DRIVEN REFRIGERATION Series User manual

SIDE-BY-SIDE REFRIGERATOR / FREEZER
DELUXE DESIGN / HIGH EFFICIENCY
REFRIGERATION SERIES
Instruction Manual
MODEL: R-700S-D (Stainless/Black)
Before using your refrigerator, please read this
manual carefully and keep it for future reference.

Welcome & Congratulations
Thank you for purchasing this quality CONTOURE™ appliance.
Congratulations on your new Deluxe Side-by-Side Refrigerator/Freezer.
For your safety and full enjoyment of this product, always read the instruction book carefully
before using.
Don’t forget to register your product at www.contoureusa.com for updates and other
relevant information.
This manual contains important information on the installation, use, and care of your appliance.
Please read this manual carefully before installation and operation of this machine to prevent injury and property damage and
to take full advantage of your appliances benefits and features.
SAVE THESE INSTRUCTIONS
Photograph above shows full refrigerator / freezer diagram.

Contents
Safety And Precautions 2
Safety and precautions 2
Important safety instructions 4
Important safe guides 5
Critical installation warnings 6
Installation Requirements 7
Parts and accessories 7
Before using your appliance 8
Installation 9
Electrical requirements 10
Electrical connection 11
Getting Started 12
Operating your appliance 12
Defrosting your appliance 13
Freezing fresh foods 14
Care And Maintenance 15
Relocating your appliance 16
Troubleshooting Tips 17
Servicing your Appliance 18
Warranty 19
Obtaining Service 20

Safety and Precautions
SAFETY AND PRECAUTIONS
Thank you for purchasing this quality CONTOURE™ appliance.
This manual contains important information on the installation, use, and care of your appliance.
Please read this manual carefully before installation and operation of this machine to prevent
injury and property damage.
WHATYOU NEED TO KNOW ABOUTSAFETY INSTRUCTIONS
Warnings and Important Safety Instructions in this manual DO NOT cover all possible
conditions and situations that may occur.It is your responsibility to use common sense,
caution and care when installing, maintaining and operating this appliance.
IMPORTANTSAFETY SYMBOLS AND PRECAUTIONS WARNING
This symbol indicates that hazards or unsafe practices may cause
serious personal injury or death.
To reduce the risk of fire, explosion, electric shock, or personal
injury when using your appliance, these basic safety precautions
MUST be followed.
These warnings are to prevent injury to you and to others. Please
follow the explicitly.
After reading this section, keep it in a safe place for future reference.
STATE OF CALIFORNIA PROPOSITION 65 WARNINGS
The California Safe Drinking Water and Toxic Enforcement Act requires
the Governor of California to publish a list of substances known to the
State of California to cause cancer, birth defects, or other reproductive
harm, and requires business to warn of potential exposure to such
substances.
This product contains a chemical known to the State of California to
cause cancer, birth defects, or other reproductive harm. This appliance
can cause low-level exposure to some of the substances listed,
including benzene, formaldehyde, and carbon monoxide.
WARNING
SAVE THESE INSTRUCTIONS
02

Safety and Precautions
REFRIGERATOR SAFETY
Your safety and the safety of those around you is very important.
This manual contains important information on the installation, use, and care of your appliance.
Please read this manual carefully before installation and operation of this machine to prevent
injury and property damage.
All safety messages will follow the Safety Alert Symbol and either the words “DANGER,”
“WARNING,” or “CAUTION.”
DANGER means that failure to heed this
safety statement may result in severe
personal injury or death.
WARNING means that failure to heed this
safety statement may result in extensive
product damage, serious personal injury, or
death.
CAUTION means that failure to heed this
safety statement may result in minor or
moderate personal injury, property or
equipment damage.
STATE OF CALIFORNIA PROPOSITION 65 WARNINGS
The California Safe Drinking Water and Toxic Enforcement Act requires
the Governor of California to publish a list of substances known to the
State of California to cause cancer, birth defects, or other reproductive
harm, and requires business to warn of potential exposure to such
substances.
This product contains a chemical known to the State of California to
cause cancer, birth defects, or other reproductive harm. This appliance
can cause low-level exposure to some of the substances listed,
including benzene, formaldehyde, and carbon monoxide.
WARNING
SAVE THESE INSTRUCTIONS
All safety messages will alert you to know what a potential hazard is, tell you how to
reduce the chance of injury and let you know what can happen if the instructions are not
properly followed.
03
For more information go to www.p65warnings.ca.gov.

