Lumirama Signature 9403-03-WHT User manual

Questions, problems, missing parts? Before returning to your retailer, call our
customer service department at [phone], 8 a.m.- 4 p.m., EST, Monday-Friday.
Date Code Purchase Date Net Weight 9.7 lbs (4.4 kg)
For best and quickest service please provide date code. You can find the date code on the
carton, hand-held remote (inside of the battery compartment), receiver or ceiling canopy.
Ceiling fan light user manual
MODEL # 9403-03-WHT
MODEL # 9403-03-WHWD
MODEL # 9403-03-BKWD

Important Safety Instructions
Additional Safety Instructions
WARNING: To avoid fire, shock and serious personal injury, follow these instructions.
1. Read your owner’s manual and safety information before installing your new fan. Review the accompanying assembly
diagrams.
2. Before servicing or cleaning unit, switch power off at service panel and lock service panel disconnecting means to prevent
power from being switched on accidentally. When the service disconnecting means cannot be locked, securely fasten a
warning device, such as a tag, to the service panel.
3. Be careful of the fan and blades when cleaning, painting, or working near the fan. Always turn off the power to the ceiling
fan before servicing.
4. Do not insert anything into the fan blades while the fan is operating.
5. The appliance is not intended for use by young children or infirm persons without supervision. Young children should be
supervised to ensure that they do not play with the appliance.
WARNING: Mount to an outlet box marked acceptable for fan support of 22.7 kg (50 lbs) or Less.
WARNING: Do not operate this fan with a variable (Rheostat) wall controller or dimmer switch. Doing so could result in damage
to the ceiling fan's remote control unit.
1. To avoid possible shock, be sure electricity is turned off at the fuse box before wiring, and do not operate fan without
blades.
2. All wiring and installation procedures must satisfy National Electrical Codes and Local Codes. The ceiling fan must be
grounded as a precaution against possible electrical shock. Electrical installation should be made or approved by a
licensed electrician.
3. The fan base must be securely mounted and capable of reliably supporting at least 50 lbs. (fan and accessories not to
exceed 50 lbs. or 22.7 kgs.). See page 5 of owner’s manual for support requirements. Consult a qualified electrician if in
doubt.
4. The fan must be mounted with the fan blades at least 10 feet from the floor to prevent accidental contact with the ceiling fan.
5. Follow the recommended instructions for the proper method of wiring your ceiling fan. If you do not have adequate
electrical knowledge or experience, have your fan installed by licensed electrician.
6. Suitable for use with solid-state speed controls.
7. This fan is to be used in dry location only.
8. For supply connections, if the conductor of a fan is identified as a grounded conductor, then it should be connected to a
grounded conductor power supply. If the conductor of a fan is identified as an ungrounded conductor, then it should be
connected to an ungrounded conductor power supply. If the conductor of a fan is identified for equipment grounding, then it
should be connected to an equipment-grounding conductor.
CAUTION: Changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment.
WARNING: TO REDUCE THE RISK OF ELECTRIC SHOCK, THIS FAN MUST BE INSTALLED WITH A GENERAL USE,
ISOLATING WALL CONTROL/SWITCH.
WARNING: This product is designed to use only those parts supplied with this product and/or accessories designated
specifically for use with this product. Using parts and/or accessories not designated for use with this product could result in
personal injury or property damage.
WARNING: To reduce the risk of personal injury, do not bend the blade bracket (flange or blade holder) when installing the
brackets, balancing the blades, or cleaning the fan. Do not insert foreign objects in between rotating fan blades.

