Donaldson Torit TRB-1 User manual

Torit Radial Blade Fan
TRB-1 to TRB-10 (60 and 50 Cycle)
Installation and Operation Manual
Installation, Operation and Service Manual
IOM AG8130401 (ENG)
Revision 3
English
Master Language
This manual contains specic precautions related to worker safety. The hazard alert image denotes safety
related instructions and warnings in this manual. DO NOT install, operate, or perform maintenance on this
collector until you have read and understood the instructions, precautions and warnings contained within this
manual.

Donaldson Company, Inc.
i
The Safety Alert Symbol indicates a hazardous situation which, if not avoided could
result in death or serious injury. Obey all safety messages following this symbol to
avoid possible injury or death. The possible hazards are explained in the associated
text messages.
NOTICE indicates a potential situation or practice which is not expected to
result in personal injury, but which if not avoided, may result in damage to
equipment.
This manual has been supplied to assist with the installation, operation and maintenance for
the collector purchased. Please read the manual before installing, operating, or performing
maintenance on the collector as it contains specic precautions for worker safety. It is the
owner’s responsibility to ensure that this manual is available for use by installers, operators and
maintenance personnel that will be working with this collector. This manual is the property of the
owner and should be left with the collector when installation has been completed. DO NOT operate
this collector until you have read and understood the instructions and warnings located in this
manual.
For additional copies of this manual, contact Donaldson Torit.
IMPORTANT NOTES

Torit Radial Blade Fan TRB-1 through TRB-10
ii
Contents
IMPORTANT NOTES .......................................................................................................................................................................i
1 Safety Communication ..............................................................................................................................................................1
2 Product Description ...................................................................................................................................................................3
3 Operation ...................................................................................................................................................................................3
4 Product Service .........................................................................................................................................................................4
Motor Maintenance .............................................................................................................................................................5
Grease Motors ....................................................................................................................................................................5
Wheel Balance ...................................................................................................................................................................5
Vibration .............................................................................................................................................................................5
Troubleshooting ..................................................................................................................................................................6
Appendix A - Installation ..................................................................................................................................................................8
Installation ..........................................................................................................................................................................9
Lifting Information .............................................................................................................................................................10
Storage .............................................................................................................................................................................10
Electrical Wiring ................................................................................................................................................................10
Fan Installation .................................................................................................................................................................11
Motor Drain Hole Orientation (for Side Mounted Fans) .............................................................................................13
TBI to TRB Fan Adapter Conversion Installation .......................................................................................................13
Side Mount Fan and Adaptor Installation (for MB collectors) ....................................................................................14
Duct Connections and Support .........................................................................................................................................15
Top Mount Chamber Silencer ...........................................................................................................................................15
Start-up / Commissioning .................................................................................................................................................16
Decommissioning .............................................................................................................................................................17
Product Information ..........................................................................................................................................................18
Service Notes ...................................................................................................................................................................19
Donaldson Industrial Air Filtration Warranty ..............................................................................................................................20

1
Donaldson Company, Inc.
Rotating blades can cause serious injury. Operate equipment only when all guards are correctly and securely in
place.
Turn all power off and lock out all power before performing service or maintenance work. It is not unusual for the
equipment to be operated from a remote location, so equipment may start or stop unexpectedly.
Keep body, hands and foreign objects away from the inlet, the outlet and the other moving parts of the fan such as
shafts, belts and pulleys.
This fan has moving parts that can cause serious bodily injury. Before operating or starting maintenance, read the
installation and maintenance instructions provided with this manual and AMCA Publication 410 “Recommended
Safety Practices for Air Moving Devices.”
Improper operation of dust collectors and/or dust control systems may contribute to conditions in a work area or
facility which could result in severe personal injury, and product or property damage. All dust collection equipment
should be used only for its intended purpose and should be properly selected and sized for its intended use.
Process owners have important responsibilities relating to identifying and addressing potential hazards in their
processes. When the potential for handling combustible dust exists within a process the process owner should
include combustion hazards in their risk management activities and should comply with applicable codes and
standards related to combustible dust.
Electrical installation must be performed by a qualied electrician.
This equipment is not designed to support site ducts, piping, or electrical services. All ducts, piping, or electrical
services must be adequately supported to prevent injury and/or property damage.
Site selection must account for wind, seismic zone, and other load conditions.
Equipment may reach peak sound pressure levels above 80 dB (A). Noise levels should be considered when
selecting collector location.
Most dusts present safety and health hazards that require precautions. Wear eye, respiratory, head and other
protection equipment suitable for the type of dust.
Some components may be heavier than they appear. Use appropriate lifting methods to avoid personal injury and/or
property damage.
1 Safety Communication

