INSTALLATION MANUAL
ECO-55 / ECO-55 CT / ECO-55 ST
(DP00070, DP00072 & DP00071 model)
Safety tested according to ULC S627,UL1482 and
ASTM E1509 by an accredited laboratory
INSTALLATIONBYAPROFESSIONAL
IS STRONGLY RECOMMENDED
Stove Builder International inc.
250, rue de Copenhague,
St-Augustin-de-Desmaures (Québec) Canada
G3A 2H3
Customer service : 418-908-8002
www.drolet.ca
CONTACT LOCAL BUILDING OR FIRE OFFICIALS ABOUT RESTRICTIONS AND INSTALLATION
INSPECTION REQUIREMENTS IN YOUR AREA.
PLEASE READ THIS ENTIRE MANUAL BEFORE INSTALLATION AND USE OF THIS PELLET FUEL-
BURNING ROOM HEATER. FAILURE TO FOLLOW THESE INSTRUCTIONS COULD RESULT IN
PROPERTY DAMAGE, BODILY INJURY OR EVEN DEATH.
READ AND KEEP THIS MANUAL FOR REFERENCE
This manual is available for free download on the manufacturer’s website. It is a copyrighted document. Re-sale
is strictly prohibited. The manufacturer may update this manual from time to time and cannot be responsible
for problems, injuries, or damages arising out of the use of information contained in any manual obtained from
unauthorized sources.
Printed in Canada 45876IA
202
ENGLISHFRANÇAIS
Page 2 INSTALLATION MANUAL ECO-55 / ECO-55 CT / ECO-55 ST
ENGLISH
1. SAFETY INFORMATION
We highly recommend that our pellet burning hearth
products be installed and serviced by professionals
Energy Technology Transfer) or in Quebec by APC
If this appliance is not properly installed,
combustible materials near it may overheat. To
instructions in this manual exactly. Contact local
installation inspection requirements in your area.
Please read this entire manual before you install and
use your new stove. You may need to get a building
permit for the installation of this appliance and the
venting system that it is connected to. Consult your
before installation. We recommend that you also
WARNING
IFTHISSTOVEISNOTPROPERLYINSTALLED,
AHOUSE FIRE MAYRESULT.TOREDUCETHE
RISK OF FIRE, FOLLOW THE INSTALLATION
INSTRUCTIONS.
NOTICE
published in any other media (owner’s manual,
BURNING ANY SOLID FUELS GENERATES
CARBON MONOXIDE IN LOW
CONCENTRATION. THIS GAS IS EVACUATED
BY THE EXHAUST VENTING SYSTEM. IN
HIGHER CONCENTRATIONS, CARBON
MONOXIDEISTOXICANDMAYCAUSEDEATH.
TO PREVENT THIS, ENSURE THAT YOUR
EXHAUST VENTING SYSTEM IS AIRTIGHT.
WARNING
THIS STOVE IS NOT RECOMMENDED TO BE
INSTALLED IN A BEDROOM.
CAUTION
THIS STOVE MUST BE CONNECTED TO
A STANDARD 120V / 60HZ, GROUNDED
ELECTRICAL OUTLET. DO NOT USE AN
ADAPTERPLUGORSEVERTHEGROUNDING
PLUG. DO NOT ROUTE THE ELECTRICAL
CORDUNDERNEATH,INFRONTOROVERTHE
STOVE.
WARNING
THIS STOVE IS MOBILE HOME APPROVED
AND REQUIRES INSTALLATION OF A FRESH
AIR KIT, SOLD SEPARATELY. THE STOVE
MUSTBEATTACHED TOTHESTRUCTUREOF
THE MOBILE HOME AND THE STRUCTURAL
INTEGRITY OF THE MOBILE HOME FLOOR,
WALL, AND CEILING / ROOF MUST BE
MAINTAINED.DONOTINSTALLINASLEEPING
ROOM.