LIMITED FIVE YEARS WARRANTY
LUMIRAMA offers this five (5) years limited warranty to the original purchaser of this Lumirama fan
(the “Product”) from the original date of purchase. This limited warranty is not transferable. The
Product is a quality product which was made, inspected and selected with care. This limited
warranty does not apply: (1) to consumable parts; (2) to normal wear and tear; (3) if Product is used
for purposes other than residential use; (4) if Product is used for purposes other than those
determined by the manufacturer or by the distributor; (5) if damages are only aesthetics and do not
affect normal use of the Product; (6) if damages, defects or other problems arise from (a) abnormal
use of the Product, or (b) inadequate maintenance of the Product, or (c) faulty installation or
assembly, or (d) installation or assembly not in accordance with the installation guide or user
manual; or (e) a modification, repair or dismantle of the Product done by someone other than those
authorized by the retailer or the distributor, or (f) negligence by the purchaser, (g) an accident or a
case of force majeure, or (h) any event not caused by the Product itself. The manufacturer, the
distributor nor the retailer shall not, under any circumstances, be held responsible for any
extraordinary, special, indirect, accessory or consecutive damages resulting from the use or the
incapacity to use the Product. Their responsibility is limited to the price paid by the purchaser for
the Product, as indicated on the invoice.
If one or more parts were defective, the retailer shall replace or repair, in its sole discretion, the
defective part or parts without charge, under the following cumulative conditions. (1) The original
purchaser of the Product shall contact the retailer where the Product was purchased and shall
bring back the defective part or parts or the Product to the retailer, with the invoice as proof of
purchase and date of purchase of the Product. (2) The purchaser shall supply the Product
identification information (such as model number and serial number, if any). If the retailer chooses
to replace the defective part or parts, the replacement part or parts may be new or reconditioned,
equivalent to new parts.
This limited warranty does not limit, restrict or exclude the protection granted by any applicable
legal warranty.
The text of this limited warranty can be amended at any time.

4
This manual is designed to make it as easy as possible for you to assemble,
install, operate and maintain your ceiling fan
Before assembling your ceiling fan, refer to section on proper method of wiring your fan (page 9). If you think
you do not have enough wiring knowledge or experience, have your fan installed by a licensed electrician.
WARNING
!
Materials
iring outlet o and o connectors ust e of type
re uired y the local code he ini u wire would e a
conductor wire with ground
NOTE: Place the parts from the loose parts bags in a small
container to keep them from being lost. If any parts are
missing contact your local retailer.
Motor Assembly (1)
ne hillips head screwdriver
One stepladder
One wire stripper
One lade
screwdriver
Tools Needed for Assembly
(Not Included)
Hand-held Remote (1)
Wall Holder (1)
Screws (2)
Battery (1)
NOTE: If you are uncertain of part description, refer to exploded view illustration.
1. Check to see that you have received the following parts:
Do not install or use fan if any part is damaged or missing. This product is designed to use only those parts
supplied with this product and/or any accessories designated specifically for use with this product.
Substitution of parts or accessories not designated for use with this product could result in personal injury or
property damage.
Unpacking Instructions
For your convenience, check-off boxes are provided next to each step. As each step is completed, place a check
mark in the box. This will insure that all steps have been completed and will be helpful in finding your place should
you be interrupted.
MED LOW
HI OFF
6F22X
GB/T8897.2 -2013
9V
R
Flat Washer(1) Anchor (1)
Screw(1) Fastener(1) Lock Washer(1)
Safety cable parts kit
Machine Screw(2) Wood Screw(4)
Wire Connectors (4)
Wood Screw(1)
Hanger parts kit
Anchor (4)

