DVD HOME THEATER SYSTEM

OWNER'S MANUAL

CD-R

VCR

AV INPUT

VIEWER

-1-

Important Safety Instructions

WARNING

Thelightningflashwithanarrowheadsymbol,within

theequilateraltriangle,isintendedtoalerttheuserto

the presence of uninsulated "dangerous voltage"

withintheproduct'senclosurethatmaybeofsufficient

magnitudetocauseanelectricshock.

Theexclamationpointwithintheequilateraltriangle

is intended to alert the user to the presence of

important operating and maintenance (servicing)

instructionsinthisownermanual.

WARNING:TOREDUCETHERISKOF ELECTRIC

SHOCK,DONOTREMOVECOVER(ORBACK).NO

USER-SERVICEABLE PARTS INSIDE. REFER

SERVICINGTOQUALIFIEDSERVICEPERSONNEL.

WARNING:

TO PREVENT FIRE OR SHOCK

HAZARD, DO NOT EXPOSE THIS

APPLIANCETORAINORMOISTURE.

CAUTION: TO PREVENT ELECTRIC SHOCK,

MATCH WIDE BLADE OF PLUG TO

WIDESLOT,FULLYINSERT.

Notes on Copyright

It is forbidden by law to copy, broadcast, show, broadcast on cable, play in public, rent copyrighted material without

permission.

Apparatus Claims of U.S. Patent Nos. 4,631,603; 4,577,216; 4,819,098 and 4,907,093 licensed for limited viewing uses

only.

DVD video discs are copy protected, and any recordings made from these discs will be distorted. This product

incorporates copyright protection technology that is protected by method claims of certain U.S. patents and other

intellectual property rights owned by Macrovision Corporation and other rights owners. Use of this copyright protection

technology must be authorized by Macrovision Corporation, and is intended for home and other limited viewing uses

only, unless otherwise authorized by Macrovision Corporation. Reverse engineering or disassembly is prohibited.

OnPlacement

• Do not use the Unit in places which are extremely hot, cold, dusty, or humid.

• Place the Unit on a flat and even surface.

• Do not restrict the air flow of the Unit by placing it in a place with poor air flow, by covering it with a cloth, or by placing

it on carpeting.

OnSafety

• When connecting or disconnecting the AC cord, grip the plug and not the cord itself. Pulling the cord may damage

it and create a hazard.

• When you are not going to use the Unit for a long period of time, disconnect the AC power cord.

OnCondensation

• Whenleftinaheatedroomwhereitiswarmanddamp,waterdropletsorcondensationmayforminsidetheUnit.When

thereiscondensationinsidetheUnit,theUnitmaynotfunctionnormally.LettheUnitstandfor1to2hoursbeforeturning

the power on, or gradually heat the room up and dry the Unit before use.

WARNING:

• Should any trouble occur, disconnect the AC power cord and refer servicing to a qualified technician.

• Do not place anything directly on the top of the Unit. Damage to the Unit can result.

• Changes or modifications to this unit not expressly approved by the party responsible for compliance could void

the user authority to operate the equipment.

This product

contains a low

power laser device.

The symbol for Class II

(Double lnsulation)

CAUTION

INVISIBLELASERRADIATIONWHEN

OPENANDINTERLOCKSDEFEATED.

AVOIDEXPOSURETOBEAM

FCCStatements

NOTE:This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part

15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a

residential installation. This equipment generates, used in accordance with the instructions, may cause harmful

interference to radio communications.

However, there is no guarantee that interference will not occur in a particular installation.If this equipment does cause

harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the

user is encouraged to try to correct the interference by one or more of the following measures:

• Reorient or relocate the receiving antenna.

• Increase the separation between the equipment and receiver.

• Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

• Consult the dealer or an experienced radio/TV technician for help.

Shielded cables must be used with this unit to ensure compliance with the Class FCC limits.

-2-

Important Safety Instructions

1. Read Instructions - All the safety and operating instructions should be read before the appliance is

operated.

2. Retain Instructions - The safety and operating instructions should be retained for future reference.

3. Heed Warnings - All warnings on the appliance and in the operating instructions should be adhered to.

4. Follow Instructions - All operating and use instructions should be followed.

5. Water and Moisture - The appliance should not be used near water - for example, near a bathtub,

washbowl, kitchen sink, laundry tub, in a wet basement, or near a swimming pool, and the like.

