Dodge Grand Caravan 2019 User manual

Grand Caravan
OWNER’S MANUAL
Second Edition
Printed in the U.S.A.
19RT-126-AB
©2018 FCA US LLC. All Rights Reserved.
Dodge is a registered trademark of FCA US LLC.
2019
Grand Caravan
2019

VEHICLES SOLD IN CANADA
With respect to any Vehicles Sold in Canada, the name
FCA US LLC shall be deemed to be deleted and the name
FCA Canada Inc. used in substitution therefore.
DRIVING AND ALCOHOL
Drunken driving is one of the most frequent causes of
accidents.
Your driving ability can be seriously impaired with blood
alcohol levels far below the legal minimum. If you are
drinking, don’t drive. Ride with a designated non-
drinking driver, call a cab, a friend, or use public trans-
portation.
WARNING!
Driving after drinking can lead to an accident.
Your perceptions are less sharp, your reflexes are
slower, and your judgment is impaired when you
have been drinking. Never drink and then drive.
This manual illustrates and describes the operation of
features and equipment that are either standard or op-
tional on this vehicle. This manual may also include a
description of features and equipment that are no longer
available or were not ordered on this vehicle. Please
disregard any features and equipment described in this
manual that are not on this vehicle.
FCA US LLC reserves the right to make changes in design
and specifications, and/or make additions to or improve-
ments to its products without imposing any obligation
upon itself to install them on products previously manu-
factured.
Copyright © 2018 FCA US LLC

TABLE OF CONTENTS
SECTION PAGE
1INTRODUCTION ...................................................................3
2GRAPHICAL TABLE OF CONTENTS ......................................................7
3GETTING TO KNOW YOUR VEHICLE ...................................................13
4GETTING TO KNOW YOUR INSTRUMENT PANEL .........................................129
5SAFETY ........................................................................157
6STARTINGANDOPERATING.........................................................239
7INCASEOFEMERGENCY ...........................................................285
8SERVICING AND MAINTENANCE .....................................................333
9TECHNICAL SPECIFICATIONS ........................................................387
10 MULTIMEDIA ....................................................................401
11 CUSTOMER ASSISTANCE ............................................................465
12 INDEX..........................................................................471
1
2
3
4
5
6
7
8
9
10
11
12

INTRODUCTION
CONTENTS
䡵INTRODUCTION .........................4
䡵HOW TO USE THIS MANUAL ...............5
▫Essential Information ......................5
▫Symbols ...............................5
䡵WARNINGS AND CAUTIONS ................5
䡵VEHICLE MODIFICATIONS/ALTERATIONS .....5
1

INTRODUCTION
Dear Customer,
Congratulations on selecting your new vehicle. Be assured
that it represents precision workmanship, distinctive styl-
ing, and high quality. This Owner’s Manual has been
prepared with the assistance of service and engineering
specialists to acquaint you with the operation and mainte-
nance of your vehicle. It is supplemented by Warranty
Information, and customer oriented documents. In the
attached Warranty Booklet, you will find a description of
the services that FCA offers to its customers, the Warranty
Certificate and the details of the terms and conditions for
maintaining its validity. Please take the time to read all of
these publications carefully before driving your vehicle for
the first time. Following the instructions, recommenda-
tions, tips, and important warnings in this manual will
help assure safe and enjoyable operation of your vehicle.
Be sure you are familiar with all vehicle controls, particu-
larly those used for braking, steering, transmission, and
transfer case shifting (if equipped). Learn how your vehicle
handles on different road surfaces. Your driving skills will
improve with experience.
This Owner’s Manual describes all versions of this vehicle.
Options and equipment dedicated to specific markets or
versions are not expressly indicated in the text. Therefore,
you should only consider the information which is related
to the trim level, engine, and version that you have
purchased. Any content introduced throughout the Own-
er’s Information, that may or may not be applicable to your
vehicle, will be identified with the wording “If Equipped”.
All data contained in this publication are intended to help
you use your vehicle in the best possible way. FCA aims at
a constant improvement of the vehicles produced. For this
reason, it reserves the right to make changes to the model
described for technical and/or commercial reasons. For
further information, contact an authorized dealer.
NOTE: After reviewing the Owner’s Information, it should
be stored in the vehicle for convenient referencing, and
remain with the vehicle when sold.
When it comes to service, remember that an authorized
dealer knows your vehicle best, has factory-trained techni-
cians and genuine MOPAR® parts, and cares about your
satisfaction.
4 INTRODUCTION

