DR. Z Amplification Signature Series User manual

Z-Master
Manual
Model: ZA-47
www.drzamps.com

Important Safety Instrucons
1) Read these instrucons.
2) Keep these instrucons.
3) Heed all warnings.
4) Follow all instrucons.
5) Do not use this apparatus near water.
6) Clean only with dry cloth.
7) Do not block any venlaon openings. Maintain at least 3 feet of distance around all sides of amplifier.
Do not block any venlaon openings with items such as newspapers, tablecloths, curtains, etc.
8) Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug
has two blades with one wider than the other. A grounding type plug has two blades and a third
grounding prong. The wide blade or the third prong are provided for your safety. If the provided
plug does not fit into your outlet, consult an electrician for replacement of the obsolete outlet.
10) Protect the power cord from being walked on or pinched parcularly at plugs, convenience
receptacles, and the point where they exit from the apparatus.
11) Only use aachments/accessories specified by the manufacturer.
12) Use only with the cart, stand, tripod, bracket, or table specified by the manufacturer, or sold
with the apparatus. When a cart is used, use cauon when moving the cart/apparatus
combinaon to avoid injury from p-over.
13) Unplug this apparatus during lightning storms or when unused for long periods of me.
14) Refer all servicing to qualified service personnel. Servicing is required when the apparatus
has been damaged in any way, such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus has been exposed to rain or
moisture, does not operate normally, or has been dropped.
15) Avoid placing any liquids on or near the amplifier that may splash or drip such as those contained in
boles, cans, glasses, etc.
*Dr Z amplifiers are capable of producing very high sound pressure levels which can cause temporary or
permanent hearing damage.
*If any screw that is actually on the amp chassis needs to be replaced contact Dr Z Amps for the proper size.
Screw size is crical for inner chassis clearances.
This symbol warns the user of dangerous voltage levels localized within the enclosure.
This symbol advises the user to read all accompanying literature for safely operang
the unit

In 2018, Joe Walsh approached Dr. Z to recreate his favorite amp of all me: a ’59 tweed Bandmaster 3×10.
While touring in the early 70s with the James Gang, Joe gied his original ’59 Bandmaster to parcular
wind-milling Brish guitarist who next recorded a classic 1971 album using the amp. 50 years later, Joe
tasked Dr. Z with recapturing the magic of the “one that got away.”
Starng with a to-spec replica of the paper wound, model 1848 output transformer by Triad Magnecs (the
manufacturer of the original transformers of the tweed era), Dr. Z made an exacng recreaon of the Band-
master and sent it off to Joe, who was ecstac with the resulng amp. Later in the year, aer Joe requested
some tweaks and alternaons, Dr. Z completed the first prototype of what would become Joe’s signature
amp: the Z-Master.
Though rooted in the ’59 Bandmaster, Dr. Z and Joe designed the Z-Master to suit his playing style and his
vast, unique collecon of guitars, resulng in what he would authencally deem his “signature amp.” These
parcular adaptaons include the independently voiced “Vol. 1” and “Vol. 2” controls that are internally
blended, as to achieve a tonal balance to suit the specific nuance of both the player and their guitar of
choice. On Joe’s request, Dr. Z also pumped up the power supply of the amp to welcome the bevy of effects
on Joe’s pedal board, creang a sustaining clean tone full of detailed shimmer and percussive punch. The
Z-Master is suited for the modern pedal effects player providing ample clean headroom early on the volume
controls, or for the guitarist who simply wants to plug in and crank up, just swing the volume dials clockwise
to unleash thick, tube overdrive and saturaon from the alnico speakers.
The Z-Master has been road-tested through the 2018 concert calendar serving as Joe’s main amp on stages
worldwide. The Z-Master pumps out 30 was through its unique 3×10 speaker configuraon. It uses three,
10” paper voice coil, alnico speakers in a parallel wiring configuraon, specifically designed for this amp. This
creates an intenonal impedance mismatch between the speakers and output transformer, which is an
integral part of the sonic recipe of the amp. As the first “signature series” amp in Dr. Z history, the Z-Master
exhibits a wholly uncanny voice not unlike the man himself, Joe Walsh.
General Informaon
Specificaons
Power Output
Output Tubes
Tubes
Recfier
Controls
Other
Configuraons
Dimension & Weight
30 Wa
2 - 5881
1 - EF86, 1 - 12AX7
1 - 5AR4
Volume 1, Volume 2, Bass, Treble, Presence
External and Internal speaker outs
Paper-wound 1848 Triad output transformer
3x10 Ultra-lite Combo
1×12 LT Combo: 22” W, 21 1/2” H, 10 5/8” D; 42 lbs.
3 - 12AX7