5
Energy Efficient Use of Ceiling Fans
Using the Ceiling Fan Year Round
Electrical and Structural Requirements
CEILING
2" x 4"
CEILING JOIST
OUTLET BOX
Figure 1
Figure 2
2" x 4"
CEILING JOIST
CEILING OUTLET BOX
Your new ceiling fan will require a grounded electrical
supply line of 120 volts AC, 60 HZ, 15 Amp Circuit.
Electrical code requires use of a fan-rated outlet box to
support the extra weight and motion associated with a
ceiling fan. A fan-rated box will be labeled as such and
typically supports up to a 32kg (70lbs) ceiling fan. Fan-
Rated Outlet Boxes vary in ratings and design. Ensure
the ratings of your ceiling fan outlet box meet the
requirements for the ceiling fan being installed. Figure 1,
Figure 2 and Figure 3 depicts different structural
configurations that may be used for mounting the
outlet box.
Low-profile use (Figure 1)
A 13mm (1/2-in) deep pancake box is meant to be
screwed to a joist or block. It’s used if only one cable is
coming into the box.
Deep-profile use (Figure 2)
A 55mm (2-1/8-in.) deep box can be attached to
blocking (2" x 4") between joists or to the joist itself, and
is roomy enough to handle more than one cable.
Winter Season: Reverse the motor and operate the
ceiling fan at low speed in the counterclockwise direction.
This produces a gentle updraft, which forces warm air
near the ceiling down into the occupied space.
Remember to adjust your thermostat when using your
ceiling fan-additional energy and dollar savings could
be realized with this simple step!
Summer Season: Use the ceiling fan in the clockwise
direction. The airflow produced by the ceiling fan creates
a wind-chill effect, making you “feel” cooler. Select a fan
speed that provides a comfortable breeze, lower speeds
consume less energy.
Ceiling fan performance and energy savings rely
heavily on the proper installation and use of the ceiling
fan. Here are a few tips to ensure efficient product
performance.
Choosing the Appropriate Mounting Location
Ceiling fans should be installed, or mounted, in the
middle of the room and at least 2,15m (7 feet) from floor
to the blade and 45cm (18 inches) from wall to the
blade. If ceiling height allows, install the fan 2,5m - 3,0m
(10-12 feet) from floor to the blade for optimal airflow.
Consult your retailer for optional mounting accessories.
Turn Off When Not in the Room
Ceiling fans cool people, not rooms. If the room is
unoccupied, turn off the ceiling fan to save energy.

6
Electrical and Structural Requirements (Continued)
If your fan is to replace an existing light fixture, turn
electricity off at the main fuse box at this time and
remove the existing light fixture.
Turning off wall switch is not sufficient. To avoid
possible electrical shock, be sure electricity is
turned off at the main fuse box before wiring. All
wiring must be in accordance with National and
Local codes and the ceiling fan must be properly
grounded as a precaution against possible electrical
shock.
WARNING
To reduce the risk of fire, electrical shock, or
personal injury, mount fan to outlet box marked
acceptable for fan support of 22.7 kg (50 lbs)
minimum. Use screws supplied with outlet box.
Most outlet boxes commonly used for support of
light fixtures are not acceptable for fan support and
may need to be replaced. Consult a qualified
electrician if in doubt.
WARNING
Brace use (Figure 3)
Paired with a deep box, this hanger is meant to span
between two joists and takes the place of wooden
blocking.
To avoid fire or shock, follow all wiring instructions
carefully. Any electrical work not described in these
instructions should be done or approved by a
licensed electrician.
WARNING
Figure 3
CEILING JOIST
CEILING
OUTLET BOX
Do not operate this fan with a variable (Rheostat) wall
controller or dimmer switch. Doing so could result in
damage to the ceiling fan's remote control unit.
WARNING
Hanger release (Figure 4)
Release the hanger assembly from the ceiling
canopy by :
•taking out the two (2) screws from the round
holes on each side of the canopy;
•by loosen the two (2) remaining screws from
the "L-shaped" holes on each side of the
canopy.
Take out
the screw
Loosen the
screw
Hanger
assembly
Ceiling
Canopy
Figure 4

7
How to Hang Your Ceiling Fan
Figure 1
MAIN FUSE BOX
Figure 2
CEILING
FLOOR
NOTE: If you are not sure if the outlet box is grounded,
contact a licensed electrician for advice, as it must be
grounded for safe operation.
WARNING
To avoid possible fire or shock, be sure electricity
is turned off at the main fuse box before hanging.
(Figure 1)
WARNING
The fan must be hung with at least 2.15m (7’) of
clearance from floor to blades. (Figure 2)
1. Securely attach the hanger bracket to the outlet box
using the outlet box screws and washers supplied with
the outlet box. (Figure 3)
2. Secure each arm of the hanger by fixing them to the
ceiling with the help of the wood screws. If the screws
cannot be screwed directly in the wood structure of
your ceiling, use a gecko by drilling a 1/4” pilot hole
into the ceiling, inserts the gecko in the hole and
screws the screw into the gecko.
3.Attach the safety cable to ceiling. Use a wood
screw to securely fasten the safety cable directly to
the wood structure of the ceiling or by using the
gecko provided. Refer to Figure 4 for set-up and
installation of the safety cable (Figure 4)
WARNING
The wire should not be clamped between the hanger
and the ceiling.
Figure 3
NO LESS
THAN
2,15m (7 ft)
screw
safety cable
spring washer
flat washer
Wood Screw
Cable Clamp
Anchor
Figure 4
Wood Screw (4)
Hanger
Bracket assembly
Outlet Box
Ceiling
Anchors (4)
Screw (4)
NOTE: Ceiling support cable cannot be secured to
outlet box only, it must be directly secured to ceiling
joist or the provided geckos, using the 3/8” x 2” wood
screws and flat washer. (Figure 3)