NOTICE
sources or modifying components is prohibited
appliance that has not been approved in writing by
the testing authority is prohibited and violates CSA
WARNING
NOTICE
When locating your appliance, make sure the vent
will not interfere with any truss, roof beams, wall
studs, water pipes or electrical wiring. It may be
easier to relocate appliance than to rework the
building structure.
Page 3
INSTALLATION MANUAL ECO-55 / ECO-55 CT / ECO-55 ST
ENGLISH
NOTICE
This stove has been developed and built for
residential supplementary heat source. Commercial
and industrial use is prohibited and will void the
warranty.
NOTICE
Stove Builder International inc. (SBI) grants no
warranty, implied or stated, for the poor installation
of your appliance and assumes no responsibility of
any consequential damages.
This product can expose you
to chemicals including carbon
monoxide, which is known to the
State of California to cause cancer,
birth defects or other reproductive
harm. For more information go to
www.P65warnings.ca.gov/
Page 4 INSTALLATION MANUAL ECO-55 / ECO-55 CT / ECO-55 ST
ENGLISH
1. SAFETY INFORMATION ............................................................................... 2
2. GENERAL FEATURES.................................................................................. 5
2.1 OVERALL DIMENSIONS (DP00070-DP00072) ...............................................................5
2.2 OVERALL DIMENSIONS (DP00071)................................................................................6
3. CLEARANCES TO COMBUSTIBLE MATERIALS ...................................... 7
3.1 CLEARANCES TO COMBUSTIBLES MATERIALS, WALLS AND CEILING ...............7
3.2 FLOOR PROTECTION ......................................................................................................8
4. VENTING SYSTEM........................................................................................ 9
4.1 GENERAL...........................................................................................................................9
4.2 RECOMMANDATIONS ......................................................................................................9
4.3 EQUIVALENT VENT LENGTH (EVL)...............................................................................9
4.3.1 RECOMMENDED EXHAUST VENTING DIAMETER.......................................................9
4.3.2 INSTALLATION COMPLIANCE.......................................................................................10
4.4 TERMINATION LOCATION.............................................................................................11
4.5 DIRECT VENT SYSTEM ................................................................................................12
4.6 INSTALLATION CONFIGURATION ...............................................................................12
.............................12
.................................................................................12
4.6.3 THROUGH A FACTORY BUILT CHIMNEY.................................................................13
4.6.4 THROUGH AN EXISTING MASONRY FIREPLACE..................................................13
4.6.5 THROUGH AN EXISTING MASONRY CHIMNEY......................................................14
5. INSTALLING THE OPTIONAL HOPPER EXTENSION............................ 14
6. MOBILE HOME INSTALLATION................................................................ 15
7. INSTALLING A THERMOSTAT................................................................... 15
7.1 THERMOSTAT LOCATION .............................................................................................15
7.2 WIRED THERMOSTAT ....................................................................................................16
7.3 WIRELESS THERMOSTAT.............................................................................................16
8. COMBUSTION AIR SUPPLY ...................................................................... 16
8.1 SOURCES OF OUTSIDE COMBUSTION AIR ..............................................................17
9. APPLIANCE SET-UP................................................................................... 18
9.1 GENERAL.........................................................................................................................18
10. WIRING DIAGRAM .................................................................................... 19
11. EXPLODED VIEWS AND PARTS LIST DP00070 AND DP00071 .......... 20
Page 5
INSTALLATION MANUAL ECO-55 / ECO-55 CT / ECO-55 ST
ENGLISH
2. GENERAL FEATURES
Recommended
chimney diameter
3 in. (75mm)
Flue outlet diameter 3 in. (75mm)
Type of chimney ULC/ORD-C441
CAN/ULC S609
UL 641 (TYPE L)
Approved for alcove
installation
Yes
Approved for mobile
home installation ‡
Yes
Shipping weight
(without option)
277 lb (DP00070-
DP00072)
286 lb (DP00071)
Appliance weight
(without option)
235 lb (DP00070-
DP00072)
242 lb (DP00071)
Particulate emission
standard
CSA B415.1-10
ASTM E2779
USA standard (safety) ASTM E1509
UL 1482
Canadian standard
(safety)
ULC S627
Electrical
requirements
Voltage and frequency
120VAC and 60Hz
Ignition : 3.02A
‡ Mobile home (Canada) or manufactured home (USA): The
US department of Housing and Urban Development describes
“manufactured homes” better known as “mobile homes” as
Canada, a mobile home is a dwelling for which the manufacture
and assembly of each component is completed or substantially
completed prior to being moved to a site for installation on
a foundation and connection to service facilities and which
2.1 OVERALL DIMENSIONS (DP00070-
DP00072)
A
B
Page 6 INSTALLATION MANUAL ECO-55 / ECO-55 CT / ECO-55 ST
ENGLISH
2.2 OVERALL DIMENSIONS (DP00071)
A
B
2.3 REGULATIONS COVERING PELLET
STOVE INSTALLATION
When installed and operated as described in these
instructions, this pellet stove is suitable for use as a
freestanding heater in residential installations.