2
Combustible Dust Hazards
Among other considerations, the current NFPA standards require owners whose processes involve potentially combustible
materials to have a current Dust Hazard Analysis, which can serve as the foundation for their process hazard mitigation strategy.
Mitigation may include but is not limited to:
• Prevention of all ignition sources from entering any dust collection equipment.
• Selection and implementation of re and explosion mitigation, suppression, and isolation strategies appropriate for the
risks in their process.
• Development and use of work practices to maintain safe operating conditions, and to ensure combustible dust does not
accumulate within their plant or process equipment.
Donaldson designs, manufactures, and sells industrial air ltration products for a wide variety of applications. Some applications
may include processes or materials with inherent re and explosion hazards. Donaldson is neither an expert nor a certied
consultant in re, spark, or explosion detection, suppression, or control. Donaldson does not provide engineering consulting
services related to process or dust hazard analyses, or code and standard compliance. Complying with applicable codes and
standards and managing the risks associated with the process or materials remains the responsibility of the process owner/
operator. Donaldson may provide referrals to consultants, suppliers of equipment or services related to the detection and/
or mitigation of sparks, res and/or explosions, but Donaldson does not assume responsibility for any such referrals, nor does
Donaldson assume any liability for the tness of a mitigation strategy or product for a particular installation or application. The
process owner’s nal selection of dust collectors and risk mitigation strategies should be based on the outcome of a Dust Hazard /
Process Hazard Analysis performed by the process owner. Although early engagement of a dust collector supplier provides helpful
insights on the availability and features of various products, process owners should consult with a combustible dust expert and/or a
process safety expert before making actual product and mitigation strategy selections.
Donaldson recommends that all industrial air ltration system designs be reviewed and approved by an expert consultant who is
responsible for the integrity of the system design and compliance with applicable codes and standards. It is the process owner’s
responsibility to understand the risks in their process and mitigate those risks in accordance with all applicable laws, regulations
and standards, including those published by the NFPA. Donaldson also recommends that proper maintenance and housekeeping
procedures and work practices be evaluated, developed, and followed to maintain any industrial air ltration products in safe
operating condition.
Many factors beyond the control of Donaldson can affect the use and performance of Donaldson products in a particular
application, including the conditions under which the product is used. Since these factors are uniquely within the user’s knowledge
and control, it is essential the user evaluate the Donaldson products to determine whether the product is t for the particular
purpose and suitable for the user’s application. All products, product specications, and data (airow, capacity, dimensions, or
availability) are subject to change without notice, and may vary by region or country.
Torit Radial Blade Fan TRB-1 through TRB-10

3
Donaldson Company, Inc.
Torit Radial Blade (TRB) Fans provide a convenient, cost-effective method of integrating a fan with a Donaldson®Torit® dust
collector. The TRB mounts directly to the clean-air outlet of the dust collector, eliminating costly transition ducts, and reducing the
footprint of the system.
The TRB Fans feature a radial blade fan wheel which provides high static pressure. It also has direct drive operation to eliminate
maintenance of fan bearings and belts. TRB Fans have computer balanced fan and motor assemblies to ensure vibration-free
operation. When mounted to a Donaldson Torit Dust collector, the fan is designed to pull dusty air through the collector to be
ltered. Cleaned air then exits the collector via the outlet of the TRB Fan.
2 Product Description
Electrical work during installation, service or maintenance must be performed by a qualied electrician and comply
with all applicable national and local codes.
Turn all power off and lock out all power before performing service or maintenance work.
Check that the collector is clear and free of all debris before starting.
Do not install in classied hazardous atmospheres without an enclosure rated for the application.
3 Operation
The use of a damper or variable frequency drive (VFD) is required to control airow through the collector.
Lack of a control damper or VFD will shorten lter life.
When a variable frequency drive (VFD) is used to control fan operation precautions should be taken to eliminate or reduce any
shaft currents which may be imposed on the motor by the VFD as stated per NEMA Mg-1. Part 31.

