Doiting ESP-M Series User manual

DOITING®Doctors of Intelligence & Technology Co., LTD
ESP-M1/M2
VER: V1.2 2018-5-18 NUM：DM0013CN
Doctors of Intelligence & Technology Co., LTD (www.doiting.com) Copyright@2014-2019
Features
SOC features
Built-in Tensilica L106 ultra-low power
consumption 32-bit cpu, the main frequency
can be 80MHz and 160MHz, also support
RTOS;
Built-in TCP/IP protocol stack;
Built-in 1 channel 10-bit high precision ADC;
Interfaces include HSPI, UART, I2C, I2S, IR
Remote Control, PWM, GPIO;
20uA deep-sleep current, less than 5uA cut-
off current;
2ms wake-up time;
1.0mW consume power (DTIM3 and standby
state);
Built-in 1M SPI flash byte;
Wi-Fi features
Support 802.11 b/g/n/e/i
Support three modes: Station, SoftAP, and
SoftAP+STA;
Support Wi-Fi Direct(P2P);
Support hardware acceleration for CCMP
(CBC-MAC, computation mode), TKIP (MIC,
RC4), WAPI(SMS4), WEP(RC4), CRC;
P2P detection, P2P GO mode/GC mode and
P2P power management;
WPA/PA2 PSK and WPS;
Support 802.11 i security: pre-certification
and TSN;
Support 802.11n (2.4 GHz);
802.1h/RFC1042 frame encapsulation;
Support seamless roam;
Support AT remote upgrade and cloud OTA
upgrade;
Support SmartConfig function for Android
and iOS device.
Module Interface
2*UART;
1*En;
1*ADC;
1*wakeup pin;
1*HSPI;
1*I2C;
1*I2S;
MAX 10* GPIOs;
Working temperature: -40℃-105℃
Module size:
12.3*mm*15mm; (ESP-M1)
12.3*mm*20mm; (ESP-M2)
Application
● Serial transparent transmission;
● WiFi prober;
● Smart power plug/Smart LED light;
● Mesh networks;
● Sensor networks;
● Wireless location recognition;
● Wireless location system beacon;
● Industrial wireless control.
Module Type
Name
Antenna Type
ESP-M1
IPEX external antenna
ESP-M2
PCB antenna on board
Module Structure

DOITING®
Doctors of Intelligence & Technology Co. Ltd (www.doiting.com) Copyright@2014-2019
Update Record
Date
Version
Update
2017-3-14
V1.0
Initial version
2017-3-18
V1.1
Add PCB design
2018-5-18
V1.2
Add system design

DOITING®
Doctors of Intelligence & Technology Co. Ltd (www.doiting.com) Copyright@2014-2019
Table of Contents
1. Introduction.........................................................................................................................1
2. Interface Definition.............................................................................................................3
3. Shape and Size.................................................................................................................... 5
4. Electronical Characteristics................................................................................................ 7
5. Power Consumption............................................................................................................7
6. Wi-Fi RF Characteristics.................................................................................................... 8
8. Minimum User System.......................................................................................................8
9. The Recommended PCB Design......................................................................................10
10. Peripheral Design Suggestion.........................................................................................12

DOITING®ESP-M1/M2 User Mannual
Doctors of Intelligence & Technology (www.doiting.com) Copyright@2014-2019 Page 1
1. Introduction
The WiFi module ESP-Mx is manufactured by using a high-performance chip named ESP8285. This
small chip is encapsulated an enhanced Tensilica’s L106 diamond series 32-bit kennel CPU with a
SRAM. Thus, ESP8285 has the complete function Wi-Fi function; it can be applied independently, and
also can be used as a slaver working with other host CPU. When ESP8285 is applied as a slaver, it can
start from the onboard flash. The built-in high-speed buffer is not only benefit to improve the system
performance, but optimize the store system. In addition, ESP-Mx WiFi module can be used as Wi-Fi
adapter by SPI/SDIO or I2C/UART interface, when it is applied to other MCU design.
The ESP-Mx WiFi module supports the standard IEEE802.11 b/g/n/e/i protocol and the complete
TCP/IP protocol stack. User can use it to add the WiFi function for the installed devices, and also can be
viewed as a independent network controller. Anyway, ESP-Mx module provides many probabilities with
the best price.
Fig. 1.1 ESP-Mx Module Structure