In Canada, the CSA B365 Installation Code for Solid
C22.1 Canadian National Electrical Code are to be
followed in the absence of local code requirements.
Code are to be followed in the absence of local code
requirements.
This stove must be connected to a pellet vent system
complying with the requirements for Pellet Vent in the
standards UL 103, UL 641, ULC S629M, CAN/ULC
S609 and ULC/ORD C441 or to a code-approved
CAUTION
DO NOT USE MAKESHIFT MATERIALS OR
MAKEANYCOMPROMISESWHENINSTALLING
THIS STOVE.
2.4 CERTIFICATION LABEL LOCATION
information published in any other media (owner’s
it is important to refer to it in order to have a safe
important information about your stove (model, serial
the inner side of the hopper lid of the stove.
Page 7
INSTALLATION MANUAL ECO-55 / ECO-55 CT / ECO-55 ST
ENGLISH
3. CLEARANCES TO COMBUSTIBLE
MATERIALS
The clearances shown in this section applies to
DP00070, DP00072 and DP00071.
The clearances shown in this section have been
determined by tests according to procedures set out in
safety standards ULC S627 (Canada), ASTM E1509
(U.S.A) and UL1482 (U.S.A.). When the pellet stove
is installed so that its surfaces are at, or beyond, the
will not overheat under normal and even abnormal
operating conditions.
WARNING
NOPARTOF THE PELLET VENTSYSTEMMAY
BE LOCATED CLOSER TO COMBUSTIBLES
THANTHEMINIMUMCLEARANCESSPECIFIED
BY THE VENT MANUFACTURER.
WARNING
NO PART OF THE STOVE MAY BE LOCATED
CLOSER TO COMBUSTIBLES THAN THE
MINIMUM CLEARANCES SPECIFIED ON THE
CERTIFICATION LABEL.
NOTICE
The following clearances are also valid for an
alcove installation. However, if the stove is
installed in an alcove, to perform maintenance, you
maintenance access doors and components.
3.1 CLEARANCES TO COMBUSTIBLES
MATERIALS, WALLS AND CEILING
MINIMUM CLEARANCES
CANADA USA
A* 3" (76 mm) 3" (76 mm)
DNote 1 Note 1
I** 48" (1 220 mm) 48" (1 220 mm)
*From the rear panel
RECOMMENDED CLEARANCES FOR
MAINTENANCE
CANADA USA
A* 12" (305 mm) 12" (305 mm)
MINIMUM CLEARANCES
CANADA USA
B6" (152 mm) 6" (152 mm)
DNote 1 Note 1
RECOMMENDED CLEARANCES FOR
MAINTENANCE
CANADA USA
B24" (610 mm) 24" (610 mm)
Note 1 : Refer to the exhaust venting system manufacturer’s
instructions for clearances to combustible materials.