Torit Radial Blade Fan TRB-1 through TRB-10
4
LOCK-OUT all energy sources prior to performing any service or maintenance on the equipment.
Electrical service or maintenance work must be performed by a qualied electrician and comply with all applicable
national and local codes.
Rotating blades can cause serious injury. Operate equipment only when all guards are correctly and securely in
place.
Turn all power off and lock out all power before performing service or maintenance work. It is not unusual for the
equipment to be operated from a remote location, so equipment may start or stop unexpectedly.
4 Product Service
Donaldson Torit TRB fans are manufactured to high standards with quality materials and components. Proper maintenance will
ensure a long and trouble-free service life.
The key to good fan maintenance is regular and systematic inspection of all fan parts. Inspection frequency is determined by the
severity of the application and local conditions. Strict adherence to an inspection schedule is essential.
Regular fan maintenance should include the following:
Check the fan wheel for any wear or corrosion, as either can cause catastrophic failures. Check also for
the build-up of material which could cause unbalance resulting in vibration, bearing wear and serious
safety hazards. Clean or replace the wheel as required.
Lubricate the bearings, but do not over lubricate.
Periodically inspect the shaft for dirt buildup, corrosion and signs of excess stress or fatigue.
During any routine maintenance, all setscrews and bolts should be checked for tightness. See Torque
Value Table.
Specically for side mounted fans (motor horizontal) conrm the motor drain hole will be oriented facing down in the fan installed
orientation. If the motor orientation in the TBI fan as-received condition will not have the motor drain hole facing down when
installed in the desired side orientation (i.e. forward blast, up blast, aft blast) then:
1. Unbolt the drive plate (with the fan wheel and motor still attached).
2. Rotate the fan wheel/motor/drive plate assembly on the fan case such that the motor drain hole will face downward when the
fan is installed in the desired side mount orientation.
3. Re-bolt the fan wheel/motor/drive plate assembly to the fan case.
Note that the fan wheel should remain attached to the motor shaft and the motor should remain bolted to the drive plate and the
wheel/motor/drive plate assembly should be rotated as a single assembly.
When the fan is mounted to the collector in the desired side mount orientation conrm that the motor drain hole is facing
downward.
Failure to position the motor drain hole facing downward in the installed fan position may result in damage
to the motor.

5
Donaldson Company, Inc.
Motor Maintenance
TRB Fans typically use motors with sealed bearings that are permanently lubricated for the life of the motor, but other types of
motors may have been selected for your fan.
ExxonMobil Polyrex™ EM is a trademark of Exxon Mobil Corporation
Vibration
The fan blower wheel should be periodically checked for material build-up and/or erosion. If material has built up on
any parts of the wheel, it must be removed and cleaned before it is put back into service.
If any parts of the wheel have been eroded, the wheel must be replaced. Failure to perform this inspection can cause
excessive vibration that will damage the fan blower and/or motor bearings. When vibration becomes excessive, it will
lead to complete fan blower failure that can result in severe personal injury and/or property damage.
The user must determine the frequency of this inspection based on the actual circumstances of their operation, but
check the vibration readings should never exceed a 12 month period.
The fan blower was balanced at the factory to comply with ANSI/AMCA Standard 204-05, Category BV-2. However, rough handling
in shipment and/or erection, weak and/or non-rigid foundations and misalignment may cause a vibration problem after installation.
After installation, the vibration levels should be checked by personnel experienced with vibration analysis and vibration analysis
equipment.
Note: The fan blower should not be operated if the vibration velocity of the fan exceeds 0.50 inches per second, lter out,
with the blower rigidly mounted.
Vibration readings for direct driven fan blowers should be taken on the motor at the top, sides, and end.
Grease Motors
Use the following steps for greaseable motors only:
1. Inspect the motor at approximately every 500 hours of operation or every 3 months, whichever occurs rst.
2. Keep the motor clean and the ventilation openings clear. If the motor is not properly ventilated overheating can occur.
3. Use an electrical insulation tester to periodically ensure that the integrity of the winding insulation has been maintained.
Investigate any signicant drop in resistance.
4. Grease the motor bearings using a high grade bearing grease. For standard service conditions ExxonMobil Polyrex™ EM
grease is recommended.
Under standard conditions, grease every 5,500 hours. In severe dirt and abrasive dust conditions, grease every 2750 hours.
Under extreme conditions, such as an environment with iron dust, grease every 550 hours.
Wheel Balance
Airstreams containing particulate or chemicals can cause abrasion or corrosion of the fan parts. This is often uneven and can lead
to wheel imbalance over time. When such wear is discovered, a decision must be made to rebalance or replace the wheel.
The soundness of all parts should be determined making sure there is no hidden structural damage. The airstream components
should also be cleaned to remove any build-up of foreign material. Specialized equipment can be used to rebalance a cleaned
wheel that is considered structurally sound.
Balance weights should be rigidly attached at a point that will not interfere with the housing nor disrupt airow.

