Dolce Vanity Mirror User manual

Bulletin NO.: 164053-00
MADE IN VIETNAM
IMPORTANT! Please keep these instructions for future reference. Please read
these instructions before assembly and use of this product.
Adult assembly is required.
Allen wrench (included) required for assembly.
Product features and decorations may vary from illustrations.
Do not use power drills or drivers.
Phillips Head Screwdriver (Not included) required for assembly.
Vanity Hutch
Vanity Mirror

Page 2
Part List
A. Hutch X 1 B. Support Rail X 2
C. Left Mirror X 1 D. Middle Mirror X 1 E. Right Mirror X 1

Part List
HARDWARE AND TOOL DIAGRAM
1-1/4" Allen head bolt X 10
FFlat Washer X 10
G
Spring Washer X 10
HIAllen Wrench X 1
Page 3

Page 4
Furniture Care Instructions
Room Climate Control
Wood, when first cut contains more than 50 percent water. When it is prepared for furniture
construction it is placed in a Kiln and the moisture content is brought down to 8 to 10 percent. Wood
is porous and responds to its environment. If the room has high humidity it will absorb it and expand
and if the humidity is low it will lose moisture and shrink.
It is important that the humidity levels in the room be controlled from extremes of too much
humidity or too little. Furniture should not be placed close to air-conditioning outlets, fireplaces,
radiators, space heaters, humidifiers or dehumidifiers. Exposure to extreme variations of
temperature and humidity can damage any fine wood product.
The Ideal Environment for Fine Furniture
Fine wood furniture will have fewer problems when its environment is controlled at a temperature
between 65 and 75 degrees and a relative humidity between 35 and 40 percent. Wood placed in an
environment outside of those limits can and will shrink or expand and may develop some small
cracks which are not material or structural defects.
Sticking Doors and Drawers
With minor changes in temperature and humidity, doors and drawers may swell and be
difficult to open or close. Tolerances have been built into the units but extreme conditions may still
cause sticking. This will adjust back to normal over time but until it does, consider using a
dehumidifier or rub candle wax or paraffin on the sides that stick.
Avoid Direct Sunlight
Keep the furniture out of direct sunlight. Ultraviolet rays will fade colors and in some cases
darken them. It can also cause crazing or hair line cracks in the finish. White finishes will yellow
naturally over time and exposure to direct sunlight will hasten this natural process along with some
woods darkening naturally over time; this is not considered to be a quality defect.
Proper Storage
If you need to put your furniture in storage for any period of time, do not place furniture in a damp
basement or hot dry attic. Allow air movement around the furniture and do not stack anything on it.
In General
Protect furniture surface from hot or extremely cold items.
Use coasters under hot or cold beverages.
Do not use synthetic fabric under accessories or lamps.
Protect tops from pens, markers and crayons.
Oils from potpourri and other scented items can damage the furniture finish.
Do not drag items across the surface of the furniture.
Allow the surface to breath by rotating your accessories and lamps.
Do not over polish the furniture, do it only two or three times a year. Over polishing can
distort the natural finish of the product.
Do not wax the furniture as wax build up can destroy the natural finish of the product.
When moving furniture always lift the unit. Do not push or drag it to avoid damage to the legs.
Keep the furniture level so doors and drawers open and close freely.
Clean with a damp, not wet, cloth. Use only a mild soap. Do not use abrasive cleaners.

Page 5
STOP
IF YOU EXPERIENCE ANY
ISSUES WITH THIS PRODUCT
BEFORE YOU
RETURN THIS TO
THE RETAILER
PLEASE FOLLOW
PROCEDURES ON THE
BACK PAGE

OPTION 1: Assembly Step 1
Step 1:
Place the Hutch (A) onto the top of the Vanity Desk.
Turn the brackets down over the edge of the dresser (FIGURE 1).
Screw the Brackets into the Vanity Desk using a Phillips Head Screwdriver.
A. Hutch X 1
Remove one screw and
flip the bracket down.
A
Vanity Desk
A
Page 6
FIGURE 1