Page 8 INSTALLATION MANUAL ECO-55 / ECO-55 CT / ECO-55 ST
ENGLISH
3.2 FLOOR PROTECTION
MINIMUM CLEARANCES
CANADA USA
C3" (76 mm) 3" (76 mm)
DNote 1 Note 1
RECOMMENDED CLEARANCES FOR
MAINTENANCE
CANADA USA
C12" (305 mm) 12" (305 mm)
DNote 1 Note 1
Note 1 : Refer to the exhaust venting system manufacturer’s
instructions for clearances to combustible materials.
FLOOR PROTECTION
CANADA** USA
E6" (152 mm)
6" (152 mm)
F6" (152 mm)
6" (152 mm)
CAUTION
THE STOVE MUST BE PLACED ON
A CONTINUOUS (GROUTED JOINTS)
NONCOMBUSTIBLE MATERIAL SUCH AS
CERAMIC TILE*, CEMENT BOARD, BRICK,
MILLBOARDOREQUIVALENT,ORANYOTHER
APPROVED OR LISTED MATERIAL SUITED
FOR FLOOR PROTECTION.
*Any type of tile will require a continuous non combustible sheet
beneath to prevent the possibility of embers falling through to the
-
shown in the previous table ONLY if the following actions are
Page 9
INSTALLATION MANUAL ECO-55 / ECO-55 CT / ECO-55 ST
ENGLISH
4. VENTING SYSTEM
CAUTION
CONNECT THIS STOVE ONLY TO A LISTED
PELLETEXHAUSTVENTINGSYSTEMFORUSE
WITH SOLID FUEL OR TO A LINED CHIMNEY
CONFORMING TO NATIONAL AND LOCAL
BUILDING CODES.
CAUTION
DO NOT CONNECT THIS STOVE TO ANY
OTHEREXISTINGVENTINGSYSTEMSERVING
ANOTHER APPLIANCE.
CAUTION
THEVENTINGSYSTEMMUSTBECOMPLETELY
AIRTIGHT AND PROPERLY INSTALLED.
ALL VENT CONNECTOR JOINTS MUST BE
SEALED AND FASTENED IN ACCORDANCE
WITH THE PELLET VENT MANUFACTURER’S
INSTRUCTIONS TO ENSURE CONSISTENT
PERFORMANCEANDAVOIDSMOKEANDASH
SPILLAGE..
CAUTION
DO NOT INSTALL A FLUE DAMPER IN THE
EXHAUST VENTING SYSTEM OF THIS UNIT.
CAUTION
DO NOT CONNECT TO OR USE IN
CONJUNCTIONWITHANYAIRDISTRIBUTION
DUCTWORK.
CAUTION
THEVENTINGSYSTEMSHOULDBECHECKED,
AT LEAST TWICE A YEAR FOR ANY BUILDUP
OF SOOT OR CREOSOTE.
4.1 GENERAL
Even though the chimney draft is mechanical, a sui-
table venting system will ensure a natural draft which
will prevent smoke spillage in your home if a power
outage occurs. Moreover, a suitable venting system
of your stove when installed in accordance with the
required EVL.
4.2 RECOMMANDATIONS
In Canada, we recommend that you use a listed pel-
let vent that meets the CAN/ULC S609 or ULC/ORD
C441 Standard. A pellet vent listed to ULC S629M is
also suitable for installation with this stove.
listed pellet vent that meets the UL 641 Standard. A
pellet vent listed to UL 103 is also suitable for instal-
lation with this stove.
or masonry chimney with the addition of a stainless
steel liner, provided the chimney is more than 4" in
diameter. The liner should be listed and should meet
the ULC S635 CAN/ULC S640 standard in Canada
and the UL 1777 standard in the USA. Refer to the
instructions provided by the vent manufacturer,
especially when passing through a wall, ceiling or
roof.
The recommended venting system inner pipe diame-
ter is 3". Use a 4" pipe if you have more than 15 feet
of Equivalent Vent Length (EVL).