Torit Radial Blade Fan TRB-1 through TRB-10
6
Problem Probable Cause Remedy
Fan blower and motor do
not start
Improper motor wire size Rewire using the correct wire gauge as specied by
national and local codes.
Not wired correctly Check and correct motor wiring for supply voltage. See
motor manufacturer's wiring diagram. Follow wiring
diagram and the National Electric Code.
Collector not wired for available
voltage
Correct wiring for proper supply voltage.
Input circuit down Check power supply to motor circuit on all leads.
Electrical supply circuit down Check power supply circuit for proper voltage. Check for
fuse or circuit breaker fault. Replace as necessary.
Damaged motor Replace damaged motor.
Fan blower and motor
start, but do not stay
running
Incorrect motor starter installed Check for proper motor starter and replace if necessary.
Access doors are open or not
closed tight
Close and tighten access doors. See Filter Installation.
Hopper discharge open Check that dust container is installed and properly sealed.
Damper control not adjusted
properly
Check airow in duct. Adjust damper control until proper
airow is achieved and the blower motor’s amp draw is
within the manufacturer’s rated amps.
Electrical circuit overload Check that the power supply circuit has sufcient power to
run all equipment.
Insu󰀩cient airow Fan rotation backwards Proper fan rotation is clockwise when viewed from the
motor side or counterclockwise when viewed through the
inlet cone. See Preliminary Start-Up Check.
Access doors open or not closed
tight
Check that all access doors are in place and secured.
Check that the hopper discharge opening is sealed and
that dust container is installed correctly.
Fan exhaust area restricted Check fan exhaust area for obstructions. Remove material
or debris. Adjust damper ow control.
Filters need replacement Remove and replace using genuine Donaldson
replacement lters. See Filter Replacement.
Excessive vibration Loose mounting bolts or set screws Tighten loose bolts or set screws.
Misalignment or excessive wear of
wheel
Align wheel and balance fan.
Misaligned or unbalanced motor Balance fan.
Bent shaft due to mishandling or
material impact
Replace motor with bent shaft and rebalance fan.
Troubleshooting

7
Donaldson Company, Inc.
Problem Probable Cause Remedy
Excessive vibration Externally transmitted vibration Isolate collector from external vibration.
Accumulation of foreign material on
the wheel
Clean the wheel.
Excessive system pressure or
restriction of airow due to closed
dampers
Open dampers far enough for fan to operate in stable ow
regime.
Inadequate performance Fan running too slowly Check power frequency against fan motor design
frequency.
Fan wheel rotating in wrong
direction or installed backwards on
shaft
Proper fan rotation is clockwise from the top of the fan.
The fan can be viewed through the back of the motor.
Poor system design, closed
dampers, air leaks or clogged lters
Check system for damper positions leak points. Check
lter Delta P.
Sharp deection of airstream at fan
outlet
Do not place fan discharge next to a wall.
Missing discharge ttings Install discharge ttings.
Excessive noise Fan operating near “stall” due
to incorrect system design or
installation
Correct system or replace with correctly sized fan.
Vibration originating elsewhere in
the system
Vibration isolate collector from the system.
Loose accessories or components Tighten accessories or components.