6. Carts and Stands - The appliance should be used only with a cart or stand that is

recommended by the manufacturer.

6A.An appliance and cart combination should be moved with care. Quick stops, excessive

force, and uneven surfaces may cause the appliance and cart combination to overturn.

7. Wall or Ceiling Mounting - The appliance should be mounted to a wall or ceiling only as

recommended by the manufacturer.

8. Ventilation - The appliance should be situated so that its location or position does not interfere with

its proper ventilation. For example, the appliance should not be situated on a bed, sofa, rug, or similar

surface that may block the ventilation openings; or, placed in a built-in installation, such as a book case

or cabinet, that may impede the flow of air through the ventilation openings.

9. Heat - The appliance should be situated away from heat sources such as radiators, heat registers,

stoves, or other appliances (including amplifiers) that produce heat.

10. Power Sources - The appliance should be connected to a power supply only of the type described in

the operating instructions or as marked on the appliance.

11. Grounding or Polarization - Precautions should be taken so that the grounding or polarization means

of an appliance are not defeated.

12. Power-Cord Protection - Power-supply cords

should be routed so that they are not likely to be

walked on or pinched by items placed upon or

against them, paying particular attention to cords

at plugs, convenience receptacles, and the point

where they exit from the appliance.

13. Cleaning - The appliance should be cleaned only

as recommended by the manufacturer.

14. Power Lines - An outdoor antenna should be

located away from power lines.

15. Outdoor Antenna Grounding - If an outside

antenna is connected to the receiver, be sure the

antenna system is grounded so as to provide

some protection against voltage surges and built

up static charges. Section 810 of the National

Electrical Code, ANSI/NFPA No. 70, provides information with respect to proper grounding of the mast

and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding

conductors, location of antenna-discharge unit, connection to grounding electrodes, and requirements

for the grounding electrode. See Figure 1.

16. Nonuse Periods - The power cord of the appliance should be unplugged from the outlet when left

unused for a long period of time.

17. Object and Liquid Entry - Care should be taken so that objects do not fall, and liquids are not spilled,

into the enclosure through openings.

18. Damage Requiring Service - The appliance should be serviced by qualified service personnel when:

A. The power-supply cord or the plug has been damaged; or

B. Objects have fallen, or liquid has been spilled, into the appliance; or

C. The appliance has been exposed to rain; or

D. The appliance does not appear to operate normally or exhibits a marked change in performance; or

E. The appliance has been dropped, or the enclosure damaged.

19. Servicing - The user should not attempt to service the appliance beyond that described in the operating

instructions. All other servicing should be referred to qualified service personnel.