HOW TO USE THIS MANUAL
Essential Information
Consult the Table of Contents to determine which section
contains the information you desire.
Since the specification of your vehicle depends on the items
of equipment ordered, certain descriptions and illustra-
tions may differ from your vehicle’s equipment.
The detailed index at the back of this Owner’s Manual
contains a complete listing of all subjects.
Symbols
Some vehicle components have colored labels whose sym-
bols indicate precautions to be observed when using this
component. Refer to “Warning Lights and Messages” in
“Getting To Know Your Instrument Panel” for further
information on the symbols used in your vehicle.
WARNINGS AND CAUTIONS
This Owner’s Manual contains WARNINGS against oper-
ating procedures that could result in a collision, bodily
injury and/or death. It also contains CAUTIONS against
procedures that could result in damage to your vehicle. If
you do not read this entire Owner’s Manual, you may miss
important information. Observe all Warnings and Cau-
tions.
VEHICLE MODIFICATIONS/ALTERATIONS
WARNING!
Any modifications or alterations to this vehicle could
seriously affect its roadworthiness and safety and may
lead to a collision resulting in serious injury or death.
1
INTRODUCTION 5

GRAPHICAL TABLE OF CONTENTS
CONTENTS
䡵FRONT VIEW ............................8
䡵REAR VIEW .............................9
䡵INSTRUMENT PANEL .....................10
䡵INTERIOR ..............................11
2

FRONT VIEW
Front View
1 — Doors 3 — Wheels/Tires 5 — Windshield
2 — Exterior Mirrors 4 — Headlights 6 — Hood/Engine Compartment
8 GRAPHICAL TABLE OF CONTENTS

REAR VIEW
Rear View
1 — Taillights 2 — Rear Windshield Wiper 3 — Liftgate
2
GRAPHICAL TABLE OF CONTENTS 9

INSTRUMENT PANEL
Instrument Panel
1 — Headlight Switch 7 — Gear Selector
2 — Instrument Cluster Display Controls 8 — Uconnect System
3 — Multifunction Lever (Behind Steering Wheel) 9 — Climate Controls
4 — Instrument Cluster 10 — Switch Panel
5 — Speed Controls 11 — Upper Glove Compartment
6 — Ignition 12 — Lower Glove Compartment
10 GRAPHICAL TABLE OF CONTENTS

INTERIOR
Interior Features
1 — Door Handles 4 — Parking Brake
2 — Door Locks 5 — Seats
3 — Window Switches 6 — Power Outlets
2
GRAPHICAL TABLE OF CONTENTS 11

GETTING TO KNOW YOUR VEHICLE
CONTENTS
䡵KEYS .................................17
▫Key Fobs .............................17
䡵IGNITION SWITCH .......................20
▫Wireless Ignition Node (WIN) — If Equipped....20
䡵REMOTE START — IF EQUIPPED .............21
▫How To Use Remote Start..................21
▫Remote Start Abort Messages ...............22
▫To Enter Remote Start Mode ................22
▫To Exit Remote Start Mode Without Driving The
Vehicle ...............................22
▫To Exit Remote Start Mode And Drive The
Vehicle ...............................23
▫General Information .....................23
䡵SENTRY KEY ...........................23
▫Key Programming ......................24
▫Replacement Keys .......................24
▫General Information .....................24
䡵VEHICLE SECURITY ALARM — IF EQUIPPED . . .25
▫Rearming Of The System ..................25
▫To Arm The System .....................25
▫To Disarm The System ...................25
▫Tamper Alert ...........................26
䡵DOORS ...............................27
▫Manual Door Locks ......................27
▫Power Door Locks — If Equipped ...........28
▫Power Sliding Side Door — If Equipped .......29
▫Child Locks............................32
䡵SEATS ................................32
▫Manual Adjustment (Front Seats) — If Equipped .33
3

▫Manual Adjustment (Rear Seats) .............35
▫Power Seats — If Equipped ................45
▫Heated Seats — If Equipped ...............47
▫Plastic Grocery Bag Retainer Hooks...........49
䡵HEAD RESTRAINTS ......................49
▫Supplemental Active Head Restraints — Front
Seats.................................50
▫Head Restraints — Second Row Quad Seats .....52
▫Head Restraints — Second Row Bench.........52
▫Head Restraints — Third Row ..............53
䡵STEERING WHEEL .......................55
▫Tilt/Telescoping Steering Column ............55
▫Heated Steering Wheel — If Equipped ........55
䡵MIRRORS ..............................56
▫Automatic Dimming Mirror — If Equipped .....56
▫Automatic Dimming Mirror With Rear View
Camera Display — If Equipped .............57
▫Outside Mirrors ........................58
▫Interior Observation Mirror ................58
▫Power Mirrors — If Equipped ..............59
▫Outside Mirrors Folding Feature ............60
▫Heated Mirrors — If Equipped .............60
▫Illuminated Vanity Mirrors — If Equipped .....60
䡵EXTERIOR LIGHTS .......................61
▫Headlight Switch ........................61
▫Multifunction Lever .....................61
▫Daytime Running Lights (DRL) — If Equipped . .62
▫High/Low Beam Switch ..................62
▫Flash-To-Pass ..........................62
▫Automatic Headlights ....................62
▫Headlights On With Wipers — If Equipped .....62
▫Headlight Delay — If Equipped .............63
▫Lights-On Reminder .....................63
▫Front Fog Lights — If Equipped .............63
▫Turn Signals ...........................63
14 GETTING TO KNOW YOUR VEHICLE