Torit Radial Blade Fan TRB-1 through TRB-10
8
Appendix A - Installation

9
Donaldson Company, Inc.
Installation
Location and Site Selection
Electrical Installation (including bonding and grounding of the collector) must be performed by a qualied electrician.
This equipment is not designed to support site ducts, piping, or electrical services. All ducts, piping, or electrical
services must be adequately supported to prevent injury and/or property damage.
Do not install in classied hazardous atmospheres without an enclosure rated for the application.
Service must be performed by trained and qualied maintenance personnel.
Turn all power off and lock out all power before performing service or maintenance work. It is not unusual for the
equipment to be operated from a remote location, so equipment may start or stop unexpectedly.
Rotating blades can cause serious injury. Operate equipment only when all guards are correctly and securely in
place,
Codes may regulate recirculating ltered air in your facility. Consult with the appropriate authorities having jurisdiction
to ensure compliance with all national and local codes regarding recirculating ltered air.
Equipment location must conform to all codes and standards, should be suitable for the type of dust being handled and should
ensure easy access for service and utility connections. Site selection must account for wind, seismic zone and other load
conditions.
Follow industry practice relative to clean air velocity into a fan.
Unloading and Positioning
Equipment should be lifted only by qualied crane or fork truck operators.
Failure to lift the equipment correctly can result in severe personal injury and/or property damage.
1. Remove any crates or shipping straps.
2. Lift the packaged collector from transport container.
3. Inspect for any damage and/or missing parts and report to freight carrier.
4. Check for any hardware which may have become loose during shipment and tighten as necessary.
Delivery and Inspection
Upon arrival inspect equipment and report any damage to delivery carrier. File any damage claims with the delivery carrier.
Request a written inspection report from the Claims Inspector to substantiate all damage claims.
Compare the equipment received with the description of product ordered. Report any incomplete shipments to the delivery carrier
and your Donaldson Torit representative.
Turn the fan wheel by hand to see that it rotates freely and does not bind. If dampers are provided, check for free operation of all
moving parts.

Torit Radial Blade Fan TRB-1 through TRB-10
10
Storage
Check dampers for free operation and lubricate moving parts prior to storage. Inspect the stored fan periodically. Rotate the wheel
by hand every two weeks to redistribute grease on motor bearing parts.
Lifting Information
Failure to lift the equipment or sub-assemblies correctly can result in severe personal injury and/or property damage.
Only qualied crane or forklift operators should be allowed to lift equipment.
1. Use all lifting points provided.
2. Fans should be lifted by the base, mounting supports, or lifting points only. Never lift a fan by the wheel, shaft, motor, motor
bracket, housing inlet, outlet, or any fan part not designed for lifting.
3. Use clevis connectors, not hooks, on lifting slings.
4. Check the Specication Control drawing for weight and dimensions of the collector and components to ensure adequate crane
capacity.
5. Use drift pins to align holes in section anges during assembly.
Electrical installation, service, or maintenance work must be performed by a qualied electrician and comply with all
applicable national and local codes.
Turn all power off and lock out all power before performing service or maintenance work. It is not unusual for the
equipment to be operated from a remote location so equipment may start or stop unexpectedly.
Do not install in classied hazardous atmospheres without an enclosure rated for the application.
Electrical Wiring

11
Donaldson Company, Inc.
Set screws should never be used more than once. If the set
screws are loose, they must be replaced. Use only knurled, cup-
point screws with a nylon locking patch.
Do not allow the fan wheel to come loose from the motor as it may cause severe injury or property damage. To
ensure proper attachment of the fan wheel:
Tighten all setscrews in fan wheel.
Repeat after 8 hours of operation.
Repeat again after two weeks of operation.
Reference Torque Value Table.
For additional information, contact the motor
manufacturer.
TRB fan wheels are dynamically balanced and assembled fans are tested at operating speeds to check the entire assembly for
conformance to vibration limits. All fans must be adequately supported for smooth operation.
Safe operating speed is a function of system temperature and wheel design. TRB fans should not be operated above 3,600 RPM.
Torque Values for TRB
Setscrew Size
and Number of
Threads/Inch
Hex Wrench
Size
(across ats)
Carbon Steel
Setscrew
Torque
In. In. Lb. - In.
1/4-20 1/8 65
5/16-18 5/32 165
3/8-16 3/16 228
7/16-14 7/32 348
1/2-13 1/4 504
5/8-11 5/16 1104
Fan Installation
Rotating blades can cause serious injury. Operate equipment only when all guards are correctly and securely in
place.
Electrical installation, service, or maintenance work must be performed by a qualied electrician and comply with all
applicable national and local codes.
Turn all power OFF and lock out all power before performing service or maintenance work. It is not unusual for the
equipment to be operated from a remote location so equipment may start or stop unexpectedly.
Do not operate in classied hazardous atmospheres without an enclosure rated for the application.
Check that the equipment is clear and free of all debris before starting.
Mounting a fan blower on the side of a collector requires a side power adapter to support the weight of the fan
blower.
Poorly installed fan blowers may separate from the collector resulting in personal injury and/or property damage.
Do not look into fan outlet to determine rotation. Material may unexpectedly be discharged from the fan. View the fan
rotation through the back of the motor.
Do not interchange a power lead with the ground wire. Severe personal injury and/or property damage may result.
When mounting a fan in an outdoor or high humidity environment, mount the motor with the motor drain
holes facing down.
If the fan rotation is reversed, correct the rotation.
To reverse rotation, three-phase power supply: Switch any two leads on the motor junction box.
Do not interchange a power lead with the ground wire. Severe damage or personal injury may result.