-3-

Table of Contents

Repeat Playback ........................................ 24

Repeatingatitle/chapter(DVD)............................24

Repeatingasingletrack/wholedisc(CD)...........24

Repeatingaspecificsection(DVD)......................24

Playing MP3 and Picture File Disc......... 25-26

PlayingaMP3filedisc............................................25

PlayingaPicturefiledisc.......................................26

PlayingaMP3/Picturefiledisc...............................26

CustomizingtheFunctionSettings ........27-34

LANGUAGEsetting..................................................27

VIDEOsetting......................................................27-29

TVShape..............................................................27

VideoOutput.......................................................28

Brightness............................................................29

Edges....................................................................29

AUDIOsetting.....................................................30-32

DigitalOut...........................................................30

L/Rspeaker..........................................................30

Subwoofer............................................................31

SurroundDelay.................................................31

CenterDelay.......................................................32

Pinknoise...........................................................32

RATINGsetting...................................................33-34

Password/Parentallock ....................................33

FactorySet..........................................................34

LanguageCodeListforDiscLanguage.......35

Maintenance................................................36

CleaningDisc..........................................................36

CleaningtheUnit...................................................36

ImportantNote.......................................................36

Trouble Shooting Guide ........................ 36-37

Important Safety Instruction ..................... 1-2

Disc Formats ................................................ 4

Before You Start ........................................... 5

Usingtheremotecontrol..........................................5

Parts and Functions .................................. 6-8

RemoteControl......................................................6-7

FrontandTopPanel...................................................8

Display ......................................................... 9

FrontPanelDisplay....................................................9

DisplayInformation...................................................9

Setup ..................................................... 10-14

ConnectingyourTV............................................10-11

ConnectingaVCR....................................................12

Connectinganothersource....................................12

Connectingthespeakers&subwoofer ..................13

Positioningthespeakersandsubwoofer..............13

Mountingrearsurroundspeakers ..........................14

TurningontheUnitandTV ......................................14

Powercordconnection...........................................14

Adjusting the Sound ............................. 15-16

Playing a Disc ....................................... 17-19

PlayingDisc.............................................................17

Pausingplayback(stillmode)...............................17

Stoppingplayback.................................................17

Toskiptoadifferenttrack......................................17

FastFoward/FastReverse.....................................18

Slow-motionplay...................................................18

Skip(Forward/Reverse)..........................................18

Zoomingintoanimage .........................................18

Angleselection.......................................................19

Audioselection.......................................................19

Subtitleselection....................................................19

Special Functions ................................. 20-22

Displayfunction(DVD)..........................................20

Locatingaspecifictitle .........................................21

Locatingaspecifictitle/chapter/track..................21

Locatingaspecifictime.........................................22

Anglesetting...........................................................22

Audiosetting..........................................................22

Subtitlesetting.......................................................22

CD/ DVDprogrammablememory...............23

DVDprogrammablememory.................................23

Title/Chapterprogrammedplayback.............23

CDprogrammablememory...................................23

Trackprogrammedplayback..........................23

-4-

The Unit can playback.

Region Management Information

Region Management Information: This Unit is designed and manufactured to respond to the Region

Management Information that is encoded on DVD discs. If the Region number printed on the DVD disc does

not correspond to the Region number of this Unit, this Unit cannot play that disc.

The region number of this Unit is 1.

Disc Function or Operation that is Not Available

When the symbol appears on the TV screen, it indicates that the function or operation attempted is not

available at that time. This occurs because the DVD disc manufacturer determines the specific functions.

Certain functions may not be available on some discs. Be sure to read the documentation provided with the

DVD.

Chapter 1 Chapter 1Chapter 2 Chapter 2Chapter 3

DVDs

[8cm(3")/12cm(5”) disc]

Notes on Unauthorized Discs

You may not be able to play back some DVD discs on this Unit if they were purchased from outside your

geographic area or made for business purposes.

Title, Chapter and Tracks

• DVDs are divided into “titles” and “chapters”. If the

disc has more than one movie on it, each movie would

be aseparate “title”. “Chapters” are sections of titles.

• Audio CDs are divided into “tracks”. A “track” is

usually one song on an Audio CD.

Note :

• Numbers identify each title, chapter, and track on a disc. Most discs have these numbers recorded on them,

but some do not.

Track 1 Track 2 Track 3 Track 4 Track 5

Icons Used on DVDs

Sample lcons Language selections for audio

Language selections for subtitles

Screen aspect ratio

Multiple camera angles

Region code indicator

1. English

2. French

1. English

2. French

Notes:

• ThisUnit supports 2-channel (L/R) audio and 5.1ch (Multi-channel) MPEG Audio 1/2 (onlywhenthe DIGITAL

AUDIO OUT coaxial jack is used for connection). It does not support 7.1 channel MPEG Audio Version 2.0.

• When playing back a CD-G (Graphics) or CD EXTRA disc, the audio portion will be played, but the graphic

images will not be shown.

Disc Formats

Audio CDs

[8cm(3")/12cm(5”) disc]

Compatible

- 5 -

BeforeYou Start

To install Batteries

1.Open the battery door.

Battery Replacement

When batteries become weak, the operating distance of the Remote Control is greatly reduced and you will

need to replace the batteries.

Notes:

• If the Remote Control is not going to be used for a long time, remove the batteries to avoid damage caused

by battery leakage corrosion.

• Do not mix old and new batteries. Do not mix ALKALINE, standard (CARBON-ZINC) or rechargeable

(NICKEL-CADMIUM) batteries.

2.Insert two "AA" or UM-3 size batteries.

Using the Remote Control

• Point the Remote Control at the REMOTE SENSOR located on the Unit.

• When there is a strong ambient light source, the performance of the infrared REMOTE SENSOR may be

degraded, causing unreliable operation.

• The recommended effective distance for remote operation is about 16 feet (5 meters).