Safety and Precautions
IMPORTANT SAFEGUIDES
BEFORE the refrigerator is used, it must be properly positioned and installed as described in this
manual. Please read the manual carefully. To reduce the risk of fire, electrical shock, or injury when
using the refrigerator, follow basic precautions, including the following:
• Plug into a grounded 3-prong outlet, do not remove grounding prong, do not use
an adapter, and do not use an extension cord.
• It is recommended that a separate circuit, serving only your refrigerator be
provided. Use receptacles that cannot be turned off by a switch or pull chain.
• Never clean refrigerator parts with flammable fluids. These fumes can create a fire
hazard or explosion. And do not store or use gasoline or other flammable vapors
and liquids in the vicinity of this or any other appliance. The fumes can create a fire
hazard or explosion.
• Before proceeding with cleaning and maintenance operations, make sure the
power line of the unit is disconnected.
• DO NOT connect or disconnect the electric plug when your hands are wet.
• Unplug the refrigerator or disconnect power before cleaning or servicing. Failure to
do so can result in electrical shock or death.
• DO NOT attempt to repair or replace any part of your refrigerator unless it is
specifically recommended in this manual. All other servicing should be referredto a
qualified technician.
SAVE THESE INSTRUCTIONS
04

Safety and Precautions
IMPORTANT SAFEGUIDES
Please follow WARNING call-outs below only when applicable to your model:
• Use two or more people to move and install refrigerator. Failure to do so can result
in back or other injury.
•The tubing shall be protectedto the extent thatit will not be grasped or
handled duringmoving ofthe product. Duringthe movement ofthe product,
should not damage therefrigerant circuit.
• To ensure proper ventilation for your refrigerator, the front of the unit must be
completely unobstructed. Choose a well-ventilated area with temperatures above
60°F (16
°
C) and below 90°F ( 32°C). This unit must be installed in an area protected
from the element, such as wind, rain, water spray or drips.
• The refrigerator should not be located next to ovens, grills or other sources of high
heat.
• The refrigerator must be installed with all electrical, water and drain connections in
accordance with state and local codes. A standard electrical supply (115 V AC
only, 60 Hz), properly grounded in accordancewiththe National Electrical
Code and local codes and ordinances is required.
• DO NOT kink or pinch the power supply cord of refrigerator.
• The fuse (or circuit breaker) size should be 15 amperes.
• It is important for the refrigerator to be leveled in order to work properly. You may
need to make several adjustments to level it.
• All installation must be in accordance with local plumbing code requirements.
• Make certain that the pipes are not pinched or kinked or damaged during
installation.
• Check for leaks after connection.
• Never allow children to operate, play with or crawl inside the refrigerator.
• Although the unit has been tested at the factory, due to long-term transit and
storage, the first batch of ice cubes must be discarded.
• DO NOT use solvent-based cleaning agents or abrasives on the interior. These
cleaners may damage or discolor the interior.
• DO NOT use this apparatus for anything other than its intended purpose.
SAVE THESE INSTRUCTIONS
05

Safety and Precautions
CRITICAL INSTALLATION WARNINGS
The installation of this appliance MUST be performed by a qualified
technician or service company.
Failing to have a qualified technician or service company install the
oven may result in electric shock, fire, an explosion, problems with
the product or injury.
Keep all packaging materials out of the reach of children. DO NOT
allow children to use them for play.
SAVE THESE INSTRUCTIONS
THINGS TO REMEMBER
READ this guide carefully it is intended to help you operate and maintain your
new Refrigerator/Freezer.
Keep your ORIGIANL proof of purchase receipt with this guide to help during
the warranty period.
If you need to locate your model number or unit serial number you can find
them on the plate located on the rear wall of your appliance. Use these
numbers in any correspondence or repair request.
If you received a damaged Refrigerator/Freezer, IMMEDIATELY contact the
dealer that sold you the unit.
Save time and money, before calling for service please check the
TROUBLESHOOTING GUIDE located in the back of the manual. It lists causes
of minor operating problems that you can correct yourself.
THIS REFRIGERATOR / FREEZER IS NOT DESIGNED FOR THE STORAGE OF
MEDICINE OR OTHER MEDICAL PRODUCTS.
06