To calculate the Equivalent Vent Length of your ins-
tallation, use the following conversions:
Qty Type of pipe Equivalent vent
length (EVL)
1 90° elbow or ‘‘Tee’’ 5 feet
1 45° elbow 3 feet
1 foot horizontal pipe run 1 foot
1 foot vertical pipe run 1/2 foot
4.3 EQUIVALENT VENT LENGTH (EVL)
4.3.1 RECOMMENDED EXHAUST VENTING
DIAMETER
Page 10 INSTALLATION MANUAL ECO-55 / ECO-55 CT / ECO-55 ST
ENGLISH
calculated like this:
2 feet of horizontal run (2 X 1' EVL) = 2' of EVL
90° elbow or "Tee" (1 X 5' EVL) =5' of EVL
12 feet of vertical run
(12' X 0.5' EVL)
= 6’ of EVL
Termination cap = 0' of EVL
Total EVL = 13' of EVL
Since the total EVL is less than 15 feet, the re-
commended exhaust venting diameter is 3".
4.3.2 INSTALLATION COMPLIANCE
To determine if your installation is compliant, the
the venting system chart. The previous installation
has 2 feet of horizontal run and 12 feet of vertical
run. It is thus standard since the venting system ends
in the gridded area.
CAUTION
•
•
CAUTION
TO REDUCE THE RISK OF SMOKE SPILLAGE
THERE SHOULD ALWAYS BE AT LEAST ONE
FOOTOFVERTICALRISEFOREACHFOOTOF
HORIZONTALRUN.INALLCASES,ATLEAST3
FEET OF VERTICAL RISE IS NEEDED.
WARNING
TERMINATIONOFASIDEWALLVENTSHOULD
BE LOCATED TO AVOID PERSONAL BURN
INJURY, FIRE HAZARD AND INTERFERENCE
WITH OR DAMAGE TO ADJACENT
PROPERTIES.EXHAUST GASES CANREACH
TEMPERATURESOF500°F(260°C)ANDCAUSE
SERIOUS BURNS.
WARNING
TERMINATION COLLAR (SPARK ARRESTER)
ISMANDATORYANDMUSTBECLEAROFANY
DEBRIS AT ALL TIME.
Page 11
INSTALLATION MANUAL ECO-55 / ECO-55 CT / ECO-55 ST
ENGLISH
CANADA
in accordance with the following.
v
A
A
J
B
B
B
B
L
BB
B
I
A
A
K
F
V
V
V
V
V
V
V
V
H
F
Min.
Clearances Description
A12" (30 cm) Clearances above grade level or any adjacent surface that might support snow, ice,
or debris.
B39" (100 cm) Clearance to window or door that may be opened.
F39" (100 cm) Clearance to corner or adjacent wall or any combustible materials.
H39" (100 cm) Not to be installed above a meter/regulator assembly within 39" (100 cm) horizontally
from the vertical center-line of the regulator and for 15’ vertically.
I72" (183 cm) Clearance to gas service regulator vent outlet or within 39’’ (100 cm) of an oil tank vent
J39" (100 cm) Clearance to the combustion air inlet to any other appliance.
K72" (183 cm) Clearance to a mechanical air supply inlet.
L84" (213 cm) Clearance above paved side-walk or a paved driveway located on public property.
39" (100 cm) Clearance to property boundary.
A vent shall not terminate underneath a veranda, porch, or deck.
A vent shall not terminate directly above a sidewalk or a paved driveway which is lo-
cated between two single family dwelling and serves both dwellings.