- 6 -

Parts and Functions

(Continued on next page)(Continued on next page)

(Continued on next page)

Remote Control

VOLUME

SETUP MENU

ENTER

SLOW SLOW

STOP PLAY PAUSE

REPEAT

PREV SEARCH

CLEAR

ANGLE SUBTITLE

A-B DISC

DISPLAY AUDIO

ZOOM/

NTSC/PAL

STANDBY/ON

SOUND

OPEN/

FUNCTION

GOTO

MEMORY

PRO LOGIC II

P. SCAN/

CVBS

DIMMER

RETURN

1) STANDBY / ON button

Turns the Unit on and puts it in standby mode.

2) RETURN button

Return to the normal operation after using the SETUP

menu.

3) Number (0 - 9) and (+10) buttons

Use when creating programs, and entering a parental

level password. To select numbers over 9, press +10

buttonandthenthesecondno.forexample,toenter18,

press +10 and then 8.

4) 5.1 / 2.1 CHANNELS button

Switch speaker output to 5.1 channel mode. (All

speakers + subwoofer)

Switch speaker outputs to 2.1 channel. (Front left/right

speakers + subwoofer)

5) MEMORYbutton

Enter the number of a selected chapter or track.

6) DIMMERbutton

Turns the display backlight ON and OFF.

7) PROLOGIC II button

In AV_IN mode, switches to Dolby Pro Logic mode for

VHS tapes encoded with Dolby Pro Logic.

8) VOLUME (+ / -) buttons

Adjust the volume.

9) SETUPbutton

Selects the SET UP menu screen.

10) / CURSOR buttons

Use to highlight selections on a menu screen and

adjust certain settings.

11) SLOWbutton

Perform slow reverse playback of DVDs.

12) / SEARCH buttons

SEARCH:Fast reverse playback.

SEARCH:Fast forward playback.

13) STOP button

Stop playback.

14) PREV button

Move reverse through titles, chapters or tracks on a

disc.

15) CLEAR button

Clear input selections and cancel certain playback

functions.

16) DISPLAYbutton

Change disc status information displayed on the TV.

17) ANGLE button

Switch the camera angle of the video presentation

whenscenes withmultiple cameraanglesare recorded

on a DVD.

18) SUBTITLE button .....

Select one of the subtitle languages programmed on a

DVD.

- 7 -

19) FUNCTIONbutton

DisplaytheFUNCTIONscreenwhereyoucancheck

or change various setting.

20) OPEN / CLOSE button

Use to open or close the disc tray.

21) GOTObutton

Skip directly to a specific location on a DVD disc.

22) SOUND button

Selects sound balance and tone controls for

adjustment with the cursor buttons.

23) P. SCAN / CVBS button

Changing YUV output to Progressive Scan Video

mode or back to CVBS mode.

24) / CURSOR buttons

Use to highlight selections on a menu screen and

make adjust certain settings.

25) MENU button

Open and close DVD's menu.

26) ENTERbutton

Confirm selections on a menu screen.

27) SLOW button

Perform slow forward playback of DVDs.

28) PLAY button

Start playback.

29) PAUSE button

Pause playback, frame advance.

30) NEXT button

Move forward through titles, chapters or tracks on a

disc.

31) ZOOMbutton

Zoom into an image.

NTSC / PAL button

In stop mode, select whether to output the video signal.

TV shows "AUTO" which means output signal depends

on DVD disc (either NTSC or PAL). TV shows "PAL" or

"NTSC" which means output signal fixed to PAL or

NTSC.

32) AUDIObutton

Select one of the audio soundtracks programmed

on a DVD or selects the audio output mode on a

AUDIO CD.

33) REPEAT-DISC button

Repeat chapter or title of a DVD.

Repeat single track or whole CD.

34) REPEAT A - B button

Perform point-to-point repeat playback on a DVD or

CD.

Parts and Functions

Remote Control

VOLUME

SETUP MENU

ENTER

SLOW SLOW

STOP PLAY PAUSE

REPEAT

PREV SEARCH

CLEAR

ANGLE SUBTITLE

A-B DISC

DISPLAY AUDIO

ZOOM/

NTSC/PAL

STANDBY/ON

OPEN/

FUNCTION

GOTO

MEMORY

PRO LOGIC II

P. SCAN/

CVBS

DIMMER

SOUND

RETURN

(Continued on next page)(Continued on next page)

(Continued on next page)

- 8 -

Rear Panel

1) Disc tray

OpenorclosetraybypushingOPEN/CLOSEbutton.

Place a disc on the disc tray, label side up.