Torit Radial Blade Fan TRB-1 through TRB-10
12
Top Mounted Fan Installation
fan housing
motor half
fan housing
inlet half
sealant
collector mounting
surface
hex bolt
at washer
at washer
hex nut
TRB fans are shipped assembled and partial disassembly is required before installing.
1. Disassemble the TRB by the blower housing fasteners and splitting the blower halves. The motor half contains the motor, half
of the blower housing, and the blower wheel.
2. Apply sealant to the collector toward the outside edge of the bolt pattern.
Note: For top-mounted TRB with a blast-gate style damper, install a spacer ring between the blower housing and the collector
to provide the necessary clearance for the damper installation.
3. Mount the inlet half of the blower housing (the one without the motor and fan wheel) to the collector using the hardware
supplied.
4. Reattach the motor half of the blower housing to the inlet half of the blower housing. Apply sealant around fan case ange to
inside of case ange bolt holes before reassembling.
5. Rotate the blower wheel after installation to ensure proper clearance between the inlet cone and the blower wheel.

13
Donaldson Company, Inc.
TBI to TRB Fan Adapter Conversion Installation
Motor Drain Hole Orientation (for Side Mounted Fans)
Motor drain holes must be oriented downward to prevent water accumulation in the motor and extend motor life.
1. Install TBI to TRB fan adapter conversion on collector fan mount.
2. Disconnect power supply.
3. Apply 1/4-in diameter rope-type sealant to the outside surface
of the fan adapter just outside the edge of the hole pattern.
4. Install the fan housing to the fan adapter using the hardware
supplied.
5. Install the motor and fan blower assembly to the fan housing
using the original fan hardware and new sealant.
6. Connect power supply to the motor. Turn the fan motor ON
then OFF to check motor rotation by referencing the rotation
arrow on the blower.
To change rotation on three phase collectors, turn power
supply OFF and switch any two leads on the output side of
the fan motor starter.
Do not interchange a power lead with the ground
wire. Severe personal injury and/or equipment
damage may result.
TBI to TRB Fan Adapter Conversion Installation
collector (reference)
sealant
TBI to TRB Fan Adapter
Specically for side mounted fans (motor horizontal) conrm the motor drain hole will be oriented facing down in the fan installed
orientation. Any reorientation of the fan motor is best accomplished while the fan is on the ground.
Install the fan with motor oriented for downward bleed hole orientation and conrm the motor bleed hole is at the bottom of the
motor.
If the motor orientation in the fan as-received condition will not have the motor drain hole facing down when installed in the desired
side orientation (i.e. forward blast, upblast, aft blast) then:
1. Unbolt the drive plate (with the fan wheel and motor still attached).
2. Rotate the fan wheel/motor/drive plate assembly on the fan case such that the motor drain hole will face downward when the
fan is installed in the desired side mount orientation.
3. Re-bolt the fan wheel/motor/drive plate assembly to the fan case.
Note that the fan wheel should remain attached to the motor shaft and the motor should remain bolted to the drive plate and the
wheel/motor/drive plate assembly should be rotated as a single assembly.
When the fan is mounted to the collector in the desired side mount orientation conrm that the motor drain hole is facing
downward.
Failure to position the motor drain hole facing downward in the installed fan position may result in damage to the
motor.

Torit Radial Blade Fan TRB-1 through TRB-10
14
Side Mount Fan and Adaptor Installation (for MB collectors)
The side mount fan adaptor allows a TRB/TBI fan blower to be mounted directly to the Modular Baghouse outlet on the rear of the
collector housing. It is not designed to be mounted on the outlet of the walk-in plenum. Field assembly of the adaptor is required.
This allows the adaptor to be assembled to the outlet location of the customer’s choosing.
Side Mount Adapter (for MB Collector)
MB collector (reference)
sealant
sealant
TBI Side Mount Fitting
TBI to TRB Fan Adapter
TRB Fan (Side Mount)
1. Remove the collector outlet cover.
2. Fasten the TBI to MB outlet adapter to the MB collector outlet using the hardware and sealant provided.
3. Mount the TBI to TRB conversion to the adaptor using the TBI to TRB Fan Conversion Installation Instructions.