United-States
• Not Less than 36" (91 cm) above any forced air inlet located within 120" (305 cm);
• Not Less than 48" (122 cm) below and horizontally from, or 12" (30 cm) above, any door, window or gravity
air inlet into any building;
• Not Less than 24" (61 cm) from an adjacent building and not less than 84" (213 cm) above grade when
located adjacent to a public walkway;
• Cannot be located less than 12" (30 cm) above grade;
• Cannot be located above a gas meter/regulator within 36" (91cm) horizontally of the vertical center line of
the regulator;
• Not within 6 feet (183 cm) of a gas service regulator vent outlet;
•
4.4 TERMINATION LOCATION
Page 12 INSTALLATION MANUAL ECO-55 / ECO-55 CT / ECO-55 ST
ENGLISH
In Canada: The permitted termination locations for a
direct vent system are the same than those permitted
with a regular pellet vent system.
In the Unites States : The permitted termination
location for a direct vent system are the same than
those permitted with a regular pellet vent system
located not less than 9" (23 cm) from any opening
through which vent gases could enter a building.
4.5 DIRECT VENT SYSTEM
4.6 INSTALLATION CONFIGURATION
4.6.1 THROUGH WALL INSTALLATION (MAIN
1. Position appliance following clearances vent
manufacturer’s instructions.
2. Install a stove adapter or a stove adapter tee onto
3.
and cut a hole of the appropriate size for vent in
the wall.
4. Install wall thimble as per vent manufacturer’s
instructions.
5. Ensure you install enough horizontal pipe length
tee section to the pipe passing through the wall.
6. Run the vent vertically up the wall for at least
36". Refer to the vent manufacturer’s instructions
for clearances to combustible materials and
installation of wall bands.
7. Install a 90 degrees elbow facing out from the
wall and then attach a 45 degree elbow facing
towards the ground. The termination of the vent
must include a spark arrester, fastened to the 45
degrees elbow.
8. Sealed outside wall thimbles with high
temperature waterproof silicone sealant.
4.6.2
1. Position appliance following clearances and
following vent manufacturer’s instructions.
2. Install a stove adapter or a stove adapter tee
outlet and the tee.
3. Drop the plumb line over the center of the tee
outlet and mark location on the ceiling.
4.
rough opening.
5.
per vent manufacturer’s instructions.
6.
where an attic insulation shield is required.
7. Run the necessary section of vent vertically so
at least 24" in United States and at least 36" in
Canada.
8. Install roof support.
9.
manufacturer’s instructions. If necessary, install
a storm collar.
Page 13
INSTALLATION MANUAL ECO-55 / ECO-55 CT / ECO-55 ST
ENGLISH
4.6.3
1. Position stove following clearances given and fol-
lowing vent manufacturer’s instructions.
2. Install a stove adapter or a stove adapter tee onto
-
and the tee.
3. Use a proper chimney adaptor for your installa-
tion.
4. Run the number of sections of vent necessary to
go through the chimney adaptor into the chimney.
5. Connect the vent to a stainless steel 4" liner ac-
cording to the vent manufacturer’s instruction.
6.
manufacturer’s instructions. If necessary, install
and seal a storm collar.
NOTICE
Before installation, the chimney must be cleaned
installer.
NOTICE
In the USA., the use of a stainless steel liner is
mandatory. In Canada, it is not mandatory but is
strongly recommended.
4.6.4 THROUGH AN EXISTING MASONRY
NOTICE
The structural condition of the masonry chimney
sweep or installer. You will need a pipe length
equal to the chimney height from the hearth. If
outside combustion air is to be used, you will need
a pipe length superior from 12 to 18 inches (30 to
46 cm) of the chimney height to ensure a proper
stove behaviour.
1. Position stove, following clearances and fol-
lowing vent manufacturer’s instructions.
2. Build and Install a blocking plate inside the chim-
plate and screws are recommended. Cut a hole
for the air intake pipe
3. Attach a section of pipe and clean out tee to the
-
4.
chimney. Stainless steel plate and screws are
recommended. Cut a hole for the vent pipe. If
needed, cut a second hole for the air intake pipe.
Seal all joints with high temperature waterproof
silicone sealant to prevent water leakage.
5. Seal and install vertical roof vent. If required, seal
and install a storm collar.