DOITING®ESP-M1/M2 User Mannual
Doctors of Intelligence & Technology (www.doiting.com) Copyright@2014-2019 Page 2
Technical parameters for ESP-Mx are listed as follows.
Table 1.1 ESP-Mx Parameters
Types
Items
Parameters
Wi-Fi
Frequency
2.4G~2.5G(2400M~2483.5M)
Transmit power
802.11b: +15.12 dBm
802.11g: +17.68 dBm
802.11n: +17.17 dBm
Receiver sensitivity
802.11b: -91 dbm (11Mbps)
802.11g: -75 dbm（54Mbps）
802.11n: -72 dbm（MCS7）
Antenna
PCB antenna / U.F.L antenna
Hardware
CPU
Tensilica L106 32 bit MCU
Interface
UART/SDIO/SPI/I2C/I2S/IR control
GPIO/ADC/PWM/SPI/I2C/I2S
Working voltage
2.5V ~ 3.6V
Working current
Average current: 80 mA,Peak current: >200mA
Working temperature
-40°C ~105°C
Environment temperature
-40°C ~ 105°C
Shape
12.3mm x 15mm x 3mm/12.3mmx20mmx3mm
Software
Wi-Fi working mode
Station/SoftAP/SoftAP+Station
Security mode
WPA/WPA2
Encryption type
WEP/TKIP/AES
Update firmware
UART Download/OTA
Software develop
Non-RTOS/RTOS/Arduino IDE etc.
Network protocol
IPv4, TCP/UDP/HTTP/FTP/MQTT
Wi-Fi working mode
Station/SoftAP/SoftAP+Station

DOITING®ESP-M1/M2 User Mannual
Doctors of Intelligence & Technology (www.doiting.com) Copyright@2014-2019 Page 3
2. Interface Definition
ESP-Mx module interface definition is shown as below。
Fig. 2.1 ESP-M1 Pin Definition
Fig. 2.2 ESP-M2 Pin Definition
Working mode and pin function is shown in Table 2.1.
Table 2.1 Working mode
Mode
GPIO0 Level
GPIO2 Level
UART Download Mode
Low
High
Flash Boot Mode
High
High

DOITING®ESP-M1/M2 User Mannual
Doctors of Intelligence & Technology (www.doiting.com) Copyright@2014-2019 Page 4
Table 2.2 Pin Function Definition
Num
Pin Name
Type
Function
1
ADC
I
A/D pin. Voltage Range: 0-1V. 10bit resolution
2
EN
I
Effective: High level. Used to enable the module
3
IO14
I/O
GPIO14;HSPI_CLK
4
IO12
I/O
GPIO12;HSPI_MISO
5
IO13
I/O
GPIO13; HSPI_MOSI; U A R T0 _C TS
6
IO15
I/O
GPIO15; MTDO;HSPICS; U ART0_RT S; Internal Pull-down
7
VCC
P
POWER：3.3V
8
GND
P
GND
9
IO2
I/O
GPIO2; U ART1 _T XD;
10
IO0
I/O
GPIO0; SPI_CS2;
11
IO4
I/O
GPIO4
12
IO5
I/O
GPIO5
13
RXD
I/O
GPIO3; UART Rxd
14
TXD
I/O
GPIO1; UART Txd
15
RST
I
Effective: Low level. Used to reset the module. Internal Pull-up.
16
GND
P
GND

DOITING®ESP-M1/M2 User Mannual
Doctors of Intelligence & Technology (www.doiting.com) Copyright@2014-2019 Page 5
3. Shape and Size
Shape and size for ESP-Mx can be shown as follows.。The Flash of ESP-Mx is 4 Mbits.
Fig. 3.1 Shape for ESP-M1
(a) Vertical View
(b) Side View
Fig. 3.2 Size for ESP-M1

DOITING®ESP-M1/M2 User Mannual
Doctors of Intelligence & Technology (www.doiting.com) Copyright@2014-2019 Page 6
Fig, 3.3 Shape for ESP-M2
(a) Vertical View
(b) Side View
Fig. 3.4 Size for ESP-M2
Table 3.1 Size for ESP-M1
Length
Width
Height
PAD Size (bottom)
Distance between Pins
12.3mm
15 mm
3 mm
0.9 mm x 1.7mm
1.5 mm
Table 3.2 Size for ESP-M2
Length
Width
Height
PAD Size (bottom)
Distance between Pins
12.3mm
20 mm
3 mm
0.9 mm x 1.7mm
1.5 mm