Front Panel:
1 2 34 5 6 7 8 9
10
1. Input: Input jack for your guitar.
2. Vol 1: Controls overall gain of the “bright” channel. This volume will have a brighter, less bass-heavy sound, great
for ghtening up humbucker guitars. It is internally jumpered with the Vol 2 control so that you can finely tune the
amount of brightness into the “normal” channel.
3. Vol 2: Controls overall gain of the “normal” channel. This control will be fuller frequency with more bass and less
treble, suited to faening the sound of single coil guitars. It is internally jumpered with the Vol 1 control so that you
can blend a faer sound into the “bright” channel.
4. Treble: Controls the overall high frequency response.
5. Bass: Controls the overall low frequency response.
6. Presence: Controls the overall high midrange presence of amp.
7. Stand-By: Leave in off posion for 1 minute when powering up the amp. Turn on for play. Place in off posion
for extended break periods.
8. Power: Switch up to turn on amplifier. Switch down to turn off amplifier.
9. Power Indicator: Lights up when power is switched on. If bulb fails replace with type T47.
10. AC Inlet: (Class I Wiring). This device is used for disconnecon from power mains and must remain readily
opearable. The power indicator light does not indicate connecon to power mains. The power cord must be
disconnected to disconnect amplifier from power mains.
11. Fuse: The fuse protects the amp from electrical faults. Replace only with the same rang and type stated below
fuse holder (2A 250v SLO BLO). If the amp repeatedly blows the fuse contact your dealer or Dr. Z Amps.
12. Internal Speaker Jack: Plug in the internal speakers here. Regardless of model, always have a speaker plugged
into the amp when it is powered on. This will prevent damage to your amp.
13. External Speaker Jack: This allows you to use an external speaker cabinet. Connect an 4 ohm extension speaker
for a parallel load of ~2 ohm*. Regardless of model, always have a speaker plugged into the amp when it is
powered on. *Internal speaker impedence mismatch is intenon with this model.
11 12 13
Back Panel:

MADE IN USA
MODEL: ___________________
SERIAL NUMBER: ___________
INPUT VOLTAGE: ____________

Dokument -Name TT.MM.JJJJ 1 of 1
Document: CE –ZA-47
Manufacturer: Dr. Z Amplication
17011 Broadway Ave.
Maple Heights, OH 44137 -3407
USA
We declare that the designated product (s)
DR. Z Z-Master
is/are in conformity with the European Directives:
2014/30/EU EMC Directive of 26 February 2014
20 11/65/EU
2014/35/EU
RoHS Directive of 8 June 2011
Electrical equipment designed for use within certain voltage limits
This declaration certies compliance with the indicated directives but implies no warranty of
properties. The safety instructions of the accompanying documentation shall be observed.
This declaration of conformity is issued under the sole responsibility of the manufacturer.
Issuer: Dr. Z Amplication
17011 Broadway Ave.
Maple Heights, OH 44137 -3407
USA
Place, date: Maple Heights, OH USA , 01.FEBRUARY.2019
Legally binding signature:
M.D. Zaite, General Manager, Dr. Z Amps
EC/EU Declaration of Conformity
