Produ t Des ription
The AWS-X weather station (also called AWX in this manual) is a GSM/GPRS
device that works with a solar panel and rechargeable battery, that can
measure the weather parameters, in the most complete version:
1- Wind speed and direction
2- Air temperature and relative humidity
3- Rain
4- Atmospheric pressure
5- Solar radiation
6- eaf wetness
7- Soil temperature
8- Soil Moisture
These data can be sent to a server connected to the internet with a static IP
address, by means of GPRS packets, at intervals programmable from 1 to 60
minutes.
AWX user manual V 1.2 6

Hardware des ription
The AWX station consists in the CPU BOX, water and dust resistant (IP56),
in which the CPU board and the battery are and the sensors that acquire the
various weather parameters. A solar panel will recharge the battery by means
of the circuit installed in the CPU box.
All these devices are supplied in aluminum metal parts, ready to be attached
to a pole (not supplied).
Setting up
To set up the station it is enough to attach it and the sensors to a pole of
the correct dimension, to connect the sensors and to program the required
features by means of a PC or SMS.
IMPORTANT: you must remove the PIN request from the SIM before
swit hing on the unit, otherwise the AWX will not work and after switching
up 2 times, the SIM will be locked, and you may need the PUK code to ock it.
To disable the PIN request, put the SIM in a telephone and disable this
request using the security menu of the phone.
How to onne t Sensors
Sensors should be attached to the plugs as indicated in the PCB.
In details:
WIND: Connect here the anemometer
RAIN: Connect here the Rain Collector after ahving removed its locking stripe
TEMP: Connect here the SOI temperature sensor
TEMP/RH: Connect here the normal AIR temperature and Relative HUmidity
sensor that is in the shield below the rain collector.
SUN: Connect here the Radiation sensor
LEAF: Connect here the eaf Wetness sensor
The Soil Moisture sensor should be connected to the connector with 2
screws.
AWX user manual V 1.2 7

Basi Programming
Please find below the commands most commonly used that you will need to
activate the station.
#PWD password command, must be followed by 6 digits (default 123456)
#MHD Followed by the name of the station. This is usualy used as a key for
the data to be stored in the server.
#APN followed by the GPRS Internet APN of your operator
#UIP followed by IP address and port where to send the UDP data.
#DSI followed by sampling interval in minutes. Better over 10.
#S P1 to Activate Sleep Mode to save energy (recommended)
# GG followed by interval in minutes between GPRS packets. Put it = DSI
#UDM defines the GPRS modality. Use 2 (#UDM2)
#RTC programs the real time clock. Note well: can be used ON Y after the
modem is succesfully registered to the operator.
#SCT This command is very important to sync the station with the operator
time, so you can see data with correct timing. Works ON Y with SMS
AWX user manual V 1.2 8

REAL TIME CLOCK
The station has a real Time Clock that is powered by the main lead battery. If
you disconnect the battery, the clock is maintained for a few minutes by a
capacitor, and then needs to be reprogrammed.
IMPORTANT: if the RTC is not programmed correctly you will not see data in
the internet, because they are stored in the database in the wrong records!
AWX user manual V 1.2 9

Example of data sent to a server in the
internet with UPD pa kets
AWS-X weather station has GPRS connectivity and can send data to a IP
address in the internet. These data can be then stored by a local application,
using a Data Base, like for example MySql, and retrieved later using PHP.
In details this is the explanation of the AWS-X data:
DATE and TIME of when data were measured
SMSC: counter of the SMS sent by the station
SI: Sampling interval. Data are measured every minute and aggregated
according to the sampling interval, that can go from 1 to 60.
WAS: WInd average speed
PRESS: Atmospheric air pressure in millibar
WMINS: Wind minimum speed in the SI interval
WGUST: Wind maximum speed in the SI interval
DWGUST: Daily wind maximum speed
LEAF: wetness. From 0=wet to 15=dry
WDIR: Wind direction in SI
WDSD: Wind Direction Variability. Form 0=steady to 15=variable
SUN: Solar radiation in W/Mq
TEMP: Air temperature average in SI
DMINTEMP: Minimum Daily Temperature
DMAXTEMP: Maximum Daily Temperature
SOILT: Soil Temperature
RF: Rainfall in SI
DRF: Daily Rainfall
SOILW: Soil moisture expressed as soil tension (0 (wet) - 200 (dry) Kpa)
DP: Dew point based on simplified calculation
RH: Relative humidity
DMINRH: Daily minimum Relative Humidity
DMAXRH: Daily Maximum Relative Humidity
AWX user manual V 1.2 10

