Ipod®/iphone® Mode
English
Page 12 Using Ipod®/iphone® Mode
English
Using iPod®/iPhone®Mode
To listen to your iPod or iPhone, simply place
your iPod/iPhone in the Universal Dock.
The CSMP175 will turn on automatically.
Music on the iPod/iPhone will start playing
automatically.
Press [Play/Pause] to start music play-
back if it does not start automatically.
Controls
When an iPod/iPhone is connected to the
Universal Dock and the CSMP175 is in iPod
mode, the following controls are available.
Remote
Key Function
[Play/Pause] Start or pause/resume playback.
[RIGHT] Skip to the next track.
Remote
Key Function
[LEFT] Skip to the previous track.
Hold
[RIGHT]
Scan forward quickly through the current
track.
Hold [LEFT] Scan in reverse quickly through the
current track.
[VOL +] Increase the volume level.
[VOL –] Decrease the volume level.
[MUTE] Disable or enable speaker output.
[BASS] Turn the Bass Boost enhancement on or
off.
[ROTATE] Rotate the dock.
[AUX/iPod] Press to switch between AUX and iPod
modes.

English
Using Ipod®/iphone® Mode Page 13
Browsing iPod/iPhone Menus with the
Remote
Some functions of your iPod/iPhone can be
controlled with the CSMP175 remote control.
Remote
Key Function
[M] Press to access the iPod/iPhone menu,
or return to a previous screen.
[UP] Use to browse iPod® or iPhone® menus.
[DOWN]
[OK] Press to enter an iPod or iPhone menu
selection.
For iPod touch and iPhone models,
you may need to start the Music/Video
player application before the remote
controls will work.
Rotating the Dock
Rotate the dock horizontally to view your
compatible iPod touch or iPhone in landscape
position.
Press [ROTATE] to rotate the dock to land-
scape position.
Press [ROTATE] again to return the dock to
its normal, vertical position.
When your iPod/iPhone is in landscape position,
you may:
Browse your media collection with Cover
Flow
View album art
Watch videos

Page 14 Using Aux Mode
English
Page 14 Using Aux Mode
English
Using AUX Mode
To listen to an auxiliary device, use a 3.5mm
auxiliary cable to connect it to the CSMP175.
Press [Standby] to turn on the CSMP175.1.
Start playback on the auxiliary device.2.
Press [AUX/iPod] to set the CSMP175 to3.
AUX mode.
The auxiliary device must have a
3.5mm headphone out or line-out
connection.
Controls
When the CSMP175 is in AUX mode, the follow-
ing controls are available.
Remote
Key Function
[VOL +] Increase the volume level.
[VOL –] Decrease the volume level.
[MUTE] Disable or enable speaker output.
[BASS] Turn the Bass Boost enhancement on or
off.
[ROTATE] Rotate the dock.
[AUX/iPod] Press to switch between AUX and iPod
modes.
Use the controls of the auxiliary device
directly to control playback.

English
Specifications Page 15Specifications Page 15
English
Specifications
Design, specifications, and manual are subject to change without notice.
Speaker
Output (RMS)
10W x 2
Frequency
Response
40 – 20,000Hz
Impedance 4Ω 8Ω
Aux Input 3.5mm stereo
Power Input: AC 100-240V 50/60Hz
Output: DC 20V, 1.8A
Remote: CR2025 battery x 1
Unit
Dimensions
(LWH)
4.4 x 15.9 x 6.2 in.
Made for* iPhone 3GS
iPhone 3G
iPhone 4G
iPhone
iPod classic
iPod touch
iPod touch 2G
iPod touch 3G
iPod touch 4G
iPod nano
iPod nano 2G
iPod nano 3G
iPod nano 4G
iPod nano 5G
iPod nano 6G
iPod 5G
iPod photo
iPod 4G
iPod 3G
iPod mini

English
Safety & Regulatory Statements Page 17Safety & Regulatory Statements Page 16
English
Safety & Regulatory Statements
The lightning flash with arrowhead symbol within an
equilateral triangle is intended to alert the user to the
presence of uninsulated “dangerous voltage” within
the product’s enclosure that may be of sufficient
magnitude to constitute a risk of electric shock.
The exclamation point within an equilateral triangle
is intended to alert the user to the presence of
important operation and servicing instructions in the
literature accompanying the appliance.
For recycling or disposal information about
this product, please contact your local
authorities or the Electronics Industries
Alliance: www.eiae.org.
For Customer Use:
Enter below the serial number that is located on the rear of the
unit. Retain this information for future reference.
Model No.
Serial No.
WARNING: To prevent fire or shock hazard, do not expose this
device to rain or moisture. Dangerous high voltage is present inside
the enclosure. Do not open the cabinet.
CAUTION: To prevent electric shock, match wide blade of plug to
wide slot of outlet and fully insert.
NOTE: This product contains electrical or electronic materials.
The presence of these materials may, if not disposed of properly,
have potential adverse effects on the environment and human
health. Presence of this label on the product means it should not be
disposed of as unsorted waste and must be collected separately.
As a consumer, you are responsible for ensuring that this product is
disposed of properly.