Parts & Accessories
SETTING UP YOUR REFRIGERATOR /FREEZER
Thank you for purchasing this quality CONTOURE™ appliance.We are excited for
you to get started using your new outdoor refrigerator/freezer.
Remove all packaging materials and accessories from the carton and oven cavity.
Examine your new unit for any damage, like dents, or a broken door. DO NOT
continue with installation if the unit is damaged.
Your new refrigerator / freezer comes with the following accessories:
1. Decorative Countertop
2. Freezer top drawer
3. Freezer door
4. Leveling Legs
5. Interior Light
6. Light switch
7. Door bins (3-in total)
8. Refrigerator Shelves (3-in total)
9. Cabinet
07

Installation Requirements
IMPORTANT SAFETY INSTRUCTIONS
To reduce the risk of fire, electrical shock or injury when using your new model
refrigerator/freezer, follow these basic precautions:
Readallinstructionsbeforeusingtherefrigerator-freezer.
DANGERorWARNING:Riskofchildentrapment.Childentrapmentandsuffocationarenot
problemsofthepast.Junkedorabandonedrefrigerator-freezersarestilldangerous...evenif
theywill“justsitinthegarageafewdays.”
Beforeyouthrowawayyouroldrefrigerator-freezer: Takeoffthedoors.Leavetheshel vesin
placesothatchildrenmaynoteasilyclimbinside.
Neverallowchildrentooperate,playwith,orcrawlinsidetherefrigerator-freezer.
Nevercleanrefrigerator-freezerpartswithflammablefluids.Thefumescancreateafirehazard
orexplosion.
Donotstoreorusegasolineoranyotherflammablevaporsandliquidsinthevicinityofthisorany
otherrefrigerator-freezer.Thefumescancreateafirehazardorexplosion.
SAVE THESE INSTRUCTIONS
BEFORE USING YOUR APPLIANCE
REMOVE alloftheexteriorandinteriorpackaging.
ChecktobesureyouhaveALLofthefollowingparts:
•3GlassRefrigeratorShelves
•3DoorBins
• 1InstructionManual
Before connectingtheunittothepowersource,letitsetuprightforapproximately2hours.
Thiswillreducethepossibilityofamalfunctioninthecoolingsystemfromhandlingduring
transportation.
Cleantheinteriorsurfacewithlukewarmwaterusingasoftcloth.
08

Safety & Installation
INSTALLATION OF YOUR APPLAINCE
Place your refrigerator-freezer on a floor that is strong enough to support the refrigerator-
freezer when it is fully loaded. To level your Refrigerator/Freezer, adjust the leveling legs at
the bottom of unit.
Allow 15cm of space between the back and sides of the unit, which allows the proper air
circulation to cool the compressor and condenser.
Place the unit away from direct sunlight and sources of heat (stove, heater, radiator, etc.).
Direct sunlight may affect the acrylic coating and heat sources may increase electrical
consumption. Extremecold ambient temperatures may also cause the
Refrigerator/Freezer not to perform properly.
Avoid placing the unit in moist areas.
Plug the unit into an exclusive properly installed-grounded wall outlet.
DO NOT under any circumstances cut or remove the third (ground) prong from the power
cord. Any questions concerning power and/or grounding should be directedtoward a
certified electrician.
SAVE THESE INSTRUCTIONS
09

Safety & Installation
ELECTRICALCONNECTION
This appliance should be properly grounded for your safety. The power cord of this
appliance is equipped with a three-prong plug which mates with standard three prong wall
outlets to minimize the possibility of electrical shock.
DO NOT under any circumstances cut or remove the third ground prong from the power
cord supplied. For personal safety, this appliance must be properly grounded.
The cord should be secured behind the appliance and not left exposed or dangling to
prevent accidental injury.
The appliance should always be plugged into its own individual electrical outlet which has
a voltage rating that matches the rating label on the appliance. This provides the best
performance and also prevent overloading house wiring circuits that could cause a fire
hazard from overheated. Never unplug the appliance by pulling the power cord. Always
grip the plug firmly and pull straight out from the receptacle. Repair or replaceimmediately
all power cords that have become frayed or otherwise damaged. Do not use a cord that
shows cracks or abrasion damagealong its length or at either end. When moving the
appliance, be careful not to damage the power cord.
SAVE THESE INSTRUCTIONS
EXTENSION CORD
It is STRONGLY recommended that you do not use an extension cord with this appliance
to avoid potential safety hazards under certain conditions.
If you do decide to use an extension cord it is absolutely necessary that it be a UL/CUL-
Listed, 3-wire grounding type appliance extension cord having a grounding type plug and
outlet and that the electrical rating of the cord be 220 volts.
10