PWR: Type of power supply. B=Battery, E=External
VBAT: Battery Voltage
AWX user manual V 1.2 11

How to program the AWX
You can program the station by means of SMS sent from your mobile.
It is a safe and reliable system, because the SMS must start with a password.
You can also program the unit using a PC by means of terminal software, like
Putty or Zterm.
To do so you need a level shifting cable that we may provide on request.
More details on appendix A.
Programming with SMS messages
This is the most convenient way, if your SIM supports SMSs, because you
can do it from everywhere and you do not need to open the box.
Every command must start with a octothorpe sign (#).
The first command of an SMS must be #PWD followed by a 6 digits valid
password. The default is 123456.
Every command SMS must end with #.
You can put more than 1 command in one SMS, as long as you don't pass the
limit for 1 SMS (160 characters).
The message will be received and checked every minute, and the unit will
answer with OK or Err depending on the result.
The AWX can send maximum 40 messages everyday (it is a protection for
your bill). This limit can be changed with the command SMC.
If you don't want to receive an answer by SMS, insert #NOA# at the end of the
SMS.
AWX user manual V 1.2 12

TCX-OS ommand list
AWX can be programmed using 3 letter commands. The commands are the
same, via SMS or via PC interface.
You can use lower case or upper case letters, or a mixture of the 2.
For example: PWD=pwd=Pwd.
Do not put spaces or other characters in the command string or among
commands.
Remember that EVERY command must start with a octothorpe (#)
This is a list of the commands most used:
#APN: Defines the Access Point Name for GPRS
#END: Exit from programming menu (if using a PC)
#GTM: ask weather data via SMS
#INI: Initialize all parameters
#LGG: define GPRS interval for sending data
#MHD: Program the NAME of the station (max 10 characters)
#NOA: Do not send acknowledgement SMS
#PWD: Password (followed by 6 digits password)
#RTC: Program real time clock date and time
#SCT: Sync real time clock with incoming message timestamp
#SLP: Enable/Disable (1/0) Sleep mode to save power
#SMC: SMS counters and 24h maximum
#UDM: Define the control system used for UPD packets (echo etc.)
#UIP: Define IP address and port
AWX user manual V 1.2 13

BASIC SMS to a tivate the unit to send GPRS data
This is an example of the SMS that is needed to activate the unit once has
been powered on.
#pwd123456
#mhdMY-AWX
#APNweb.vodafone.it
#uip192.168.135.110:999
#lgg60
#slp1
#udm2
#sct
#
It should be one complete string, no spaces, no CRs (we have put the CRs
here only to improve legibility).
In details:
#pwd123456 = Password, needed at the start of any message.
#mhdMYAWX = Name of the station. Needed to identify it on the server.
#APNweb.vodafone.it = APN of your operator. Needed to send data in gprs
#uip192.168.135.110:999 = IP address and port of your server
(if you want to use our server ask us the correct IP address).
#lgg60 = gprs interval at 60 minutes (you can put a value from 01 to 60)
we recommend to use the same value as DSI.
#slp1 = sleep mode active
#udm2 = upd data sent with local check and echo check
#s t = Sync real time clock with this message timestamp
# = message closure
AWX user manual V 1.2 14

Detailed ommand Des ription
#PWD
Password. This command must always come first. Use 6 digits as a password.
The default one, when the device comes from the factory, is 123456. You may
change it, using the #CAP command.
Remember that if you change it and forget it, you will have to return the device
for a total reset, and this service has a cost.
In all the following examples we will use 123456 as an example of password.
#APN
Defines the Access Point Name for GPRS.
Every operator has a different APN that allows connection to the internet using
mobile devices. For example web.omnitel.it or ibox.tim.it or isp.vodafone.ie
are all valid APN for different operators. You should ask your operator which is
the correct one for your SIM.
#END
Exit from PC programming menu. This is not an SMS command.
#GTM
Using this command it is possible to ask the station to send
an SMS with the weather data of the last Sampling Interval.
This command will not work when the station has just been switched on,
before at least a period corresponding to a sampling interval has elapsed.
#INI
INItialize parameters to default settings. This command will erase all the
eeprom and reinitialize to factory settings.
IMPORTANT!: all your numbers and other settings will be erased!!!
Password will be reset to 123456.
After issuing this command, wait at least 2 minutes before sending other
commands to the unit.
AWX user manual V 1.2 15