DOITING®ESP-M1/M2 User Mannual
Doctors of Intelligence & Technology (www.doiting.com) Copyright@2014-2019 Page 7
4. Electronical Characteristics
Table 4.1 Electronical Characteristics
Parameters
Condition
Min
Classical
Max
Unite
Store Temperature
-
-40
Normal
125
℃
Sold Temperature
IPC/JEDEC J-
STD-020
-
-
260
℃
Working Voltage
-
2.5
3.3
3.6
V
I/O
VIL/VIH
-
-0.3/0.75VIO
-
0.25VIO/3.6
I/O
VOL/VOH
-
N/0.8VIO
-
0.1VIO/N
IMAX
-
-
-
12
Electrostatic release
quantity (Human model)
TAMB=25℃
-
-
2
KV
Electrostatic release
quantity (Human model)
TAMB=25℃
-
-
0.5
KV
5. Power Consumption
Table 5.1 Power Consumption
Parameters
Min
Classical
Max
Unit
Tx802.11b, CCK 11Mbps, POUT=+17dBm
-
170
-
mA
Tx802.11g, OFDM 54 Mbps, POUT =+15dBm
-
140
-
mA
Tx802.11n,MCS7,POUT =+13dBm
-
120
-
mA
Rx 802.11b，1024 Bytes, -80dBm
-
50
-
mA
Rx 802.11g，1024 Bytes, -70dBm
-
56
-
mA
Rx 802.11n，1024 Bytes, -65dBm
-
56
-
mA
Modem-sleep①
-
15
-
mA
Light-sleep②
-
0.9
-
mA
Deep-sleep③
-
20
-
μA
Note
①: Modem-Sleep mode can be used for the case that CPU is always working, e.g., PWM or I2S etc. If
WiFi is connected and no data is to transmitted, in this case, WiFi modem can be closed to save power
energy. For example, if at DTIM3 status, keep asleep at 300ms, Then, the module can wake up to receive
the Beacon package within 3ms and the current being 15mA.
②: Light-Sleep mode can used for the case that CUP can stop the application temporally, e.g., Wi-Fi
Switch . If Wi-Fi is connected and there is no data packet to transmitted, by the 802.11 standard (e.g., U-
APSD), module can close Wi-Fi Modem and stop CPU to save power. For example, at DTIM3, keep up

DOITING®ESP-M1/M2 User Mannual
Doctors of Intelligence & Technology (www.doiting.com) Copyright@2014-2019 Page 8
sleeping at 300ms, it would receive the Beacon package from AP after each 3ms, then the whole average
current is about 0.9mA.
③Deep-Sleep mode is applied to the case that Wi-Fi is not necessary to connect all the time, just send
a data packet after a long time (e.g., transmit one temperate data each 100s) . it just need 0.3s-1s to
connect AP after each 300s, and the whole average current is much smaller 1mA.
6. Wi-Fi RF Characteristics
The data in the following Table is gotten when voltage is 3.3V and 1.1V in the indoor temperature
environment.
Table 6.1 Wi-Fi RF Characteristics
Parameters
Min
Classical
Max
Unite
Input frequencey
2412
-
2484
MHz
Input impedance
-
50
-
Ω
Input reflection
-
-
-10
dB
At 72.2Mbps, output power consumption for PA
15.5
16.5
17.5
dBm
At 11b mode, output power consumption for PA
19.5
20.5
21.5
dBm
Sensibility
-
-
-
-
DSSS, 1Mbps
-
-98
-
dBm
CCK11, Mbps
-
-91
-
dBm
6Mbps(1/2 BPSK)
-
-93
-
dBm
54Mbps(3/4 64-QAM)
-
-75
-
dBm
HT20, MCS7(65 Mbps, 72.2 Mbps)
-
-72
-
dBm
Adjacent Inhibition
OFDM, 6Mbps
-
37
-
dB
OFDM, 54Mbps
-
21
-
dB
HT20, MCS0
-
37
-
dB
HT20, MCS7
-
20
-
dB

DOITING®ESP-M1/M2 User Mannual
Doctors of Intelligence & Technology (www.doiting.com) Copyright@2014-2019 Page 9
7. The Recommended Sold Temperature Curve
图7. 1 Temperature Curve when sold

