Doohan iTank DH01 User manual


DOOHAN Intelligent Electric Scooter
DH01 Intelligent Electric Scooter
Owner’s Manual
Executive standard:168/2013/EU Q/ZGDQ·001
Zhejiang Doohan Technology Corp LTD
Compilation
Check
Approval

Preface
Thank you for purchasing the iTank intelligent electric scooter, distributed by SSR
Motorsports. Before driving, please make yourself familiar with the contents of this
manual. Your personal safety and security, not only depends on your own
watchfulness and familiarity with the operative technology, but also is related to your
familiarity with the mechanical properties of this three-wheel electric scooter.
Every time before driving, check the operational conditions of your electric scooter. If
you require regular maintenance or repair, only SSR Motorsports authorized dealers
will know how to handle the problems and ensure the product’s optimum performance.
If you have relevant machinery technical knowledge and maintenance tools, you can
purchase maintenance and repair parts from your local SSR Motorsports dealership.
This operating manual elaborates on the main points of correct operational approaches,
simple maintenance and adjustment methods, of the DOOHAN iTank intelligent
electric scooter, in order to expect its durable usage. If technical specifications change,
parts of pictures or content in this manual may have some differences from model to
model, please take this into account. The company reserves the right of final
interpretation.
We hope you enjoy riding your Doohan iTank, once again thank you for purchasing a
DOOHAN intelligent electric scooter.

Important notes
Driver and passenger
This scooter is designed for only one driver to operate. Never exceed the load
weight provided in this manual.
Road Conditions
This scooter shall only be driven on the normal road. The scooter can be driven in the
rain and snow, but cannot wade. When water floods in to the center shaft, it may
cause the electrical components, batteries or other parts filled with water to fail.
Consider all safety factors, please abide by traffic regulations, and slow down in the
rain and snow and on slippery roads, increase braking distance to ensure safety
when braking.
Warnings on safety and environmental protection should be pasted on the middle of
head back cover outside, glove compartment cover upside and back shelf upside
(clearly visible before or during use).
For the safety of others, please do not lend your scooter to those who do not have a
driving license and lack of driving experience, this will also keep you from
unnecessary damage.
Please read this operation manual carefully.
Please pay special attention to the WARNING notes within this owner’s manual.

Warning:
Means that if not abiding by the instructions in this manual, your operation may cause
serious injury or death.
Attention:
Means that if not abiding by the instructions in this manual, your operation may cause
injury to persons or machine part damage.
This manual shall be regarded as a permanent part of the three-wheel electric scooter.
Even though the scooter is transferred to others, this manual shall be transferred also

Contents
I、Safe Driving of intelligent electric scooter
II、Location schematic of every machine part and operation manual
III、Daily inspection and adjustment
IV、Operation guide
V、Maintenance and repair
VI、Common Fault and elimination methods
VII、Vehicle Storage
VIII、Vehicle Identification
IX、Main technical data
X、Electrical schematic diagram(DH01)
XI、After-sales Service

I Safe Driving of Three-wheel Electric Scooter
Safe Driving Regulations
1. Many traffic accidents of three-wheel scooters are caused because car drivers fail to see intelligent
electric scooter drivers, therefore, three-wheel electric scooter drivers should try to enable car drivers to
see them clearly, for example:
※Wearing bright-color clothes. Wear a safety helmet, also suitable protective glasses.
※Avoid drivers blind spots, if you cannot see them in their mirror than they can see you in their
mirror.
2. Many traffic accidents occur in road crossings, parking lot entrances and carriageways. Therefore,
when driving across these places, drivers should be more cautious.
3. Speed is a major factor in many traffic accidents. Drivers should observe speed regulations, absolutely
do not drive at excessive speeds.
4. Many accidents were closely related to the driving experience. Drivers who have just learned to drive
should be familiar with every performance and operation of the scooter, before driving on the highway.
Never lend your scooter to others who do not have a driving license and are lacking driving experience.
5. Drivers should avoid driving through rugged roads, for which may lead to steering failure or body
structure damage.

6. Before driving the scooter, detailed checks must be conducted carefully.
7. While driving, both hands must hold the handlebar, and both feet firmly placed on the floorboards.
8. While driving, calling or answering the phone, as the main cause of inattention, is likely to cause traffic
accidents. Please stop your scooter first, then call or answer the phone.
9. Changing lanes obtrusively is one of the main causes of traffic accidents. If the driver needs to change
lanes, please use your turn signal in advance, observe the vehicles behind you, and then change lanes
after confirming it is safe.
Load
※Warning:
Glove compartment, shelves and other storage facilities, can only be carry lighter objects.
Weight of carried objects should not exceed the stipulated value in table 1.
Table 1
Storage Compartment
Weight
Glove compartment
20kg

※When calculating the scooter's load-carrying capacity (maximum 150 kg) and estimating whether
or not it’s overloaded, the weight of all goods contained on the scooter, the driver and crew should
all be added up.
※If the scooter is overloaded, it will affect its stability and operations.
※All objects mounted on the scooter should be fastened tightly.