Safety, Precautions & Installation
ELECTRICALCONNECTION
SAVE THESE INSTRUCTIONS
SURGE PROTECTOR
Most electrical appliances use a series of electric control boards to operate. These boards
are very susceptible to power surges and could be damaged or destroyed.
If the appliance is going to be used in an area or if your city / country is prone to power
surges / outages; it is suggested that you use a power surge protector for all electrical
devices / appliances you use. The surge protector that you select must have a surge block
high enough to protect the appliance it is connected to. If you have any questions
regarding the type and size of surge protector needed contact a licensed electrician in your
area.
Damages due to power surges are not considered a manufacturer covereddefect and will
void your product warranty.
(continued)
11

Getting Started
OPERATINGYOUR APPLIANCE
INTERIOR LIGHT
The temperature control is located in the refrigerator
section.
This control will adjust the temperature for both the
refrigerator and freezer sections.
The first time you turn the unit on, set the temperature
control to “7” the coldest.
(SETTINGTHETEMPERATURECONTROL)
The range of the temperature controls are from position “0” or NO COOLING to
“7” the coldest.
After 24 to 48 hours, adjust the temperature control to the setting that best suits
your needs.
We recommend the setting number “5” setting for standardrefrigerator use.
When you open the door the light automatically TURN ON.
When you close the door the light will automatically turn OFF automatically.
DEFROSTING YOUR APPLIANCE
For the most efficient operation of your Refrigerator/Freezer and to minimize energy
consumption we recommend defrosting the freezer compartment when the frost on the
appliance walls exceeds ~1cm in thickness.
There is no need to defrost the refrigerator compartment. Any ice the is deposited on
the inner back wall will defrost automatically.
Ice may build up on the inner back wall during operation. The unit is designed so when
the compressor is not operating ice will automatically begin to defrost. Water droplets
collected during this process will drain through to an outlet in the inner back wall of the
unit onto a drain pan located above the compressor. From there the water will
evaporate.
12

Getting Started
DEFROSTINGYOUR APPLIANCE
DO NOT use boiling water to attempt to defrost your appliance. This may damage some of
your Refrigerator/Freezer’s components.
NEVER use a sharp or metallic instrument to remove frost from your appliance. It may
damage the cooling coils and will void the warranty. Should you desire to remove frost
from your appliance, we recommend using a plastic scraper.
(continued)
HOW TO DEFROST YOUR APPLIANCE
Reset the thermostat to the “0” position and disconnect the power supply.
Remove the frozen food from the appliance and place it in a cooler to keep cool.
Leave the door open for a while so that you can easily scrape frost off of the surface.
Please remember DO NOT use sharp or metallic instruments to remove frost from
your appliance.
When using a PLASTIC scrapper be careful NOT to damage the inner surface of the
freezer.
Wipe up the scrapped up frost and ice to remove it before it is completely defrosted.
13

Getting Started
Proper use of this appliance, adequately packed food, correct temperaturesettings and
taking into account hygienic precautions will substantially influence the quality of freezing
your food and/or storing frozen foods.
The freezer compartment is designed for the ”long-term” storage of frozen food.
The “life” of the foods stored varies and we recommend that you do not exceed the storage
times given by the food manufacturer.
Pre-packagedor commercially frozen foods should be stored in accordance with the frozen
food’s manufacturer instructions.
Carefully select the food you intended to freeze to make sure it is of adequate quality and
suitable for freezing.
Use correct packagingand wrap foods tightly when freezing. Packaging should be airtight
and shouldn’t leak.
Take all necessary sanitary precautions when preparing foods to be frozen. Foils and bags
should be soft enough to tightly wrap around the foods you are preparing to freeze.
We recommend marking packages with date of freezing, type and amount of food frozen.
If the load amount inside of the freezer is too large, the quality of freezing will be reduced
whereby affecting the quality of frozen food. Please be careful not to overload your
freezer’s capacity.
14