2) STANDBY indicator

When the Unit is turned on by pressing the

STANDBY/ON button, the light will illuminate a few

seconds.IfyoupresstheSTANDBY /ONbuttonon

the remote control, the Unit will turn off and go into

standby mode. The light will continue to illuminate.

3) Displaywindow

Display system information.

4) OPEN/CLOSEbutton

Use to open and close the disc tray.

11) COMPONENT VIDEO jacks (Y, PB/CB, PR/CR)

12) VIDEO OUT (TV) jack

13) DIGITAL AUDIO OUT jack

14) VIDEO IN (VCR) jack

15) AUDIO IN (L/R) jacks

16) Right FRONT speaker terminals

17) SUBWOOFER terminals

18) Left REAR speaker terminals

19) AUDIO OUT (L/R) jacks

20) S-VIDEO (DVD) output jack

21) Right REAR speaker terminals

22) CENTER speaker terminals

23) Left FRONT speaker terminals

24) Power cord

Front and Top Panel

5) PLAYbutton

Press to start or resume playback

6) STOPbutton

Stop playing a disc.

7) FUNCTIONbutton

Select the source.

8) VOLUMEcontrols

Changetheloudnessofthesoundfromthespeakers

connected to the Unit.

9) STANDBY/ON button

Turn the power on or off.

10) Remote sensor

Receive the remote control unit signals.

Parts and Functions

Note:

Screen saver - If no button is pressed within 2 minutes, the screen save function will activate, If you want to return

to the normal screen, press any button.

- 9 -

Region (Local) Number Error Indicator

Iftheregion(local)numberofthediscthatyouattempttoplaydiffersfromtheregionnumberoftheUnit,"InvalidRegion"

appears on the TV screen. (The disc cannot be played).

If no disc is loaded

whentheMainUnit

is switched on.

Tray open

Tray closed

Stopped

Playing

Paused

Fast forward

Fast reverse

Slow

Repeat A - B

Remarks

"" appears when the tray is closed and:

1)There is no disc in the tray.

2)The disc type is not playable in this Unit.

3)The disc is not loaded correctly (upside-down, etc.)

The display changes to show

other indicators.

Freezesthe imageon thescreenor pausesaudioplayback.

The display changes to show other indicators.

Does not function for Audio CDs.

Repeat a specific section.

The operation is not permitted by the DVD Unit or the

disc.

TV Screen Unit Display

No Disc

x 2

A-B

ANGLE indicator

Appears when multiple camera

angles are recorded in the section

oftheDVDthatiscurrentlyplaying.

DOLBY DIGITAL indicator

Displayswhile Dolby Digital

sound processing is being

performed or when the

loaded disc contains Dolby

Digital sound

OPERATION indicator

Indicates the operation

status of the disc and Unit.

REPEAT 1 playback indicator

Displayed during repeat a CD

playback.

Display

Front Panel Display

Display Information

The DVD displays the information shown below on the TV screen and on the Unit's DVD display depending

on the operation status.

Display Examples

REPEAT A-B playback

indicator

Displayed during repeat a

specific section of DVD

playback.

MEMORY indicator

Displayed during

programmed playback.

DOLBYPROLOGIC II indicator

When Dolby Pro Logic sound

isselectedin AV_IN mode, the

light will illuminate.

1/2

Play

Pause

Rep A- Rep A-B

Stop

- 10 -

Setup

(continued to next page)(continued to next page)

(continued to next page)

A. Connecting a TV

The Unit can be connected to your TV in several different ways, depending on the design of your TV.

RCAAudio/Videocable

Use the supplied Audio/Video cable.

1. Connect the VIDEO OUT and left/right AUDIO OUT jacks on the unit to the VIDEO IN and left/right AUDIO IN jacks

on your TV.

S-Videocable

Use an S-Video cable (not supplied) and the Audio cable (not supplied).

1. Use an S-Video cable to connect the S-VIDEO (DVD) jack on your Unit to the S-VIDEO IN jack on your TV.

2. UsetheAudiocable to connect the left/right AUDIO OUTjacksonthe unit to the left/right AUDIO INjacksonyour TV.

To wall

outlet

S-Video cable (not supplied)

Audio cable

(not supplied)

(red)

(white)

To wall

outlet

Audio/Video cable (supplied)

(red)

(yellow)

(white)

Note:

• If you want the sound come from the speakers of the Main Unit, you need not to connect the left/right AUDIO OUT

jacks from the Main Unit to your TV.