8
How to Wire Your Ceiling Fan
MAIN FUSE BOX
Figure 2
Figure 1
NOTE: Factory setting is all up. Do not use this position.
1. To set the code on receiver unit, slide dip switches to
the same positions as set on the remote. (Figure 1)
NOTE: The remote unit has 16 different code
combinations. To prevent possible interference from or
to other remote units, simply change the combination
code in the remote and receiver.
To avoid possible electrical shock, be sure electricity
is turned off at the main fuse box before wiring.
(Figure 2)
WARNING
CAUTION: INCORRECT WIRE CONNECTION WILL
DAMAGE THIS RECEIVER.
NOTE: If you are not sure if the outlet box is grounded,
contact a licensed electrician for advice, as it must be
grounded for safe operation.
Dip Switch
Receiver Remote Control
ON DIP
21 34
9V
ON ON DIP
12 43

9
How to Wire Your Ceiling Fan (continued)
NOTE: If you feel that you do not have enough electrical wiring knowledge or experience,
have your fan installed by a licensed electrician.
Check to see that all connections are tight, including
ground, and that no bare wire is visible at the wire
connectors except for the ground wire. Do not
operate fan until the blades are in place. Noise and
motor damage could result.
WARNING
x 4
WIRE
CONNECTORS
HARDWARE USED:
Figure 3
BLACK
ANTENNA
BLACK
WHITE
L
N
AC POWER
GROUND MOTOR HOUSING GREEN
BLACK
WHITE
3. Connect green wires from motor housing to bare (ground) wire using wire connector.
Connect black wire from receiver unit marked “AC IN L” to black supply wire using wire connector.
Connect white wire from receiver unit marked “AC IN N” to white supply wire using wire connector.
Connect white wire from receiver unit marked “TO MOTOR N” to white wire from fan and driver input.
(Already connected by the manufacturer)
Connect black wire from receiver unit marked “TO MOTOR L” to black wire from fan .
(Already connected by the manufacturer)
Connect blue wire from receiver unit marked “FOR LIGHT” to black wire from driver
input. (Already connected by the manufacturer)
Connect red wire from driver output unit marked “+” to red wire from fan light.
(Already connected by the manufacturer)
Connect black wire from driver output unit marked “-” to blue wire from fan light.
(Already connected by the manufacturer)
(Figure 3)
BLACK(LIGHT)
WHITE(MOTOR N)
BLACK(MOTOR L)
DRIVER
OUTPUT
INPUT
BLACK(-)
RED(+)
BLUE(-)
RED(+)
WHITE(MOTOR N)

10
How to Install Your Canopy Housing
Figure 1
NOTE: This step is applicable after the neccessary
wiring is completed.
1.Assemble the canopy by rotating it to aligned the
"L-shaped" holes from the canopy over the two (2)
screws on the hanger bracket, taking care not to
pinch the wires. Tighten the two (2) screws. Fully
assemble and tighten the remaining two (2) screws
previously removed, into the round holes on each
side of the canopy (Figure 1)
WARNING
To avoid possible fire or shock, make sure that the
electrical wires are completely inside the canopy
housing and not pinched between the housing and the
ceiling.
Hanger
assembly
Loosen the
screw
Ceiling
Canopy
screw

