DoorBird A8001 User manual

A8001
WEDGE CORNER WALL-MOUNT
ADAPTER

TECHNISCHE DATENTECHNICAL SPECIFICATIONS
GENERAL
Material Polycarbonate
Weight 44 g
Weatherproof Yes, IP65
Dimensions 148 x 60 x 27 mm (H x W x D)
5.83 x 2.36 x 1.06 in (H x W x D)
Scope of delivery 1x Wedge corner wall-mount adapter
1x Small parts (screws and dowels)
EAN 4260423867345
Warranty see www.doorbird.com/warranty
Angle 7,5° vertical down or up
Compatible door stations D1101V Surface Mount and D1102V Surface
Mount
Screw the adapter to the wall. Screw the mounting housing to
the adapter.
Put the front panel with the
attached Main Eletrical Unit on
the mounting housing.
Turn the safety screws clockwise
until they are firmly tightened.
Recommended mounting height with A8001
Body height: 185 cm (72.8 in) Body height: 185 cm (72.8 in)
Lens height: 135 cm (52.0 in)
Lens height: 145 cm (57.1 in)
Body height: 175 cm (68.9 in) Body height: 175 cm (68.9 in)
Lens height: 121 cm (48.0 in)
Lens height: 135 cm (53.1 in)
Recommended mounting height without A8001
147 mm
5.79 in
60,00 mm
2.36 in
27,20 mm
1.07 in
8°
8,11 mm
0.32 in
1 2 3 4
