DRIVEN DRWC5CM User manual

Installation Instructions | Owners Manual
Due to continuous improvement of the product, specifications are subject to change without notice.
TM

MONITOR SPECIFICATIONS
Panel:
Resolution:
Power:
Storage temperature:
Working temperature:
5 inch Digital Panel Screen
800*480
DC12V
-22℉〜176℉
-4℉to 158℉
CAMERA SPECIFICATIONS
Image Sensor:
Effective Pixels:
System:
IR Night Vision:
Night vision visible distance:
Power:
Storage temperature:
Working temperature:
Operating frequency range Cover:
1/3 sensor
720x576 pixel
AHD
with IR
about 9 ft.
DC 12V & 24V
-22℉〜176℉
-4℉to 158℉
2.4GHz~2.4835GHz
FEATURES
• 5" High Definition TFT LCD Monitor with Anti-glare Shade
• Weatherproof IP67 Reverse Camera with 120 Degree viewing Angle
• Wireless Camera Uses a Digital Signal that can be transmitted for
Long distances, Suitable for RV Vehicles
• 12/24V DC Power Supply
Congratulations on purchasing the Driven™ DRWC5CM wireless reverse camera
system. This system uses the latest technology available to ensure that it is durable,
reliable and can provide a clear image of the view behind your vehicle while reversing.
This product uses the latest digital technology to ensure durability and simple DIY
installation.
2

Please familiarize yourself with these instructions before starting your
installation.
The Monitor is equipped with a cigarette lighter plug that can be easily inserted
into the cigarette lighter socket in the vehicle.
MONITOR INSTALLATION
1) Find a suitable location on your dashboard or window screen for your
monitor. Please ensure it is in a location where it is easily viewable and
does not disturb your vision of the road while driving.
2) Clean the location that you have decided to place the monitor to
ensure that it is dust and grease free ( it is recommended to use alcohol
wipes to do this)
3) Mount the monitor base using the supplied suction cup.
STANDARD OPERATION
After the monitor and camera have been successfully installed and paired
(if required), turn the ignition key on ensuring the RED power button on
the monitor cigarette plug is switched on, View the image from the
camera on the monitor. If no image is visible, check all wiring connections
are securely fastened. If the image displays properly, please follow the
instructions below to adjust your screen settings:
3

ADJUSTMENT AND CAMERA PAIRING SETTINGS
After camera and monitor has been
successfully paired, hold the K3 button for
3 seconds to toggle reversing lines on the
screen. This is shown in the picture:
K1: In Menu Mode use K1 as UP function, when not in Menu Mode K1 will Turn on/off
Scale Lines.
K2: Press Shortly to enter Menu Mode. Hold for 3 second to confirm Function selection.
K3: In Menu Mode use K3 as Down Function.
Use the K1 or K3 to choose the PAIRING, PICTURE,MIR-FLIP.
PAIRING: In Menu Mode select Pairing and hold K2 for 3 seconds to confirm Pairing
Mode.
4

PICTURE: In Menu Mode select Picture and hold K2 for 3 seconds to confirm Picture Image
Adjusting.
MIR-FLIP: In Menu Mode select MIR-FLIP and hold K2 for 3 seconds to confirm Image
Reverse Mode.
5

CAMERA INSTALLATION
CAMERA WIRING CONNECTION
Proper installation of the Camera is critical to the overall view you will be able to
see from your in-cab DRIVEN DRWC5CM wireless monitor. In most cases the
rear-view camera mount on an RVs is mounted just below the rear top clearance
lights. If your clearance lights are too low, this shouldn’t be a problem, simply plan
to for installation of the camera at the highest point of the rear outer panel of
your RV.
Most modern-day RVs are prewired with a 12v DC power supply cable that
hidden behind a camera mount cover. If this is the case, simply remove the 4
mounting screws off the pre-mounted base, connect the simple 2 wire red and
black cables to the new harness and replace the complete mount and base with
the DRIVEN DRWC5CM camera by screwing it down securely with the previously
removed screws.
In the event that your RV or trailer does not come prewired with a 12v DC power
supply at the desired location, you will have to carefully run a power supply cable
to the location on your RV were you wish to mount your camera system. Plan
your wire route for under the RV trailer. Be sure to avoid areas that could be
affected by heat or abrasion. Make sure to properly fuse the power supply cable
at its origin.
Once the camera is powered up, follow the pairing instructions provided with the
DRIVEN DRWC5CM wireless monitor. Align the camera and test the angle of the
view. Make sure to adjust the angle several times to check your options. Once you
have chosen the specific angle for the camera you are good to go.
Camera Wiring Connection
6

NOTES

TM
LIMITED WARRANTY
DrivenTM warrants any products purchased in the U.S.A. from an
authorized Driven TM dealer.
All Products are warranted to be free from defects in material and
workmanship under normal use and service for a period of one (1) year.
This warranty applies to the original purchase only.
DrivenTM will either repair or replace (at its own discretion) any unit that
has been found to be defective and under warranty provided the defect
occurs within the one (1) year warranty period.
This limited warranty does not exted to units that have been subjected to
misuse, abuse, neglect, or accident. In Driven’sTM judgment, products that
show evidence of having been altered, modied or serviced without
Driven’s authorization, will be ineligible under this warranty.
To Obtain warranty service please contact your retailer or visit our
website at www.drivenelectronics.com
