DOC ECO-SWEEP Guide

ECO-SWEEP
Care and Use Guide
Please make sure you read and understand this
Care and Use Guide before using this product.

ASSEMBLY INSTRUCTIONS
HANDLE ASSEMBLY
1. ASSEMBLE THE TUBE HANDLE
Insert the sliding handle (3) into the tube handle (2)
and let the stop spring (34) pop into the holes on
both sides.
2. ASSEMBLE TUBE HANDEL TO THE SWEEPER BODY
Connect the tube handle hole to the screw on both sides of the sweeper body
and tighten up the turning knobs (5) by turning clockwise. Do not overtighten.
Sliding handle Tube adjustable handle Stop spring in proper position
IN THE BOX
Sweeper body
Turning knob 2pcs
Tube handle 1 set Instruction manual 1pc
The spare parts item No. mentioned below please refer to the explosion drawing.
ECO-SWEEP
Care and Use Guide
Please make sure you read and understand this
Care and Use Guide before using this product.

WASTE CONTAINER DETACH AND ASSEMBLY
1. Detach the container
Lift the waste container by lifting it up and away
from the brush housing.
Step 1:
1. Lift the container handle
and release it.
2. Lift the front portion of
the waste container to
accept the hooks of the
brush housing.
Step 2:
1. Interlock the hooks of
the brush housing with
the notched portion of
the waste container.
Step 3:
1. Lower the front of the
the waste container to
combine to the brush
housing.
2. Push down the container
handle to lock it.
2. Waste Container Assembly
Brush Housing
Waste Container
Interlocked and assembled.
Container Handle

2. Suitable for wet and dry use including sawdust, metal filings, leaves, stones,
papers, cans, cups, broken glass, large debris, sand and dirt.
1. Extremely easy to use. Normal walking speed recommended for
optimum results.
3. Works on all surfaces including workshops, driveways, walkways, store
fronts, patios, garages and pool decks. Works best of flat surfaces.
4. While sweeping, the carrying capacity of the waste container can be
maximized by lifting the front periodically to allow the waste to shift to the back of
the container.
5. When sweeping, fine dust particles may remain in the brushes, they should be
cleaned regularly for best results.
OPERATION

EMPTYING WASTE CONTAINER
BRUSH ADJUSTMENT
The height adjustment knob for the circular brooms is located on the front.
Turn clockwise to lower. Turn counter-clockwise to raise.
Use medium setting for all uneven surfaces like exposed aggregate or
tiles, and for sweeping up small debris.
Use higher setting for all even, hard floors like asphalt or concrete, and
for sweeping large debris.
Use lower setting for uneven surfaces like decks or pavers, and for sweeping up
fine dust.
NOTE: As circular brooms get older, you may need to use a progressively lower
setting or replace with new circular brooms.
Detach the waste container, and empty it into trash can. Reattach empty waste
container to the brush housing to continue use.

BRUSH (CIRCULAR BROOM) REPLACEMENT
1. Set the height adjustment
knob to the far right, lowest
setting side.
2. Pull the inclined wheels
(15/16) strongly and remove it
with the axle (13 14).
Keep not e o f t he left and
right wheels as they must be
replaced on same side for
normal operation.
3. Pull out the circular broom
together with the toothed sleeve.

4. Remove the toothed
sleeve.
5. Insert the toothed sleeve
into the replacement brush
6. Reinsert the brush and
ensure it is completely
seated into the rod housing.
7. Reinsert the inclined
wheel and axle into the
rod. Firmly push until
the assembly pops into
position.
MAINTENANCE
The sweeper body and brooms can be cleaned with cool water. Do not wash
with hot water or use hot air to dry as this may warp the brushes.
Spool cords and threads can be wiped down with a damp cloth and should be
removed for best cleaning results.

EXPLOSION DRAWING
1、
2、
3、
4、
5、
6、
7、
8、
9、
10、毛刷右（1
11、轴承1626（2
12、直齿轮（2
13、轮轴左（1
14、轮轴右（1
15、前轮右（1
16、前轮左（1
17、集尘板衬板（1
18、开口挡圈6（2
JL550扫地机爆炸图

1. Handle grip 1
2. Tube Adjustable Handle 1
3. Sliding handle parts 2
4. Container handle 1
5. Turning knob 1
6. Front cover 1
7. Adjusting Bar 2
8. Axle cover 2
9. Left circular broom 1
10. Right circular broom 1
11. Bearing 1626 2
12. Toothed bushing 2
13. Axle left 1
14. Axle right 1
15. Right inclined wheel 1
16. Left inclined wheel 1
17. Holder ground board 1
18. Washer 6 2
19. Collecting plate 1
20. Bolt M8X30 2
21. Screw ST4X8 2
22. PU washer 2
23. Turning knob 2
24. Container 1
25. Wheel complete 2
26. Wheel cap 2
27. Quick-fastener 11.5 2
28. Axle cover 4
29. Axle left welding part 1
30. Axle right welding part 1
31. Container cap 1
32. Stop spring 2
33. Screw ST4X16 21

STORAGE
Do not store in direct sunlight. To hang or store flat, fold the tube handle parallel
to the body and hang it on the wall, if desired, to save storage space.
Please make sure the sweeper is securely hung to avoid it dropping and
causing possible injury or damage.
Always take great care when hanging or removing sweeper from the storage
position.

TROUBLE SHOOTING
Issue: Sweeper is not picking up debris effectively.
1. Check the height of the brushes and adjust if needed.
2. Clean the unit and remove dirt and/or debris stuck from the brushes,
spools, or under machine itself.
3. Lubricate the gear parts.

NOTE:
2. Before using, make sure the unit is in good and safe condition.
1. This unit is NOT for use on carpet.
3. Heavy stones and large size tree branches may not be able to be collected.
Do not attempt to sweep debris that is too large for the unit.
4. When sweeping very fine dust, small traces may remain in the middle of the
machine and a second sweeping is suggested to the best results.
5. Please avoid sweeping long rope, yarn, or string-like material to avoid
tangling and damage to brushes, spools, or gears.
SAFETY WARNING!
1. Always be aware of your surroundings and take care when sweeping and
operating the machine around children and/or pets.
2. This unit is not a toy.
4. Please do not operate the sweeper barefoot or wearing open-toed shoes.
5. Please do not attempt to sweep burning or smoking materials to avoid fire hazard
and personal injury.
6. Please do not collect flammable, explosive, and/or poisonous materials.
3. Please do not let your hair, feet, fingers, jewelry, or clothes close to the
collecting mouth of the unit.
7. Take additional caution when collecting and/or emptying glass or other
sharp materials and always wear safety gloves.
8. Please do not operate or store the unit close to heating source.
