dreo DR-HFV001 User manual

Quick Start
Guide
Cordless Stick
Vacuum Cleaner
ASSEMBLING YOUR
VACUUM CLEANER
Assembly
For normal operation, all accessories must be attached securely.
Assembly for cleaning ceilings, floors and corners:
click
click
click
Assembly for cleaning furniture surfaces:
Assembly for cleaning in a flexible way:
click
click
CHARGING YOUR
VACUUM CLEANER
Fully charge your new vacuum before first use. You can connect to charger
either directly or on the dock.
Installing the Battery
Charging
When battery level is below 20%, the vacuum will switch to
Turbo mode automatically.
To install, slide the battery
into the slot in the back of
the main body.
To remove, press and hold
the Battery Release Button
then slide out the battery.
Tip:
1
2
• Install on concrete load-bearing walls only.
• Do not drill into any damp walls like bathroom and kitchen walls.
Charging Directly
Flip open the charging cap on the main body and charge directly.
Charging on the Dock
1. Find an ideal height between 50 and 60 inches (125 and 150 cm). Apply
the sticker on the wall and drill through the holes, then install the plastic
anchors.
2. Align the holes in the docking station with the anchors and drill the
screws into place.
3. Connect the charger into the charging port at the bottom of the station.
4. Rest the vacuum cleaner and accessories onto the docking station.
50-60 in
1 2 3 4

Quick Start
Guide
Cordless Stick
Vacuum Cleaner
ASSEMBLING YOUR
VACUUM CLEANER
Assembly
For normal operation, all accessories must be attached securely.
Assembly for cleaning ceilings, floors and corners:
click
click
click
Assembly for cleaning furniture surfaces:
Assembly for cleaning in a flexible way:
click
click
CHARGING YOUR
VACUUM CLEANER
Fully charge your new vacuum before first use. You can connect to charger
either directly or on the dock.
Installing the Battery
Charging
When battery level is below 20%, the vacuum will switch to
Turbo mode automatically.
To install, slide the battery
into the slot in the back of
the main body.
To remove, press and hold
the Battery Release Button
then slide out the battery.
Tip:
1
2
• Install on concrete load-bearing walls only.
• Do not drill into any damp walls like bathroom and kitchen walls.
Charging Directly
Flip open the charging cap on the main body and charge directly.
Charging on the Dock
1. Find an ideal height between 50 and 60 inches (125 and 150 cm). Apply
the sticker on the wall and drill through the holes, then install the plastic
anchors.
2. Align the holes in the docking station with the anchors and drill the
screws into place.
3. Connect the charger into the charging port at the bottom of the station.
4. Rest the vacuum cleaner and accessories onto the docking station.
50-60 in
1 2 3 4

Quick Start
Guide
Cordless Stick
Vacuum Cleaner
ASSEMBLING YOUR
VACUUM CLEANER
Assembly
For normal operation, all accessories must be attached securely.
Assembly for cleaning ceilings, floors and corners:
click
click
click
Assembly for cleaning furniture surfaces:
Assembly for cleaning in a flexible way:
click
click
CHARGING YOUR
VACUUM CLEANER
Fully charge your new vacuum before first use. You can connect to charger
either directly or on the dock.
Installing the Battery
Charging
When battery level is below 20%, the vacuum will switch to
Turbo mode automatically.
To install, slide the battery
into the slot in the back of
the main body.
To remove, press and hold
the Battery Release Button
then slide out the battery.
Tip:
1
2
• Install on concrete load-bearing walls only.
• Do not drill into any damp walls like bathroom and kitchen walls.
Charging Directly
Flip open the charging cap on the main body and charge directly.
Charging on the Dock
1. Find an ideal height between 50 and 60 inches (125 and 150 cm). Apply
the sticker on the wall and drill through the holes, then install the plastic
anchors.
2. Align the holes in the docking station with the anchors and drill the
screws into place.
3. Connect the charger into the charging port at the bottom of the station.
4. Rest the vacuum cleaner and accessories onto the docking station.
50-60 in
1 2 3 4

Quick Start
Guide
Cordless Stick
Vacuum Cleaner
ASSEMBLING YOUR
VACUUM CLEANER
Assembly
For normal operation, all accessories must be attached securely.
Assembly for cleaning ceilings, floors and corners:
click
click
click
Assembly for cleaning furniture surfaces:
Assembly for cleaning in a flexible way:
click
click
CHARGING YOUR
VACUUM CLEANER
Fully charge your new vacuum before first use. You can connect to charger
either directly or on the dock.
Installing the Battery
Charging
When battery level is below 20%, the vacuum will switch to
Turbo mode automatically.
To install, slide the battery
into the slot in the back of
the main body.
To remove, press and hold
the Battery Release Button
then slide out the battery.
Tip:
1
2
• Install on concrete load-bearing walls only.
• Do not drill into any damp walls like bathroom and kitchen walls.
Charging Directly
Flip open the charging cap on the main body and charge directly.
Charging on the Dock
1. Find an ideal height between 50 and 60 inches (125 and 150 cm). Apply
the sticker on the wall and drill through the holes, then install the plastic
anchors.
2. Align the holes in the docking station with the anchors and drill the
screws into place.
3. Connect the charger into the charging port at the bottom of the station.
4. Rest the vacuum cleaner and accessories onto the docking station.
50-60 in
1 2 3 4

m
ST/PDT
[e-mail]
Mon - Fri, 9:00 am-5:00 pm P
[phone]
www.dreo.com
Looking for help?
Contact us to get expert support.
Rev_1.0_EN
GENTLE REMINDER
Check the appliance regularly and contact us if it shows any of the follow-
ing signs:
- Power cord or plug is damaged.
- Loud noise, unusual smell or excessive heat.
Scan the QR code below or search "Dreo House Cleaning"
to join our Facebook group. Our online engineers are always ready to
solve any product problems you may experience.
1. Rotate the filter lid counterclockwise and pull out the filter unit.
2. Hold the filter while rotating the lid to separate filter and lid.
3. Wash and dry up completely before installing them back into place.
Clean the filter regularly for blockages. It is recommended to replace the
filter every 3 months or when the icon alerts on the LED display.
HEPA Filter
Do not put the filter in a dishwasher, washing machine,
tumble dryer, oven, microwave or near a naked flame.
Cyclone Assembly
1. Hold the cyclone assembly and rotate to release it from the main body.
2. Wash and dry up completely before installing it back into place.
24
hrs
Do not wash the main body.
Brushroll
1. Slide the tab on the underside of the floor brush head to pop up brushroll.
2. Remove blockages on the brushroll and near the suction mouth.
3. Wash the brushroll with cold water and dry up completely.
4. Insert the brushroll back and make sure it clicks in place.
24
hrs
• Check the brushroll if the headlights on the brush head
won’t come on.
• Wash the brushroll only.
Do not wash the floor/carpet brush head.
USING YOUR
VACUUM CLEANER
Mode Button
LED Display
WARNING:
Do not use to suck up water or
other liquids.
Power Button
Eco Low power suction, suitable for cleaning
hard floors.
Turbo High power suction, suitable for cleaning
carpets and rugs.
Max Maximum power suction, suitable for deep
cleaning tasks.
Auto Adapts the suction power to surfaces
automatically.
Dustbin
1. Hold the main body in a downwards
position.
2. Pull the dustbin cover as shown to dump
the dust out.
Keep the dust below the MAX fill line. Using your vacuum when dust is
above the MAX fill line may cause malfunction.
CLEANING AND
MAINTENANCE