OPTION 1: Assembly Step 2
1- 1/4" Allen head bolt X 4
FFlat Washer X 4
G
Spring Washer X 4
HIAllen Wrench X 1
B. Support Rail X 2
G
H
F
I
B
B
A
Vanity Desk
Step 2:
- Attach Support Rails (B) to Vanity Desk as shown in large Diagram below.
- Insert Bolts (F) through Spring Washers (H), Flat Washers (G), holes
on Support Rails (B) into inset nuts on back panel of Vanity Desk.
Tighten all bolts with Allen Wrench (I).
Page 7

OPTION 1: Assembly Step 3
Step 3:
- Attach Middle Mirror (D) to Support Rails (B) as shown in large Diagram below.
- Insert bolts (F) through Spring Washers (H), Flat Washers (G), holes
on Support Rails (B), into inset nuts on back panel of Middle Mirror (D).
Tighten all bolts with Allen Wrench (I).
I
G
H
F
1- 1/4" Allen head bolt X 4
FFlat Washer X 4
G
Spring Washer X 4
HIAllen Wrench X 1
D. Middle Mirror X 1
D
A
Vanity Desk
B
B
Page 8

OPTION 1: Assembly Step 4
Step 4:
- Attach Left Mirror (C), and Right Mirror (E) to Middle Mirror (D)
as shown in large Diagram and (FIGURE 4).
C. Left Mirror X 1 E. Right Mirror X 1
D
E
D
E
C
OPTION 1
Page 9
Vanity Desk
A
FIGURE 4

OPTION 2: Assembly Step 1
Step 1:
- Attach Support Rails (B) to Vanity Desk as shown in large Diagram below.
- Insert Bolts (F) through Spring Washers (H), Flat Washers (G), holes
on Support Rails (B) into inset nuts on back panel of Vanity Desk.
Tighten all bolts with Allen Wrench (I).
1- 1/4" Allen head bolt X 4
FFlat Washer X 4
G
Spring Washer X 4
HIAllen Wrench X 1
B. Support Rail X 2
B
B
G
H
F
I
Page 10
Vanity Desk

OPTION 2: Assembly Step 2
Step 2:
- Attach Middle Mirror (D) to Support Rails (B) as shown in large Diagram below.
- Insert Bolts (F) through Spring Washers (H), Flat Washers (G), holes
on Support Rails (B) into inset nuts on back panel of Middle Mirror (D).
Tighten all bolts with Allen Wrench (I).
1- 1/4" Allen head bolt X 6
FFlat Washer X 6
G
Spring Washer X 6
HIAllen Wrench X 1
G
H
F
B
D
D. Middle Mirror X 1
I
Page 11
Vanity Desk

OPTION 2: Assembly Step 3
Step 3:
- Attach Left Mirror (C) and Right Mirror (E) to Middle Mirror (D) as shown
in large Diagram and (FIGURE 3).
C. Left Mirror X 1 E. Right Mirror X 1
D
E
C
D
E
OPTION 2
Page 12
Vanity Desk
FIGURE 3

Page 13
Most inquiries can be answered by visiting our website. There, you can
order parts, find assembly instructions, and get answers to frequently
asked questions on all of our brands.
You can also email us. In order for us to provide you with the best service possible, please
include the following information in your email:
1. Your Name
2. Address
3. Phone Number
4. Item Number and description of your product
5. PO#
6. Production Date
All product information will be on the product label located on the back of
all dressers and other furniture, and on either the inside bottom of the headboard, crib
ends, or stabilizer bar of your crib, depending on which model you have.
Someone will contact you via e-mail or phone to help you with your issues.
If you do not have internet access, you can fax your information to us.
If you do not have internet or fax access, please call us at our toll free number.
Be sure to have all of the above information ready to give to your Customer Service Specialist.
Manufactured for and distributed by Bivona & Company®, LLC
125 Jackson Avenue Suite 1, Edison, NJ 08837.
MADE IN VIETNAM
Product Assistance Procedures
Procedures to follow should you have any questions:
Contact
You have purchased a quality piece of furniture. Our International team has spent
many hours designing and engineering this piece and packaging to ensure you will
be satisfied with your purchase. But if for any reason you need help with your
purchase please contact us at any time.
Bivona & Company®, LLC
125 Jackson Avenue Suite 1,
Edison, NJ 08837
Toll Free: 1-888-963-8125;
Fax: [phone]
Website: www.bivonaco.com
Email: [email protected]
U.S.A