II Location schematic of every machine part and operation manual
Diagram sketch of components and parts
Rear
view
mirror
Head
Light
Turn
Signal
Under-seat
compartment
Front
battery
cover
Side
stand
Side
battery
cover
License
plate
lamp
Seat
keyhole
Instru
-ment
cluster
Tail
light

Diagram sketch of components and parts
Charging
port
Rear
brake
lever
Passenger
Grab Rail
Handlebar
grip
Front
brake
lever
Reflector

Instrument cluster illustration
Reverse gear indicator light
Right-turning indicator light
High beam indicator lamp
Headlight Indicator
Low battery indicator light
Best energy state
Real-time
speed
Battery indicator
Fault display
Battery Percentage
Cycling mode
Total travelled distance
Real-time current indicator
Left-turning indicator light

Icon illustration
Left Turn Signal Indicator Light up left-turning light
Right Turn Signal Indicator Light up right-turning light
High beam Indicator Light Light up high beam indicator lamp
Headlight Indicator Light up sidelight of the front and back
Low Battery Indicator Light Electric quantity of battery is lower than 30%
Reverse Gear Indicator Light The motorcycle is in reverse gear state
Best Energy State Best energy savings mode
Cycling mode Transmission Gear
Real-time Speed MPH/KPH Indicator

Battery Percentage It shows the current battery percentage.
Fault display Lights up if unit is experiencing a failure.
Battery indicator Shows the current battery charge level, and per grid
represents the 10% of full battery.
Low battery
Full battery
total travelled distance Shows the total travelled distance of the
scooter.
Real-time current indicator According to the changes of real-time current
value, it shows the condition of controller
real-time power output.

Ignition Switch:
△Start Up Operation:
Hit the unlock key on the remote control, and unlock successfully.
After the confirmation of successful unlock, insert the key and turn to the position. After
that, the scooter can be operated and keys cannot be pulled out.
When the self-test of the system is complete, it enters a waiting state.
Hold the brake handle, lift the kick stand, let go of the brakes when driving.
Handlebar Lock
L
Off state
Starting state

Right combination switches:
1. Reverse Switch:
Switch to R for reverse, switch to D for moving forward
2. Gear switch:
1 is the low gear 25km/h, and 2 is high gear 45km/h.
Gear switches can be used to interchange 25km/h and 45km/h.
3. Horn switch:
Press down this button, the horn will sound.
Horn switch
Gear
switch
Reverse switch

Left combination switches:
1. Headlight dimmer switch:
Press down “ ” to turn on the headlight high beam light; Press down
“ ”to light up the low beam headlight.
2.Overtake indicator light button
Press this button when high beam is on to temporarily use the low beam only.
3. Turning indicator lights button:
Turn left if the button is placed in “ ”position, and the left
turn signal will light up at the same time. Turn right if the
button is placed in the iron“ , and the right turn signal will
light up at the same time. Press the button in the middle
position and the turn signal will turn off.
4. Horn switch:
Press down this button, the horn will beep immediately.
△Behind the handlebars
Remark:USB interface must not be used for any
electrical appliances except phone chargers.
Otherwise, the factory shall not be responsible for
any damage the occurs.
Turn Signal
indicator light
High/Low
Headlight Beam
Switch
Horn
Ignition lock
Storage Pocket
USB interface
Hook
Overtake Switch

Battery Compartment Operation
①Opening the seat compartment: insert the key into the keyhole for the seat latch, and turn the
key to the right.
②Open seat compartment: rotate the battery compartment knob to the corresponding position
along the direction of B to open the front battery compartment, and rotate along the
corresponding direction of Ato open the side battery compartment lock.
Keyhole for Seat
Latch
Open side battery
compartment
Open front battery
compartment

III、Daily Inspection and Adjustment
Check before driving:
Before driving the scooter, drivers should make a routine inspection of the intelligent electric
scooter to ensure adequte performance of the scooter and to ensure
safe driving.
Brake handle free stroke:
Appropriate clearance is necessary for the brake handles, and
normal clearance should in the range of 10 to 20 millimeters.
Fluid pressure type brake system
Brake fluid inspection:
(1)Straighten the handlebars, and check the brake fluid in the master cylinder tank. The brake fluid
must be maintained between the upper and lower mark limits.
(2)Check the brake pad wear when brake fluid is reduced to the lower limit label mark.
(3)If the brake pads are abraded, and the brake fluid does not exceed the limitation, usually it
indicates that a brake fluid leak exists. Please seek an inspection and repair service from a dealership.
(4)Brake Fluid:DOT3 or DOT4

Notice: Once brake maintenance is required, owners should take their scooters to an authorized SSR
dealership for repairs. All special maintenance departments have trained technical personnel
responsible for maintenance and repair. The scooter parts can only be changed with real original parts
from the manufacturer.
Tires
The tire pressure should be inspected and adjusted routinely.
Check the tire pressure only after the tires have cooled.
Check often whether there are punctures in the tires, tires need to be repaired immediately when
tire air leakage occurs.
Check whether there are cut marks, staples, nails or other sharp objects in the tire surfaces. Check
whether or not the indentation, indenture or distortion of rims exists. If any damage has been
noted, please contact a maintenance department for inspection.
If the tire tread patterns are worn to the tread wear indicators, new tires should be installed.