Care and Maintenance
CLEANINGYOUR APPLIANCE
The interior surface of your Refrigerator/Freezer is designed to NOT absorb odors but we
recommend an occasional wipe down with a water/baking soda solution to keep the inside
fresh. (EXAMPLE: 2 tablespoons of baking soda for every 1 quart of warm water).
Before cleaning, turn the temperature dial to “0” and unplug the unit.
DO NOT clean any part of this appliance without unplugging the cord.
CAUTION failure to unplug the Refrigerator/Freezer could result in electrical shock or
personal injury.
Carefully remove food and baskets and place them in a cooler to protect your food.
The outside of the unit should be cleaned with mild detergent and warm water.
DO NOT use abrasivecleaners or sharputensils to clean your appliance.
DO NOT use commercial cleaners on any part of your appliance.
DO NOT drop the shelves inside your unit or they may break.
POWER FAILURE
Most power failures are corrected within a few hours and should not affect the temperature
of your Refrigerator/Freezer if you minimize the number of times the door is opened.
If the power is going to be off for a longer period of time, you need to take the proper steps
to protect your food.
VACATION TIME
If you are not going to use your unit for a short period of time, you may leave the unit
operating for a period of three weeks or less.
If you are nog going to use your appliance for several months, remove all food and
unplug the power cord. Clean and dry the interior thoroughly. To prevent odor and
mold growth, leave the door slightly open.
15

Care and Maintenance
RELOCATINGYOUR APPLIANCE
If you wish to relocate your Refrigerator/Freezerplease follow the following steps:
• Remove ALL food (place food in a cooler if necessary)
• Securely tape down ALL loose items inside the unit (including glass shelves
and /or storage bins.
• Turn the levelling screws up to the base of the unit to avoid damage
• Tape both, refrigerator and freezer doors shut
• Be sure the unit REMAINS in the upright position during transportation
TIPS TO SAVE ENERGY & REDUCE CONSUMPTION
If possible, keep your unit in the coolest area of the room, away from heat producing
appliances or heating ducts, and out of direct sunlight.
Allow hot foods cool to room temperature before placing them in the refrigerator.
Overloading the unit forces the compressor to run longer. Foods that freeze too slowly
may lose quality, or spoil.
Be sure to wrap foods properly, and wipe containers dry before placing them in the unit.
This cuts down on frost build-up inside the freezer.
Organize and label food to reduce door openings and extended heat exposure by leaving
the door open when searching for foods.
Remove as many items as needed at one time, and close the door as soon as possible.
16

Troubleshooting
FREQUENTLY ASKED QUESTIONS
You can solve many common ”problems” with your Refrigerator/Freezer by referencing our
“Frequently asked Question”guide below.
Please try these suggestions prior to calling a qualified service technician to serviceyour
unit.
UNIT DOES NOT OPERATE
• Check to be sure the unit is plugged in
• The circuit breaker may have tripped or there is a blown fuse
• The Refrigerator/Freezer temperature control is set to “0”
COMPRESSOR TURNS ON / OFF FREQUENTLY
• Check to see if the room temperature is hotter than normal
• A large amount of food has been added to the Refrigerator or Freezer
exceeding the recommend load capacity
• The doors are opened too often or left open for too long
• The unit’s temperature control is NOT set correctly
• The door gaskets do not seal properly
• The Refrigerator/Freezer does NOT have the correct clearance(s)
VIBRATION(S)
• Check to make sure the unit is level
THE UNIT SEEMS TO MAKE TOO MUCH NOISE
• Some rattling noise may come from the flow of the refrigerant which is normal
• As each cycle ends you may hear some “gurgling” sounds coming from the flow
of refrigerant–this is normal
• Contraction and expansion of the inside walls may cause “popping” and/or
“crackling” noises –this is normal
• Check to make sure the unit is sitting level
THE DOORS WILL NOT CLOSE PROPERLY
• Make sure the doors are properly installed and not reversed
• Check to make sure the unit is sitting level
• The door gasket may be dirty
• The crisper bin is not in it’s proper position
If you have a problem that you cannot solve, please do not hesitate to call our service line.
17
