Dover ProGauge MagLink LX User manual

Part Number: M2052-EU, Rev. 1
Issue Date: V
User's Manual
MagLink LX
M2052-EU
Revision: 1

NOTE: Before you use this manual, make sure you have the most recent revision. Look at the
revision of this document to make sure it agrees with the most current revision found at
http://www.opwglobal.com/opw-fms/tech-support/manuals-how-to-videos. Download the
latest revision if necessary.
ProGauge is a part of Dover Fueling Solutions.
Contact
START ITALIANA S.r.l.
Via Pola 6
20813 Bovisio Masciago (MB)
Italy
Tel. [phone]
Fax [phone]
Copyright Information
© 2020 Dover Fueling Solutions. All rights reserved. DOVER, the DOVER D Design, DOVER FUELING
SOLUTIONS, and other trademarks referenced herein are trademarks of Delaware Capital Formation.
Inc./Dover Corporation, Dover Fueling Solutions UK Ltd. and their affiliated entities.
M2052-EU Rev.: 1 Dover Fueling Solutions Page 2

Table of Contents
Section 1 Preface 5
Section 2 General Warnings 6
Section 3 Introduction 7
Section 4 General Description 9
4.1 Compatible Probes 11
4.2 Correct Use 12
4.3 Incorrect Use 12
Section 5 Power ON/OFF 13
Section 6 Product Labels 14
Section 7 Graphical User Interface 15
7.1 Inventory 15
7.1.1 Status Icons 16
7.2 Main Menu 19
7.3 Status Page 19
7.4 Calendar 20
7.5 Notifications 20
7.6 History 21
7.7 Maintenance 21
7.8 Shifts 22
7.9 Reports 23
7.9.1 Sales Report 23
7.9.2 Shift Report 23
7.9.3 Delivery Report 24
7.9.4 Leakage Report 24
7.9.5 History 24
7.9.6 System/Alarms 25
M2052-EU Rev.: 1 Dover Fueling Solutions Page 3

7.10 Configuration 25
7.10.1 System Configuration 25
7.10.2 Tank Configuration 26
Section 8 Technical Support 27
M2052-EU Rev.: 1 Dover Fueling Solutions Page 4

Section 1 Preface
Start Italiana S.r.l. has made every effort possible to see that this document is complete, accurate and
updated. With every revision of the console, the related information is added to the document. Start Italiana
S.r.l. reserves the right to make unannounced improvements and/or changes in the product and/or
associated programs. Start Italiana S.r.l. is not liable for damages of any kind, including those resulting in the
document, including typographical errors.
Making copies, citing quotes or other reproductions of all or part of this document is permitted only after
written consent of Start Italiana S.r.l.
Patents protect trademark or name.
Copyright 2019© Start Italiana S.r.l. – All rights reserved
M2052-EU Rev.: 1 Dover Fueling Solutions Page 5

Section 2 General Warnings
Carefully read the instructions in this manual before you do the installation procedures.
Only approved persons are permitted to install this equipment and configure the console.
The manufacturer is not responsible for operations that are not included in this manual.
The manufacturer is not liable in regards to competent bodies for changes to the equipment and software that
are not approved.
In case of failure or defect, refer directly to an authorized service provider or manufacturer.
The manufacturer is not liable for injury and/or damage to persons and/or property and/or pets caused by the
failure to obey safety instructions.
All approved personnel must know all safety requirements in this manual, the configuration manual and the
user manual.
Refer directly to an approved service provider or manufacturer for questions about the operation of the
equipment.
IMPORTANT: You must read and obey all safety instructions in this manual before you use
this equipment.
WARNING: Incorrect use of this equipment that does not agree with the
instructions in this manual can cause a risk to safety.
M2052-EU Rev.: 1 Dover Fueling Solutions Page 6

Section 3 Introduction
This manual was prepared in accordance with IEC 82079-1 standards. “Preparation of instructions for use -
Structuring, content and presentation - Part 1: General principles and detailed requirements and according to
the ATEX Directive 2014/34/EU concerning equipment and protective systems intended for use in potentially
explosive atmospheres."
This manual gives all necessary information about the installation of the Maglink LX console.
IMPORTANT: This manual must be used together with the related product manuals:
M2050-EU MagLink LX Installation Manual
M2051-EU MagLink LX Configuration Manual
You must install the console as shown in M2050-EU MagLink LX Installation Manual,
configure the console as instructed in the M2051-EU MagLink LX Configuration Manual, and
use the console in the field as shown in this manual.
WARNING: This device must not be discarded with household waste. This
device is labeled in accordance with European Directive 2012/19/UE
concerning used electrical and electronic appliances (waste electrical and
electronic equipment – WEEE).
This guideline gives the methods for the return and recycling of used
electronic devices as applicable throughout the EU. To return your used
device, use the return and collection systems available to you.
The battery used in this device may present a risk of fire or chemical burn if
mistreated. Do not disassemble, heat above 50°C or incinerate.
The table that follows lists reference data of the manufacturer:
Data Description
Name START ITALIANA S.r.l.
Address
Via Pola 6
20813 Bovisio Masciago (MB)
Italy
Telephone [phone]
Fax [phone]
Website www.startitaliana.com
e-Mail [e-mail]
M2052-EU Rev.: 1 Dover Fueling Solutions Page 7