- 11 -

Setup

(continued to next page)(continued to next page)

(continued to next page)

Componentvideooutputs(DVD)

Some TVs or monitors are equipped with component video inputs.

UsingtheAudiocable(notsupplied),connecttheleft/rightAUDIOOUTjacksonyourUnittotheleft/rightAUDIOINjacks

on your TV and the Component video cable (not supplied), connect the Green plug YVIDEO OUT jack on your Unit

to YVIDEOINjackon your TV, the Blue plug PB/CBVIDEO OUT jackon your Unitto PB/CBVIDEOIN jack on your TV

and the Red plug PR/CRVIDEO OUT jack on your Unit to PR/CRVIDEO IN jack on your TV to view the higher quality

picture playback.

Progressiveoutputs(DVD)

Some TVs or monitors are equipped with component video inputs that are capable of reproducing a progressively

scanned video signal.

UsingtheAudiocable(notsupplied),connecttheleft/rightAUDIOOUTjacksonyourUnittotheleft/rightAUDIOINjacks

on your TV and the Component video cable (not supplied), connect the Green plug YVIDEO OUT jack on your Unit

to YVIDEOINjackon your TV, the Blue plug PB/CBVIDEO OUT jackon your Unitto PB/CBVIDEOIN jack on your TV

andtheRedplugPR/CRVIDEOOUTjackonyourUnittoPR/CRVIDEOINjackonyourTVtoenjoyhighestqualitypicture

with less flicker.

Press the SETUP button and select Video Output to YUV (see page 28). Connect the component video cable to TV,

press the P. SCAN button on the remote control when DVD is stopped. " P. SCAN" will be shown. You can select

the output signal for better picture quality.

Notes:

• When progressive output is activated, no video signal output from S-video and RCA (CVBS) video jacks.

• Make sure your TV supports progressive scan component video signal, press the P. SCAN button repeatedly

until "CVBS" display for going back CVBS video signal.

Notes :

• Connect the Unit to your TV directly. If you connect the Unit through a VCR, the playback picture will be distorted

because DVD discs are copy protected.

• When you connect the Unit to other equipment, be sure to turn off the power and unplug all of the equipment from

the wall outlet before making any connection.

• Refer to the instruction manual of the connected equipment as well.

To wall

outlet

Component video cable

(not supplied)

To VIDEO IN

VIDEO

OUT

VIDEO

OUT

P/C

VIDEO

OUT

P/C

To VIDEO IN

Audio cable (not supplied)

(red)

(white)

CoaxialAntennaJack

Some TVs do not have an RCA or S-Video jack, they only have a coaxial antenna jack. In order to connect this Unit to

these TVs, you must purchase an RF modulator (available in the Audio/Video department of most electronics retailers

or at http://www.1800customersupport.com) and follow the instructions included with it.

- 12 -

Setup

Notes :

• WhenyouconnecttheUnittoother

equipment,besuretoturnoffthepowerandunplugalloftheequipmentfromthewalloutletbeforemakinganyconnection.

• Iftheexternalequipmentisatelevisionandthisaudiosystemisclosedtoit,youmayexperienceinterferenceifthetunerfunction

isselectedwhilethetelevisionisworking.

• Ifyouhavea stereoVCR, makesure you set it in stereo mode.

• Duetocopyrightprotection,DVDmoviescannotbecopied.IfyoucopyaDVDmovieontoavideotape,theresultingcopywillbe

unclear,with poor soundquality.This isNOTcausedbyadefectiveDVD system.

• Refertotheinstructionmanualoftheconnectedequipmentaswell.

B. Connecting a VCR

1. UsingthesuppliedAudio/Videocable,

connectthe yellowplugfromVIDEO

OUTjackon yourUnit toVIDEO IN

jackonyourTV,connecttheleft/right

AUDIO OUT jacks on your Unit to

left/rightAUDIOINjackson yourTV.

Ifyou wantthesoundcomefromthe

speakersoftheMainUnit,youneed

not to connect the left/right AUDIO

OUTjacksfromtheMainUnittoyour

TV.

2. UsingtheVideocable(notsupplied),

connecttheVIDEOIN(VCR)jackon

yourUnittoVIDEOOUTjackonyour

VCR.

3. UsingtheAudiocable(notsupplied),

connecttheleft/rightAUDIOINjacks

onyourUnittotheAUDIOOUTjacks

onyourVCR.