▫Lane Change Assist ......................64
▫Battery Protection .......................64
䡵INTERIOR LIGHTS .......................64
▫Courtesy/Interior Lighting ................64
䡵WINDSHIELD WIPER AND WASHERS ........66
▫Windshield Wiper Operation................67
▫Rear Wiper And Washer ...................68
䡵CLIMATE CONTROLS .....................68
▫Manual Climate Control Overview ...........68
▫Automatic Climate Control Overview .........76
▫Climate Control Functions .................85
▫Automatic Temperature Control (ATC) —
If Equipped............................86
▫Operating Tips .........................86
䡵WINDOWS .............................89
▫Power Vent Windows — If Equipped .........89
▫Power Windows ........................89
䡵HOOD ................................92
▫Opening The Hood ......................92
▫Closing The Hood .......................93
䡵LIFTGATE .............................94
▫Opening .............................94
▫Closing ..............................94
▫Power Liftgate — If Equipped...............95
▫Cargo Area Features .....................97
䡵LOAD LEVELING SYSTEM — IF EQUIPPED ....97
䡵GARAGE DOOR OPENER — IF EQUIPPED .....98
▫Before You Begin Programming HomeLink .....98
▫Programming A Rolling Code ...............99
▫Programming A Non-Rolling Code ..........100
▫Canadian/Gate Operator Programming .......101
▫Using HomeLink .......................102
▫Security..............................102
▫Troubleshooting Tips ....................103
3
GETTING TO KNOW YOUR VEHICLE 15

▫General Information .....................104
䡵INTERNAL EQUIPMENT ..................104
▫Storage ..............................104
▫Cupholders ...........................113
▫Sun Screens — If Equipped ................115
▫Electrical Power Outlets — If Equipped .......115
▫Power Inverter — If Equipped .............119
▫Smoker’s Package Kit — If Equipped ........120
▫Sunglass Storage Bin — If Equipped .........120
䡵ROOF LUGGAGE RACK — IF EQUIPPED ......122
▫Deploying The Crossbars .................123
▫Stowing The Crossbars ...................126
16 GETTING TO KNOW YOUR VEHICLE

KEYS
Key Fobs
Your vehicle uses a keyless ignition system. This system
consists of a Remote Keyless Entry (RKE) key fob and a
Wireless Ignition Node (WIN) with integral ignition. You
can insert the key fob into the ignition switch with either
side up. It also contains an emergency key, which stores in
the rear of the key fob.
NOTE: The key fob may not be found if it is located next to
a mobile phone, laptop or other electronic device; these
devices may block the key fob’s wireless signal.
The emergency key allows for entry into the vehicle should
the battery in the vehicle or the key fob go dead. You can
keep the emergency key with you when valet parking.
To remove the emergency key, slide the mechanical latch at
the top of the key fob sideways with your thumb and then
pull the key out with your other hand.
NOTE: When using the emergency key to gain access to
your vehicle, be aware that the security alarm may be
triggered. Insert the key into the ignition and place the
ignition in the ON/RUN mode to disarm the security
system.
Key Fob
3
GETTING TO KNOW YOUR VEHICLE 17

To Unlock The Doors And Liftgate
Push and release the unlock button on the key fob once to
unlock the doors. Push and release the unlock button a
second time within 5 seconds to unlock the liftgate. The
turn signal lights will flash to acknowledge the unlock
signal.
To Lock The Doors And Liftgate
Push and release the lock button on the key fob once to lock
the doors. The turn signal lights will flash to acknowledge
the lock signal.
Replacing The Battery In The Key Fob With Remote
Control
The replacement battery is one CR2032 battery.
NOTE:
•Perchlorate Material — special handling may apply. See
www.dtsc.ca.gov/hazardouswaste/perchlorate
•Do not replace coin battery unless the cluster display
indicates a message “Key Fob Low Battery”
•Do not touch the battery terminals that are on the back
housing or the printed circuit board.
1. Remove the emergency key by sliding the mechanical
latch on the back of the key fob sideways with your
thumb and then pull the key out with your other hand.
Emergency Key Removal
18 GETTING TO KNOW YOUR VEHICLE