NOTE: The units of measurement contained in this manual refer to a specified selection by
the user. Refer to the M2051-EU MagLink LX Configuration Manual for more information on
how to set units of measure.
M2052-EU Rev.: 1 Dover Fueling Solutions Page 8

Section 4 General Description
This console is used to monitor probe levels and gives tank alarm notifications. The console can hold up to
16 on-board probes, four (4) on-board relays with six (6) inputs and an external expansion module that can
hold up to four (4) expansion cards.
NOTE: A maximum of two (2) MagDirects with 8 probes each can be added.
NOTE: Each expansion card can have 8 relay outputs, 8 digital inputs or 4-20mA. These
cards can be put together so that the system can have 32 relays and 0 inputs, 32 inputs and 0
relays and a mixture of both in increments of 8.
The console can interface with a site's FCC/POS through serial or Ethernet connection.
The console has a resistive type touchscreen that can be used with fingers (also with gloves), stylus pens for
touchscreens and other applicable tools. To use the screen it is necessary to contact the screen and apply a
light force.
M2052-EU Rev.: 1 Dover Fueling Solutions Page 9

The table below shows the technical characteristics of the console:
MagLink LX Technical Characteristics
Characteristic Value
Power supply 100 - 240 V~, 50-60 Hz
Consumption 15 VA
Operating temperature (-10 - +50) °C
Relative humidity (5 - 95)%, non-condensing
Number of probes 32 (16 probes through internal barrier and 16 probes with
added MagDirect modules)
Number of ON-OFF external sensors Up to 32
Number of ON-OFF internal sensors 6 (only when Dipswitch 2 is ON)
External relay outputs Up to 32
Internal relay outputs 4
Lower power of the relay output 0,5 A, 33 V~, or 2 A, 30 V DC
Output power for the probes 12 V DC, 100 mA per output for each probe, connectors MR3
MR4 (up to 8 probes for each connector)
Serial communication of the probes RS485
Host communication (management) RS232 and TCP/IP (almost every forecourt controller have the
protocol integrated)
Printer communication RS232
Integrated web server for remote con-
figuration, consultation, com-
munication, and emails as well as
HOST COMMUNICATION
TCP/IP
GSM modem for SMS service 1 Optional
IFSF 1 Optional
Case Plastic
Protection IP40
Dimensions 265 x 190 x 95 mm
M2052-EU Rev.: 1 Dover Fueling Solutions Page 10

4.1 Compatible Probes
The probes in the list below are compatible with the MagLink LX:
lXMT EXD 485
lXMT SI 485
lXMT RF (an RF receiver is necessary)
lDMP-IS-485
NOTE: ALL the floats used on probes have more than 10 years of life time in the fuel tanks
Auxiliary equipment that can be used with the MAGLINK LX console include:
lExpansion cards, up to 32 relays and 0 inputs, up to 32 inputs and 0 relay, and a mixture of both in
increments of 8.
lLocal Printer
M2052-EU Rev.: 1 Dover Fueling Solutions Page 11

4.2 Correct Use
Only use the MagLink LX console for use as given in this manual. The console must be installed in a safe
arrea. The console includes an intrinsic safety barrier and two (2) channels (BRA-2SIP) to connect XMT-SI-
485 and DMP-IS-485 probes.
The table below shows the characteristics of use of the intrinsically safe barrier contained in the console:
MAGLINK LX Features (barrier) Description
Group (area of use) II (Surface industries different from mines)
Category and type of potentially explosive atmosphere (1) G
Protection mode ia
Group of substances (gases, vapours or mists) IIB
The specifications of use for console security and for the Barrier are given in this manual and on the product
label.
IMPORTANT: Safety instructions constitute an attachment to this manual and users must
acknowledge it before using the equipment.
WARNING: The Console must not be used in hazardous areas (because
there is a risk of fire and explosion). The probes of the XMT-SI-485 family are
installed in hazardous areas and must be connected to the Barrier contained
in the console.
4.3 Incorrect Use
Incorrect and alternative uses include:
lResistive touch screen: Only use fingers or special tools made for resistive touchscreens to select
screen options.
lUSB and USB Port devices: Only use this port for firmware updates, console backup and USB
printer connection.
lSerial ports: Only use the serial ports for printer and PC connection with management programs that
interface with the protocols given by Start Italiana S.r.l.
lNetwork cable: Only use the network cable connection for console configuration, and local network
connections (Refer to the M2051-EU Configuration manual).
M2052-EU Rev.: 1 Dover Fueling Solutions Page 12