Analogue connection

Usingthe Audio cable(not supplied),

connectthe left/rightAUDIOOUTjack

on your Unit to the AUDIO IN jack on

theother analogue equipment.

Digital connection

UsingtheCoaxial DigitalAudio cable

(not supplied), connect the DIGITAL

AUDIO OUT on your Unit to the

DIGITAL AUDIO IN jack on your

anotherequipment.

Listening to another audio

equipment

1. Turn on the Unit.

2. Turnon youraudioequipment and

followtheinstructionsincludedwith

it to select the AUDIO IN or

DIGITAL IN function.

C.Connecting another source

Watching aVideotape

1. Turn on the Unit, use the FUNCTION button on the remote control or the front panel to select "AV IN".

2. Turnon yourTV andfollow theinstructions included withit toselect theVIDEO inputwhich correspondsto theVIDEO INjack

that is connected to the Unit.

3. Turn on theVCR and followthe instructionsincluded withit to playthe videotape.

Notes:

• IfyouhaveamonoVCR,thevolumelevelfromthespeakerswillbelow.Toavoidthis,connecttheleft/rightaudiooutfromtheUnit

totheleft/rightaudioinputsonyourTV using the supplied A/V cable.

• S-videoandComponentVideo jacks(Y, PB, PR)is onlyforDVD.

To wall

outlet

Audio/Video cable

(supplied)

(red)(yellow) (white)

(red)

(yellow)

(white)

Audio cable (not supplied)

(red)

(white)

Video cable (not supplied)

(yellow)

To wall outlet

Audio cable

(not supplied)

Coaxial digital audio cable

(not supplied)

(red) (white)

(red)

(white)

Audio equipment with digital

audio input jack

Amplifier of

stereo system, etc.

(not included)

DIGITAL

CONNECTION

ANALOGUE

CONNECTION

- 13 -

Setup

(continued to next page)(continued to next page)

(continued to next page)

D.Connecting the speakers &

subwoofer

The speaker cords have been color-coded to

simplify connection. Just plug the POSITIVE

(+) and NEGATIVE (-) ends of each speaker

wire into the corresponding jacks on the rear

oftheUnit,matchingthecolortubeontheend

of the speaker wire to the color-coded

connector.

E. Positioning the speakers and subwoofer

CENTER

Place on the top of or

below the TV.

REAR SPEAKERS

Place right beside or slightly

behind your listening position,

and a little higher than your ears.

SUBWOOFER

Can be placed anywhere.

FRONT SPEAKERS

Place on both sides of the TV,

equal distances apart.

To wall outlet

FRONT (RIGHT) REAR (RIGHT)

SUBWOOFER

REAR (LEFT)

CENTER

FRONT (LEFT)

IMP. 6 ohm

RIGHT LEFT

IMP. 6 ohm

IM P. 3 ohm

FRONT FRONTREAR REAR

SUBWOOFER CENTER

- 14 -

Setup

Turning on the Unit and TV

1)Press the STANDBY/ON button to turn the Unit ON, or

2)Press the STANDBY /ON button on the remote control or the FUNCTION button or the PLAY button to turn on

the Unit while the Unit is in standby mode.

3)Turn on the TV by pressing its POWER button.

4)Select the channel on your TV corresponding to the VIDEO IN jack that the Unit is connected to. See TV User

guide for more information.

• If you have connected the Unit successfully, the DVD logo (start-up picture) will appear on your TV screen.

Power cord connection

• Make sure that all the components and speakers are connected correctly.

• To prevent electrical shock, match wide blade of plug to wide slot, fully insert.

• Be sure the AC power cord is disconnected and all functions are off before making connections.

• When you are not going to use the Unit for a long period of time, disconnect the power cord.

Mounting rear surround speakers

1) Mark the correct mounting position on the wall.

2) Insert a fixing screw(s) at the marked position on the wall.

3) Align the slot hole(s) of the speaker over the screw and pull the speaker downward until it is firmly hooked.

Need More Help?

DO NOT RETURN THIS TO THE STORE

Please call Customer Service at 1-800-252-6123

or visit online help at http://www.1800customersupport.com

- 15 -

To adjust the surround sound balance while Dolby Digital and Dolby Pro Logic II

decoding is in effect

Use the remote control to make the following changes to speaker balance:

Front speaker (left)

• Press the SOUND button repeatedly to display , then press the or CURSOR button to adjust the