DOITING®ESP-M1/M2 User Mannual
Doctors of Intelligence & Technology (www.doiting.com) Copyright@2014-2019 Page 10
8. Minimum User System
This module can work just at 3.3V working voltage:
Fig.8.1 minimum system
Note
(1) the working voltage for module is DC 3.3V;
(2) the max current from IO of this module is 12mA;
(3) RST Pin is enabled when it is low level; and EN pin is enabled when it is high level;
(4) WiFi module is at update mode: GPIO0 is low level, then module reset to power; Wi-Fi module
is at working mode: GPIO0 is at high level, and then reset to power;
(5) Wi-Fi module is connected to RXD of the other MCU, and TXD is connected to RXD of the
other MCU.
9. The Recommended PCB Design ( Take ESP-M2 as an Example)
ESP-Mx Wi-Fi module can be sold on PCB board directly. For the high RF performance for the device,
please notice the placement of the module. There are three ways to use the module.
Solution 1:optical solution. The WiFi module is placed on the side of the board, and the antennas are
all exposed, and there is no metal material around the antenna, including wires, metal casings, weight
plates, and the like.
Solution 2:suboptical solution. The WiFi module is placed on the side of the board, and the antenna
below is hollowed out. There is a gap of not less than 5 mm reserved with the PCB, and there is no metal
material around the antenna, including wires, metal casings, weight plates, and the like.
Solution 3: The WiFi module is placed on the side of the board, and the PCB area under the antenna is
empty, and copper cannot be laid.

DOITING®ESP-M1/M2 User Mannual
Doctors of Intelligence & Technology (www.doiting.com) Copyright@2014-2019 Page 11
Fig.9.1 Solution 1
Fig.9.2 Solution 2

DOITING®ESP-M1/M2 User Mannual
Doctors of Intelligence & Technology (www.doiting.com) Copyright@2014-2019 Page 12
Fig.9.3 Solution 3
10. Antenna
Antenna Type: PCB Antenna
Antenna Gain(Peak): 2.07 dBi
Antenna size chart:

DOITING®ESP-M1/M2 User Mannual
Doctors of Intelligence & Technology (www.doiting.com) Copyright@2014-2019 Page 13
11. Peripheral Design Suggestion
Wi-Fi module is already integrated into high-speed GPIO and Peripheral interface, which may be
generated the switch noise. If there is a high request for the power consumption and EMI characteristics,
it is suggested to connect a serial 10~100 ohm resistance, which can suppress overshoot when switching
power supply, and can smooth signal. At the same time, it also can prevent electrostatic discharge (ESD).
The information in this article, including the URL for reference, if there is any change, without prior
notice.
Documents are provided by the current version without any guarantee responsibility, including
merchantability, suitable for any particular purpose or non-infringement guarantees, and any guarantees
presented by any proposal, specification, or sample mentioned elsewhere. This document has no any
responsibility, including the use of the information within this document produced by the infringement of
any patent rights. This document in this, by estoppel or otherwise, grant any intellectual property
licensing, whether express or implied license.
The Wi-Fi alliance marks shall be owned by the Wi-Fi alliance.
All the mentioned brand names, trademarks and registered trademarks presented in this document are
the property of their respective owners, and hereby declare.
FCC regulatory information
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two
conditions: (1) this device may not cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause undesired operation.
Warning: changes or modifications not expressly approved by the party responsible for compliance
could void the user’s authority to operate the equipment.
End Device Labelling
Please notice that if the FCC identification number is not visible when the module is installed inside
another device, then the outside of the device into which the module is installed must also display a label
referring to the enclosed module. This exterior label can use wording such as the following: “Contains
FCC ID: 2A2P9-ESP-M2” any similar wording that expresses the same meaning may be used.
RF Exposure Compliance
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with a minimum distance of 20cm between the radiator
& your body. This transmitter must not be co-located or operating in conjunction with any other antenna
or transmitter.
Installation Notice
The module is limited to OEM installation ONLY. The OEM integrator is responsible for ensuring that
the end-user has no manual instruction to remove or install module.

