Dorel Home Products DA2036219 User manual

Date of Purchase Lot Number (TAKEN FROM CARTON)
Thank you for purchasing from Dorel!
THIS INSTRUCTION BOOKLET CONTAINS IMPORTANT SAFETY
INFORMATION. PLEASE READ AND KEEP FOR FUTURE REFERENCE.
1
C.W. - 11/ 27 /2020
© 2020 Dorel Home Products All Rights Reserved
Weight Limit: 250 Lb / 113 Kg
DO NOT RETURN TO THE STORE !
I f parts are missing or damaged, we will gladly ship your
replacement parts free of charge.
Visit www.dhpfurniture.com/eng/replacement-parts
or call Toll-Free 1-800-267-1739
You can also chat with us at www.dhpfurniture.com
DA2036519
(Light Gray Linen)
DA2036219 (Camel Faux Leather)
(Black Faux Leather)
DA2036019
)Navy Blue Linen
(
DA2036319
Office Task Chair
B34DA203621900-260306-W

●Work in a spacious area and near where the unit will be used, preferably on a
carpet, or use a piece of the cardboard packaging to protect your floor and product.
●Make sure all parts are included. Most parts are labeled or stamped on the raw
edge.
●Read each step carefully. It is very important that each step of the instructions is
performed in the correct order. If these steps are not followed in
sequence, assembly difficulties will occur
e .
●This product may contain small components. Please ensure that they are kept
away from small children.
●
Limited1 year Warranty
warrants this product to be free from defects in material and workmanship
and agrees to remedy any such defect. This warranty covers one year from the
date of original purchase from authorized retailers. This is solely limited to the
repair or replacement of defective parts and assembly labor is not included.
This warranty does not apply to any product which has been improperly
assembled, subjected to misuse or abuse or which has been altered or repaired in
any way.The warranty does not cover wearing, tearing, fading or splitting of the
fabric (where applicable). Liability for consequential damages is excluded to the
extent exclusion is permitted by law. This warranty gives you specific legal rights
and you may also have other rights which vary from state to state or province to
province.
To obtain warranty service, purchaser must present original bill of sale.
Components repaired or replaced are warranted through the remainder of the
original warranty period only. The defective components will be repaired or
replaced without charge, subject to the terms and conditions described above.
Visit www.dhpfurniture.com to view the limited warranty valid in the U.S. and
Canada.
Contact Us!
For help with assembly, identifying parts, product information or to order parts,
please contact us:
Read Before Beginning Assembly
This product is packaged in
1 carton
15 mins
Do NOT use
powertools
1-800-267-1739
DHP Consumer Services
12345 Albert Hudon, Suite 100,
Montreal, Quebec H1G 3L1
[e-mail]
Monday to Friday
Saturday
Sunday
9am to 9pm (Eastern Time)
10 am to 6:30 pm (Eastern Time)
11 am to 7 pm (Eastern Time)
Chat
with us! www.dhpfurniture.com
Dorel
●This product is designed for home use and is not intended for commercial use.

3
PARTS LIST
A
C
E
E
D
E
E
E
B

4
IMPORTANT:
Each part has a unique part number. Please reference the appropriate part
number when contacting
customer service for replacement parts.
Before throwing any packaging, please verify all contents and make sure
you have received all the parts listed above!
PARTS LIST
1 PC
1 PC
1 PC 5 PCS
GAS LIFT
1 PC
SEAT PLATE
SEAT STAR BASE CASTER
PART
LABELS
PART NUMBERS
DA2036219
T806180 T806210 T806220 T806230
T806190
T806200
T806050
T806060 T806060 T806060 T806060
T806050 T806050 T806050
T806190
T806200
T806190
T806200
T806190
T806200
(Camel Faux Leather)
A
B
C
D
E
DA2036319
(Light Gray Linen)
DA2036519
(Navy Blue Linen)
DA2036019
(Black Faux Leather)
ABCD E

DA2036219
DA2036319
DA2036519
DA2036019
Ø1/4"*3/4"
4 PCS
HARDWARE LIST
1
12 2
ALLEN KEY
1 PC
Hardware Pack
Please do not completely tighten all the hardware,
until the entire assembly is complete, unless
otherwise indicated in the step-by-step
instructions.
The screw(s), bolt(s) to be used at each step are
shown in actual size in the lower right corner of
the page.
BOLT
5
HP#: TS037416QE-00

Step 1
6
Attach casters Ex5 to star base Das shown.
E
E
E
EE
D

Step 2
7
Attach gas lift C to star base D as shown.
C
D

Step 3
8
B
A
FRONT
FRONT
1
4
Attach seat plate Bto seat Awith bolts ，
as shown.
1
1
2
Place the plate Bwith the ''FRONT'' sticker towards
the front of the chair A.

9
A
C
Step 4
Attach seat Aand seat plate Bto gas
lift Cas shown.
B

Y furniture can be disassembled and
reassembled to move.
10
CAUTION: This unit is intended for use only with the products and/or maximum
weights indicated. Use with other products and/or products heavier than the
maximum weights indicated may result in instability or cause possible injury.
•Move your new furniture carefully, with two
people lifting and carrying the unit to its new
location.
•our
•Clean the product with a soft damp cloth. DO
NOT use harsh chemicals or abrasive cleaners.
•Check bolts and nuts periodically and tighten if
necessary.
Helpful Hints
Weight Limit:
250 lb / 113 Kg
That's it ! You've finished assemblin g your chair!