Page 14 INSTALLATION MANUAL ECO-55 / ECO-55 CT / ECO-55 ST
ENGLISH
4.6.5 THROUGH AN EXISTING MASONRY
CHIMNEY
1. Position stove following clearances following vent
manufacturer’s instructions.
2. Mark the center of the hole where the vent pipe
will go through the masonry chimney.
3. It is necessary to make a hole in the masonry
with a one-inch diameter greater than the diame-
ter of the vent pipe used.
4. Install the cleanout tee at the bottom of the ver-
tical vent system and lower it down the chimney
until the center branch of the tee is aligned with
the hole in the masonry.
5. Connect the horizontal vent pipe to the cleanout
tee by pushing it through the hole in the masonry.
6. If desired, once the horizontal pipe is in place,
the space between the pipe and masonry may be
7. -
ry chimney. Stainless steel plate and screws are
recommended. Cut a hole for the vent pipe. If
needed, cut a second hole for the air intake pipe.
Seal all joints with high temperature waterproof
silicone sealant to prevent water leakage.
8.
waterproof silicone sealant.
9. Seal and install vertical roof vent. If required, seal
and install a storm collar.
10. If desired, install a trim collar and use an addi-
tional horizontal vent pipe length, if required, to
connect the stove to the chimney.
5. INSTALLING THE OPTIONAL
HOPPER EXTENSION
To increase the hopper capacity, it is possible to
your dealer or website for details.
Page 15
INSTALLATION MANUAL ECO-55 / ECO-55 CT / ECO-55 ST
ENGLISH
6. MOBILE HOME INSTALLATION
NOTICE
connect the stove to an outside combustion air
feet.
When installed in a mobile home, the stove must be
anchoring holes located on each side of the pedes-
according to the standard or ULC/ORD-C441 CAN/
ULC-S609. A vent system meeting the requirements
of ULC S629M can also be used.
this pellet stove must be connected to a venting sys-
tem that meets the requirements of UL 641 standard.
A vent system that meets the requirements of UL 103
standard may also be used.
7. INSTALLING A THERMOSTAT
Using a thermostat will help you maintain a constant
temperature throughout the house. A low voltage
or hand held model can be used.
NOTICE
Thermostat manufacturer’s instructions always
override the information published in the following
section.
7.1 THERMOSTAT LOCATION
Location of the thermostat is very important to obtain
accordance with applicable building codes.
Install the thermostat in a location that provides
doors, near corners, air vents, direct sunlight or heat
generating devices.
If the thermostat is installed in the same room as the
stove, it should also be located at least 15 to 20 feet
from the stove. To prevent cycling, you should avoid
installing the thermostat on a poorly insulated outside
wall or directly in front of the stove.
A Thermostat
BMinimum 15'
NOTICE
Installing the thermostat in front of the stove or
in front of a window will tend to make the stove
cycle too often and wear components prematurely.
See operation’s manual for more details on how to
operate the stove with the proper pilot mode.
Page 16 INSTALLATION MANUAL ECO-55 / ECO-55 CT / ECO-55 ST
ENGLISH
7.2 WIRED THERMOSTAT
Before installing the thermostat, unplug the power
cord from the power outlet.
block located at the rear on the right hand side of the
stove when facing it. Loosen the two middle screws
and insert the wires in the terminals. Tighten the two
screws. Open the thermostat and connect the wires
as per the manufacturer’s instructions.
Open the thermostat and connect the wires as per
the manufacturer’s instructions.
Connect one wire on “RH” and the other wire on “W”.
-
formation refer to the manufacturer’s instructions.
7.3 WIRELESS THERMOSTAT
If you are using a wireless thermostat or a hand
held thermostatic remote control, connect the two
thermostat wires to the terminal block located at the
rear on the right hand side of the stove while facing it.
If the receiver wires are equipped with quick-connect
terminals you can connect them directly to the stove’s
wiring harness.
To do so, open the right hand side decorative panels
and disconnect wires (B) and (C) attached to the rear
of the terminal block (A) and connect them to the re-
ceiver.