English
Safety & Regulatory Statements Page 17
Warnings and Precautions
To prevent any injuries, the following safety precautions should be
observed in the installation, use, servicing and maintenance of this
equipment. Before operating this equipment, please read this manual
completely, and keep it nearby for future reference.
Important Safety Instructions
Read Instructions: All the safety and operating instruc-1.
tions should be read before the product is operated.
Retain Instructions: The safety and operating instruc-2.
tions should be retained for future reference.
Heed Warnings: All warnings on the product and in3.
the operating instructions should be adhered to.
Follow Instructions: All operating and usage instruc-4.
tions should be followed.
Do not place the equipment on uneven or unstable5.
carts, stands, tables, shelves etc. The equipment
may fall, causing serious injury to children or adults
and serious damage to the equipment itself. Always
place the equipment on the floor or on a surface that is
sturdy, level, stable and strong enough to support the
weight of the equipment.
Use only a cart or stand recommended6.
by the manufacturer. This equipment
and recommended cart or stand
should be handled with care. Quick
stops, excessive force, and uneven
surfaces may cause the equipment
and cart/stand to overturn.
Do not disable the 3-wire grounding type plug. The7.
grounding pin on the 3-prong plug is an important fea-
ture. Removing the grounding pin will increase the risk
of damaging the equipment.
If you can not fit the plug into the electrical outlet, con-8.
tact an electrician to install a grounding outlet.
Always operate this equipment from the type of power9.
source indicated on the rear of the serial/model plate.
Never overload wall outlets and extensions.10.
Remove the plug from the wall outlet, if the equipment11.
will not be used for a long period of time.
Do not place, use or handle this equipment near wa-12.
ter.
Never expose the equipment to liquid, rain, or moisture.13.
Seek service if any of the above is spilled into the
equipment.

Page 18 Safety & Regulatory Statements
English
Do not expose the equipment to extreme temperature14.
or to direct sunlight, as the equipment may heat up
and suffer damage.
Do not install the equipment near any heat sources15.
such as radiators, heat registers, stoves, or any other
apparatus that might produce heat.
Do not attempt to service the equipment yourself.16.
Opening and removing the covers may expose you17.
to dangerous voltage or other hazards and may void
your warranty. Refer service to qualified personnel.
Do not place or drop any other objects on top.18.
Do not insert anything into the ventilation holes of your19.
equipment. Inserting any metal or flammable objects
may result to fire or electric shock.
Refer all servicing to qualified service personnel.20.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or
plug is damaged, liquid has been spilled or objects
have fallen into the apparatus, the apparatus has
been exposed to rain or moisture, does not operate
normally, or has been dropped.
Always remove the power cord from the outlet before21.
cleaning the equipment.
Never use liquid or aerosol cleaners on the equipment.22.
Clean only with a soft dry cloth.
Only use attachments/accessories specified by the23.
manufacturer.
Where the mains plug is used as the disconnected24.
device, the disconnect device shall remain readily
operable.
Listening with Earphones
Listen at moderate Volumes to avoid hearing damage.•
If you hear no sound during playback, do not turn the Volume up•
as the music may suddenly begin at a high Volume. Excessive
sound pressure from earphones and headphones can cause
hearing loss.
To avoid damaging your ears, adjust the Volume to the lowest•
level before playback, and turn up to the desired level when
playback has started.

English
Safety & Regulatory Statements Page 19
Legal and Trademark Notices
“Made for iPod” and “Made for iPhone” mean that an electronic
accessory has been designed to connect specifically to iPod or
iPhone, respectively, and has been certified by the developer to
meet Apple performance standards. Apple is not responsible for the
operation of this device or its compliance with safety and regulatory
standards. iPod and iPhone are trademarks of Apple Inc., registered
in the U.S. and other countries.
iPod and iPhone are trademarks of Apple Inc., registered in the U.S.
and other countries.
This symbol on the product or in the instructions means
that your electrical and electronic equipment should be
disposed at the end of its life separately from your
household waste.
There are separate collection systems for recycling in
the EU.

20
Svenska
Innehåll
Tack...............................................................................................................................................22
Förpackningens innehåll.................................................................................................................22
Funktioner.......................................................................................................................................22
CSMP175, snabbinfo................................................................................................................... 23
Huvudenhet................................................................................................................................... 23
Fjärrkontroll...................................................................................................................................... 25
Fjärrkontrollens batteri........................................................................................................27
Komma igång ..............................................................................................................................28
Anslutningar....................................................................................................................................28
Ansluta till ström...................................................................................................................28
Ansluta en iPod®eller iPhone®............................................................................................28
Ansluta en extern enhet......................................................................................................29
Basfunktioner..................................................................................................................................29
Använda iPod/iPhone-läge .......................................................................................................30
Knappar..........................................................................................................................................30
Bläddra i iPod- eller iPhone-menyer med fjärrkontrollen............................................31
Rotera dockan ...............................................................................................................................31