#LGG
Define the interval at which the GPRS packets will be sent.
Minimum 1 minute, maximum 60 minutes.
We suggest to keep this value at 60 minutes, not to pay too much for data
traffic
Example: # GG6
#MHD
Message HeaDer. This command allows you to program the Name of the
station. and the serial number of the SMS messages (autoincremented)
Every message is sent by the unit in a format similar to the following:
TCX-0001
Where TCX is the name of the device, that can be programmed with MHD,
0001 is the serial number (continuously incremented) of the SMS and then the
following text that is the real information sent with the SMS and that varies
accordin gto the reason why the SMS was generated (i.e. A ARM, Command
answers etc.).
With the command MHD you can program the Name and the serial number, if
you want. If you program only the name, you need to use up to 10 characters
and close with a #, as in the following example:
#PWD123456#MHD=my tcx#
If you want also to program the serial number, make sure you are
programming the header using exactly 10 characters and then, after a
comma, program a 4 digit serial number. For example:
#PWD123456#MHD=my-awx....,0001
To check what the current header and serial number is, you can send the
message: #PWD123456#MHD?
AWX user manual V 1.2 16

#NOA
NO Acknowledgement. Use this command if you don't want the device to
answer to your SMS command with another SMS.
#RTC
Real Time Clock. Use this command to program a specific date and time in
the real time clock of the device. You will need to have it programmed well if
you want to use the feature WHO in a useful way. See also #SCT.
The command is as follows:
#PWD123456#RTC09/12/05,11:58:01
and to check you can use
#PWD123456#RTC?
RTC=09/12/05,11:58:01
#SCT
Synchronize Clock with SMS TimeStam . This command provides a easy way
to set your device clock without needing to send the longer RTC command.
Simply send: #PWD123456#RTC and your clock will be automatically
synchronized with the network. This is expecially useful during Summer or
Winter time changes
#SLP
Slee the Station. This command is very usefull for power saving and should
always be used. The station will enter power save, but still measure
parameters, and will wake up every minute to check incoming SMS etc.
Example: #S P1
AWX user manual V 1.2 17

#UDM
UDP mode.
The AWX can send UDP packets in 3 modes, defined by UDM.
0= Data are sent with no control.
1= data are send checking that the GSM Modem hasn't received an error
from the network or has no signal.
2- In addition to 1, the unit waits for an echo of the same packet, coming from
the server
We suggest to use #UDM2
#UIP
Define IP address and ort
This command is used to tell the AWX where to send the data.
You should enter here the static IP address of the server you are using and
the port. Make sure this port is not filtered by a firewall.
Example: #UIP127.127.0.1:999
AWX user manual V 1.2 18

Most ommon problems and solutions
I have inserted the SIM but the unit doesn’t work:
Check to have removed the PIN request from the SIM. If you didn’t do it and
you have switched-on the unit more than 3 times, you may need to use the
PUK. Check with SIM instructions for details
Weather data don't arrive to the Server
Check that the UPD port you are using is not filtered by a firewall.
Make sure you have programmed the correct name of the station
with command MHD.
Make sure you have synced the real time clock of the station with command
SCT.
Contact us for more information
AWX user manual V 1.2 19

APPENDIX A
Programming with PC
It is possible to program this device with a PC, using the special level shifting
cable that we can supply on request.
Setup the communication software of your PC or MAC ( Putty or Zterm work
well) to communicate at 9600 baud, 8 bit, no parity, 2 stop bits.
When you switch on the AWX it will output [hello] through the serial port and
the status led will blink very fast for a few seconds.
During this time you can enter the programming menu by typing [menu] on the
keyboard (only menu, no square brackets). Press Enter.
NOTE: at this stage, the modem is not registered to the network, so you
cannot program RTC.
Once the modem is registered, you need to wait one minute, until the unit
stops clicking (you hear a ticking every second, normally, when this stops
momentarily, press ENTER.
Press ENTER on your keyboard.
The screen (after a few seconds) will show [hello]
Type [menu] and press ENTER.
The unit will enter the programming menu as follows:
>
hello!
>menu
PASSWORD?
>123456
TCX OS v9.0, (c)1999-2009 DPS-Promatic srl
Device name: AWX
>
As you can see after having typed [menu] the device has requested to enter
the password. Type 123456 if you have not changed it.
At this point you can enter the commands directly without needing to type the
password anymore.
AWX user manual V 1.2 20