8. COMBUSTION AIR SUPPLY
NOTICE
connect the stove to an outside combustion air
feet.
It is recommended to install an outside air inlet in or
near the room where the stove is installed. When
doing so, it is preferable to choose a wall which is
conditions surrounding your house.
Page 17
INSTALLATION MANUAL ECO-55 / ECO-55 CT / ECO-55 ST
ENGLISH
An insulated 3” inside diameter metallic pipe, either
-
take (D).
To complete the installation, make a hole of 1/4" to
1/2" (6 mm à 13 mm) bigger than the insulate pipe
diameter in the outside wall of the house at the
inlet cap (E) in the hole (open side down) and fasten
the register to the wall, with screw.
Place the insulated pipe (A) over the register tube
At each end, carefully pull back the insulation and
pipe and the air inlets. Carefully push the insulation
in place using aluminum tape.
A rodent guard (minimum 1/4” wire mesh) must be
used at the termination. All connections must be
secured and airtight by either using the appropriately
sized hose clamp and/or UL-181-AP foil tape.
Make sure that the fresh air intake back draft shutter
functions freely. The fresh air intake back draft shutter
is located in the back of the stove.
8.1 SOURCES OF OUTSIDE COMBUSTION
AIR
CAUTION
IT IS FORBIDDEN TO DRAW COMBUSTION AIR
FROM A BASEMENT, AN ATTIC, A GARAGE OR
ANY CONFINED SPACE
• You can draw air from a ventilated crawl space
• You can draw air directly from an outside wall,
behind the stove.
Page 18 INSTALLATION MANUAL ECO-55 / ECO-55 CT / ECO-55 ST
ENGLISH
9. APPLIANCE SET-UP
9.1 GENERAL
Make sure the fresh air intake back draft shutter
works freely.
Remove all tools or accessories that have been in-
serted in the stove for transportation purposes.
Test the door seal by closing and latching the door
on a strip of paper. Test all around the door. The
paper should not slip out easily. If it does, see the
maintenance section in the operation manual.
Page 19
INSTALLATION MANUAL ECO-55 / ECO-55 CT / ECO-55 ST
ENGLISH
10. WIRING DIAGRAM
Page 20 INSTALLATION MANUAL ECO-55 / ECO-55 CT / ECO-55 ST
ENGLISH
11. EXPLODED VIEWS AND PARTS LIST DP00070 DP00072 AND DP00071
Other manuals for ECO-55
4
This manual suits for next models
5
Table of contents
Other Drolet Indoor Fireplace manuals
Drolet
Drolet MONT BLANC User manual
Drolet
Drolet Escape 1800-I Insert User manual
Drolet
Drolet DB03029 User manual
Drolet
Drolet ESCAPE 1500-I User manual
Drolet
Drolet GRIZZLY User manual
Drolet
Drolet ESCAPE 1800 DB03100 User manual
Drolet
Drolet Escape 1400 Insert User manual
Drolet
Drolet VISION XL User manual
Drolet
Drolet Escape 1800 User manual
Drolet
Drolet ESCAPE 45221 User manual
Popular Indoor Fireplace manuals by other brands
Paramount Fitness
Paramount Fitness BLT-999A-7 Instructions for use
HASE
HASE SENDAI PRO Maintenance and installation instructions
Heatilator
Heatilator CRAVE4836 installation manual
kozy heat
kozy heat BAY-36-MV Installation and operation manual
Dimplex
Dimplex DF3033ST owner's manual
BRULA
BRULA B Assembly and operating instructions
Outdoor Lifestyles
Outdoor Lifestyles ODVILLAG-36T installation manual
Somogyi
Somogyi Home FKK 01 instruction manual
FDC
FDC ENIGMA II SLIMLINE owner's manual
Dimplex
Dimplex DF3033ST owner's manual
Bentone
Bentone BG 800 CN Installation and maintenance instruction
Vermont Castings
Vermont Castings SA36R installation manual