How to Operate Your Ceiling Fan
11
3. To make fan operational, install 6F22 9V battery
(included) in hand-held remote transmitter, with fan
power off. Then follow the remote code setting
process. (If not used for long periods of time, remove
battery to prevent damage to transmitter). Store the
remote away from excessive heat or humidly.
(Figure 3)
NOTE: The remote unit has 16 different code
combinations. To prevent possible interference from
oor to ther remote units, simply change the combination
code in the remote and receiver.
NOTE: Factory setting is all up. Do not use this position.
Figure 4
4. To set the remote code same positions as the
receiver with a small screwdriver or ball point pen
(neither included), slide dip switches firmly up or
down. (Figure 4)
Check to see that all connections are tight, including
ground, and that no bare wire is visible at the wire
connectors, except for the ground wire. Do not
operate fan until the blades are in place. Noise and
fan damage could result.
WARNING
Figure 2
MAIN FUSE BOX
1. IMPORTANT: Using a full range dimmer switch
(not included) to control fan speed will damage the fan.
To reduce the risk of fire or electrical shock, do not use
a full range dimmer switch to control the fan speed.
(Figure 1)
Figure 1
For illustrative purposes only-not
intended to cover all types of controls
WARNING
Do not operate this fan with a variable (Rheostat) wall
controller or dimmer switch. Doing so could result in
damage to the ceiling fan's remote control unit.
2. Restore electrical power to the outlet box by turning
the electricity on at the main fuse box. (Figure 2)
Figure 3
6F22 9V
Battery
(1 pcs)
9V
Dip Switch
ON DIP
1234Remote

12
6.
(Figure 6)
Reverse Switch Information
Counter-Clockwise
Winter
Clockwise
Right
5. Remote functions: (Figure 5)
•Indicator LED light: Send command signal
How to Operate Your Ceiling Fan (continued)
Figure 5
•HI Large air volume
MED Medium air volume
•
•LOW Small air volume
•OFF Turns fan off
• Light button: Turns light on and off.
Press and hold this button without releasing it to
enter the dimming mode, and the light will
automatically cycle between bright and dark.
When the light is adjusted to the required
brightness, release the button
MED LOW
HI OFF
Warm weather - (Forward) A downward air flow
creates a cooling effect as shown in . (Figure 7)
This allows you to set your air conditioner on a
higher setting without affecting your comfort.
Figure 7
Figure 8
7.
Cool weather - (Reverse) An upward airflow moves
warm air off the ceiling area as shown in. (Figure 8)
This allows you to set your heating unit on a lower
setting without affecting your comfort.
8.
Reverse
Switch
DOWN
BAS
ABAJO
UP
HAUT
ARRIBA
Figure 6

How to Install Your Remote Control
13
1. Installing Wall Holder: (Figure 1)
Attach wall holder using the two provided screws.
Maintenance
Do not use water when cleaning your ceiling fan.
It could damage the motor or the finish and create
the possibility of electrical shock.
CAUTION
1. Periodic cleaning of your new ceiling fan is the only
maintenance that is needed. When cleaning, use only
a soft brush or lint free cloth to avoid scratching the
finish. Abrasive cleaning agents are not required and
should be avoided to prevent damage to finish.
Figure 1 Screws (2)
Wall Holder
screwdriver
(not furnished)
Replacement and disassembly diagram of fan blades.
Figure 1
Clamping
Blade Assembly Nut
Be careful not to tear off the balance stickers on the
fan blades. The fan blades have been calibrated for
dynamic balance, so as not to cause the lamp body
to shake when the fan is running.(Figure 2)
WARNING Labels for correcting the
dynamic balance of the
fan
Figure 2

14
Troubleshooting
For your own safety turn off power at fuse box or circuit breaker before trouble shooting your fan.
WARNING
Trouble Probable Cause Suggested Remedy
1. FAN WILL
NOT START
1. Check main and branch circuit fuses
or circuit breakers.
2. Check line wire connections to fan
and switch wire connections in the
switch housings.
CAUTION: Make sure main power is
turned off !
1. Fuse or circuit breaker blown.
2. Loose power line connections to the
fan, or loose switch wire connections
in the switch housing.
2. FAN SOUNDS NOISY
4. Dead battery in remote control. 4. Replace with new battery.
1. Check to make sure all screws in
motor housing are snug (do not
overtighten).
2. Check to make sure wire connectors
in switch housing are not rattling
against each other or against the
interior wall of the switch housing.
CAUTION: Make sure main power is
turned off !
1. Loose screws in motor housing.
2. Wire connectors inside housing
rattling.
3. Reversing switch in neutral position. 3. Make sure reversing switch position is
all the way to one side.