15
Donaldson Company, Inc.
Duct Connections and Support
Any duct or attenuator/silencer should have independent support. Do not use the fan to support duct or attenuator/silencer.
Isolating the fan from duct with ex connections reduces transmission of vibration.
Fans handling hot gases must be rated for operation at the gas temperature and require expansion joints at both the inlet and
discharge to prevent excessive loads caused by thermal growth.
Top Mount Chamber Silencer
1. Apply sealant and attach the bottom panel to the collector
as described on the assembly drawing shipped with the
silencer using a combination of hardware removed from the
collector and supplied hardware.
2. Install the fan and motor assembly as described in this
manual.
3. Route rigid or exible conduit from the junction box on the
motor to the outside wall of the silencer to house wiring.
4. Install the top of the silencer and attach silencer to base
using the supplied hardware.
5. Loosen the wing nut on the damper and adjust from 30 to
50% closed.
Typical Top Mount Chamber Silencer
top mount
chamber silencer

Torit Radial Blade Fan TRB-1 through TRB-10
16
Start-up / Commissioning
1. If possible, carefully spin the fan blower wheel by hand to ensure it rotates freely and no rubbing or clicking noise is heard.
2. Check that all fan blower mounting ange and duct work hardware is tight.
3. Check all fan blower wheel set screws are tight per Torque Values table found in this manual.
4. Ensure any inspection doors in the duct work are securely bolted or locked.
5. Ensure all electrical power components are properly sized and matched for electrical system.
6. Check that all required guards are properly secured.
7. If fan blower is mounted on an elevated support structure, make sure the structure is welded at all joint connections and the
structure is properly braced to prevent “side sway”.
8. Close any dampers to minimize load on motor, especially on fans with high temperature construction. Never subject a “cold”
fan to a “hot” gas stream. If the fan motor will be handling “hot gasses” greater than 150°F (65°C) it is imperative that the fan
motor be subjected to a gradual rate of temperature increase, not to exceed 15°F/minute (8°C/minute). The same temperature
limits are also important when the fan motor is experiencing a drop in temperature until the temperature drops down to 150°F
(65°C). Only when the entire fan motor has reached an equilibrium temperature of 150°F (65°C) or less, should the power be
turned OFF.
9. Ensure the power source connections to the fan motor are per the motor manufacturer’s instructions.
10. Ensure the fan motor wheel is stationary prior to start-up. Starting a fan motor with a wheel that is rotating backwards can
cause wheel damage.
Do not look into fan outlet to determine rotation. View the fan rotation through the back of the motor.
Check that the exhaust plenum is free of tools or debris before checking blower/fan rotation.
Stand clear of exhaust to avoid personal injury.
Do not interchange a power lead with the ground wire. Severe damage or personal injury may result.
a. Turn fan motor ON momentarily (i.e. bump start) to check for proper fan rotation as noted on the fan housing.
11. If the fan rotation is reversed, correct the rotation.
To reverse rotation, three-phase power supply: switch any two leads on the motor junction box.
Do not interchange a power lead with a ground wire or severe personal injury and/or property damage may result.
Instruct all personnel on safe use and maintenance procedures.
Rotating blades can cause serious injury. Operate equipment only when all guards are correctly and securely in
place.
Electrical installation, service, or maintenance work must be performed by a qualied electrician and comply with all
applicable national and local codes.
Turn all power OFF and lock out all power before performing service or maintenance work. It is not unusual for the
equipment to be operated from a remote location so equipment may start or stop unexpectedly.
Do not operate in classied hazardous atmospheres without an enclosure rated for the application.
Check that the equipment is clear and free of all debris before starting.

17
Donaldson Company, Inc.
Once the equipment has reached the end of operational life it will need to be decommissioned.
During decommissioning, there is potential for exposure to the dust in the collector. Most dusts present safety and
health hazards that require precautions. Wear eye, respiratory, head, and other protection equipment suitable for the
type of dust when performing any decommissioning activities.
LOCK-OUT all energy sources prior to performing any decommissioning activities on the equipment.
Electrical service must be performed by a qualied electrician.
Disconnection of ducts must be performed by a qualied contractor.
1. Lock-Out all energy sources to the equipment.
2. Disconnect the equipment from the exterior of the collector.
3. Dispose of the equipment in accordance with all local codes and regulations.
Decommissioning