DOITING®ESP-M1/M2 User Mannual
Doctors of Intelligence & Technology (www.doiting.com) Copyright@2014-2019 Page 14
The module is limited to installation in mobile application; A separate approval is required for all other
operating configurations, including portable configurations with respect to Part 2.1093 and difference
antenna configurations.
We use the bottom plate to assist the test, but the bottom plate is not needed when the module
is installed, and it can be directly installed on the product.
FCC Part 15B Compliance of End Device
The OEM integrator is responsible for ensuring that the host product which is installed and operating
with the module is in compliant with Part 15B unintentional Radiator requirements, please note that For a
Class B digital device or peripheral, the instructions furnished the user manual of the end-user product
shall include the following or similar statement, placed in a prominent location in the text of the manual:
Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against
harmful interference in a residential installation. This equipment generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception,
which can be determined by turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
—Reorient or relocate the receiving antenna.
—Increase the separation between the equipment and receiver.
—Connect the equipment into an outlet on a circuit different from that to which the receiver is
connected.
—Consult the dealer or an experienced radio/TV technician for help.
List of applicable FCC rules：FCC Part15 Subpart C, Section 15.247
Information on test modes and additional testing requirements
To investigate the maximum EMI emission characteristics generates from EUT, the test system was pre-
scanning tested base on the consideration of following EUT operation mode or test configuration mode
which possible have effect on EMI emission level. Each of these EUT operation mode(s) or test
configuration mode(s) mentioned above was evaluated respectively.
RADIATED EMISSION TEST (BELOW 1GHz):
Pre-Scan has been conducted to determine the worst-case mode from all possible combinations between
available modulations, data rates, XYZ axis and antenna ports (if EUT with antenna diversity

DOITING®ESP-M1/M2 User Mannual
Doctors of Intelligence & Technology (www.doiting.com) Copyright@2014-2019 Page 15
architecture).
For the test results, only the worst case was shown in test report.
RADIATED EMISSION TEST (ABOVE 1GHz):
Pre-Scan has been conducted to determine the worst-case mode from all possible combinations between
available modulations, data rates, XYZ axis and antenna ports (if EUT with antenna diversity
architecture).
Additional testing Part15SubpartB disclaimer
The grantee should include a statement that the modular transmitter is only FCC authorized forthe
specific rule parts (i.e.，FCC transmitter rules )listedonthegrant，and that the host productmanufacturer
is responsible for compliance to any other FCC rules that apply to the host notcovered by the modular
transmitter grant of certification .If the grantee markets their product asbeing Part
15SubpartBcompliant( when it also contains unintentional - radiator digital circuit y)，then the grantee
shall provide a notice stating that the final host product still requires Part 15 Subpart B compliance testing
with the modular transmitter installed .
FCC Radiation Exposure Statement:
This equipment complies with FCC radiation exposure limits set forth for an uncontrolled environment.
This equipment should be installed and operated with minimum distance 20cm between the radiator &
your body.
FCC INFORMATION (additional)
OEM INTEGRATION INSTRUCTIONS:
This device is intended only for OEM integrators under the following conditions: The module must be
installed in the host equipment such that 20 cm is maintained between the antenna and users, and the
transmitter module may not be co-located with any other transmitter or antenna. The module shall be only
used with the internal antenna(s) that has been originally tested and certified with this module. As long as
3 conditions above are met, further transmitter test will not be required. However, the OEM integrator is
still responsible for testing their end-product for any additional compliance requirements required with
this module installed (for example, digital device emissions, PC peripheral requirements, etc.).
Validity of using the module certification:
In the event that these conditions cannot be met (for example certain laptop configurations or co-location
with another transmitter), then the FCC authorization for this module in combination with the host
equipment is no longer considered valid and the FCC ID of the module cannot be used on the final
product. In these circumstances, the OEM integrator will be responsible for re-evaluating the end product
(including the transmitter) and obtaining a separate FCC authorization.
Module label:
FCC ID: 2A2P9-ESP-M2
The final end product must be labeled in a visible area with the following: “Contains FCC ID:2A2P9-
ESP-M2 ”. Information that must be placed in the end user manual:
The OEM integrator has to be aware not to provide information to the end user regarding how to install or
remove this RF module in the user's manual of the end product which integrates this module. The end
user manual shall include all required regulatory information/warning as show in this manual.
The module not applicable Limited module procedures. The module is a Single module and complies
with the requirement of FCCPart15.247
The module has its own antenna ，anddoesn'tneedahost's printed board microstriptrace antenna etc, Not
applicable Trace antenna designs

DOITING®ESP-M1/M2 User Mannual
Doctors of Intelligence & Technology (www.doiting.com) Copyright@2014-2019 Page 16
Disclaimer and Copyright Notice
Note:
Because of the product update or other reasons, this
manual may change. Doctors of Intelligence & Technology
Co., LTD Keeps the right to change the contents of this
manual in the absence of any notice or reminders. This
manual is used only as a guide, Doctors of Intelligence &
Technology Co., LTD would try their best to provide the
accurate information in this manual, but it does not ensure
that the manual content is completely right and national, all
the statements in this manual, and information and advice do
not mean to provide any express or implied guarantees.