Section 5 Power ON/OFF
IMPORTANT: Only authorized/trained personnel can energize the console and must obey
the manufacturer's instructions. Operation must obey the safety instructions shown in the
Installation Manual (M2050-EU).
To energize the console:
1. Make sure that the power button is in the OFF position (0).
2. Connect the power cable.
3. Connect the corporate network cable, if necessary.
4. Push the power button to the ON position (1).
If the console is not configured when it is energized it will cause an alarm because it does not communicate
with a tank. Push the red arrows up or down until you see the page "ALARM LOG." Push the ACK button to
stop the alarm.
To make changes to the console configuration, refer to the MagLink LX Configuration Guide M2051-EU.
To de-energize the console, push the power button to the OFF position.
NOTE: The Maglink-LX console uses an industrial grade SD card. Safe data storage is
available if there is power loss.
M2052-EU Rev.: 1 Dover Fueling Solutions Page 13

Section 6 Product Labels
lName and address of the manufacturer
lCE marking with the Notified Body
lProduct Name
lThe "Caution" symbol (0434B of 01/2004), according to ISO 7000
lSerial number
lYear of production
lPower Supply(VAC and Hz)
lPower consumption (VA)
lOperating temperature (°C)
lIngress protection (IP grade)
lFuse rating
lIndication that inside there is intrinsically safe circuit
lName and address of the manufacturer
lEquipment Type (BRA-SIP, or BRA-2SIP)
lATEX Reference number of the certificate
lATEX Marking: Ex II (1) G [Exia] IIB FISCO power supply UM=250 V [Exia] IIB
lSerial number
lElectrical data
M2052-EU Rev.: 1 Dover Fueling Solutions Page 14

Section 7 Graphical User Interface
7.1 Inventory
The Inventory page shows information related to tanks. Up to four (4) tanks can be shown on a page.
TIP: Move your finger across the display to the right to see the information for more tanks.
Tap on a tank image to get more information about that tank.
A screen will open that shows information related to the categories in the tables that follow:
Volume
Product Gross Product volume at the current temperature (includes the water volume)
Comp. prod Compensated product volume temperature (at 15° C or 20° C: refer to the configuration)
Water Current water volume
Ullage Empty space calculated from the safe working capacity (refer to the configuration)
Capacity The total capacity of the tank (refer to the strapping table).
M2052-EU Rev.: 1 Dover Fueling Solutions Page 15

Level
Product Current product height
Water Current water height
Safe capacity Refer to the configuration
Maximum height Tank height (refer to the strapping table).
NOTE: The density data in the table that follows will show only if a Density Measurement
sensor is installed.
Density
Density The density at current temperature
Weight The weight of the product calculated by the measured density
Temperature
Current The current product temperature.
Compensated The temperature setting that is used for volume compensation (refer to the con-
figuration).
7.1.1 Status Icons
Status OK (Green) No Alarm
lThe "Traffic Light" is green.
lThere are no Alarms.
lThe NO ALARM button is "grayed out."
M2052-EU Rev.: 1 Dover Fueling Solutions Page 16

Status Alarm HH, H (Red) In Alarm
lThe "Traffic Light" is red.
lThe alarms are HH (High-High) and H (High).
lThe color in the related fields is changed to pink.
lThe “Acknowledge Alarm” button is On. Push the Acknowledge Alarm button to aknowledge the alarm
in the system.
Status Alarm HH, H (Yellow) Alarm Aknowledged
lThe "Traffic Light" is yellow.
lThe alarms HH (High-High) and H (High) have been acknowledged
lThe color in the related fields is changed to yellow.
lThe ACKNOWLEDGED button is "grayed out."
TIP: Move your finger down the display to see the next screen.
M2052-EU Rev.: 1 Dover Fueling Solutions Page 17

This screen shows the configured thresholds. There are four (4) action button selections:
lDiagnostic
lEmail Inventory
lPrint Inventory
lSMS Inventory
TIP: Move your finger down the display to see more tank settings and the Strapping table.
M2052-EU Rev.: 1 Dover Fueling Solutions Page 18

7.2 Main Menu
Push the Home button in the top right of the Inventory screen to go to the Main Menu.
7.3 Status Page
Push the Status icon on the Main Menu.The display will navigate to the "Status" screen that shows
information related to the condition of the Tanks or Sensors (move the Sensor slider to the right to see the
Sensor status).
The icons will show in green if there are no alarms. If a tank or sensor is in alarm, its icon will show in red.
M2052-EU Rev.: 1 Dover Fueling Solutions Page 19

7.4 Calendar
Push the Calendar icon on the Main Menu and the "Calendar" screen will come into view.
There is a group of icond along the left side of the calendar. These icons are used as filters to select what
events are shown on the calendar display.
lSelect this icon to show events related to the console.
lSelect this icon to show events related to tanks.
lSelect this icon to show events related to sensors.
lSelect this icon to show deliveries.
lSelect this icon to show alarms.
lSelect this icon to show warnings.
lSelect this icon to show leak tests.
Use the radio buttons along the right side of the calendar to select the applicable tanks.
Push a date box to see information for the events on that date.
7.5 Notifications
M2052-EU Rev.: 1 Dover Fueling Solutions Page 20
