Dowell 4001 360D User manual

4001 360D
30"H Wall Corner Lazy Susan
INSTALLATION GUIDE
page 1
Short steel tube
Spanner
360°.Revolving basket Lock out Inching nut
Revolving bearing stand
Fixed short pin
Fixed long pin
Long steel tube
Fixed bearing stand

4001 360D
30"H Wall Corner Lazy Susan
INSTALLATION GUIDE
page 2
Hold the assembly groupware of
the B showing infix it of the D
showing and the plug into short
steel tube, and lock it and tight with
inching nut.
C
D E F
A
B
Fit in according to the sequence of the A,
and use spanner to aim at the hole in the
nut and clamp the revolving basket.
(view)
Note: Block position of the
steel basket (as the arrowhead
show) with fixed slot support-
ing as the magnify view.
Magnifying view
Hold the locomotors nut of fixed short
pin infix the long steel tube, and then
begin to go to use fixed long pin infix the
hole of long steel tube.
A
C
B
